Components List

Part Name
TB Glass
Glass for top and bottom shelves
M Glass
Glass for middle shelves
Cable tidy
CT
F-WD
Foot (Wood Support)
TB-1
Tube
TB-2
Tube
FT
Foot Tube
CC-L
Chrome Cap
CC-S
Chrome Cap
I B-1
I bolt (NO.1)
IB-2
I bolt (NO.2)
I B-3
I bolt (NO.3)
F B
Foot bolt
(Attached in the cable tidy)
T E S
Tube send seal
TOOL-1
3# Tool (screw IB-1)
TOOL-2
5# Tool (screw IB-2 and IB-3)
Assembly Instructions
Model AVM-005
Part Details
Description
Specification
Size: 610*520mm
Thickness:8mm
Size:610*495mm
Thickness:8mm
Size:
Thickness:
Size:
Thickness
Length:146mm
Diameter:50mm
Length:246mm
Diameter:50mm
Length:130mm
Diameter:50mm
Diameter:50mm
Thickness:8mm
Diameter:28mm
Thickness:8mm
Length:45mm
Diameter:6mm
Length:35mm
Diameter:10mm
Length:50mm
Diameter:10mm
Length:90mm
Diameter:6mm
Diameter:50mm
Thickness:2mm
Page 1/3
Qty
Figure
2
3
1
1
6
2
2
2
2
2
2
8
2
18
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVM-005 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RTA AVM-005

  • Page 1 Assembly Instructions Page 1/3 Model AVM-005 Components List Part Details Part Name Description Specification Figure Size: 610*520mm TB Glass Glass for top and bottom shelves Thickness:8mm Size:610*495mm M Glass Glass for middle shelves Thickness:8mm Cable tidy Size: Thickness: F-WD Foot (Wood Support)
  • Page 2 Assembly Instructions Page 2/3 Model AVM-005...
  • Page 3 Assembly Instructions Page 3/3 Model AVM-005 Stage 1 Please note stand is best assembled from the bottom up. 1.1 Place foot bolts (FB) through bottom shelf (B Glass), Foot (F-WD) and the holes at the bottom of the cable tidy (CT). Then screw the foot bolts into the cable tidy nuts until tight.
