- Page 1 INSTRUCTION MANUAL Planer KP312 KP312S 003868 DOUBLE INSULATION IMPORTANT: Read Before Using.
-
Page 2: Specifications
EC Declaration of Conformity sockets without earth wire. ENG102-2 Makita Corporation responsible For European countries only manufacturer declare that the following Makita Noise machine(s): The typical A-weighted noise level determined according Designation of Machine: to EN60745: Planer Sound pressure level (L ) : 92 dB(A) Model No./ Type: KP312,KP312S... -
Page 3: General Power Tool Safety Warnings
Do not abuse the cord. Never use the cord for representative in Europe who is: carrying, pulling or unplugging the power tool. Makita International Europe Ltd. Keep cord away from heat, oil, sharp edges or Michigan Drive, Tongwell, moving parts. Damaged or entangled cords Milton Keynes, Bucks MK15 8JD, England increase the risk of electric shock. -
Page 4: Planer Safety Warnings
Use of the power cause vibration and shorten tool life. tool for operations different from those intended 17. Use only Makita blades specified in this could result in a hazardous situation. manual. Service 18. -
Page 5: Functional Description
stop. FUNCTIONAL DESCRIPTION Overload protecter (Option) This tool is equipped with an overload protector which CAUTION: automatically cuts out to break the circuit whenever Always be sure that the tool is switched off and • heavy work is prolonged. When it cuts out, inspect the unplugged before adjusting or checking function on blade for damage or something wrong. -
Page 6: Removing Or Installing Planer Blades
Handle the blades very carefully. Use gloves or • rags to protect your fingers or hands when removing or installing the blades. Use only the Makita wrench provided to remove or • install the blades. Failure to do so may result in 003880 overtightening or insufficient tightening of the installation bolts. -
Page 7: Correct Setting
For the correct planer blade setting Your planing surface will end up rough and uneven, unless the blade is set properly and securely. The blade must be mounted so that the cutting edge is absolutely level, that is, parallel to the surface of the rear base. Below are some examples of proper and improper settings. -
Page 8: Front Roller
Nozzle assembly and joint (Accessory) Front roller 1. Front roller 1. Chip guide 003887 003884 When performing repeated cuts, the use of the front roller Nozzle assembly and joint are used when connecting the enables quick and effortless return of the tool toward an tool to vacuum cleaner. -
Page 9: Optional Accessories
Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Planer blade • Triangular rule • Nozzle assembly •... - Page 12 Makita Corporation Anjo, Aichi, Japan www.makita.com 884478F229...
