  • Page 1 ® R&S Compact Video Tester User Manual (E@<L2) 2116122802...
  • Page 2 ® This manual describes the R&S VTS (2115.7100.02) with firmware version FW 02.20 and later. In addition to the base unit, all available options are described. For details on options, see the data sheet. © 2020 Rohde & Schwarz GmbH & Co. KG Mühldorfstr.
  • Page 3: Table Of Contents

    Scaling and Evaluating Diagrams................. 30 Changing between Open Applications..............32 Presetting the R&S VTS....................32 Managing Your Favorites....................33 Getting Help.........................34 3.7.1 Displaying Help......................34 3.7.2 Navigating in the Help....................35 Operating the R&S VTS in a LAN................37 User Manual 2116.1228.02 ─ 14...
  • Page 4 ® Contents R&S 3.8.1 Connecting the R&S VTS to a Network................ 38 3.8.2 Connecting the R&S VTS to a Computer..............38 3.8.3 Zero Configuration Networking..................39 3.8.4 Configuring the Network Card..................39 3.8.5 Firewall Settings......................40 Setting Up Remote Operation..................41 3.9.1 Using the Remote Desktop................... 41 3.9.2...
  • Page 5 ® Contents R&S 6 Basic Instrument Configurations............87 System Tab........................87 Remote Tab........................89 License Keys Tab......................93 6.3.1 Displayed Information and Common Buttons..............93 6.3.2 Installing License Keys....................95 SW/HW-Equipment Tab....................98 Hardware Settings Tab....................100 6.5.1 Reference Subtab....................... 100 6.5.2 Update Subtab......................101 Service Tab........................
  • Page 6 ® Contents R&S Scope Subtab......................136 Vector Subtab......................142 Auto Subtab.......................145 9 Audio Analyzer Application.............. 158 Main Dialog of the Application.................158 Input Subtab......................158 Ch. Status Subtab..................... 163 Level Subtab......................173 THD+N Subtab......................178 Freq. Resp. Subtab....................180 9.6.1 Common Settings and Commands................180 9.6.2 FFT Spectrum Measurement Mode................
  • Page 7 ® Contents R&S 10.1.7 SCDC Subtab......................253 10.1.8 CTS Subtab.........................257 10.1.9 CEC Subtab........................ 272 10.2 HDMI Analyzer Application..................274 10.2.1 Main Dialog of the Application..................275 10.2.2 Input Subtab........................275 10.2.3 Video Subtab.......................279 10.2.4 Audio Subtab.......................282 10.2.5 HDCP Subtab......................285 10.2.6 InfoFrame Subtab....................... 288 10.2.7 SCDC Subtab......................290 10.2.8...
  • Page 8 ® Contents R&S 12 MHL Applications................403 12.1 MHL Generator Application..................403 12.1.1 Main Dialog of the Application..................403 12.1.2 Output Subtab......................403 12.1.3 Signal Subtab......................405 12.1.4 InfoFrame Subtab....................... 417 12.1.5 EDID Reader Subtab....................428 12.1.6 CTS Subtab.........................430 12.1.7 CBUS Subtab......................434 12.2 MHL Analyzer Application..................437 12.2.1 Main Dialog of the Application..................437 12.2.2...
  • Page 9 ® Contents R&S 14.1.1 Addressing Module Slots.................... 480 14.2 Common and General Commands................480 14.2.1 Common Commands....................481 14.2.2 CALibration Subsystem....................486 14.2.3 DIAGnostic Subsystem....................486 14.2.4 HCOPy Subsystem..................... 486 14.2.5 INSTrument Subsystem....................487 14.2.6 MMEMory Subsystem....................489 14.2.7 SENSe Subsystem......................496 14.2.8 SOURce Subsystem....................
  • Page 10 ® Contents R&S 14.4.11 ROUTe Subsystem......................667 14.4.12 SENSe Subsystem......................669 14.4.13 UNIT Subsystem......................670 14.5 Audio Analyzer Application..................671 14.5.1 ABORt Subsystem...................... 671 14.5.2 CALCulate Subsystem....................672 14.5.3 CONFigure Subsystem....................677 14.5.4 DISPlay Subsystem....................685 14.5.5 INITiate Subsystem..................... 686 14.5.6 MMEMory Subsystem....................686 14.5.7 READ Subsystem.......................
  • Page 11 ® Contents R&S 14.8.4 DISPlay Subsystem....................964 14.8.5 INITiate Subsystem..................... 964 14.8.6 MMEMory Subsystem....................965 14.8.7 READ Subsystem....................... 966 14.8.8 ROUTe Subsystem......................969 14.9 Time Domain Analyzer Application................. 970 14.9.1 ABORt Subsystem...................... 970 14.9.2 CONFigure Subsystem....................970 14.9.3 DISPlay Subsystem....................979 14.9.4 INITiate Subsystem.....................
  • Page 12 ® Contents R&S 18 Maintenance, Storage and Disposal..........1008 18.1 Cleaning........................1008 18.2 Storage........................1008 18.3 Disposal........................1008 List of Commands................1009 User Manual 2116.1228.02 ─ 14...
  • Page 13: Preface

    Includes the contents of the getting started manual. The contents of the user manual is available as help on the R&S VTS. The help offers quick, context-sensitive access to the complete information for the base unit and the software options.
  • Page 14: Data Sheets And Brochures

    Conventions Used in the Documentation 1.1.5 Data Sheets and Brochures The data sheet contains the technical specifications of the R&S VTS. It also lists the options and their order numbers, and optional accessories. The brochure provides an overview of the instrument and deals with the specific char- acteristics.
  • Page 15: Key Features

    To drag & drop 1.3 Key Features The R&S VTS video test center is a universal platform for testing video and audio inter- faces on consumer electronics equipment in R&D where a wide variety of applications need to be addressed and involve different AV interface technologies. The modular platform accommodates up to eight test modules and can be equipped with additional software to optimally suit the requirements of specific applications.
  • Page 16: Safety And Regulatory Information

    ® Safety and Regulatory Information R&S Safety Instructions 2 Safety and Regulatory Information The product documentation helps you use the product safely and efficiently. Follow the instructions provided here and in the Chapter 2.1, "Safety Instructions", on page 16. Intended use The product is intended for the development, production and verification of electronic components and devices in industrial, administrative, and laboratory environments.
  • Page 17 ® Safety and Regulatory Information R&S Safety Instructions Choosing the operating site Only use the product indoors. The product casing is not waterproof. Water that enters can electrically connect the casing with live parts, which can lead to electric shock, serious personal injury or death if you touch the casing.
  • Page 18: Labels On The Product

    ® Safety and Regulatory Information R&S Labels on the Product ● If the product needs an external power supply, use the power supply that is deliv- ered with the product or that is recommended in the product documentation or a power supply that conforms to the country-specific regulations.
  • Page 19: Warning Messages In The Documentation

    ® Safety and Regulatory Information R&S Korea Certification Class B Table 2-1: Labels regarding product and environment safety Labeling in line with EN 50419 for disposal of electrical and electronic equipment after the prod- uct has come to the end of its service life. For more information, see "Electrical and electronic equipment"...
  • Page 20: Operating Concepts

    Devices", on page 57. ● What to do if you want to operate an R&S VTS that is used by another user in a remote operation/control session? Depends on the session type, see "To end the connection at the R&S VTS"...
  • Page 21 ® Operating Concepts R&S Home Screen In the left pane, all open applications are displayed. These applications are presented as a tab in the application screen, see Chapter 3.2, "Basic Layout of the Application Screen", on page 22. In the right pane on the "Applications" tab, all available but closed applications are dis- played.
  • Page 22: Basic Layout Of The Application Screen

    ® Operating Concepts R&S Basic Layout of the Application Screen 2. Slide it into the right pane of the home screen and release it. Remote command: on page 488 INSTrument:DEACtivate You can only open and close measurement applications. Signal generating applica- tions are running all the time.
  • Page 23 ® Operating Concepts R&S Basic Layout of the Application Screen Figure 3-1: Application screen (example) 1 = Title bar 2 = Messages 3 = Toolbar 4 = Tab title 5 = Favorites 6 = Parameter values 7 = Subtabs Title bar See (1) in Figure 3-1.
  • Page 24 Creates a screenshot of the current screen content, and opens the "File" dialog. Enter a filename and select the file format: PNG, JPG or BMP. The default directory is D:\VTS\UserData\Hardcopy Help Displays the help topic that corresponds to the selected parameter set.
  • Page 25: On-Screen Actions

    ® Operating Concepts R&S On-Screen Actions Displays the important parameters for the selected application all the time. If a parame- ter is editable, you can also change its value here. You can change the favorites, see Chapter 3.6, "Managing Your Favorites", on page 33.
  • Page 26: Hiding Or Displaying A Parameter Pane

    ® Operating Concepts R&S On-Screen Actions 3.3.2 Hiding or Displaying a Parameter Pane If a dialog is divided into a graph pane and a parameter pane, you can enlarge the graph pane by hiding the parameter pane. 1. Click to hide the parameter pane. The graph is displayed as large as possible.
  • Page 27 ® Operating Concepts R&S On-Screen Actions The selected field content is highlighted. The minimum and maximum value is dis- played. Note: For details on the on-screen keypad, see Chapter 3.3.3.1, "On-Screen Key- pad", on page 28. 2. If you want to enter a new numeric value, use the digit keys. Separate decimal pla- ces by using the decimal point key.
  • Page 28 ® Operating Concepts R&S On-Screen Actions Table 3-1: Cursor behavior Cursor look Function Horizontal underline Underlined numbers or characters are selected. Colored rectangle Marked numbers or characters are overwritten. Vertical line New entries are inserted at the cursor position. 3.3.3.1 On-Screen Keypad For data input in dialog boxes, the touchscreen provides an on-screen keypad to enter numeric values and units.
  • Page 29 ® Operating Concepts R&S On-Screen Actions Description Left arrow key; moves the cursor to the left. Right arrow key; moves the cursor to the right. Down key; decreases the value of the digit on which the cursor is placed. If you want to increase the step width, place the cursor on a digit to the left.
  • Page 30: Scaling And Evaluating Diagrams

    ® Operating Concepts R&S On-Screen Actions 3.3.4 Scaling and Evaluating Diagrams Also to the scaling offered by the controls of the graphical user interface, you can also scale diagrams using the touchscreen. To shift a diagram in negative or positive x/y-direction 1.
  • Page 31 ® Operating Concepts R&S On-Screen Actions Figure 3-3: Scaling the x-axis To compress or stretch the y-axis 1. Touch and hold the diagram in one of the left corners until the up or down arrow is displayed (see Figure 3-4). 2.
  • Page 32: Changing Between Open Applications

    "To close an application" on page 21. 3.5 Presetting the R&S VTS Use the preset functionality to set the R&S VTS to a well-defined state. This allows you to change parameter values from well defined starting point. To preset the R&S VTS 1.
  • Page 33: Managing Your Favorites

    Your favorites Application-independent favorites that are displayed in the lower row. You can add and remove favorites from any application of the R&S VTS. This allows fast opera- tion that goes beyond individual applications. If your favorite is from another application, it only displays a value if the corre- sponding application is running.
  • Page 34: Getting Help

    3.7 Getting Help If you need information, you can display the help. If you prefer reading in a PDF, you can look up information in the user manual that is delivered with the R&S VTS on disk. 3.7.1 Displaying Help You can display the help at any time while operating the R&S VTS.
  • Page 35: Navigating In The Help

    ® Operating Concepts R&S Getting Help To close the help dialog ► In the toolbar, click again. ► In the upper right corner of the dialog, click the close button. 3.7.2 Navigating in the Help To provide you with as much information as possible at a glance, the "Help" dialog opens with the table of contents hidden.
  • Page 36 ® Operating Concepts R&S Getting Help Navigation pane See (1) in Figure 3-5. Contains the following tabs: ● "TOC" Table of contents ● "Index" Topic catalog ● "Search" Full-text search Breadcrumbs See (2) in Figure 3-5. Displays the navigation to the displayed topic if you use the table of contents. You can display any topic of this path by clickping the underlined text.
  • Page 37: Operating The R&S Vts In A Lan

