STOCKHOLM 3 DOOR 1 DRAWER WARDROBE
DO NOT
USE
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF
SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND
PERIODIC MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH THE
FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE THIS
PRODUCT. ITS USE WILL INVALIDATE ANY CLAIM YOU MAY HAVE AND
COULD MAKE THIS PRODUCT UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECEIVES IT MAY BE
NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME TO TIME. THIS IS
COMPLETELY NORMAL FOR ANY FLAT PACK FURNITURE.
DO NOT OVERTIGHTEN FIXING.
FOR CLEANING, YOU MAY USE A DAMP CLOTH (NOT WET)
DO NOT USE POLISH, DETERGENT OR CHEMICAL CLEANERS.
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT. ALWAYS USE A
PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT MARKING.
ASSEMBLY INSTRUCTIONS
FOR DOMESTIC USE ONLY
IMPORTANT
SEC/SH/01/19/EU1
PAGE 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Seconique STOCKHOLM
Summary of Contents for Seconique STOCKHOLM
- Page 1 SEC/SH/01/19/EU1 STOCKHOLM 3 DOOR 1 DRAWER WARDROBE ASSEMBLY INSTRUCTIONS DO NOT FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
- Page 2 SEC/SH/01/19/EU1 (SCREWDRIVER NOT PROVIDED) USE A FLAT HEAD SCREWDRIVER TO TIGHTEN THE CAM NUTS. A QUARTER TURN CLOCKWISE IS ALL THAT IS NEEDED. STEP 1 - PUSH CAM BOLT INTO INSERT STEP 2 - ALIGN THE CAM BOLT WITH THE HOLE AND PUSH TOGETHER UNTIL FLUSH. ( MAKE SURE THE ARROW OF THE CAM LOCK IS POINTING TOWARD ON THE EDGE OF THE PANEL.) STEP 3 - THE HEAD OF THE BOLT GOES INTO THE WIDE MOUTH OF THE CAM LOCK.
-
Page 3: Parts List
SEC/SH/01/19/EU1 PART LIST PARTS LIST PILLAR LEG_LEFT 2 PCS PLEASE CHECK THAT YOU HAVE ALL THE PARTS LISTED BEFORE YOU START ASSEMBLING. IF YOU DO FIND THAT SOMETHING IS MISSING, DO NOT CONTINUE ASSEMBLY, PLEASE CONTACT PILLAR LEG_RIGHT 2 PCS YOUR SUPPLIER IMMEDIATELY. -
Page 4: Hardware List
SEC/SH/01/19/EU1 HARDWARE LIST DOWEL 6 X 30MM 55 PCS STOPPER 1 PC BOLT M7 X 60MM 4 PCS DRAWER RUNNER A-L/R 2 PCS SCREW M3.5 X 12MM 20 PCS DRAWER RUNNER B - L/R 2 PCS BOLT M6 X 50MM 4 PCS PLASTIC CORNER BLOCK 12 SETS... - Page 5 SEC/SH/01/19/EU1 STEP 1 STEP 2 HARDWARE NEEDED: HARDWARE NEEDED: 22PCS 5PCS STEP 2.1 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 5...
- Page 6 SEC/SH/01/19/EU1 STEP 3 STEP 4 HARDWARE NEEDED: HARDWARE NEEDED: 4PCS 4PCS 6PCS 4PCS 2PCS 6PCS BACK FRONT Upper Second Hole First Hole Last Forth Hole SCREW MUST BE INSERTED IN THE FIRST HOLE ON THE DRAWER RUNNER THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
- Page 7 SEC/SH/01/19/EU1 STEP 5 STEP 6 HARDWARE NEEDED: HARDWARE NEEDED: MAKE SURE THE ARROW ON THE CAM LOCK IS POINTING 16PCS 4PCS TOWARD THE HOLE ON THE EDGE OF THE PANEL. 4PCS 6PCS 6PCS 2PCS STEP 5.1 STEP 5.2 Upper Second Hole Last Forth Hole First Hole SCREW MUST BE INSERTED...
- Page 8 SEC/SH/01/19/EU1 STEP 7 STEP 8 HARDWARE NEEDED: HARDWARE NEEDED: FRONT 4PCS 8PCS FINISHED FRONT EDGE FINISHED FRONT EDGE STEP 7.1 STEP 8.1 ROUND EDGE THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 8...
- Page 9 SEC/SH/01/19/EU1 STEP 9 STEP 10 HARDWARE NEEDED: HARDWARE NEEDED: 8PCS 6PCS 2PCS ROUND EDGE STEP 9.1 STEP 10.1 ROUND EDGE THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 9...
- Page 10 SEC/SH/01/19/EU1 STEP 11 STEP 12 HARDWARE NEEDED: HARDWARE NEEDED: 18PCS 2PCS 1. VERTICAL 9PCS 6PCS ADJUSTMENT VIA 12SETS SLOT IN THE MOUNTING PLATE 2. LATERAL ADJUSTMENT BY SCREW ADJUSTING STEP 11.1 3.FRONT-TO-BACK BY THE SLACKING THE HINGE ARM MOUNTING SCREW YOU SHOULD RE-ADJUST SCREWS AS SHOWN TO ALIGN DOOR ONCE HINGES 14,15&16...
- Page 11 SEC/SH/01/19/EU1 STEP 13 STEP 14 HARDWARE NEEDED: HARDWARE NEEDED: 2PCS 2PCS 6PCS 6PCS 1. VERTICAL 1. VERTICAL ADJUSTMENT VIA ADJUSTMENT VIA SLOT IN THE SLOT IN THE MOUNTING PLATE MOUNTING PLATE 2. LATERAL 2. LATERAL ADJUSTMENT ADJUSTMENT BY SCREW BY SCREW ADJUSTING ADJUSTING 3.
- Page 12 SEC/SH/01/19/EU1 STEP 15 STEP 15.3 HARDWARE NEEDED: 8PCS 8PCS 2PCS 3PCS 2PCS FINISHED FRONT EDGE STEP 15.1 STEP 15.4 MAKE SURE THE ARROW ON THE CAM LOCK IS POINTING TOWARD THE HOLE ON THE EDGE OF THE PANEL. 18&19 18&19 18&19 STEP 15.2 STEP 15.5...
- Page 13 SEC/SH/01/19/EU1 STEP 16 STEP 17 HARDWARE NEEDED: HARDWARE NEEDED: 4PCS 6PCS 2PCS LAST THIRD HOLE 2PCS 2PCS THIRD HOLE STEP 16.1 STEP 16.2 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 13...
- Page 14 SEC/SH/01/19/EU1 STEP 18 Wall Wall HARDWARE LIST (Z) Anti-Tip Strap - 2pcs (Z1) M4 X 16MM - 2pcs WARNING SERIOUS OR FATAL INJURIES CAN OCCUR FROM FURNITURE TIPPING OVER. TO PREVENT THE FURNITURE FROM TIPPING OVER WE RECOMMEND THAT IT IS PERMANENTLY FIXED TO THE WALL. WALL FIXING ARE NOT SUPPLIED WITH THIS PRODUCT AS DIFFERENT WALL MATERIAL REQUIRES DIFFERENT TYPES OF FIXING DEVICES.
