JVC LT-32HA4WU Quick Start Manual

1
Insert the batteries into the handset
Slide the back cover up to open the battery
compartment of the remote control. Observe the
correct polarity (+/-) when inserting batteries.
Replace the cover.
2
Connect the Aerial/Cable straight to your TV
Aerial or Cable
3
Connect the TV to the mains socket
insert plug...
Quick Start Guide
4
To switch the TV on
Connect the power cord to the 220-240V AC, 50 Hz.
To switch on the TV from standby mode either:
1. Press the " " button, P+ / P- or a numeric
button on the remote control.
2. Press the side function switch until the TV comes
on from standby.
5 5
HDMI input HDMI input
PLEASE ENSURE BOTH UNITS ARE SWITCHED
OFF BEFORE CONNECTING. Use a HDMI to HDMI
cable to connect the two units together. To select the
HDMI input, press the SOURCE "
remote control. Each time it is pressed, the on-screen
menu confirms your selection.
To HDMI connection on
the device
6
Start Auto Setup procedure
IMPORTANT: Ensure that the aerial/cable is
connected and a Common Interface module is not
inserted before switching on the TV for the first
time installation. Do not insert a common interface
module during the search process.
When turned on for the first time, the language
selection screen is displayed. Select the desired
language and press OK.
First Time Installation (FTI) screen will be displayed
next. Set your preferences using the navigation
buttons and when finished, press OK to continue.
If Home Mode is selected, Store mode will be disabled
after the First Time Installation. Press OK button to
continue and select Yes to proceed.
You can activate Store mode option to be available in
"Other settings" menu and your TV's features will be
illustrated on the top of the screen. A confirmation
screen will be displayed. Select YES to proceed.
Aerial Installation
If you select AERIAL option from the Search Type
screen, the television will search for digital terrestrial
TV broadcasts.
NOTE: You can press MENU button to cancel.
" button on the
After all the available stations are stored, the Channel
List will be displayed on the screen. If you would like
the channels to be sorted according to LCN(*), please
select YES and press OK.
Press MENU button to quit channel list and watch
TV.
(*) LCN is the Logical Channel Number system that
organizes available broadcasts in accordance with a
recognizable channel sequence (if available).
Cable Installation
Select CABLE option and press OK button on the
remote control. To continue, you can select frequency
ranges from this screen.
Enter the frequency range manually by using the
numeric and press OK to start the search.
Note: Searching duration will change depending on
the selected search step.
