- Page 1 Documentation EJ3255 5-Channel Potentiometer Measurement with Sensor Supply Version: Date: 2020-06-15...
-
Page 3: Table Of Contents
........................ 30 IPC integration .......................... 31 Disassembly of the signal distribution board ................... 33 5 EtherCAT basics ............................ 34 6 Commissioning............................ 35 Note on documentation for the EL3255 ................... 35 EJ3255 - Object description and parameterization................ 35 6.2.1 Restore object........................ 36 6.2.2 Configuration data ...................... 36 6.2.3 Profile-specific objects (0x6000-0xFFFF) ................ - Page 4 Table of contents 7 Appendix .............................. 46 EtherCAT AL Status Codes ...................... 46 EJ3255 - Firmware compatibility ..................... 46 Firmware Update EL/ES/EM/ELM/EPxxxx .................. 46 7.3.1 Device description ESI file/XML.................. 47 7.3.2 Firmware explanation ...................... 50 7.3.3 Updating controller firmware *.efw................... 51 7.3.4 FPGA firmware *.rbf...................... 53 7.3.5...
-
Page 5: Foreword
EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding applications or registrations in various other countries. ® EtherCAT is registered trademark and patented technology, licensed by Beckhoff Automation GmbH, Germany. Copyright © Beckhoff Automation GmbH & Co. KG, Germany. The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express authorization are prohibited. -
Page 6: Safety Instructions
All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards. -
Page 7: Intended Use
• Chapters Basics communication, TwinCAT Quick Start , TwinCAT development environment and General Notes - EtherCAT Slave Application replaced by references in the chapter Guide through documentation • Chapter EJ3255 - Object description and parameterization added • Update chapter EJ3255 - Pinout • First publication EJ3255... -
Page 8: Marking Of Ethercat Plug-In Modules
EJxxxx (s. note on documentation of ELxxxx [} 35]). Marking of EtherCAT plug-in modules Designation A Beckhoff EtherCAT device has a 14-digit technical designation, made up as follows (e.g. EJ1008-0000-0017) • Order identifier ◦ family key: EJ ◦ product designation: The first digit of product designation is used for assignment to a product group (e.g. -
Page 9: Fig. 1 Order Identifier (A), Revision Number (B) And Serial Number (C) Using The Example Of Ej1008
Associated and synonymous with each revision there is usually a description (ESI, EtherCAT Slave Information) in the form of an XML file, which is available for download from the Beckhoff web site. • The product designation, version and revision are read as decimal numbers, even if they are technically saved in hexadecimal. -
Page 10: Fig. 2 Order Identifier (A), Revision Number (B) And Serial Number (C) Using The Example Of Ej1008
KK - week of production (CW, calendar week) 08 - week of production: 08 YY - year of production 15 - year of production: 2015 FF - firmware version 08 -f irmware version: 08 HH - hardware version 16 - hardware version: 16 Version: 1.1 EJ3255... -
Page 11: Beckhoff Identification Code (Bic)
1.7.1 Beckhoff Identification Code (BIC) The Beckhoff Identification Code (BIC) is increasingly being applied to Beckhoff products to uniquely identify the product. The BIC is represented as a Data Matrix Code (DMC, code scheme ECC200), the content is based on the ANSI standard MH10.8.2-2016. - Page 12 Example of composite information from items 1 - 4 and 6. The data identifiers are marked in red for better display: An important component of the BIC is the Beckhoff Traceability Number (BTN, item no. 2). The BTN is a unique serial number consisting of eight characters that will replace all other serial number systems at Beckhoff in the long term (e.g.
