Operation - Benchmark MyTemp Mini CO2 Operation Manual

3. Connect the CO₂ Gas supply
The Gas tubes provided are combined with 4mm (dia.) and 6mm (dia.) tube. Insert the 4mm edge of tube
to gas inlet port and connect 6mm edge of tube to gas regulator which is installed on the cylinder or gas
line in your lab.
DO NOT connect the gas supply to CO₂ "SAMPLE PORT"
-Turn on the gas supply with the pressure set to 1 Bar (or 14.5 Psi)
NOTE! : To confirm that there are no leaks in the CO₂ connections, a "bubble check" is recommended.
Apply soapy water to each fitting and check if any bubbles are generated. If so, readjust the fitting.
4. Connect the power cord.
-This incubator is provided with 12V DC adopter which is available at the range of voltage from 100 to
240V.
-Plug the connector to power receptacle and back of incubator (refer to CONFIGURATION)
-Plug the power plug to the outlet.

5. Operation

5.1 Power switch on
Turn on the power switch. The digital LED will display current temperature and CO₂% in the chamber.
5.2 Setting temperature
a. Press the "TEMP SET"
temperature.
Set up the desired temperature by pressing UP (▲) or DOWN (▼).
b.
c. Press "TEMP/SET" key
Note:
If you don't press "SET" key after set-up, the new set-up value will not be saved.
5.3 Setting CO2
a. Press "CO2 SET"
b. Input the desired value of Co2 density
c. Press "SET" key again
Note:
If you don't press "CO2 SET" key after set-up, the new set-up value will not be saved.
Page 9 / 12
key, then, the LED screen will flash and display current programmed
after adjustment. The "SAVE" message is shown on the display.
key. Then, LED screen will be flashing.
by adjusting UP (▲) or DOWN (▼) key
after input. "SAVE" is shown up on LED screen as below.
