How to Connect with
Roger Pen and EasyPen
3
4
5
General Operation
To switch on, press the On/Off button on the side of the Roger Pen/EasyPen for 3 seconds.
•
To switch off, press the press the On/Off button on the side of the Roger Pen/EasyPen for 3 seconds.
•
To connect, hold your Roger Pen/EasyPen close (within 10 cm/4 inches) from the
•
Roger receiver. Then, press the connect button on your Roger Pen/EasyPen.
•
When charging with the supplied USB power cord, the indicator light will shine solid green when fully charged.
1
2
6
8
7
Device Description
1.
On/Off/Mute
2.
Connect
3.
Indicator light (LED)
4.
Microphone
5.
Charging and audio input (micro-USB)
6.
Slot for Roger Pen/EasyPen
7.
Audio input (3.5mm/1/8 inch jack)
8.
Charging input (micro-USB)
Advertisement
Table of Contents
Related Manuals for Phonak Roger Pen
Summary of Contents for Phonak Roger Pen
- Page 1 To switch on, press the On/Off button on the side of the Roger Pen/EasyPen for 3 seconds. • To switch off, press the press the On/Off button on the side of the Roger Pen/EasyPen for 3 seconds. • To connect, hold your Roger Pen/EasyPen close (within 10 cm/4 inches) from the •...
- Page 2 Connecting to Computers/Tablets Make sure you have switched on your Roger Pen/EasyPen. Plug the rectangular end of the short audio cable into the bottom of your Roger Pen/EasyPen. Plug the round end of the short audio cable into the headphone output of your computer or portable device.