-
Page 13: Certificates
• The cRUus imprint identifies devices that meet product safety requirements according to U.S. and Canadian regulations. • The warning symbol is a request to read the corresponding documentation. The documentations for EtherCAT plug-in modules can be downloaded from the Beckhoff homepage. Fig. 4: Marking for CE and UL using EJ1008 as an example EJ3255... -
Page 14: System Overview
Coded components reduce the unit costs and the risk of miswiring. Beckhoff offers development of signal distribution boards as an engineering service. Customers have the option to develop their own signal distribution board, based on the design guide. -
Page 15: Product Overview
5-channel EtherCAT plug-in module enables a temporally high-resolution and cost-efficient position detection. The EJ3255 diagnostics detect broken wire, loss of supply voltage and short-circuit for each channel. The 5 channels are measured simultaneously (at the same time). -
Page 16: Ej3255 - Technical Data
Product overview EJ3255 - Technical data Technical data EJ3255 Number of analog inputs Power supply via Up contacts Technology ratiometric potentiometer evaluation with own supply, 3-wire connection Distributed Clocks Feed voltage potentiometer typ. 10 V ±10% Internal resistance >> 100 kΩ to wiper connection Input filter limit frequency typ. -
Page 17: Ej3255 - Pinout
Product overview EJ3255 - Pinout Fig. 7: EJ3255 - Pinout The PCB footprint can be downloaded from the Beckhoff homepage. NOTE Damage to devices possible! • The pins named with “NC” must not be connected. • Before installation and commissioning read the chapters Installation of EJ modules [} 19] and Commissioning [} 35]! -
Page 18: Ej3255 - Leds
Product overview EJ3255 - LEDs Fig. 8: EJ3255 - LEDs Color Display State Description green Init State of the EtherCAT State Machine: INIT = initialization of the plug-in module flashing Pre-Operational State of the EtherCAT State Machine: PREOP = function for mailbox commu-... -
Page 19: Installation Of Ej Modules
In the EJ1101-0022 coupler, the RJ45 connectors and optional ID switches are external and can be positioned anywhere on the signal distribution board, as required. This facilitates feeding through a housing. The EJ940x power supply plug-in modules provide an optional reset function (see chapter Connection of the documentation for EJ9400 and EJ9404) EJ3255 Version: 1.1... -
Page 20: Fig. 10 Pcb With Embedded Pc, Ek1110-0043 And Ejxxxx, Rear View Ek1110-0043
The EK1110-004x EtherCAT EJ Couplers relay the following parameters to the signal distribution board via the rear connector: • the E-bus signals, • the E-bus voltage U (3.3 V) and EBUS • the peripheral voltage U (24 V Fig. 10: PCB with Embedded PC, EK1110-0043 and EJxxxx, rear view EK1110-0043 Version: 1.1 EJ3255... -
Page 21: Ejxxxx - Dimensions
12 mm x 152 mm x 55 mm EJ1957 (ej_12_2x16pin_extended_code4747) Fig. 11: EJxxxx - Dimensions The technical drawings can be downloaded from the download finder. The drawings are named as described in the drawing below. Fig. 12: Technical drawings from download finder EJ3255 Version: 1.1... -
Page 22: Installation Positions And Minimum Distances
[} 23]) ensures an adequate reaching area. The signal distribution board must have a thickness of 1.6 mm and a minimum distance of 4 mm from the mounting surface, in order to ensure latching of the modules on the board. Version: 1.1 EJ3255... -
Page 23: Installation Positions
The recommended minimum distances should not be regarded as restricted areas for other components. The customer is responsible for verifying compliance with the environmental conditions described in the technical data. Additional cooling measures must be provided, if required. EJ3255 Version: 1.1... -
Page 24: Fig. 15 Other Installation Positions
All other installation positions are characterized by a different spatial position of the signal distribution board, see Fig. Other installation positions. The minimum distances to ambient specified above also apply to these installation positions. Fig. 15: Other installation positions Version: 1.1 EJ3255... -
Page 25: Codings
The following table provides an overview of the signal types with corresponding color coding. Signal type Modules Color Coupler EJ11xx No color coding Digital input EJ1xxx Yellow Digital output EJ2xxx Analog input EJ3xxx Green Analog output EJ4xxx Blue Motion EJ7xxx orange System EJ9xxx grey EJ3255 Version: 1.1... -
Page 26: Mechanical Position Coding
There is no plug protection between modules with the same signal type. During installation the module type should therefore be verified based on the device name. Fig. 18: Pin coding; sample: digital input modules Version: 1.1 EJ3255... -
Page 27: Installation On The Signal Distribution Board
The required contact pressure can only be established and the maximum current carrying capacity en- sured if the module is latched securely. 5. Use placeholder modules (EJ9001) to fill gaps in the module strand. EJ3255 Version: 1.1... - Page 28 • During installation ensure safe latching of the modules on the signal distribution board! The conse- quences of inadequate contact pressure include: ð loss of quality of the transferred signals, ð increased power dissipation of the contacts, ð impairment of the service life. Version: 1.1 EJ3255...
