Aluminium Cabinets
Jupiter
Art No.
43600
Nitro
Art
No.42400
Thank you for purchasing this HiB product.
Please read through these instructions carefully and refer back to them during installation to ensure that
your product is fitted safely and that it retains its high quality finish.
Please retain this leaflet for future reference.
Before drilling, ensure there are no hidden cables or pipes in the wall.
Please Note Atomic & Electron cabinets must be installed with a minimum
distance of 150mm between the infra-red sensor switch and any surface or
object to ensure correct operation of the sensor.
Kore
Art No.
43900
LED Cabinets
Mercury
Art No.
43700
Callisto
Art No.
44100
Atomic
Art No.
42700
FI
#02 008 R150923
Quantum
Art No.
42500
Electron
Art No.
42600
Min. 150mm
Ver No.
1.0 Jan 2016
