FBD 37 Series Service Bulletin

Frozen Beverage Dispensers

Cleaning and Sanitizing 37x, 56x, and 77x Dispensers

FBD dispensers are shipped from the factory cleaned and sanitized in accordance with NSF guidelines. After installation of
the dispenser, the operator must provide continuous maintenance as described in this bulletin and always adhere to state
and local codes to ensure proper operational and sanitation requirements are met. Failure to properly clean and sanitize the
dispenser can negatively affect components, drink quality, and dispenser operation. FBD recommends that the dispenser
be sanitized annually or when the dispenser has been non-operational for an extended period of time.
A few precautions when cleaning:
• Water lines should NOT be disconnected during the cleaning and sanitizing process. This is to avoid
contamination.
• FBD recommends using Stera-Sheen or Kay-5 for sanitizing.
• DO NOT use strong bleaches or detergents when cleaning the equipment. They could damage the plastic and
metal parts.
• DO NOT use metal scrapers, sharp objects, steel wool, scouring pads, abrasives, solvents, etc., on the dispenser
as they can damage the finish on various materials.

Daily Cleaning

Use a mild soap solution, such as hand dish-washing detergent, diluted with water at 90°F to 100°F (32°C to 38°C) to clean
the exterior of the equipment. Remove all product residue from the surfaces of the dispenser. Rinse thoroughly using clean
water also at 90°F to 100°F (32°C to 38°C) to remove the remaining soap. Remove the drip tray (if not connected to drain
plumbing) and cup rest and clean in a sink using a mild soap solution.

Sanitizing

The dispenser should be sanitized annually. Follow Kay-5 or Stera-Sheen directions for preparing the solution with clean
water at 90°F to 100°F (32°C to 38°C). Kay-5 or Stera-Sheen are preferred because they also contain ingredients to assist
in cleaning. The following procedure must be followed for sanitizing the dispenser in accordance with NSF guidelines. The
process describes the procedure for one barrel. Repeat for additional barrels.
For 37x and 77x, press the up or down arrow on the keypad to highlight the barrel to be sanitized. Press the green
button and then select OFF. Press the green button again and select DEFROST.
1
For 56x, press OFF and then DEFROST for the desired barrel.
While the barrel is defrosting, remove the drip tray (if not connected to drain plumbing), splash plate, and the cover
2
located behind the splash plate.
3 Disconnect the syrup line from the syrup BIB.
Once the barrel has defrosted, navigate to the MANUAL ON/OFF menu located under the SERVICE MENU section
4
and activate both the CO
FBD TECHNICAL SUPPORT: 866-323-2777 (U.S.), 852-2369-3998 (International),
Please refer to the FBD web site (www.fbdfrozen.com) for information relating to FBD Installation,
Operation and Service Manuals, Instruction Sheets, Technical Bulletins, Service Bulletins, etc.
Service Bulletin 20-006
Rev 01 04/30/2020
and solution solenoids for the barrel to be sanitized.
2
800-176-986 (Australia), or www.fbdfrozen.com
©2020 FBD Partnership, LP. All Rights Reserved.
FBD Partnership, LP
• P.O. BOX 18597 • SAN ANTONIO, TX 78218 USA •
• 210-637-2800 • FAX 210-637-2844 • www.fbdfrozen.com •
• FBD TECHNICAL SUPPORT • 1-866-323-2777 •
• TECHNICAL SUPPORT FAX 1-210-637-2832 •
FBD Hong Kong, LTD
Empire Centre, No. 208A
68 Mody Road, Tsim Sha Tsui
Hong Kong office: 852-2369-3998
Fax: 852-2369-3983
(Instructions continued on next page)
