Quick Installation Guide
2-Port Dual Monitor DisplayPort KVM Switch
TK-240DP
4-Port Dual Monitor DisplayPort KVM Switch
TK-440DP
Monitor with a DisplayPort
A
Power
(Required)
Monitor with a DisplayPort
Power
(Required)
Monitor with a DisplayPort
TK-440DP
CONSOLE
PC 4
PC 3
PC 2
PC 1
B
B
B
B
B
A
A
A
A
A
A
TK-240DP
CONSOLE
B
A
B
Monitor with a DisplayPort
B
PC 2
PC 1
B
B
A
A
Note:
Connect the Keyboard and Mouse to the KVM
console ports before connecting the USB
connections to each PC.
LED Indicators
LED
Status
Definition
Flashing Green
No USB Connection
PC (Green)
Solid Green
USB Connected
Off
No Connection
Solid Red
Active Connection
Hub (Red)
Off
No Connection
Advertisement
Table of Contents
Related Manuals for TRENDnet TK-240DP
Summary of Contents for TRENDnet TK-240DP
- Page 1 Monitor with a DisplayPort Monitor with a DisplayPort Quick Installation Guide 2-Port Dual Monitor DisplayPort KVM Switch TK-240DP TK-240DP 4-Port Dual Monitor DisplayPort KVM Switch Power CONSOLE PC 2 PC 1 TK-440DP (Required) Monitor with a DisplayPort Monitor with a DisplayPort...