-
Page 29: Extension Options
Exchanging placeholder modules and B2 - Assigning reserve slots) according to the specifications for the signal distribution board. Fig. 20: Sample: Exchanging placeholder modules and assigning reserve slots E-bus supply Exchange the placeholder modules with other modules changes the current input from the E-Bus. Ensure that adequate power supply is provided. EJ3255 Version: 1.1... -
Page 30: Linking With Ethercat Terminals And Ethercat Box Modules Via An Ethernet/Ethercat Connection
Installation of EJ modules 4.6.2 Linking with EtherCAT Terminals and EtherCAT Box modules via an Ethernet/EtherCAT connection Example of extension via an Ethernet/EtherCAT connection Version: 1.1 EJ3255... -
Page 31: Ipc Integration
EtherCAT extension (EK1110) or EtherCAT Coupler (EJ1100) is required. The Embedded PC can be expanded with EtherCAT terminals that are not yet available in the EJ system, for example. Fig. 21: Example PCB with Embedded PC, EK1110-0043 and EJxxxx, rear view EK1110-0043 EJ3255 Version: 1.1... -
Page 32: Fig. 22 Example For The Connection Of A C6015 Ipc To An Ej System
The figure below shows the connection of a C6015 IPC to an EJ system as an example. The components shown are schematic, to illustrate the functionality. Fig. 22: Example for the connection of a C6015 IPC to an EJ system Version: 1.1 EJ3255... -
Page 33: Disassembly Of The Signal Distribution Board
Disassembly of an unsecured signal distribution board may result in damage to the board. 2. Press the upper and lower mounting tabs simultaneously and pull the module from board while gently moving it up and down. EJ3255 Version: 1.1... -
Page 34: Ethercat Basics
EtherCAT basics EtherCAT basics Please refer to the EtherCAT System Documentation for the EtherCAT fieldbus basics. Version: 1.1 EJ3255... -
Page 35: Commissioning
EtherCAT XML Device Description The display matches that of the CoE objects from the EtherCAT XML Device Description. We rec- ommend downloading the latest XML file from the download area of the Beckhoff website and in- stalling it according to installation instructions. -
Page 36: Restore Object
The value 1 corresponds to 65535 (0x00010000). 80n0:13 Limit 1 First limit value for setting the status bits (resolution 0.1 INT16 0x0000 (0 °C) 80n0:14 Limit 2 Second limit value for setting the status bits (resolution INT16 0x0000 (0 0.1 °C) Version: 1.1 EJ3255... -
Page 37: Profile-Specific Objects (0X6000-0Xffff)
0x00 (0 = invalid). 60n0:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the data BOOLEAN 0x00 (0 of the associated TxPDO is updated. 60n0:11 Value Measured value as 32 bit signed integer INT16 0x0000 (0 EJ3255 Version: 1.1... -
Page 38: Configuration Data Vendor-Specific
CoE profile used (5001). The Hi-Word contains (19665801 the module profile according to the modular device pro- file. Index 1008 Device name Index Name Meaning Data type Flags Default (hex) 1008:0 Device name Device name of the EtherCAT slave STRING EJ3255 Version: 1.1 EJ3255... - Page 39 (hex) 1802:0 AI TxPDO-Par Standard PDO parameter TxPDO 3 UINT8 0x06 (6 Ch.2 1802:06 Exclude TxPDOs Specifies the TxPDOs (index of TxPDO mapping objects) OCTET- 03 1A that must not be transferred together with TxPDO 3. STRING[2] EJ3255 Version: 1.1...