    The corresponding topic is displayed in the content pane. 3.8 Operating the R&S VTS in a LAN The R&S VTS is equipped with a network interface and can be connected to an Ether- net LAN (local area network). The network card operates with 1000 Mbit Ethernet IEEE 802.3ab.
  • Page 38: Connecting The R&S Vts To A Network

    To connect the R&S VTS to a network 1. Fulfill all prerequisites mentioned above. 2. Make sure that the R&S VTS is switched off. This is the only way to ensure that the network connection is reliably detected and any disruptions during the operation of the R&S VTS are avoided.
  • Page 39: Zero Configuration Networking

    The IP addresses 192.168.xxx.yyy are available for use here. xxx and yyy can assume values of 1 to 255. The value for the subnet mask is 255.255.255.0. 2. Connect the R&S VTS and the computer with a standard RJ.45 cross-over cable (LAN cable).
  • Page 40: Firewall Settings

    The default computer name is composed as follows: <instrument short name>-<serial number> Example: VTS-100104 The serial number consists of 6 digits and is printed on the cabinet of the R&S VTS. Networks without DHCP Server In networks that assign fixed IP addresses, the network administrator usually config- ures the network card.
  • Page 41: Setting Up Remote Operation

    R&S Setting Up Remote Operation To enable data transfer or to allow access to the R&S VTS, define exceptions using the Windows 7 Start menu. For details refer to the Windows 7 documentation or contact your network administrator for support.
  • Page 42 3. In the "Remote Desktop Connection" dialog, click "Show Options". 4. On the "General" tab in the "Computer" field, enter the host name of the R&S VTS. Every R&S VTS is delivered with a host name that is suitable for use with manual remote desktop, see also "...
  • Page 43: Using A Vnc Client

    If the VNC connection is activated, any user in the network who knows the password and IP address of the R&S VTS can access it. To prevent this, disable the VNC server service or uninstall the VNC program on the R&S VTS.
  • Page 44: Setting Up Remote Control

    Card", on page 39). 3.10.1 VISA Libraries A VISA installation is a prerequisite for remote control. On the R&S VTS, VISA is already installed. VISA (virtual instrument software architecture) is a standardized software interface library providing input and output functions to communicate with instruments. The used...
  • Page 45: Remote Control Interfaces And Protocols

    3.10.2.1 LAN Interface The LAN (local area network) interface of the R&S VTS is based on TCP/IP and con- sists of a connector, a network interface card and protocols. Connect the computer and the R&S VTS to a common network with TCP/IP network protocol.
  • Page 46: Basic Procedures

    HiSLIP data is sent to the device using the "fire and forget" method with immediate return. Thus, a successful return of a VISA operation such as viWrite() does not guarantee that the R&S VTS has finished or started the requested command, but is delivered to the TCP/IP buffers.
  • Page 47: Using Raw Tcpip/Sockets

    To switch to manual operation 1. Wait until command processing is completed. Otherwise the R&S VTS returns to remote control immediately. 2. The R&S VTS remains in the remote state until you perform one of the following actions. ● Send the &GTL interface command (go to local).
  • Page 48 ® Operating Concepts R&S Setting Up Remote Control double Timeout; } SocketsRawTcpIpConfig; /* METHOD ********************************************************************/ // Function name : ConnectToServer // Description : Connects to the server // Return type : void // Argument : char *pHostName: e. g. "172.29.48.10", // the Windows host name is not supported! // Argument : int port:...
  • Page 49 ® Operating Concepts R&S Setting Up Remote Control //connect to socket // The sockaddr_in structure specifies the address family, // IP address, and port of the server to be connected to. struct sockaddr_in ClientService; ClientService.sin_family = AF_INET; ClientService.sin_addr.s_addr = inet_addr(pHostName); ClientService.sin_port = htons((u_short)atol(pPort));...
  • Page 50 ® Operating Concepts R&S Setting Up Remote Control free(pBuffer); return SentBytes; /* METHOD ********************************************************************/ // Function name : Receive // Description : Receives characters from the server // Return type : int: returns the total number of bytes received // Argument : char *pReceiveBuffer // Argument : unsigned int BufferSize: size of pReceiveBuffer...
  • Page 51 ® Operating Concepts R&S Setting Up Remote Control //be lost! ReceivedBytes = recv(SocketsRawTcpIpConfig.CurrentSocketDescr, pReceiveBuffer, BufferSize - 1, 0); if(ReceivedBytes <= 0) printf( "Could not receive data!\n" ); WSACleanup(); exit(4); break; default: break; return ReceivedBytes; /* METHOD ********************************************************************/ // Function name : _tmain // Description : main entry;...
  • Page 52 ® Operating Concepts R&S Setting Up Remote Control //Initialize configuration memset(&SocketsRawTcpIpConfig, 0, sizeof(SocketsRawTcpIpConfig)); SocketsRawTcpIpConfig.CurrentSocketDescr = INVALID_SOCKET; SocketsRawTcpIpConfig.ClientIsConnected = false; //Initialize WS2_32.dll wVersionRequested = MAKEWORD(2, 2); WSAStartup(wVersionRequested, &wsaData); //connect to desired server ConnectToServer(argv[1], argv[2], argv[3]); //main task: - wait for command to be sent to the unit - when the command contains a "?"...
  • Page 53 ® Operating Concepts R&S Setting Up Remote Control return 0; User Manual 2116.1228.02 ─ 14...
  • Page 54: Getting Started

    5. Check the equipment for damage. If the delivery is incomplete or equipment is damaged, contact Rohde & Schwarz. For information on warranty conditions for the R&S VTS, refer to the terms of the deliv- ery documents. 4.1.3 Choosing the Operating Site Specific operating conditions ensure accurate measurements and avoid damage to the product and connected devices.
  • Page 55 ® Getting Started R&S Preparing for Use See also "Choosing the operating site" on page 17. Electromagnetic compatibility classes The electromagnetic compatibility (EMC) class indicates where you can operate the product. The EMC class of the product is given in the data sheet under "General data". ●...
  • Page 56 ® Getting Started R&S Preparing for Use max. 250 N max. 500 N Correct Different dimensions Too many instruments 4. NOTICE! Overheating can damage the product. Prevent overheating as follows: ● Keep a minimum distance of 10 cm between the fan openings of the product and any object in the vicinity.
  • Page 57: Considerations For Test Setup

    Chapter 4.2.2.1, "AC Power Supply Connector and Switch", on page 62 4.1.6 Connecting External USB Devices Using the USB interfaces, you can directly connect USB devices to the R&S VTS. This number can be increased as necessary by using USB hubs. User Manual 2116.1228.02 ─ 14...
  • Page 58: Switching On Or Off

    4.1.6.1 Memory Stick The R&S VTS has a disk drive. You can exchange data by using a memory stick which you plug into one of the USB interfaces. The memory stick is automatically assigned a free drive letter and you can use Windows Explorer to transfer data.
  • Page 59: Checking The Provided Options

    To switch off the R&S VTS 1. Check the status displays on the front panel of the R&S VTS. If the REMOTE sta- tus display on the front panel is on, do not switch off the R&S VTS. Someone else is using the R&S VTS by remote control.
  • Page 60: Turn-On Tests

    Chapter 6.4, "SW/HW-Equipment Tab", on page 98. For an overview of the all options available for the R&S VTS, refer to the Rohde & Schwarz Homepage. 4.1.9 Turn-On Tests During power-on and on an ongoing basis during operation, the R&S VTS automati- cally monitors the main instrument functions.
  • Page 61 4-1. The basic state is indicated by LEDs. POWER ON Displays the power supply status. ● LED off: No power is supplied. R&S VTS is switched off. ● LED green: Power is supplied. REMOTE Displays the remote control status. ●...
  • Page 62: Rear Panel

    1024x768 pixels or higher. You can use a DVI-I cable for connecting R&S VTS and display, but the analog video interface (pins C1 to C4) is not provided by the R&S VTS.
  • Page 63 Figure 4-2. 1 gigabit LAN interface (1000 Base-T). Used to connect the R&S VTS to a local net- work for remote control, remote operation, printouts and data transfer. The assignment of the RJ.45 CAT5 connector supports twisted-pair category 7 UTP/STP cables in a star configuration (UTP stands for "unshielded twisted pair", and STP for "shielded...
  • Page 64 ® Getting Started R&S Instrument Tour ● Chapter 3.10.2.1, "LAN Interface", on page 45. Table 4-2: Pin assignment Name Description TX+_D1 Transmit data, positive TX-_D1 Transmit data, negative RX+_D2 Receive data, positive BI+_D3 Bi-directional, positive BI-_D3 Bi-directional, negative RX-_D2 Receive data BI+_D4 Bi-directional, positive BI-_D4...
  • Page 65 ® Getting Started R&S Instrument Tour Table 4-3: Pin assignment Signal name Description VBUS Power On demand up to 900 mA USB 2.0 differential pair Ground SSRX− Super speed transmitter differential pair SSRX+ GND_DRAIN Ground for signal return SSTX− Super speed receiver differential pair SSTX+ 4.2.2.5 HDMI Connector...
  • Page 66 ® Getting Started R&S Instrument Tour Description Reserved (not connected) DDC/CEC ground +5 V power (+5 V / 500 mA) Hot plug detect 4.2.2.6 MHL RX/TX Module (R&S VT-B2350) The MHL RX/TX module (R&S VT-B2350) is optional. MHL is the abbreviation for mobile high-definition link. Figure 4-4: MHL RX/TX module MHL IN ANALYZER HDMI type A socket.
  • Page 67 ® Getting Started R&S Instrument Tour Table 4-5: Pin assignment Description Not connected CD_SENSE Not connected Not connected TMDS GND Not connected MHL data+ (TMDS) MHL data shield MHL data– (TMDS) Not connected TMDS GND Not connected Not connected Not connected CD_PULLUP Not connected VBUS_CBUS_GND...
  • Page 68 ® Getting Started R&S Instrument Tour Table 4-6: Pin assignment Description VBUS (+5 V / 200 mA) MHL data– (TMDS) MHL data+ (TMDS) CBUS Ground Shield Shield HDMI OUT AUXILIARY HDMI type A socket. Used to output an HDMI signal conforming to the HDMI specifica- tion version 1.4b.
  • Page 69 ® Getting Started R&S Instrument Tour SPDIF IN ANALYZER Toslink connector (female). Used as optical digital audio input. The input is configured in the audio analyzer application under "Input" on page 160. An LED indicates the status: ● LED off: Currently not used. ●...
  • Page 70 ® Getting Started R&S Instrument Tour Table 4-7: Pin assignment Name Description TX+_D1 Transmit data, positive TX-_D1 Transmit data, negative RX+_D2 Receive data, positive BI+_D3 Bi-directional, positive BI-_D3 Bi-directional, negative RX-_D2 Receive data BI+_D4 Bi-directional, positive BI-_D4 Bi-directional, negative Case Ground 4.2.2.8 HDMI TX Module (R&S VT-B360)
  • Page 71 ® Getting Started R&S Instrument Tour 100 Mbit/s LAN interface (100 Base-T). Used to connect the HDMI Ethernet and audio return channel (HEAC). The assignment of the RJ.45 CAT5 connector supports twisted pair category 7 UTP/STP cables in a star configuration (UTP stands for "unshielded twisted pair", and STP for "shielded twisted pair").
  • Page 72 ® Getting Started R&S Instrument Tour An LED indicates the status: ● LED off: Currently not used. ● LED green: Used by an application. Connected state is valid for the HDMI signal. ● LED yellow: Used by an application but connection cannot be achieved. The pin labeling and pin assignment are shown in Chapter 4.2.2.5, "HDMI Connector",...
  • Page 73 ® Getting Started R&S Instrument Tour An LED indicates the status: ● LED off: Currently not used. ● LED green: Used by an application. Connected state is valid for the HDMI signal. ● LED yellow: Used by an application but connection cannot be achieved. The pin labeling and pin assignment are shown in Chapter 4.2.2.5, "HDMI Connector",...
  • Page 74 ® Getting Started R&S Instrument Tour ● LED green: Used by an application. Synchronization state is valid for the compo- nent video.* ● LED yellow: Used but synchronization cannot be achieved.* * Synchronization can be achieved by evaluating the Y/G signal or the external video synchronization signals fed in by the [H-SYNC] and [V-SYNC] connectors (see below).
  • Page 75: Accessories

