www.alfatronelectronics.com
ALFATRON ELECTRONICS GmbH GERMANY
ALF-12X-SDIC, ALF-20X-SDIC, ALF-30X-SDIC Full HD
PTZ Camera user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALF-12X-SDIC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ALFAtron ALF-12X-SDIC

  • Page 1 ALFATRON ELECTRONICS GmbH GERMANY ALF-12X-SDIC, ALF-20X-SDIC, ALF-30X-SDIC Full HD PTZ Camera user manual...
  • Page 2 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Warning The improper operation may destroy the structure of the product and lead to abnormal operation of the camera. Please pay attention to the following operations. Do not grasp the lens barrel with your hand while moving the camera;...
  • Page 3 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 Alfatron ALF-12X-SDIC and ALF-20X-SDIC Preface This manual describes in detail the functions, installation and operation principles and methods of the product. Before installing and using this product, please read it carefully. 1. Safety Precautions • During transportation, storage, installation and use, it is necessary to prevent heavy pressure, severe vibration and immersion so as to avoid damage to products.
  • Page 5 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC • Do not rotate the cylinder of the product by hand, otherwise it will destroy the rotating shaft of the structure or cause abnormal work of the signal line. Installation and placement of equipment should be horizontal and stable, and the •...
  • Page 6: Table Of Contents

    5.1.3,Inquiry command ........................- 24 - 5.2,P ....................- 25 - ELCO PROTOCOL COMMAND LIST 5.3 P ....................- 26 - ELCO PROTOCOL COMMAND LIST 6. WARRANTY ............................- 27 - LIMITED WARRANTY IN RESPECT OF ALFATRON PRODUCTS............. - 27 - - 3 -...
  • Page 7: Fast Installation

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 1. Fast Installation 1.1 Product introduction Picture 1.1 Interface Interface specification: 1. Lens 7. Power Switch Key 13. Audio Input Interface (Line-IN) 2. Camera Base 8. Power input socket(DC12V) 14. RS232 Input Interface 3. Remote Controller 9.
  • Page 8: Interface Wiring

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 1.2 Interface wiring Picture 1.3 Wiring 1. If the No. 0 preset is set, the camera will switch to the No. 0 preset when the power-on self-check is completed. 2. The default address of the remote controller is 1#, the menu is restored to the factory default, and the address of the remote controller is restored to 1# 1.3 Bracket mount...
  • Page 9 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC - 6 -...
  • Page 10 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 2)Upside down mount - 7 -...
  • Page 11 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC - 8 -...
  • Page 12: Product Overview

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 2. Product overview 2.1 Dimension Figure 2.2 Camera dimension 2.2 Accessory When you unpack, check that all the supplied accessories are included: Figure 2.1 Accessory Configuration Standard IR Remote controller Ceiling or Wall mounting 1x Power adapter...
  • Page 13: Rs-232 Interface

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 2.3 RS-232 Interface 1)RS-232 interface Computer or Control Keyboard and Product Connection Method Product WindowsDB-9 1.DTR 1.DCD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND 4.DTR 5.RXD 5.GND 6.GND 6.DSR 7.IR OUT 7.RTS 8.NC 8.CTS 9.RI 2)Mini-DIN8-pin Port...
  • Page 14: Main Features

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Ring Indicator 4)VISCA networking mode is as follows: Product Cascade Connection Method Product 1 Product 2 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD 4.GND 4.GND 5.RXD 5.RXD 6.GND 6.GND 7.IR OUT 7.OPEN 8. NC 8.OPEN Note: The product has RS232 input and output interface, which can be cascaded.
  • Page 15: Technical Specification

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC interfaces support audio and video output simultaneously; SDI supports 100m transmission in 1080P60 format. 6. Multiple Video compression: Support H.265/H.264 video compression; Supports video compression up to 1920 x 1080 resolution 60 frames/seconds. Support AAC, MP3, G. 711A audio compression, support 8000, 16000, 32000, 44100, 48000 sampling frequency.
  • Page 16 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Minimum 0.5Lux (F1.8, AGC ON) Illumination 2D & 3D DNR White Balance Auto / Manual/ One Push/ 3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K Focus/Aperture/ Auto/Manual/One Push Focus Electronic Shutter Iris Auto/Manual Shutter Auto/Manual ON/OFF OFF/ Dynamic level adjustment Video Adjustment Brightness,Color,Saturation,Contrast,Sharpness,B/W mode,Gamma curve >55dB...
  • Page 17: Remote Controller

