  • Page 1 User reference guide Daikin Altherma 3 R F+W EHBH04DA6V7 EHVH08S18D*6V7 EHVX08S23D*6V7 EHBH08DA6V7 EHVH08S23D*6V7 EHVX08S18D*9W7 EHBH08DA9W7 EHVH08S18D*9W7 EHVX08S23D*9W7 EHVH08S23D*9W7 EHBX04DA6V7 EHVH04SU18DA6V7 EHBX08DA6V7 EHVX04S18D*3V7 EHVH04SU23DA6V7 EHBX08DA9W7 EHVX04S18D*6V7 EHVX04S23D*3V7 EHVH08SU18DA6V7 EHVH04S18D*6V7 EHVX04S23D*6V7 EHVH08SU23DA6V7 EHVH04S23D*6V7 EHVX08S18D*6V7...
  • Page 2 Symptom: The water at the tap is too cold........................49 Symptom: Heat pump failure ............................49 Symptom: The system is making gurgling noises after commissioning................. 50 User reference guide EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 3 Table of contents 8 Relocation Overview: Relocation ..............................51 9 Disposal 10 Glossary EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 4 Indicates a situation that could result in minor or moderate injury. NOTICE Indicates a situation that could result in equipment or property damage. INFORMATION Indicates useful tips or additional information. Symbols used on the unit: EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 5 ▪ Do NOT rinse the unit. ▪ Do NOT operate the unit with wet hands. ▪ Do NOT place any objects containing water on the unit. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 6 Waste batteries must be treated at a specialized treatment facility for reuse. By ensuring waste batteries are disposed of correctly, you will help to prevent potential negative consequences for the environment and human health. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 7 Format: Digital files on http://www.daikineurope.com/support-and-manuals/ product-information/ Latest revisions of the supplied documentation may be available on the regional Daikin website or via your installer. The original documentation is written in English. All other languages are translations. Breadcrumbs Breadcrumbs (example: [4.3]) help you to locate where you are in the menu structure of the user interface.
  • Page 8 2 Press the left dial to enter the submenu. 3 Turn the left dial and go to Operation range. Operation range 4 Press the left dial to enter the submenu. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 9 Radiators, heat pump convectors, or fan coil units INFORMATION The indoor unit and the domestic hot water tank (if installed) can be separated or integrated depending on the indoor unit type. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 10 Dials and buttons You use the dials and buttons: ▪ To navigate through the screens, menus and settings of the LCD screen ▪ To set values EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 11 : Press the right dial. Confirm your choice and go to the next menu item. 4.2 Possible screens: Overview The most common screens are as follows: EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 12 The temperatures are shown in circles. If the circle is grey, the corresponding operation (example: space heating) is currently not active. Outdoor unit : Outdoor unit a2 a3 : Quiet mode active a3 Measured ambient temperature EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 13 ▪ : Fancoil unit ▪ : Radiator g2 Leaving water temperature setpoint g3 Room thermostat type: ▪ : Daikin user interface used as room thermostat ▪ : External control ▪ Hidden: Leaving water temperature control g4 Measured room temperature Additional...
  • Page 14 User settings mode and quiet mode. Displays data and information about the Information indoor unit. Installer settings Restriction: Only for the installer. Gives access to advanced settings. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 15 Maximum temperature limit Fixed by the unit Restricted by the installer Current temperature Measured by the unit Desired temperature Turn the right dial to increase/ decrease. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 16 Room temperature control Room temperature control ON Room temperature control OFF EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 17 Water pipe freeze prevention. Even if you turn OFF space heating/cooling operation ([C.2]: Operation > Space heating/cooling), water pipe freeze prevention –if enabled– will remain active. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 18 To determine if a heating/cooling heat pump model is installed 1 Go to [4]: Space heating/cooling. 2 Check if [4.1] Operation mode is listed and editable. If so, a heating/cooling heat pump model is installed. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 19 ▪ Cooling only: Restricted 4 Confirm the changes. Example: Changeover restrictions When Restriction During cold season. Heating only Example: October, November, December, January, February and March. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 20 During room temperature control, you can use the room temperature setpoint screen to read out and adjust the desired room temperature. 1 Go to [1]: Room. Room EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 21 You can use the leaving water temperature setpoint screen to read out and adjust the desired leaving water temperature. 1 Go to [2]: Main zone or [3]: Additional zone. Main zone Additional zone EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 22 4 hours starting from the scheduled start-up of disinfection. If the booster heater is restricted during disinfection, this function will NOT be successful and the applicable warning AH will be generated. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 23 In reheat mode the DHW tank continuously heats up to the temperature shown on the home screen (example: 50°C) when the temperature drops below a certain value. 60°C 50°C 40°C 15°C 00:00 07:00 14:00 21:00 DHW tank temperature Time EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 24 (example: 45°C). This ensures that a minimum amount of hot water is available at all times. Example: EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 25 1 Go to [5.1]: Tank > Powerful operation 2 Turn powerful operation Off or On. Usage example: You immediately need more hot water You are in the following situation: EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 26 The Advanced user pin code is 1234. Additional menu items for the user are now visible. Advanced user 1234 User pin code The User pin code is 0000. User 0000 EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 27 Then you can do the following: 1 Go to [7.4.1]: User settings > Quiet > Activation. 