    ® Getting Started R&S Instrument Tour ● Green: Used by an application. Connected state is valid for the time domain mea- surement. ● Yellow: Used by an application but connection cannot be achieved. SMA connector. This line carries the single ended positive TMDS signal without DC off- set terminated with 50 Ω...
  • Page 76 ® Getting Started R&S Instrument Tour Figure 4-13: HDMI type A TPA (plug) HDMI IN HDMI type A connector. Used to connect the probe to the source. Suitable for sockets up to HDMI 2.0, HDMI 1.4b included. CLK, CH-, CH+, CONTROL These connectors are used to connect the probe to the TMDS time domain analyzer module (R&S VT-B2380).
  • Page 77 ® Getting Started R&S Instrument Tour To connect the probe The R&S cable consists of 4 individual wires. To help you connect the correct ends, the wires are labeled. Matching ends carry the same name. 1. Connect the CONTROL connectors of the R&S cable: a) One end goes into the CONTROL socket of the TMDS time domain analyzer module (R&S VT-B2380).
  • Page 78 ® Getting Started R&S Instrument Tour ● Chapter 10.3.4, "Tracer Subtab", on page 335 Figure 4-14: HDMI pass-through adapter to R&S VT-B2363 HDMI type A socket. Connect it to either socket of the HDMI RX/TX 600 MHz module (R&S VT-B2363): ●...
  • Page 79: File And Data Management

    R&S 5 File and Data Management The R&S VTS uses files to save all instrument and user data. Managing files is a cen- tral application. When you open the "File" dialog, the current application is still running, but it is covered by the "File" dialog. For general information on the graphical user interface, see Chapter 3.3, "On-Screen...
  • Page 80: Saving And Recalling Instrument Settings

    ● To repeat a measurement under specific conditions on the R&S VTS. ● To transfer the settings used in a test setup with more than one R&S VTS. To save instrument settings, you can: ● Use the intermediate memories, see "Quick Device dialog"...
  • Page 81: Saving And Loading Files

    ® File and Data Management R&S Saving and Loading Files 3. Select the drive from which you want to recall the instrument settings. 4. Select a folder. 5. Select a file. Note: Only files that match the selected extension are displayed. 6.
  • Page 82: File Dialog

    ® File and Data Management R&S File Dialog To load a file 1. Open the application-specific "File" dialog, see "To open the application-specific File dialog" on page 79. 2. Select the "Load <file>" or "Recall <file>" tab. 3. Select the drive from which you want to load the file. 4.
  • Page 83 If a memory stick is connected, the name of the memory stick is displayed in the list. It is assigned the E: drive. ● <Network drive> If the R&S VTS is connected to a network, all network drives for which you have access rights are displayed. User Manual 2116.1228.02 ─ 14...
  • Page 84: Folders

    ® File and Data Management R&S File Dialog Note: C: drive. The C: drive is a protected system drive. To prevent system files from being deleted or overwritten inadvertently, the C: drive is not displayed. It can be accessed only by the service. Remote command: on page 491 MMEMory:CDIRectory...
  • Page 85: New Folder Button

    ® File and Data Management R&S File Dialog Remote command: on page 493 MMEMory:DELete on page 495 MMEMory:RDIRectory New Folder button Opens the "New Folder" dialog ("New Folder dialog" on page 85). New Folder dialog ← New Folder button Enter a name for the new folder using the on-screen keyboard (Chapter 3.3.3.2, "On- Screen Keyboard",...
  • Page 86: Save All

    Only available on the "Save Instrument" and "Recall Instrument" tabs. Saves all current settings immediately. If the settings are not changed afterwards, these settings are provided when the R&S VTS is switched off and on again. User Manual 2116.1228.02 ─ 14...
  • Page 87: Basic Instrument Configurations

    ® Basic Instrument Configurations R&S System Tab 6 Basic Instrument Configurations The setup is a central application. When you open the "Setup" dialog, the current appli- cation is still running, but it is covered by the "Setup" dialog. For general information on the graphical user interface, see Chapter 3.3, "On-Screen Actions",...
  • Page 88 If you are not familiar with LAN configurations, ask your network administrator. Network Adapter ← LAN Services Displays the available LAN networks. If there is more than one, you can select one from the list. See also Chapter 3.8.1, "Connecting the R&S VTS to a Network", on page 38. Remote command:...
  • Page 89: Remote Tab

    For remote control, communication between the R&S VTS and the controlling com- puter is established based on the VISA (virtual instrument software architecture) stan- dard. Depending on the interface used for the connection between R&S VTS and com- puter, different protocols are used. The remote control information is sorted according to the used protocol.
  • Page 90 ® Basic Instrument Configurations R&S Remote Tab HiSLIP........................... 90 └ HiSLIP-n......................91 └ Visa Resource..................91 └ Assigned Instrument................91 └ HiSLIP Port................... 91 TCPIP..........................91 └ TCPIPn......................91 └ Visa Resource..................91 └ Assigned Instrument................91 └ Data Port....................91 └ Control Port...................92 └...
  • Page 91 The connections are numbered consecutively, starting at 1. For each connection, detailed information is listed. Visa Resource ← TCPIPn ← TCPIP Displays the resource name used by the programs for identification and control of the R&S VTS. Has the form TCPIP::host name::data port::SOCKET, where: TCPIP Used network protocol host name Computer name of the R&S VTS...
  • Page 92 505 SYSTem:COMMunicate:VXI<inst>:GTR Visa Resource ← VXI-11-n ← VXI-11 Displays the resource name used by the programs for identification and control of the R&S VTS. Has the form TCPIP::host name::inst0::INSTR, where: TCPIP Used network protocol host name Computer name of the R&S VTS...
  • Page 93: License Keys Tab

    Basic Instrument Configurations R&S License Keys Tab 6.3 License Keys Tab The R&S VTS includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/). The OpenSSL Toolkit is used unchanged in the license key procedure. Further information: ●...
  • Page 94 Restart button........................95 Device Identification Displays the identification number that is unique for each R&S VTS. The string has the following structure: <part number>-<serial number>-<checksum> Part No. ← Device Identification Displays the part number of the R&S VTS, for example 2115.7300K02.
  • Page 95: Installing License Keys

    *IDN? Active License Keys Only available on the "Active Licenses" subtab. Lists all software options that are enabled on the R&S VTS. If a license is temporary, the expiration date is also displayed. Deactivation Keys Only available on the "Deactivation Keys" subtab.
  • Page 96 If the key is not accepted, an error message is displayed. Reenter the license key or use the license file, see "To install a license file" on page 96. 5. Click "Restart" to reboot the R&S VTS. 6. Check whether the option is active: The option is displayed under "Active License Keys"...
  • Page 97 ® Basic Instrument Configurations R&S License Keys Tab All Content and all single keys contained in the RSI file are displayed. All Content contains all license keys. The name of a single key starts with Activation. 7. Select All Content or a single activation key. Under "Install Info", information about the selected license key(s) is displayed.
  • Page 98: Sw/Hw-Equipment Tab

    ® Basic Instrument Configurations R&S SW/HW-Equipment Tab 8. Click "OK" to install the selected license key(s). 9. Click "Restart" to complete the installation. 6.4 SW/HW-Equipment Tab The tab is divided into two panes. In the lower "Info" pane, additional information to the selected option is displayed.
  • Page 99 ® Basic Instrument Configurations R&S SW/HW-Equipment Tab Hardware Configuration....................99 Software Licenses......................99 Installed Software......................99 Operating System......................99 Hardware Configuration Lists the currently installed hardware. For each installed hardware option, the status and the part number are displayed. If you select an option, additional information is dis- played in the "Info"...
  • Page 100: Hardware Settings Tab

    ® Basic Instrument Configurations R&S Hardware Settings Tab 6.5 Hardware Settings Tab The content depends on the installed (hardware) options. 6.5.1 Reference Subtab Groups the reference oscillator parameters. External Reference Frequency................... 100 └ Source......................100 └ Adjustment State...................101 └ Adjustment DAC Value.................
  • Page 101: Update Subtab

    Thus the frequency can be impaired freely, for example to simulate a frequency error. Note: If enabled, the R&S VTS is no longer in a calibrated state. However, the calibra- tion value is not changed. The R&S VTS resumes the calibrated state after disabling this mode.
  • Page 102: Service Tab

    During the installation, a boot device(s) update (PCI update) is performed. If you switch off the R&S VTS during this boot device(s) update, the R&S VTS will fail and has to be returned to the R&S service center in Munich. Be aware that only the R&S service cen- ter in Munich is able to fix this failure.
  • Page 103: Av Distortion Analyzer Application

    ® AV Distortion Analyzer Application R&S Main Dialog of the Application 7 AV Distortion Analyzer Application Requires the following options: ● AV inspection option (R&S VT-K2110) ● For extended functionality: AV distortion analysis option (R&S VT-K2111) ● Suitable module as described in the data sheet, see also "Input"...
  • Page 104: Monitor View

    ® AV Distortion Analyzer Application R&S Monitor View Parameters that are often needed are provided as default favorites below the tab title. Some of the default favorites of the application itself are also available on one of the subtabs. ● "Signal"...
  • Page 105 ® AV Distortion Analyzer Application R&S Monitor View To show and hide the monitor view ► On the left border of the main dialog, click The monitor view offers 4 different views. To select a view, click the corresponding tab. Combo subtab......................105 Signal...
  • Page 106 ® AV Distortion Analyzer Application R&S Monitor View Reference subtab Shows the picture and the audio levels of the selected reference signal. Difference subtab Shows the difference picture and the difference audio level and audio delay. User Manual 2116.1228.02 ─ 14...
  • Page 107: Common Buttons And Dialogs

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs 7.3 Common Buttons and Dialogs The following buttons and dialogs are available throughout the application. 7.3.1 Buttons Pane Groups all common buttons (see Figure 7-1). Start button........................107 Stop button........................107 Clear button.........................107 Set Ref.
  • Page 108: Set Reference Dialog

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs Set Ref. button Opens the "Set Reference" dialog to record the reference sequence. Only available if the measurement has been stopped. See Chapter 7.3.2, "Set Reference Dialog", on page 108. Settings button Opens the "Edit Settings"...
  • Page 109 ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs The title bar varies depending on the status. ● "<>" No reference sequence has been recorded or loaded. ● <temp.avr> A reference sequence has been recorded but not saved. ● <name.avr>...
  • Page 110: Synchronization

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs Synchronization based on a time code in the images of the sequence. The time code is set under "TC Window Top, TC Window Bottom, TC Window Left, TC Win- dow Right" on page 111.
  • Page 111: Tc Window Top, Tc Window Bottom, Tc Window Left, Tc Window Right

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs Sets the allowed number of missing frames during recording. ● "0" to "9999" Use this function if the DUT skips frames during playback, which can happen if the CPU of the DUT cannot keep up with the decoding. This behavior can significantly extend the recording (learning) time, especially for long sequences.
  • Page 112 ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs Remote command: on page 544 CONFigure<hw>:AVDA:REFerence:COMMand Abort button Only available if recording has been started ("Learn" button). Stops recording (learning) without discarding of the results. To continue recording, proceed with "Learn button"...
  • Page 113: Edit Settings Dialog