- Page 40 (hex) 1809:0 AI TxPDO-Par Compact PDO parameter TxPDO 10 UINT8 0x06 (6 Ch.5 1809:06 Exclude TxPDOs Specifies the TxPDOs (index of TxPDO mapping objects) OCTET- 08 1A that must not be transferred together with TxPDO 10. STRING[2] Version: 1.1 EJ3255...
- Page 41 0x0F (TxPDO-State)) 1A02:0A SubIndex 010 10. PDO Mapping entry (object 0x6010 (AI Inputs Ch.2), UINT32 0x6010:10, 1 entry 0x10 (TxPDO-Toggle)) 1A02:0B SubIndex 011 11. PDO Mapping entry (object 0x6010 (AI Inputs Ch.2), UINT32 0x6010:11, 16 entry 0x11 (Value)) EJ3255 Version: 1.1...
- Page 42 Meaning Data type Flags Default (hex) 1A05:0 AI TxPDO-Map Com- PDO Mapping TxPDO 6 UINT8 0x01 (1 pact Ch.3 1A05:01 SubIndex 001 1. PDO Mapping entry (object 0x6020 (AI Inputs Ch.3), UINT32 0x6020:11, 1 entry 0x11 (Value)) Version: 1.1 EJ3255...
- Page 43 1A08:0A SubIndex 010 10. PDO Mapping entry (object 0x6040 (AI Inputs Ch.5), UINT32 0x6040:10, 1 entry 0x10 (TxPDO Toggle)) 1A08:0B SubIndex 011 11. PDO Mapping entry (object 0x6040 (AI Inputs Ch.5), UINT32 0x6040:11, 16 entry 0x11 (Value)) EJ3255 Version: 1.1...
- Page 44 TxPDO mapping object) 1C13:04 Subindex 004 4. allocated TxPDO (contains the index of the associated UINT16 0x1A06 (6662 TxPDO mapping object) 1C13:05 Subindex 005 5. allocated TxPDO (contains the index of the associated UINT16 0x1A08 (6664 TxPDO mapping object) Version: 1.1 EJ3255...
- Page 45 Number of occasions that the interval between SYNC0 UINT16 0x0000 (0 and SYNC1 event was too short (DC mode only) 1C33:20 Sync error The synchronization was not correct in the last cycle BOOLEAN 0x00 (0 (outputs were output too late; DC mode only) EJ3255 Version: 1.1...
