Summary of Contents for TRENDnet TK-205K
- Page 1 Quick Installation Guide TK-205K...
-
Page 2: Table Of Contents
Table of Contents Table of Contents Deutsch ... 1. Bevor Sie anfangen ... 2. Installation ... 3. Bedienung ... Specifications ... Troubleshooting ... Version 02.08.2006... -
Page 3: Deutsch
1. Bevor Sie anfangen Systemanforderungen PS/2-Tastatur PS/2-Maus VGA-kompatibler Monitor Windows XP/2000/ME/98SE, Unix und Linux Anwendung PC 1 LCD Monitor PS/2 Keyboard TK-205 Anleitung zur Schnellinstallation KVM-Kabel (zwei) Cable Cable 2-Port PS/2 KVM Switch (TK-205K) PS/2 Mouse Deutsch Packungsinhalt PC 2... -
Page 4: Installation
2. Installation Hinweis: Der PS/2-KVM-Umschalter TK-205 benötigt weder spezielle Treiber noch eine eigene Software. 1. Schalten Sie alle Computer und Peripheriegeräte aus und trennen Sie alle Stromversorgungskabel 2. Verbinden Sie die gemeinsam genutzte Tastatur, den Monitor und die Maus mit dem Konsolen-Port des KVM-Umschalters. -
Page 5: Bedienung
3. Bedienung Hinweis: Um von einem Computer zum anderen zu wechseln, können Sie die Drucktasten auf dem Gerät oder Tastenkombinationen verwenden. 3.1 Drucktasten 3.1 The Push Buttons Drücken Sie auf die entsprechende Taste, um den gewünschten PC auszuwählen. 3.2 Tastenkombinationen Eine Tastenkombination setzt sich aus drei Tasten zusammen: Tastenkombination = ScrLk (ROLLEN) + ScrLk (ROLLEN) + Befehlstaste(n) - Page 6 Schnellübersicht für den TK-205 Befehl ScrLk PC auswählen (x ist eine Zifferntaste. x = 1 oder 2, entsprechend der Kanalnummer des PC) Unmittelbar darunter ScrLk liegender PC-Kanal Unmittelbar darüber ScrLk liegender PC-Kanal ScrLk Autoscan Press any key on keyboard Autoscan beenden Vereinbarung zu Tastenkombinationen: Die Darstellung der Tastenkombination bedeutet, dass Sie die einzelnen tasten nicht gleichzeitig, sondern...
-
Page 7: Specifications
Specifications Computer Connections KVM Cable Cable Interface (all male) Console Connectors (all female) Port Selection Auto-Scan Interval Keyboard State Power Supply Dimensions Weight Operating Temperature Storage Temperature Humidity Certifications 2 Sets of 1.2M (4ft) KVM Cables To Console: 1 x VGA/SVGA HDB 15-pin To PC: 1 x PS/2 Mouse 6-pin Mini Din 1 x PS/2 Keyboard 6-pin Mini Din... -
Page 8: Troubleshooting
How do I switch from one computer to another with the KVM switch? Because the TK-205 KVM switch supports Hot-Key commands, you can use Hot-Key commands to switch between 2 computers. If you still encounter problems or have any questions regarding the TK-205K, please contact Trendnet's Technical Support Department. Certifications This equipment has been tested and found to comply with FCC and CE Rules. - Page 9 TK-205K - 2 Year Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
- Page 10 PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR USE OF TRENDnet'S PRODUCTS. TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY...
-
Page 11: Product Warranty Registration
Email: support@trendnet.com Tech Support Hours 24/7 Toll Free Tech Support Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 3135 Kashiwa Street Torrance, CA 90505 Copyright ©2006. All Rights Reserved. TRENDnet. Contact...