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs 7.3.3 Edit Settings Dialog To open the "Edit Settings" dialog ► Click "Settings" in the common buttons pane (see Figure 7-1). The "Edit Settings" dialog is displayed. Restricted number of displayed status/result traces Up to 4 status traces can be displayed simultaneously.
  • Page 114 ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs <Measurement parameters table> To configure the measurements according to the following criteria, the table consists of the following columns: ● "Enable" Enables or disables the parameter display on the "List" tab. Chapter 7.6, "List Subtab", on page 124...
  • Page 115 ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs Remote command: "Visible Error" parameter (failure point measurement) on page 528 CONFigure<hw>:AVDA:LIST:FPOint:VERRor[:STATe] "Picture Failure Point" parameter (failure point measurement) on page 526 CONFigure<hw>:AVDA:LIST:FPOint:PICTure[:STATe] "Audio Failure Point" parameter (failure point measurement) on page 524 CONFigure<hw>:AVDA:LIST:FPOint:AUDio[:STATe] <Video parameters>...
  • Page 116 ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs on page 532 CONFigure<hw>:AVDA:LIST:PSNR:CR:AVERage "SSIM" parameter (video measurement) on page 542 CONFigure<hw>:AVDA:LIST:SSIM[:STATe] on page 541 CONFigure<hw>:AVDA:LIST:SSIM:LIMit on page 541 CONFigure<hw>:AVDA:LIST:SSIM:AVERage "Mos-V" parameter (video measurement) on page 530 CONFigure<hw>:AVDA:LIST:MOSV[:STATe] on page 530 CONFigure<hw>:AVDA:LIST:MOSV:LIMit "Rendering Rate"...
  • Page 117: Visible Error Definition Dialog

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs 7.3.4 Visible Error Definition Dialog To open the "Visible Error Definition" dialog 1. Click "Settings" in the common buttons pane (see Figure 7-1). The "Edit Settings" dialog is displayed. 2. Open the "Failure Point" parameter list. 3.
  • Page 118: Audio Failure Point Definition Dialog

    ® AV Distortion Analyzer Application R&S Common Buttons and Dialogs 7.3.6 Audio Failure Point Definition Dialog To open the "Audio Failure Point Definition" dialog 1. Click "Settings" in the common buttons pane (see Figure 7-1). The "Edit Settings" dialog is displayed. 2.
  • Page 119: Latency Settings Dialog

    Dark to bright or bright to dark transition of the average picture level (APL) of the incoming HDMI video signal ● Slope of a trigger signal that is connected to the trigger input of the R&S VTS The following settings define the trigger conditions. To open the "Latency Settings" dialog 1.
  • Page 120: Setting Options Dialog

    ® AV Distortion Analyzer Application R&S Input Subtab 7.3.10 Setting Options Dialog To open the "Setting Options" dialog 1. Click "Settings" in the common buttons pane (see Figure 7-1). The "Edit Settings" dialog is displayed. 2. Click "Options". Optional measurement parameters Optional settings to configure the measurement results.
  • Page 121 ® AV Distortion Analyzer Application R&S Input Subtab Input..........................121 External Sync......................122 Color..........................122 Picture Aspect Ratio....................122 <Input and reference signal parameters>..............122 └ Input column....................122 └ Reference column..................123 Input Sets the input signal for the measurement. The available input list is hardware-dependent. It depends on the type and number of installed modules.
  • Page 122 ® AV Distortion Analyzer Application R&S Input Subtab Remote command: on page 578 ROUTe<hw>:AVDA:MODule:CATalog? on page 579 ROUTe<hw>:AVDA:MODule:SELect External Sync. Only available if "Component" is set under "Input" on page 121. Determines whether an internal or external synchronization signal is used. ●...
  • Page 123: Detection Subtab

    ® AV Distortion Analyzer Application R&S Detection Subtab Reference column ← <Input and reference signal parameters> Displays the reference signal parameters. Only visible if the monitor view is hidden, "To show and hide the monitor view" on page 105. To configure the reference signal, click the "Set Ref.
  • Page 124: List Subtab

    ® AV Distortion Analyzer Application R&S List Subtab <Status>........................124 <Counter>........................124 <Status> Displays the status of the measurement. ● "Detection Running" The measurement has been started but synchronization to the reference has not yet taken place. ● "Detection Passed" The measurement has been started, and the reference was recognized. This infor- mation is preserved, even if the signal cannot be synchronized to the reference later on.
  • Page 125 ® AV Distortion Analyzer Application R&S List Subtab ► Use the buttons on the right of the tab to configure the measurement. Chapter 7.3, "Common Buttons and Dialogs", on page 107. <Measurement results table>..................125 └ <General results>..................125 └ <Failure point results>..................
  • Page 126 ® AV Distortion Analyzer Application R&S List Subtab on page 558 READ<hw>[:SCALar]:AVDA:LIST:CNUMber? on page 559 READ<hw>[:SCALar]:AVDA:LIST:CTIMe? <Failure point results> ← <Measurement results table> Groups the results of the failure point measurement. Remote command: on page 561 READ<hw>[:SCALar]:AVDA:LIST:FPOint:VERRor? on page 561 READ<hw>[:SCALar]:AVDA:LIST:FPOint:PICTure? on page 560 READ<hw>[:SCALar]:AVDA:LIST:FPOint:AUDio?
  • Page 127: Trace Subtab

    ® AV Distortion Analyzer Application R&S Trace Subtab 7.7 Trace Subtab Shows the progress of the measurement results over time. If visible, the monitor view is displayed in the left pane, see Chapter 7.2, "Monitor View", on page 104. The total number of simultaneously displayed status/result traces is restricted, see "Restricted number of displayed status/result traces"...
  • Page 128 ® AV Distortion Analyzer Application R&S Trace Subtab <Status trace>......................128 <Result trace>......................128 <Status trace> Shows the measurement result status over time as a colored bar. In the Chapter 7.3.3, "Edit Settings Dialog", on page 113, select the measurement results of which you want to display the status.
  • Page 129: Log Subtab

    ® AV Distortion Analyzer Application R&S Log Subtab Icon Go to Next preceding cycle with limit violation Next succeeding cycle with limit violation Cycle succeeding the currently displayed cycle Cycle that is measured The storage depth is limited to approximately an hour measuring, then the older results are overwritten.
  • Page 130 ® AV Distortion Analyzer Application R&S Log Subtab Save Log button......................130 Hold button........................131 Continue button......................131 <Measured data list> Each row represents a frame. 3 parameters are always displayed to define the frame exactly. ● "hh:mm:ss" Time when the frame was measured. ●...
  • Page 131 ® AV Distortion Analyzer Application R&S Log Subtab The file name is composed as follows: distortion_analyzer_log_jjjj-mm-dd_hh-mm-ss.csv Example: distortion_analyzer_log_2013-09-05_09-07-15.csv Note: In the list, only the data of the last 1000 frames are displayed. But in the CSV files, all measured data is saved. Remote command: on page 549 MMEMory<hw>:AVDA:LOG:DATA:SAVE...
  • Page 132: Video Analyzer Application

    ® Video Analyzer Application R&S Input Subtab 8 Video Analyzer Application Requires the following options: ● Video analyzer option (R&S VT-K2100) ● Suitable module as described in the data sheet, see also "Input" on page 135 8.1 Main Dialog of the Application The parameters are grouped on tabs.
  • Page 133 ® Video Analyzer Application R&S Input Subtab Signal.......................... 133 Resolution........................133 Video Standard......................133 Averaging Level......................134 Freeze......................... 134 Average........................134 Quantization........................ 134 Quantization Range....................134 Component Format..................... 135 Picture Aspect Ratio....................135 Input..........................135 External Sync......................136 Signal Displays the status of selected video analyzer input. ●...
  • Page 134: Signal

    ® Video Analyzer Application R&S Input Subtab Displays the video standard (BG Pal, M/NTSC, ...) of the measured input signal. Remote command: on page 653 READ<hw>[:SCALar]:VIDeo:STANdard? Averaging Level If averaging is enabled under "Average" on page 134, displays the current averaging level.
  • Page 135: Component Format

    ® Video Analyzer Application R&S Input Subtab Quantization Signal Full range Limited range Cb,Cr 0 to 1023 64 to 960 12 bit R,G,B,Y 0 to 4095 256 to 3760 Cb,Cr 0 to 4095 256 to 3840 16 bit R,G,B,Y 0 to 65535 4096 to 60160 Cb,Cr 0 to 65535...
  • Page 136: Scope Subtab

    ® Video Analyzer Application R&S Scope Subtab Component input signal Required hardware option: analog A/V RX module (R&S VT-B2370). ● "HDMI" [<module slot>] HDMI input signal Required hardware option, one of the following: – HDMI RX 225 MHz module (R&S VT-B2360) –...
  • Page 137 ® Video Analyzer Application R&S Scope Subtab <Chart display>......................137 └ Single waveform chart.................. 138 └ Parade waveform chart.................138 └ Overlay waveform chart................139 └ Overlay sync waveform chart................139 View..........................139 Line..........................140 Field..........................140 X..........................140 Settings Trace dialog....................140 └ Rescale......................140 └...
  • Page 138 ® Video Analyzer Application R&S Scope Subtab CONFigure<hw>:SCOPe:TRACe:CURSor<cursor>:X:LPOSition:PIXel on page 598 CONFigure<hw>:SCOPe:TRACe:CURSor<cursor>:X:LPOSition:TIME on page 598 Single waveform chart ← <Chart display> Parade waveform chart ← <Chart display> Shows all three component signals (YCbCr or RGB) side by side simultaneously. Dia- gram interactions such as scaling or moving the cursors affect all three displays simi- larly.
  • Page 139: Parade Waveform Chart

    ® Video Analyzer Application R&S Scope Subtab Overlay waveform chart ← <Chart display> Shows all 3 component signals (YCbCr or RGB) top down simultaneously. Diagram interactions such as scaling or moving the cursors affect all three displays similarly. Overlay sync waveform chart ← <Chart display> Shows all 3 component signals (YCbCr or RGB) top down simultaneously, and a binary display of the external sync signals, H-SYNC and V-SYNC.
  • Page 140: Overlay Waveform Chart

    ® Video Analyzer Application R&S Scope Subtab "Overlay waveform chart" on page 139. ● "Overlay Sync" Only available if "On" is set under "External Sync" on page 136. "Overlay sync waveform chart" on page 139. Remote command: on page 642 DISPlay<hw>[:WINDow]:SCOPe:TRACe:SELect on page 648 READ<hw>:ARRay:SCOPe:TRACe?
  • Page 141: C1, C2

    ® Video Analyzer Application R&S Scope Subtab Displays one video line. ● "2 Lines" Displays two video lines. ● "1st Field" Displays the complete 1 video field. Only available for interlaced video input sig- nals. ● "2nd Field" Displays the complete 2 video field.
  • Page 142: Vector Subtab

    ® Video Analyzer Application R&S Vector Subtab Span Only available if "Slope" is set under "C1, C2" on page 141. Sets the span. Remote command: on page 642 DISPlay<hw>[:WINDow]:SCOPe:TRACe:X:LPOSition:PIXel on page 643 DISPlay<hw>[:WINDow]:SCOPe:TRACe:X:LPOSition:TIME CONFigure<hw>:SCOPe:TRACe:CURSor<cursor>:X:LPOSition:PIXel on page 598 CONFigure<hw>:SCOPe:TRACe:CURSor<cursor>:X:LPOSition:TIME on page 598 8.4 Vector Subtab Divided into the graph pane and parameter pane.
  • Page 143 ® Video Analyzer Application R&S Vector Subtab Cursor Line / Pos......................145 Gain..........................145 Phase.......................... 145 <Measurement results table> The cursor measured results are the chrominance amplitude, the chrominance phase and the associated luminance level. Only if the Component/PAL standard is selected, there are pairs of measurement values (V+ and V-) for the chrominance amplitude, the chrominance phase and the associated luminance level.
  • Page 144 ® Video Analyzer Application R&S Vector Subtab Figure 8-2: Vector diagram, PAL standard The vector diagram graphically displays the color information, magnitude and phase of one measured video line. The endpoints of all color vectors in the diagram are joined by line.
  • Page 145: Auto Subtab