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 3. Remote Controller Instructions for the application of remote controllers: Remote controllers are divided into two types: infrared remote controllers and wireless remote controllers. Please read the following according to the actual type of remote controllers.
  • Page 18 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC key of the remote control. The remote control receives the green flashing of the indicator lamp. Release the key and stop the flashing of the indicator lamp. Infrared remote control can be used for preset setting, positioning, horizontal, pitch rotation and other operations.
  • Page 19 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Set Preset: Set preset key + 0-9 number key: Note: Up to 10 presets can be set by remote control. Call preset:Set preset key + 0-9 number key. Note: If the number key is not preset, it is invalid.
  • Page 20: Menu Introduction

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Recovery Default 【#】 + 【#】 + 【8】 : Switching Video Format 720P30 【#】 + 【#】 + 【9】 : Switching Video Format 720P25 Note:If the address of the remote control used before is not 1, but one of 2, 3, 4;...
  • Page 21: Network Connection

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 4. Network Connection 4.1. Network Connection Network Connection: Connect products directly with PC external network ports by network wires or connect products to Internet network. Access network can be through routers or switches. Users can login product IP through browsers.
  • Page 22: Ie Log In

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC address. Verify the success of adding network segments. Open "Start" in the computer, select "Run" to enter cmd, click "OK" and open the DOS command window to enter Ping 192.168.5.26. Press the Enter key. After the product self-check is completed, the above steps can also be followed to verify whether the network is connected properly.
  • Page 23: Software Upgrade

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC live/xxx) If the default IP address of the camera is 192.168.5.163, the way to obtain the RTSP video stream is as follows: rtsp://192.168.5.163:554/live/av0(av0 Main stream) rtsp://192.168.5.163:554/live/av1(av1 Secondary bitstream) If the default IP address of the camera is 192.168.5.163, the way to obtain RTMP video stream is as rtmp://192.168.5.163:1935/live/av0(av0Main stream)...
  • Page 24: Visca Protocol List

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 5.1 VISCA protocol list 5.1.1 Camera return command Ack/Completion Message Command packet Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. z = camera address + 8...
  • Page 25 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Command Function Command packet Note One Push mode 8x 01 04 35 03 FF 5000k 8x 01 04 35 04 FF Manual 8x 01 04 35 05 FF 6500k 8x 01 04 35 06 FF...
  • Page 26 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Command Function Command packet Note CAM_NR(3D) 8x 01 04 54 0p FF P=0-8 0:OFF p = 0 – 4 0:Default 1:0.47 2: CAM_Gamma 8x 01 04 5B 0p FF 0.50 3:0.52 4:0.55 8x 01 04 23 00 FF...
  • Page 27: 3,Inquiry Command

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Command Function Command packet Note Upright 8x 01 06 01 VV WW 02 01 FF ZZZZ: Tilt Position DownLeft 8x 01 06 01 VV WW 01 02 FF DownRight 8x 01 06 01 VV WW 02 02 FF...
  • Page 28: Pelco -Dprotocol Command List

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC y0 50 00 FF CAM_PictureEffectModeInq 8x 09 04 63 FF y0 50 04 FF B&W CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p: Memory number last operated. y0 50 02 FF SYS_MenuModeInq...
  • Page 29: Pelco -Pprotocol Command List

    Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00 0x02 Pan Speed Tilt Speed Upleft 0xFF Address 0x00 0x0C Pan Speed Tilt Speed Upright 0xFF Address 0x00 0x0A Pan Speed Tilt Speed...
  • Page 30: Warranty

    Response Byte 6. Warranty Limited warranty in respect of Alfatron Products 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. The serial number on the product must be clearly visible and not have been tampered with in any way whatsoever.
  • Page 31 Alfatron ALF-12X-SDIC, ALF-20X-SDIC and ALF-30X-SDIC 1.9 A 7 (seven) year limited warranty is given on the aforesaid product where used correctly according to the Company’s instructions, and only with the use of the Company’s components. 1.10 The Company will, at its sole option, provide one of the following three remedies to whatever extent it shall deem necessary to satisfy a proper claim under this limited warranty: 1.10.1 Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free...
