AE6 SERIES
6 SERIES
Solar Street Light
Solar Street Light
User Manual
User Manual
AE6.129-A
www.leadsun.com.au
Advertisement
Table of Contents
Related Manuals for leadsun AE6 Series
Summary of Contents for leadsun AE6 Series
- Page 1 Address: 1920 S. Archibald Ave. Suite I, Ontario, CA 91761 Phone: 909.476.0900 Fax: 909.466.0130 Email: sales@leadsun-us.com Solar Street Light Solar Street Light LEADSUN Australia Pty Ltd User Manual User Manual Address: 42 Greens Road, Dandenong South, Victoria 3175 Phone: +61 1300 281 005 Fax: +61 3 8610 0393 Email: sales @leadsun.com.au...
-
Page 2: Product Maintenance
Cautions Product maintenance Please read the below cautions carefully before using the AE6 series solar street light to avoid physical injury and product failure caused by improper use. In order to assure that the solar panel receive the light efficiently, please use clear water to clean the dirt mark on the surface of the panel regularly and prohibit the use of chemical or abradant which includes chlorobenzene. -
Page 3: Functional Specification
Functional Specification Component Brief description Solar panel To absorb solar energy and convert into electricity Bird spike Motion detection Manage LED light, communication and control charging and Charging controller discharging. PIR Motion sensor Adjust the brightness automatically by the motion sensor. Illumination USB Type-B Port Special port for programming... -
Page 4: Part List
Check if all the components are complete before installation, the components and quantity of each set as follows: AE6 series is the latest double-sided photovoltaic module high power solar street light released by LEADSUN, it adopts higher conversion efficiency mono-crystalline silicon double-sided solar panel,... -
Page 5: Product Installation
Operation instruction Product installation Installation conditions Long press the button for (5s) to switch the working modes: If the installation site is on the northern hemisphere, the solar panel should face to the south and if it is on the southern hemisphere, the panel should face to the north. (See Picture 1) In the OFF mode, if the lighting condition is normal, it will start up automatically;... - Page 6 Product installation Install the X bracket Install the solar power system First put the X bracket on the installation frame at the middle of the solar power supply Connect the solar power system with the extended cables in the light pole and lock the system, then clip the 8 screws into the X bracket slot from the installation frame, last, use the connectors in turns.
-
Page 7: Wireless System Installation
Product installation 7. Wireless system installation Application scenarios (Suitable for EDGE type) Each wireless street light communication distance range from 800 to 3000m. One gateway street light can remote control 120 street lights. Cautions: 1. Please confirm if the 4G module in the gateway is support the data network covered by the Road installation local carrier before installation. -
Page 8: Troubleshooting
No lighting at night Check if the light is in ON mode or not. Test according to the "Button Instructions" from the chapter "Operation Instruction" in A. iPhone please go to the App Store searching 'LEADSUN EDGE' then click this manual.