    ● "7MH108 Analog Composite Video Analysis" ● "7MH107 Analog Component Video Analysis" Application notes for the R&S VTS are provided on the Rohde & Schwarz Home Page under http://www.rohde-schwarz.com/applications/vtc_vte_vts. To configure the displayed measurement results 1. Click "Settings". The "Auto and Measurement Settings" dialog is displayed.
  • Page 146 ® Video Analyzer Application R&S Auto Subtab <Measurement results table>..................147 └ [+] All button....................148 └ [-] All button....................148 └ Value column....................148 └ Unit column....................148 └ Lower Limit column..................148 └ Upper Limit column..................148 └ Status column....................148 └...
  • Page 147 ® Video Analyzer Application R&S Auto Subtab <Parameter configuration dialog>................153 └ Test Signal....................154 └ Test Line......................154 └ Line Counter....................154 └ Location Unit....................155 └ Location table....................155 └ Bandwidth (composite inputs)...............156 └ Bandwidth (component and digital inputs)............ 156 └...
  • Page 148 ® Video Analyzer Application R&S Auto Subtab ● "Timing" Chapter 14.4.2.6, "Timing (Component, HDMI, MHL Input Signal)", on page 594 ● "Jitter" Chapter 14.4.2.7, "Jitter (Component, HDMI, MHL Input Signal)", on page 594 Remote command: Chapter 14.4.10.3, "READ<hw>[:SCALar]:VIDeo:MEASure Subsystem", on page 654 [+] All button ←...
  • Page 149 ® Video Analyzer Application R&S Auto Subtab Save button Opens a dialog box to save the current measurement results in a CSV file. You can define a separator on the "Extras tab" on page 152. Remote command: on page 646 MMEMory<hw>:VIDeo:MEASure:RESult:NTSC:STORe on page 646 MMEMory<hw>:VIDeo:MEASure:RESult:PAL:STORe...
  • Page 150 ® Video Analyzer Application R&S Auto Subtab Figure 8-5: Example for composite input Remote command: Chapter 14.4.6.3, "CONFigure<hw>:VIDeo:MEASure Subsystem", on page 601 <Settings table> ← Auto and Measurement Settings dialog Contains all available parameters grouped by key issues, as in the "<Measurement results table>"...
  • Page 151 ® Video Analyzer Application R&S Auto Subtab Lower Limit column ← <Settings table> ← Auto and Measurement Settings dia- Sets the lower limit for monitoring the individual parameter. Remote command: Depends on the parameter group and the video standard: CONFigure<hw>:VIDeo:MEASure:<parameter group>:<video standard>: LIMit:LOWer Chapter 14.4.6.3, "CONFigure<hw>:VIDeo:MEASure Subsystem",...
  • Page 152 ® Video Analyzer Application R&S Auto Subtab Digits of a full range digital signal with the corresponding number of bits. Only used for HDMI, MHL input (digital signal). ● "LRange8", "LRange10", "LRange12", "LRange16" Digits of a limited range digital signal with the corresponding number of bits. Only used for HDMI, MHL input (digital signal).
  • Page 153 ® Video Analyzer Application R&S Auto Subtab Decimal Separator in csv File ← Extras tab ← Auto and Measurement Settings dialog Defines the separator used in the CSV file. Select the column delimiter and decimal separator. ● "Comma" Separates the decimal places by commas and the columns by semicolons. ●...
  • Page 154 ® Video Analyzer Application R&S Auto Subtab Test Signal ← <Parameter configuration dialog> Each parameter needs a defined test signal. See Chapter 14.4.3, "Test Signals", on page 595. Remote command: Depends on the parameter group and the video standard. See Chapter 14.4.3, "Test Signals", on page 595.
  • Page 155 ® Video Analyzer Application R&S Auto Subtab Line number referred to the frame including the V-blanking area. Note: For composite input (NTSC and PAL standards), only the "Full Field" line count- ing mode is used (see above). Remote command: on page 609 CONFigure<hw>:VIDeo:MEASure:COMPonent:ANALog:CLINe on page 609 CONFigure<hw>:VIDeo:MEASure:COMPonent:DIGital:CLINe...
  • Page 156 ® Video Analyzer Application R&S Auto Subtab on page 644 INITiate<hw>:VIDeo:MEASure:LOCation? Querying the number of valid locations: READ<hw>[:SCALar]:VIDeo:MEASure:TSIGnal:LOCation:COUNt? on page 662 Positioning the location cursor: CONFigure<hw>:VIDeo:MEASure:TSIGnal:LOCation:CURSor<line>:CENTer on page 637 CONFigure<hw>:VIDeo:MEASure:TSIGnal:LOCation:CURSor<line>:SPAN on page 637 Querying the name of the location where the cursor is positioned: READ<hw>[:SCALar]:VIDeo:MEASure:TSIGnal:LOCation:CURSor<line>: on page 663 NAME?
  • Page 157 ® Video Analyzer Application R&S Auto Subtab Applies a weighting curve. ● "Default (NTC7)" ● "Unified (CCIR)" Remote command: on page 630 CONFigure<hw>:VIDeo:MEASure:NOISe:NTSC:WEIGhting User Manual 2116.1228.02 ─ 14...
  • Page 158: Audio Analyzer Application

    ® Audio Analyzer Application R&S Input Subtab 9 Audio Analyzer Application Requires the following options: ● Audio analyzer option (R&S VT-K2150) ● Suitable hardware option as described in the data sheet, see also "Input" on page 160 The audio analyzer application provides a suite of tools for measuring audio perfor- mance and quality.
  • Page 159 ® Audio Analyzer Application R&S Input Subtab Wave Display Configuration..................159 └ Zoom......................159 Audio Hardware Configuration..................160 └ Input......................160 └ Monitor......................160 └ Impedance....................160 └ Coupling......................161 Measurements Values....................161 └ Channel Count....................161 └ Sample Rate....................161 └ Sample Format.....................
  • Page 160 ® Audio Analyzer Application R&S Input Subtab Remote command: on page 685 DISPlay<hw>:AUDio:WAVeform:ZOOM Audio Hardware Configuration Provides details of the audio input devices available. Input ← Audio Hardware Configuration Sets the input signal. The available input list is hardware-dependent. It depends on the type and number of installed modules.
  • Page 161 ® Audio Analyzer Application R&S Input Subtab Sets the impedance of both analog audio inputs. ● 100 kΩ ● 600 Ω Remote command: on page 680 CONFigure<hw>:AUDio:INPut:IMPedance Coupling ← Audio Hardware Configuration Only available if "Analog L/R" is set under "Input"...
  • Page 162 ® Audio Analyzer Application R&S Input Subtab Remote command: on page 703 READ<hw>[:SCALar]:AUDio:SAMPle:FORMat? Analog/Digital Reference Unit Sets the reference units that allow to display the measurement results in units relative to a user-defined set of reference values. Table 9-1: Explanation of reference units available Unit Analog input Digital input...
  • Page 163: Status Subtab

    ® Audio Analyzer Application R&S Ch. Status Subtab Remote command: Analog input devices: SENSe<hw>:AUDio:REFerence:ANALog:OFFSet:DBRB on page 753 Digital input devices: SENSe<hw>:AUDio:REFerence:DIGital:OFFSet:DBRB on page 755 dBSPL1 Reference ← Analog/Digital Reference Unit Sets the reference level for measuring the sound pressure level. Remote command: Analog input devices: SENSe<hw>:AUDio:REFerence:ANALog:DBSPl<source>...
  • Page 164 ® Audio Analyzer Application R&S Ch. Status Subtab Channel Status Mode....................165 <Results table>......................165 └ Alignment Level.................... 165 └ Audio Mode....................165 └ Category Code....................166 └ Channel Destination..................166 └ Channel Mode....................166 └ Channel Number...................167 └ Channel Status Mode................... 167 └ Clock Accuracy.....................
  • Page 165 ® Audio Analyzer Application R&S Ch. Status Subtab └ User Bits Management................. 172 └ Valid Flag...................... 172 └ Word Length....................172 Channel Status Mode The mode is selected automatically. ● "Consumer" ● "Professional" Only available for S/PDIF sources Depending on the mode, the available analyzer results change in the "<Results table>"...
  • Page 166 ® Audio Analyzer Application R&S Ch. Status Subtab Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:AUDiomode? on page 704 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA: on page 707 AUDiomode? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: on page 714 AUDiomode? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 720 AUDiomode? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 722 AUDiomode? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 737 VALidity:AUDiomode? Category Code ← <Results table> Only available if "Consumer"...
  • Page 167 ® Audio Analyzer Application R&S Ch. Status Subtab Channel Number ← <Results table> Available for both channel status modes. Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:CHANnel? on page 705 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA: on page 707 CHANnel? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: on page 715 CHANnel? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 721 CHNumber? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 723 CHNumber?
  • Page 168 ® Audio Analyzer Application R&S Ch. Status Subtab Cyclic Redundancy Check Character ← <Results table> Only available if "Professional" is displayed under "Channel Status Mode" on page 165. Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 722 CRCFlag? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 724 CRCFlag? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 738 VALidity:CRCFlag?
  • Page 169 ® Audio Analyzer Application R&S Ch. Status Subtab Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:LOCK? on page 732 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 725 LOCK? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 740 VALidity:LOCK? Maximum Word Length ← <Results table> Only available if "Consumer" is displayed under "Channel Status Mode" on page 165.
  • Page 170 ® Audio Analyzer Application R&S Ch. Status Subtab Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 733 MCNumber? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 726 MCNumber? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 741 VALidity:MCNumber? Origin Data ← <Results table> Only available if "Professional" is displayed under "Channel Status Mode" on page 165.
  • Page 171 ® Audio Analyzer Application R&S Ch. Status Subtab Reference Signal ← <Results table> Only available if "Professional" is displayed under "Channel Status Mode" on page 165. Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 734 REFSignal? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 727 REFSignal? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 742 VALidity:REFSignal? Sampling Frequency ←...
  • Page 172 ® Audio Analyzer Application R&S Ch. Status Subtab Time of Day ← <Results table> Only available if "Professional" is displayed under "Channel Status Mode" on page 165. Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 736 TODaddress? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 729 TODaddress? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 744 VALidity:TODaddress? Use of Auxiliary Bits ←...
  • Page 173: Level Subtab

    ® Audio Analyzer Application R&S Level Subtab Remote command: READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:WLENgth? on page 719 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA: on page 711 WLENgth? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: on page 719 WLENgth? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 745 WLENgth? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: on page 730 WLENgth? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: on page 745 VALidity:WLENgth? 9.4 Level Subtab This measurement provides a continuous real-time measurement of the RMS, quasi- peak and peak level of the incoming audio data.
  • Page 174 ® Audio Analyzer Application R&S Level Subtab <Channel table>......................174 └ <Measurement selector>................174 └ <Unit selector>....................174 └ Frequency ....................175 Filter..........................175 └ Filter Configuration dialog................175 Averaging button......................176 └ Level Averaging Config dialog..............176 └ Average....................176 └ Algorithm.....................176 └...
  • Page 175 ® Audio Analyzer Application R&S Level Subtab Unit Description "dBSPL2" Decibels relative to second analog sound pressure reference level "Vpp" Volts pp referenced to Volts RMS The Vpp value is calculated from the RMS voltage level and is valid for sine wave signals only.
  • Page 176 ® Audio Analyzer Application R&S Level Subtab The available filters are described in Chapter 9.11, "Weighting Filters", on page 196. Remote command: on page 750 SENSe<hw>:AUDio:LEVel:FILTer<Index> Averaging button Only available if measurement is stopped and "RMS" is selected under "<Measure- ment selector>"...
  • Page 177 ® Audio Analyzer Application R&S Level Subtab Sets the period used to calculate the median. ● "0 s" to "10 s" Default value: 0.01 s. Remote command: on page 675 CALCulate<hw>:AUDio:LEVel:AVERage:SETTling:TIME Tolerance ← Level Averaging Config dialog ← Averaging button Only available if "Flat"...
  • Page 178: Thd+N Subtab

    ® Audio Analyzer Application R&S THD+N Subtab 9.5 THD+N Subtab This measurement provides a continuous realtime measurement of the total harmonic distortion plus noise for each of the channels of incoming audio. In addition to the THD +N results, the RMS level and the detected fundamental frequency of each channel are also displayed.
  • Page 179 ® Audio Analyzer Application R&S THD+N Subtab <Channel table> For each channel, the parameters are displayed. The background color of the channel cell matches the color of the corresponding bar in the bar chart. Remote command: on page 747 READ<hw>[:SCALar]:AUDio:THDN:MEASure:VALue? THD+N ←...
  • Page 180: Freq. Resp. Subtab