-
Page 46: Appendix
Check on the Beckhoff website whether more up-to-date documentation is available. Firmware Update EL/ES/EM/ELM/EPxxxx This section describes the device update for Beckhoff EtherCAT slaves from the EL/ES, ELM, EM, EK and EP series. A firmware update should only be carried out after consultation with Beckhoff support. -
Page 47: Device Description Esi File/Xml
The ESI device description is stored locally on the slave and loaded on start-up. Each device description has a unique identifier consisting of slave name (9 characters/digits) and a revision number (4 digits). Each slave configured in the System Manager shows its identifier in the EtherCAT tab: EJ3255 Version: 1.1... -
Page 48: Fig. 24 Device Identifier Consisting Of Name El3204-0000 And Revision -0016
The device revision is closely linked to the firmware and hardware used. Incompatible combinations lead to malfunctions or even final shutdown of the device. Corresponding updates should only be carried out in consultation with Beckhoff support. Display of ESI slave identifier... -
Page 49: Fig. 26 Configuration Is Identical
The ESI/EEPROM identifier can be updated as follows under TwinCAT: • Trouble-free EtherCAT communication must be established with the slave. • The state of the slave is irrelevant. • Right-clicking on the slave in the online display opens the EEPROM Update dialog, Fig. EEPROM Update EJ3255 Version: 1.1... -
Page 50: Firmware Explanation
Firmware explanation Determining the firmware version Determining the version on laser inscription Beckhoff EtherCAT slaves feature serial numbers applied by laser. The serial number has the following structure: KK YY FF HH KK - week of production (CW, calendar week) -
Page 51: Updating Controller Firmware *.Efw
• offline: The EtherCAT Slave Information ESI/XML may contain the default content of the CoE. This CoE directory can only be displayed if it is included in the ESI (e.g. "Beckhoff EL5xxx.xml"). The Advanced button must be used for switching between the two views. -
Page 52: Fig. 31 Firmware Update
Appendix Fig. 31: Firmware Update Proceed as follows, unless instructed otherwise by Beckhoff support. Valid for TwinCAT 2 and 3 as EtherCAT master. • Switch TwinCAT system to ConfigMode/FreeRun with cycle time >= 1 ms (default in ConfigMode is 4 ms). A FW-Update during real time operation is not recommended. -
Page 53: Fpga Firmware *.Rbf
The TwinCAT System Manager indicates the FPGA firmware version. Click on the Ethernet card of your EtherCAT strand (Device 2 in the example) and select the Online tab. The Reg:0002 column indicates the firmware version of the individual EtherCAT devices in hexadecimal and decimal representation. EJ3255 Version: 1.1... -
Page 54: Fig. 32 Fpga Firmware Version Definition
Fig. 33: Context menu Properties The Advanced Settings dialog appears where the columns to be displayed can be selected. Under Diagnosis/Online View select the '0002 ETxxxx Build' check box in order to activate the FPGA firmware version display. Version: 1.1 EJ3255... -
Page 55: Fig. 34 Dialog Advanced Settings
Older firmware versions can only be updated by the manufacturer! Updating an EtherCAT device The following sequence order have to be met if no other specifications are given (e.g. by the Beckhoff support): • Switch TwinCAT system to ConfigMode/FreeRun with cycle time >= 1 ms (default in ConfigMode is 4 ms). - Page 56 • In the TwinCAT System Manager select the terminal for which the FPGA firmware is to be updated (in the example: Terminal 5: EL5001) and click the Advanced Settings button in the EtherCAT tab: • The Advanced Settings dialog appears. Under ESC Access/E²PROM/FPGA click on Write FPGA button: Version: 1.1 EJ3255...
-
Page 57: Simultaneous Updating Of Several Ethercat Devices
The firmware and ESI descriptions of several devices can be updated simultaneously, provided the devices have the same firmware file/ESI. Fig. 35: Multiple selection and firmware update Select the required slaves and carry out the firmware update in BOOTSTRAP mode as described above. EJ3255 Version: 1.1... -
Page 58: Restoring The Delivery State
Fig. 37: Entering a restore value in the Set Value dialog Alternative restore value In some older terminals the backup objects can be switched with an alternative restore value: Deci- mal value: 1819238756, Hexadecimal value: 0x6C6F6164An incorrect entry for the restore value has no effect. Version: 1.1 EJ3255... -
Page 59: Support And Service
Beckhoff's branch offices and representatives Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: http://www.beckhoff.com You will also find further documentation for Beckhoff components there. - Page 60 Marking for CE and UL using EJ1008 as an example ..............Fig. 5 EJ system sample........................Fig. 6 EJ3255............................Fig. 7 EJ3255 - Pinout ........................... Fig. 8 EJ3255 - LEDs..........................Fig. 9 E-bus power supply with EJ1100 or EJ1101-0022 + EJ940x ............Fig. 10 PCB with Embedded PC, EK1110-0043 and EJxxxx, rear view EK1110-0043......