2 Select Most quiet. Advantage: The outdoor unit runs in its most quiet level. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 28 1 Go to [8]: Information. Possible read-out information In menu… You can read out… [8.1] Energy data Produced energy, consumed electricity, and consumed gas [8.2] Malfunction history Malfunction history EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 29 If domestic hot water tank mode is Reheat setpoint ▪ Schedule + reheat To define energy prices Only possible if Bivalent is enabled by the installer. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 30 If no schedule is set, the Electricity price for High is taken into account. To set the electricity price schedule timer 1 Go to [7.5.4]: User settings > Electricity price > Schedule. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 31 Calculation of the gas price Gas price=Actual gas price+(Incentive/kWh×0.9) Gas price=4.08+(5×0.9) Gas price=8.58 Calculation of the electricity price Electricity price=Actual electricity price+Incentive/kWh Electricity price=12.49+5 Electricity price=17.49 EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 32 [7.4.2] User settings > Program when the unit has to use which quiet Quiet > Schedule mode level: ▪ ▪ Quiet ▪ More quiet ▪ Most quiet EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 33 3 Go to [1.2]: Room > Heating schedule. To clear the content of the week schedule 1 Select the name of the current schedule. User defined 1 EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 34 6:00 20°C 22:00 18°C 8:30 18°C --:-- 17:30 21°C Note: To clear an action, set its time as the time of the previous action. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 35 5 Repeat this action for all other weekdays. — User defined 1 To program the schedule for Saturday and copy it to Sunday 1 Select Saturday. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 36 The schedule name can contain up to 15 characters. 5 Confirm the new name. INFORMATION Not all schedules can be renamed. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 37 Additional zone - Cooling ▪ Tank INFORMATION To operate weather dependent, correctly configure the setpoint of the main zone, additional zone or tank. See "4.8.4 Using weather-dependent curves" [  40]. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 38 EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 39 The icon corresponds to the heat emitter for that zone: ▪ : Underfloor heating ▪ : Fan coil unit ▪ : Radiator ▪ : Domestic hot water tank EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 40 [2.5] Main zone > Heating WD curve Main zone – Cooling [2.6] Main zone > Cooling WD curve Additional zone – Heating [3.5] Additional zone > Heating WD curve EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 41 Cold ↑ ↑ ↑ ↑ Cold ↓ ↑ ↓ ↑ — ↓ — ↓ Cold ↑ ↓ ↑ ↓ ↓ ↓ ↓ ↓ "4.8.2 2-points curve" [  38]. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 42 Only accessible by installer (***) Only applicable when WLAN adapter is installed INFORMATION Depending on the selected installer settings and unit type, settings will be visible/ invisible. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 43 Comfort setpoint [5.2] Eco setpoint [5.3] Reheat setpoint [5.4] 4.10.2 Settings menu Setting Fill in… Main zone Thermostat type [2.A] Additional zone (if applicable) Thermostat type [3.A] EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 44 Operation Setting Fill in… Information Dealer information [8.3] EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 45 Program to turn ON the domestic hot water pump only during periods of the day when instant hot water is necessary. Example: In the morning and evening. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 46 Do NOT use the unit until a service person confirms that the part from which the refrigerant leaked has been repaired. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 47 Maintenance and service 6.2 To find the contact/helpdesk number 1 Go to [8.3]: Information > Dealer information. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 48 "4.7.1 Using preset values" [  29]. ▪ Adjust room temperature schedule. See "4.7.3  Using and programming schedules"    32] and "4.7.4  Schedule screen: Example" [  33]. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 49 When auto emergency is set to Manual and a heat pump failure occurs, the domestic hot water and space heating operation will stop and need to be recovered manually via the user interface. To recover operation manually, go to EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 50 If yes, make sure that the room where you want to purge air is sufficiently ventilated. Reason: Refrigerant might leak into the water circuit, and subsequently into the room when you purge air from the heat emitters or collectors. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 51 If you want to relocate parts of your system (user interface, indoor unit, outdoor unit, DHW  tank…), contact your installer. You can find the contact/helpdesk number via the user interface. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 52 Do NOT try to dismantle the system yourself: dismantling of the system, treatment of the refrigerant, oil and other parts MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. EHBH/X04+08DA*V7 + EHVH/X04+08S(U)18+23DA/DJ3V+6V+9W7 User reference guide Daikin Altherma 3 R F+W 4P618959-1 – 2020.03...
  • Page 53 Optional equipment Equipment made or approved by Daikin that can be combined with the product according to the instructions in the accompanying documentation. Field supply Equipment NOT made by Daikin that can be combined with the product according to the instructions in the accompanying documentation.