    ® Audio Analyzer Application R&S Freq. Resp. Subtab Averaging button Opens the dialog to configure the averaging functions. See "Level Averaging Config dialog" on page 176. Remote command: on page 677 CALCulate<hw>:AUDio:THDN:AVERage:STATe on page 677 CALCulate<hw>:AUDio:THDN:AVERage:ALGorithm on page 677 CALCulate<hw>:AUDio:THDN:AVERage:TIME on page 677 CALCulate<hw>:AUDio:THDN:AVERage:SETTling:TIME on page 677...
  • Page 181: Fft Spectrum Measurement Mode

    ® Audio Analyzer Application R&S Freq. Resp. Subtab Mode Sets the measurement mode. ● "FFT Spectrum" Chapter 9.6.2, "FFT Spectrum Measurement Mode", on page 181. ● "Frequency Sweep" Chapter 9.6.3, "Frequency Sweep Measurement Mode", on page 183. Remote command: on page 673 CALCulate<hw>:AUDio:FRESponse:MODE Filter "Filter"...
  • Page 182 ® Audio Analyzer Application R&S Freq. Resp. Subtab <Chart display>......................182 <Channel table>......................182 Size........................182 Average Count......................183 <Chart display> Displays the results of the FFT. Each enabled input channel is plotted separately. Remote command: on page 691 READ<hw>:ARRay:AUDio:FRESponse:TRACe? <Channel table> The background color of the channel cell matches the color of the corresponding trace.
  • Page 183: Frequency Sweep Measurement Mode

    ® Audio Analyzer Application R&S Freq. Resp. Subtab Average Count Sets the number of FFT measurements to be averaged for the chart display. A high average count setting, especially when combined with large FFT sizes, can result in long delays before the chart display updates. ●...
  • Page 184 ® Audio Analyzer Application R&S Freq. Resp. Subtab <Chart display> Displays the chart for the selected measurement. Select the measurement and the dis- played channel traces under "Graphics column" on page 184. The measured values are displayed over the detected frequencies of each incoming audio data channel.
  • Page 185: Snr Subtab

    ® Audio Analyzer Application R&S SNR Subtab Remote command: on page 694 READ<hw>[:SCALar]:AUDio:DIPHase:MEASure:VALue? on page 750 SENSe<hw>:AUDio:IPHase:UNIT Cursor Defines the position on the x-axis of the displayed measurement values. The exact cur- sor position is displayed in the field. Use the arrow keys to shift the position of the cursor or enter a value. If you enter a new frequency value that does not match a valid frequency of the current measure- ment, the value is adjusted accordingly.
  • Page 186 ® Audio Analyzer Application R&S SNR Subtab <Channel table>......................186 └ SNR......................186 Signal Length......................186 Noise Length....................... 187 Filter..........................187 Stop button........................187 Start button........................187 <Channel table> For each channel, the parameters are displayed. The background color of the channel cell matches the color of the corresponding bar in the bar chart. SNR ←...
  • Page 187: Crosstalk Subtab

    ® Audio Analyzer Application R&S Crosstalk Subtab Remote command: on page 684 CONFigure<hw>:AUDio:SNR:SLENgth Noise Length Sets the noise length that is analyzed for each cycle. If this setting does not match the test signal of the DUT, the results are inaccurate. ●...
  • Page 188 ® Audio Analyzer Application R&S Crosstalk Subtab <Channel table>......................188 └ Crosstalk....................... 188 └ Level....................189 └ Frequency..................... 189 Reference Channel..................... 189 Filter..........................189 Averaging button......................189 Stop button........................189 Start button........................189 <Channel table> For each channel, the parameters are displayed. The background color of the channel cell matches the color of the corresponding bar in the bar chart.
  • Page 189: Phase Subtab

    ® Audio Analyzer Application R&S Ch. Phase Subtab Remote command: on page 749 SENSe<hw>:AUDio:CROSstalk:UNIT RMS Level ← <Channel table> "<Unit selector>" on page 174. Frequency ← <Channel table> "Frequency " on page 175. Reference Channel Sets the signal source channel. Remote command: on page 678 CONFigure<hw>:AUDio:CROSstalk:REFerence...
  • Page 190 ® Audio Analyzer Application R&S Ch. Phase Subtab Remote command to query measurement progress on page 696 READ<hw>[:SCALar]:AUDio:IPHase:COMMand:PROGress? <Channel table>......................190 └ Phase......................190 └ Level....................191 └ Frequency..................... 191 Reference Channel..................... 191 Filter..........................191 Averaging button......................191 Stop button........................191 Start button........................191 <Channel table>...
  • Page 191: Quality Subtab

    ® Audio Analyzer Application R&S Quality Subtab Remote command: on page 750 SENSe<hw>:AUDio:IPHase:UNIT RMS Level ← <Channel table> "<Unit selector>" on page 174. Frequency ← <Channel table> "Frequency " on page 175. Reference Channel Sets the channel whose phase is used as the reference phase. Remote command: on page 681 CONFigure<hw>:AUDio:IPHase:REFerence...
  • Page 192 ® Audio Analyzer Application R&S Quality Subtab Measure Type......................192 Channel........................193 <Test report>....................... 193 Save button......................... 193 Score........................193 Calibrate button......................193 └ Calibration dialog..................193 └ Capture....................194 └ Gain..................194 └ Delay..................194 └ Auto Gain..................194 └ Auto Delay................194 └...
  • Page 193: Channel

    ® Audio Analyzer Application R&S Quality Subtab ● "POLQA - Narrow" Requires the listening quality analysis POLQA option (R&S VT-K2159) Perceptual objective listening quality assessment (POLQA) is a test for the speech quality as perceived by a listener. POLQA has additional handling for variable delays.
  • Page 194: Capture

    ® Audio Analyzer Application R&S Quality Subtab Capture ← Calibration dialog ← Calibrate button Groups the calibration parameters of the captured audio. Gain ← Capture ← Calibration dialog ← Calibrate button Only available if the auto gain is disabled, see "Auto Gain"...
  • Page 195: Stop Button

    ® Audio Analyzer Application R&S Quality Subtab Remote command: on page 698 READ<hw>[:SCALar]:AUDio:QC:COMMand:STATe? on page 698 READ<hw>[:SCALar]:AUDio:QC:COMMand:PROGress? Stop button "Stop button" on page 177. Start button "Start button" on page 177. <Graph pane> The graph pane on the left provides two displays. <Results graphs>...
  • Page 196: Weighting Filters

    700 READ<hw>[:SCALar]:AUDio:QC:REFerence:VALFile? 9.11 Weighting Filters In addition to the user-definable filters, the R&S VTS also offers many weighting filters which conform to the relevant standards. A Weighting Standards: DIN 45412, DIN 45633, IEC 179, IEC 651, ANSI S1.4 Application: weighted noise measurement User Manual 2116.1228.02 ─...
  • Page 197 ® Audio Analyzer Application R&S Weighting Filters Figure 9-1: A weighting filter C Message Standard: IEEE 743-1995 Application: weighted noise measurement Figure 9-2: C message filter CCITT Standards: ITU-T Rec. O.41, CISPR 6-76, ITU-T Rec. P.53 Application: psophometrical weighting User Manual 2116.1228.02 ─ 14...
  • Page 198 ® Audio Analyzer Application R&S Weighting Filters Figure 9-3: CCITT filter CCIR 1k /ITU468 Standard: ITU-R BS.468-4 Application: quasi-peak measurement CCIR 2k Standard: ITU-R BS.468-4, but with 0 dB gain point at 2 kHz User Manual 2116.1228.02 ─ 14...
  • Page 199 ® Audio Analyzer Application R&S Weighting Filters De-Emphasis 50 15 Standard: CCIR Rec. 651 Application: compact disc Figure 9-4: De-emphasis 50 15 filter De-Emphasis 50 Standard: ARD Spec. 5/3.1 User Manual 2116.1228.02 ─ 14...
  • Page 200 ® Audio Analyzer Application R&S Weighting Filters Application: weighted noise measurement Figure 9-5: De-emphasis 50 filter De-Emphasis 75 Standard: ARD Spec. 5/3.1 Application: weighted noise measurement Figure 9-6: De-emphasis 75 filter IEC Tuner Standard: DIN/IEC 60315-4 Application: measurements on FM tuners User Manual 2116.1228.02 ─...
  • Page 201 ® Audio Analyzer Application R&S Weighting Filters Figure 9-7: IEC tuner filter JITTW Standard: AES 3 Application: weighting of jitter transmission function 1st order HP -3 dB at 700 Hz -20 dB at 70 Hz Figure 9-8: JITTW filter Pre-Emphasis 50 15 Standard: CCIR Rec.
  • Page 202 ® Audio Analyzer Application R&S Weighting Filters Figure 9-9: Pre-emphasis 50 15 filter Pre-Emphasis 50 Standard: ARD Spec. 5/3.1 Application: weighted noise measurement Figure 9-10: Pre-emphasis 50 filter Pre-Emphasis 75 Standard: ARD Spec. 5/3.1 Application: weighted noise measurement User Manual 2116.1228.02 ─ 14...
  • Page 203: Suitable Test Signals And Procedures

    ® Audio Analyzer Application R&S Suitable Test Signals and Procedures Figure 9-11: Pre-emphasis 75 filter HPF 22 Hz High-pass with 3 dB cutoff frequency at 22 Hz HPF 400 Hz High-pass with 3 dB cutoff frequency at 400 Hz LPF 22 kHz Lowpass with 3 dB cutoff frequency at 22 kHz LPF 30 kHz Lowpass with 3 dB cutoff frequency at 30 kHz...
  • Page 204: Level Measurement

    ® Audio Analyzer Application R&S Suitable Test Signals and Procedures For other levels, you can either use a signal generator with volume control or create additional test files. Analog input DUT Excessive signal levels can damage the equipment. Refer to the DUT specifications for information on MOL and NOL.
  • Page 205: Thd+N Measurement

    ® Audio Analyzer Application R&S Suitable Test Signals and Procedures The maximum and minimum levels are recorded and compared to the 1 kHz level to give the ±dB levels quoted. Tip: A longer sweep time yields more accurate the results. 9.12.2 THD+N Measurement The parameters are described in Chapter 9.5, "THD+N...
  • Page 206: Frequency Response Measurement

    ® Audio Analyzer Application R&S Suitable Test Signals and Procedures 9.12.3 Frequency Response Measurement The parameters are described in Chapter 9.6, "Freq. Resp. Subtab", on page 180. Perform this test with a swept tone. The start and stop frequencies depend on the DUT specifications.
  • Page 207: Crosstalk Measurement

    ® Audio Analyzer Application R&S Suitable Test Signals and Procedures The period of sine component can be 1 s, 2 s, 3 s, 4 s, or 5 s long. Likewise, the silence section can be 1 s, 2 s, 3 s, 4 s, or 5 s long. Longer periods give more accurate results.
  • Page 208: Hdmi Applications

    ® HDMI Applications R&S HDMI Generator Application 10 HDMI Applications ● HDMI Generator Application................. 208 ● HDMI Analyzer Application................... 274 ● CEC/DDC Analyzer Application................325 ● Content and Codes....................339 10.1 HDMI Generator Application Requires the following options: ● Suitable module as described in the data sheet See also "Module (default favorite)"...
  • Page 209: Output Subtab

    ® HDMI Applications R&S HDMI Generator Application Module (default favorite) Selects the module that is used for HDMI analysis. The available input list is hardware-dependent. It depends on the type and number of installed modules. ● "Tx 300MHz" HDMI TX 300 MHz module (R&S VT-B360) ●...
  • Page 210 B360) provides 4 outputs. ● "On" ● "Off" Note: To indicate the output at your R&S VTS, click "Indicate". A flashing LED indicates the output until you click "OK". Remote command: on page 821 CONFigure<hw>:HDGenerator:OUTPut:HDMiout<port> HDMI Out (HDMI CTS RX/TX 600 MHz module) Only available if "CTS Rx/Tx 600MHz"...
  • Page 211 B2363) provides one output. ● "On" ● "Off" Note: To indicate the output at your R&S VTS, click "Indicate". A flashing LED indicates the output until you click "OK". Remote command: on page 821 CONFigure<hw>:HDGenerator:OUTPut:HDMiout<port> Enable 5V (HDMI RX/TX 600 MHz module) Only available if "Rx/Tx 600MHz"...
  • Page 212 ® HDMI Applications R&S HDMI Generator Application – "VESA Code" is set under "Video Code" on page 216 – "DVI" is set under "Signaling Mode" on page 217 Remote command: on page 820 CONFigure<hw>:HDGenerator:OUTPut:HDCPout<port> Scrambling Determination (HDMI RX/TX 600 MHz module) Only available if "Rx/Tx 600MHz"...
  • Page 213: Signal Subtab

    ® HDMI Applications R&S HDMI Generator Application 10.1.3 Signal Subtab Only available if "Tx 300MHz" or "Rx/Tx 600MHz" is set under "Module (default favor- ite)" on page 209. Defines the video/audio signal and the signal properties. Additional options required Using files that contain more than 1 frame requires the HDMI moving pictures option (R&S VT-K361).
  • Page 214 ® HDMI Applications R&S HDMI Generator Application └ Aspect Ratio....................216 Video Configuration.....................217 └ Video Configuration dialog................217 └ Component Format................217 └ Signaling Mode................... 217 └ Quantization Range................217 └ Deep Color..................217 └ Pixelshift Vertical.................217 └ Vertical....................218 └ Pixelshift Horizontal................218 └...
  • Page 215 840 CONFigure<hw>:HDGenerator:SIGNal:NOBLack General ← Content Selection dialog ← Content Selection Selects either content from the designated R&S VTS directory or another location. All Signals ← General ← Content Selection dialog ← Content Selection Displays all available signals. File ← General ← Content Selection dialog ← Content Selection Opens the "File"...
  • Page 216 ® HDMI Applications R&S HDMI Generator Application EBU Signals ← Libraries ← Content Selection dialog ← Content Selection For future use only. HDR Signals ← Libraries ← Content Selection dialog ← Content Selection Displays all available high dynamic range (HDR) signals, see Chapter 10.4.2, "HDR Signals", on page 342.
  • Page 217 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 839 CONFigure<hw>:HDGenerator:SIGNal:ASPRatio Video Configuration Click to open the "Video Configuration" dialog, see "Video Configuration dialog" on page 217. In gray color, the most important settings of the video configuration are displayed. Video Configuration dialog ←...
  • Page 218 ® HDMI Applications R&S HDMI Generator Application ● "Off" Remote command: on page 837 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:PIXVertical Vertical ← Video Configuration dialog ← Video Configuration Sets the scroll velocity and direction. ● "-63 Lines/Frame" to "63 Lines/Frame" The sign defines the scroll direction: Positive values move the image upwards, negative values move the image downwards.
  • Page 219 ® HDMI Applications R&S HDMI Generator Application Note: This setting only affects the video signal. It has no impact on the setting of the HDMI interface. Example: If a 12-bit signal is selected and the resolution clipping is set to 8 bit, the signal is transmitted as a 12-bit signal, but the lower 4 bits of the signal are set to 0.
  • Page 220 ® HDMI Applications R&S HDMI Generator Application Y Level, C Level, C Level ← Video Configuration dialog ← Video Configu- ration Only available if "YCbCr 4:4:4", "YCbCr 4:2:2" or "YCbCr 4:2:0" is set under "Compo- nent Format" on page 217. Sets the individual variation of the signal components amplitude.
  • Page 221 ® HDMI Applications R&S HDMI Generator Application Audio Configuration Click to open the "Audio Configuration" dialog, see "Audio Configuration dialog" on page 221. In gray color, the most important settings of the audio configuration are displayed. Audio Configuration dialog ← Audio Configuration Groups the parameters to configure the audio signal.
  • Page 222 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 825 CONFigure<hw>:HDGenerator:SIGNal:AUDConf:RESolution Channel Allocation (hex) ← Audio Configuration dialog ← Audio Configuration Only available if "Generator" is set under "Audio" on page 221. Specifies the speaker allocation. ● "00" to "31" Successive abbreviations (see Table 10-7).
  • Page 223 ® HDMI Applications R&S HDMI Generator Application Pause button Only available if a signal is being played or the play was stopped. Pauses playing the signal selected under "Content Selection" on page 215. Remote command: on page 839 CONFigure<hw>:HDGenerator:SIGNal:COMMand on page 860 READ<hw>:HDGenerator:SIGNal:STATus? Resolution dialog Sets the resolution in the format filter.
  • Page 224 ® HDMI Applications R&S HDMI Generator Application H. Total Pixels ← User Defined tab ← Resolution dialog Displays the number of horizontal total pixels, calculated as follows: "H. Active Pixels" + "H. Blanking Pixels" Remote command: on page 861 READ<hw>:HDGenerator:SIGNal:VICD:CUSTom:HTOPixel? H.
  • Page 225: Hdcp Subtab

    ® HDMI Applications R&S HDMI Generator Application Remote command: on page 830 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:VBPorch V. Blanking Lines ← User Defined tab ← Resolution dialog Displays the number of vertical blanking lines. Remote command: on page 861 READ<hw>:HDGenerator:SIGNal:VICD:CUSTom:VBLank? V. Total Lines ← User Defined tab ← Resolution dialog Displays the number of vertical total lines.
  • Page 226 ® HDMI Applications R&S HDMI Generator Application HDCP Mode........................ 226 HDCP State.........................226 Re-Authentication button.....................226 <HDCP version 1.4 parameters>................227 └ AKSV......................227 └ BKSV......................227 └ Ri'........................227 └ An........................227 <HDCP version 2.2 parameters>................227 └ r(rx)....................... 227 └ r(tx)........................227 └ r(n)........................ 227 └...
  • Page 227 ® HDMI Applications R&S HDMI Generator Application <HDCP version 1.4 parameters> Only available if: ● Output signal complies with HDCP version 1.4. ● "On" is set under "HDCP (HDMI RX/TX 600 MHz module)" on page 211 AKSV ← <HDCP version 1.4 parameters> Displays the key selection vector of the transmitter.
  • Page 228: Infoframe Subtab

    ® HDMI Applications R&S HDMI Generator Application Remote command: on page 848 READ<hw>:HDGenerator:HDCP:H? L ← <HDCP version 2.2 parameters> Displays the locality check hash value calculated by the receiver of the locality check. Remote command: on page 848 READ<hw>:HDGenerator:HDCP:L? 10.1.5 InfoFrame Subtab Only available if "Tx 300 MHz"...
  • Page 229 ® HDMI Applications R&S HDMI Generator Application └ Component Format..................232 └ Active Format Information Present............... 232 └ Info......................233 └ Scan Information...................233 └ Colorimetry....................233 └ Picture Aspect Ratio..................233 └ Active Format Aspect Ratio................233 └ Content..................... 234 └ Extended Colorimetry...................
  • Page 230 ® HDMI Applications R&S HDMI Generator Application └ MPEG Frame....................240 <Vendor-specific InfoFrame 1 to 4 parameters>............240 └ Active......................240 └ Type Number (hex)..................240 └ Version Number.................... 240 └ Length of InfoFrame..................240 └ Checksum (hex)....................241 └ IEEE OUI (hex)..................... 241 └...
  • Page 231 ® HDMI Applications R&S HDMI Generator Application └ Active......................246 └ Type Number (hex)..................246 └ Next Field......................247 └ Profile....................247 └ Affected Sequence Num................247 └ Current Sequence Num................247 └ No Current GBD....................247 └ Format Flag....................247 └ Facet Mode....................
  • Page 232 ® HDMI Applications R&S HDMI Generator Application ● "Vendor Specific InfoFrame 3" ● "Vendor Specific InfoFrame 4" ● "Dynamic Range and Mastering InfoFrame" Only available if "Rx/Tx 600MHz" is set under "Module (default favorite)" on page 209. ● "Gamut Boundary Data" ●...
  • Page 233 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 779 CONFigure<hw>:HDGenerator:INFoframe:AUX:AFPResent Bar Info ← <AVI InfoFrame parameters> ● "Not Valid" ● "Vertical Bar" ● "Horizontal Bar" ● "Both Bars" Remote command: on page 779 CONFigure<hw>:HDGenerator:INFoframe:AUX:BARinfo Scan Information ← <AVI InfoFrame parameters> ●...
  • Page 234 ® HDMI Applications R&S HDMI Generator Application IT Content ← <AVI InfoFrame parameters> ● "On" ● "Off" Remote command: on page 783 CONFigure<hw>:HDGenerator:INFoframe:AUX:ITContent Extended Colorimetry ← <AVI InfoFrame parameters> ● "xvYCC 601" ● "xvYCC 709" ● "sYCC 601" ● "Adobe YCC 601" ●...
  • Page 235 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 787 CONFigure<hw>:HDGenerator:INFoframe:AUX:YCCQuant Content Type ← <AVI InfoFrame parameters> ● "Graphics" ● "Photo" ● "Cinema" ● "Game" Remote command: on page 781 CONFigure<hw>:HDGenerator:INFoframe:AUX:CONTenttype Line Number of Top Bar End ← <AVI InfoFrame parameters> ●...
  • Page 236 ® HDMI Applications R&S HDMI Generator Application Checksum (hex) ← <Audio InfoFrame parameters> Displays the checksum hexadecimal. Remote command: on page 774 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CSUM? Coding Type ← <Audio InfoFrame parameters> ● "Stream Header" ● "PCM" ● "AC-3" ● "MPEG-1" ● "MP3" ●...
  • Page 237 ® HDMI Applications R&S HDMI Generator Application Remote command: CONFigure<hw>:HDGenerator:INFoframe:AUDio:SAMPling:FREQuency on page 777 Sampling Size ← <Audio InfoFrame parameters> ● "Stream Header" ● "16 bit" ● "20 bit" ● "24 bit" Remote command: CONFigure<hw>:HDGenerator:INFoframe:AUDio:SAMPling:SIZE on page 778 Code Extension ← <Audio InfoFrame parameters> ●...
  • Page 238 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 776 CONFigure<hw>:HDGenerator:INFoframe:AUDio:LFEPlayback <SPD InfoFrame parameters> Source product description (SPD) InfoFrame Only available if "SPD InfoFrame" is set under "Packet Type" on page 231. Active ← <SPD InfoFrame parameters> Enables or disables the SPD InfoFrame. See also "Max.
  • Page 239 ® HDMI Applications R&S HDMI Generator Application ● "D-VHS" ● "HDD Recorder" ● "DVC" ● "DSC" ● "Video CD" ● "Game" ● "PC General" ● "Blu-Ray Disc" ● "Super Audio CD" ● "HD DVC" ● "PMP" Remote command: on page 807 CONFigure<hw>:HDGenerator:INFoframe:SPD:SOURceinfo <MPEG InfoFrame parameters>...
  • Page 240 ® HDMI Applications R&S HDMI Generator Application Field Repeat (for 3:2 Pull-Down) ← <MPEG InfoFrame parameters> ● "On" ● "Off" Remote command: on page 804 CONFigure<hw>:HDGenerator:INFoframe:MPEG:FREPeat MPEG Frame ← <MPEG InfoFrame parameters> Enables or disables the MPEG InfoFrame. ● "Unknown" ●...
  • Page 241 ® HDMI Applications R&S HDMI Generator Application Checksum (hex) ← <Vendor-specific InfoFrame 1 to 4 parameters> Displays the checksum hexadecimal. Remote command: on page 810 CONFigure<hw>:HDGenerator:INFoframe:VSIF:CSUM? IEEE OUI (hex) ← <Vendor-specific InfoFrame 1 to 4 parameters> ● "00" "00" "00" to "FF" "FF" "FF" Remote command: on page 816 CONFigure<hw>:HDGenerator:INFoframe:VSIF:OUI...
  • Page 242 ® HDMI Applications R&S HDMI Generator Application Extended HDMI VIC ← <Vendor-specific InfoFrame 1 to 4 parameters> ● "1" to "255" Remote command: on page 814 CONFigure<hw>:HDGenerator:INFoframe:VSIF:HVIC 3D Structure ← <Vendor-specific InfoFrame 1 to 4 parameters> ● "Frame Packing" ● "Field Alternative"...
  • Page 243 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 819 CONFigure<hw>:HDGenerator:INFoframe:VSIF:VWPReferred Metadata Type ← <Vendor-specific InfoFrame 1 to 4 parameters> ● "Parallax" ● "Reserved" Remote command: on page 815 CONFigure<hw>:HDGenerator:INFoframe:VSIF:METatype Parallax Zero ← <Vendor-specific InfoFrame 1 to 4 parameters> ●...
  • Page 244 ® HDMI Applications R&S HDMI Generator Application Number of Regions ← <Vendor-specific InfoFrame 1 to 4 parameters> ● "0" to "4", "9", "16" ● "Reserved" Remote command: on page 816 CONFigure<hw>:HDGenerator:INFoframe:VSIF:NREGions Max Picture Disparity ← <Vendor-specific InfoFrame 1 to 4 parameters> ●...
  • Page 245 ® HDMI Applications R&S HDMI Generator Application Electro-Optical Transfer Function ← <Dynamic range and mastering InfoFrame parameters> Sets the electro-optical transfer function. ● "HDR Luminance Processing" ● "SDR Luminance Processing" ● "SMPTE ST 2084" ● "Future EOTF" Remote command: on page 790 CONFigure<hw>:HDGenerator:INFoframe:DRMI:EOTF Static Metadata Descriptor ←...
  • Page 246 ® HDMI Applications R&S HDMI Generator Application White Point X ← <Dynamic range and mastering InfoFrame parameters> ● "0.00000" to "1.00000" Remote command: on page 792 CONFigure<hw>:HDGenerator:INFoframe:DRMI:WPX White Point Y ← <Dynamic range and mastering InfoFrame parameters> ● "0.00000" to "1.00000" Remote command: on page 792 CONFigure<hw>:HDGenerator:INFoframe:DRMI:WPY...
  • Page 247 ® HDMI Applications R&S HDMI Generator Application Next Field ← <Gamut boundary data parameters> ● "On" ● "Off" Remote command: on page 796 CONFigure<hw>:HDGenerator:INFoframe:GBD:NEXT GBD Profile ← <Gamut boundary data parameters> ● "P0" ● "P1" ● "P2" ● "P3" Remote command: on page 798 CONFigure<hw>:HDGenerator:INFoframe:GBD:PROFile Affected Sequence Num ←...
  • Page 248 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 794 CONFigure<hw>:HDGenerator:INFoframe:GBD:COLPrecision Color Space ← <Gamut boundary data parameters> ● "RGB" ● "YCC 601" ● "YCC 709" Remote command: on page 794 CONFigure<hw>:HDGenerator:INFoframe:GBD:COLSpace Number of Vertices ← <Gamut boundary data parameters> ●...
  • Page 249 ® HDMI Applications R&S HDMI Generator Application Remote command: on page 795 CONFigure<hw>:HDGenerator:INFoframe:GBD:MAXBlue Black Point ← <Gamut boundary data parameters> ● "0" to "4095" Remote command: on page 793 CONFigure<hw>:HDGenerator:INFoframe:GBD:BLACk<port> Red Primary ← <Gamut boundary data parameters> ● "0" to "4095" Remote command: on page 797 CONFigure<hw>:HDGenerator:INFoframe:GBD:PRED<port>...
  • Page 250 ® HDMI Applications R&S HDMI Generator Application ISRC Valid ← ISRC1 ● "On" ● "Off" Remote command: on page 801 CONFigure<hw>:HDGenerator:INFoframe:ISRC:VALid ISRC Status ← ISRC1 ● "Unknown" ● "Track Start" ● "Track Intermediate" ● "Track End" Remote command: on page 801 CONFigure<hw>:HDGenerator:INFoframe:ISRC:STATus UPC EAN ISRC ←...
  • Page 251: Edid Reader Subtab

    ® HDMI Applications R&S HDMI Generator Application on page 806 CONFigure<hw>:HDGenerator:INFoframe:SPD:HBYTe<port> on page 804 CONFigure<hw>:HDGenerator:INFoframe:MPEG:HBYTe<port> on page 814 CONFigure<hw>:HDGenerator:INFoframe:VSIF:HBYTe<port> on page 791 CONFigure<hw>:HDGenerator:INFoframe:DRMI:HBYTe<port> on page 795 CONFigure<hw>:HDGenerator:INFoframe:GBD:HBYTe<port> on page 800 CONFigure<hw>:HDGenerator:INFoframe:ISRC:HBYTe<port> on page 802 CONFigure<hw>:HDGenerator:INFoframe:ISRTwo:HBYTe<port> PB0 to PB27 Packet bytes 0 to 27 For the SPD InfoFrame, use 25 packet bytes as defined in the standard.
  • Page 252 ® HDMI Applications R&S HDMI Generator Application Output(HDMI TX 300 MHz module)................252 Output(HDMI RX/TX 600 MHz module)..............252 Save EDID Data......................252 Update.........................252 Output(HDMI TX 300 MHz module) Sets the output for the EDID reading. The HDMI TX 300 MHz module (R&S VT-B360) provides 4 outputs.
  • Page 253: Scdc Subtab

    ® HDMI Applications R&S HDMI Generator Application Remote command: on page 771 CONFigure<hw>:HDGenerator:EDID:UPDate 10.1.7 SCDC Subtab Only available if "Rx/Tx 600MHz" is set under "Module (default favorite)" on page 209. The status and control data channel (SCDC) is a point-to-point communication protocol enabling data exchange between an HDMI source and an attached HDMI sink.
  • Page 254 OUI ← <Manufacturer-specific registers set by the sink> Organizationally unique identifier manufacturer Remote command: on page 853 READ<hw>:HDGenerator:SCDC:OUI? Identifier ← <Manufacturer-specific registers set by the sink> Identifier of the R&S VTS Remote command: on page 853 READ<hw>:HDGenerator:SCDC:IDENtifier? User Manual 2116.1228.02 ─ 14...
  • Page 255 859 READ<hw>:HDGenerator:SCDC:SWVersion? <Versions> Displays version information. Sink Version ← <Versions> Sink software version; always set to "1" for R&S VTS. Remote command: on page 858 READ<hw>:HDGenerator:SCDC:SINKversion? Source Version ← <Versions> Source software version; always set to "1" for R&S VTS.
  • Page 256 ® HDMI Applications R&S HDMI Generator Application Update CED ← <Update flags> Enabled by the sink if any error counter value: ● Increments by more than 4 in 1 second. ● Reaches its maximum value. Remote command: on page 859 READ<hw>:HDGenerator:SCDC:UPDate:CED? Update Status ←...
  • Page 257: Cts Subtab

    ® HDMI Applications R&S HDMI Generator Application Number of all read character errors since: – HDMI connection was made. – Last manual reset of the character error counters using "Reset Errors button" on page 257. Remote command: on page 857 READ<hw>:HDGenerator:SCDC:SCRambling:ERRNull? on page 856 READ<hw>:HDGenerator:SCDC:SCRambling:ERR<channel>?
  • Page 258 ® HDMI Applications R&S HDMI Generator Application Output......................... 260 <Test case> button......................260 └ CTS Sink Tests dialog...................260 CTS Configuration dialog.................... 261 └ 8-15 Character Synchronization..............261 └ 8-16 Acceptance of All Valid Packet Types...........261 └ Video Format..................261 └ <CDF sink parameters>..............261 └...
  • Page 259 ® HDMI Applications R&S HDMI Generator Application └ 8-27 High Bitrate Audio.................264 └ Video Format..................264 └ Audio Format..................264 └ 8-28 One Bit Audio..................264 └ Video Format..................264 └ 8-29 3D: Video Format Timing..............264 └ Video Format..................264 └...
  • Page 260 ® HDMI Applications R&S HDMI Generator Application └ HF2-26 Video Format Declaration..............268 └ <CDF sink parameters>..............268 └ HF2-31 Sink EDID - YCbCr 4:2:0 - Data Blocks........... 268 └ HF2-32 YCbCr 4:2:0 BT.2020 - Data Block..........268 └ <CDF sink parameters>..............269 └...
  • Page 261 ® HDMI Applications R&S HDMI Generator Application Note: If HDMI CTS RX/TX 600 MHz module (R&S VT-B2362) was refitted and starting a test case causes an error message, see "Start button" on page 272. Remote command: on page 767 CONFigure<hw>:HDGenerator:CTS:SELect CTS Configuration dialog In a tree view, displays all available test cases.
  • Page 262 ® HDMI Applications R&S HDMI Generator Application <CDF sink parameters> ← 8-18 HDMI Format Support Requirements ← CTS Con- figuration dialog Set the following CDF parameters in accordance with the CDF (capabilities declaration form) of the DUT: ● "CDF Sink 60 Hz" ●...
  • Page 263 ® HDMI Applications R&S HDMI Generator Application Video Format ← 8-21 Audio Clock Regeneration ← CTS Configuration dialog "Video Format" on page 261. N Value ← 8-21 Audio Clock Regeneration ← CTS Configuration dialog Sets the value of numerator N. ●...
  • Page 264 ® HDMI Applications R&S HDMI Generator Application Color Depth ← 8-25 Deep Color ← CTS Configuration dialog Sets the color depth that is used for the selected test. ● "10 bit" ● "12 bit" ● "16 bit" Remote command: on page 763 CONFigure<hw>:HDGenerator:CTS:CDEPth 8-27 High Bitrate Audio ←...
  • Page 265 ® HDMI Applications R&S HDMI Generator Application 8-30 4K x 2K Video Format Timing ← CTS Configuration dialog Only available if "HDMI 2.0 Output (HDMI RX/TX 600 MHz module)" on page 211 or "HDMI Out 1 to 4 (HDMI TX 300 MHz module)" on page 210 is as output.
  • Page 266 ® HDMI Applications R&S HDMI Generator Application Video Format ← HF2-5 6G - Scrambling ← CTS Configuration dialog "Video Format" on page 261. HF2-6 6G - 2160p 24-bit Color Depth ← CTS Configuration dialog Only available if "HDMI 2.0 Output (HDMI RX/TX 600 MHz module)" on page 211 or "HDMI Out (HDMI CTS RX/TX 600 MHz module)"...
  • Page 267 ® HDMI Applications R&S HDMI Generator Application Video Format ← HF2-8 6G - 2160p 3D ← CTS Configuration dialog "Video Format" on page 261. 3D Format ← HF2-8 6G - 2160p 3D ← CTS Configuration dialog "3D Format" on page 264. Pixel Clock Frequency ←...
  • Page 268 ® HDMI Applications R&S HDMI Generator Application Test Configuration ← HF2-24 YCbCr 4:2:0 Deep Color ← CTS Configuration dia- "Test Configuration" on page 266. Video Format ← HF2-24 YCbCr 4:2:0 Deep Color ← CTS Configuration dialog "Video Format" on page 261. Color Depth ←...
  • Page 269 ® HDMI Applications R&S HDMI Generator Application <CDF sink parameters> ← HF2-32 YCbCr 4:2:0 BT.2020 - Data Block ← CTS Con- figuration dialog Set the following CDF parameters in accordance with the CDF (capabilities declaration form) of the DUT: ● "CDF Sink_HDMI_YCBCR_420_BT2020_YCC"...
  • Page 270 ® HDMI Applications R&S HDMI Generator Application Pixel Encoding ← HF2-37 6G - Non-2160p Deep Color ← CTS Configuration dia- "Pixel Encoding" on page 262. Color Depth ← HF2-37 6G - Non-2160p Deep Color ← CTS Configuration dialog "Color Depth" on page 264.
  • Page 271 ® HDMI Applications R&S HDMI Generator Application ● "CDF Sink_HDMI_YCBCR_420_DC12" ● "CDF Sink_HDMI_YCBCR_420_DC16" ● "CDF Sink_OSD_Disparity" ● "CDF Sink_DualView" ● "CDF Sink_IndepView" ● "CDF Sink_SCDC" ● "CDF Sink_SCDC_Read_Request" ● "CDF Sink_Above_340" ● "CDF Sink_LTE_340Mcsc_Scrambling" Remote command: on page 764 CONFigure<hw>:HDGenerator:CTS:CDFSink HF2-54 HDR Static Metadata Data Block ←...
  • Page 272: Cec Subtab

    The R&S VTS itself participates in the CEC communication. Depending on the mode, the R&S VTS listens to all CEC traffic or only to the CEC traffic dedicated to its logical address. Each received command or reply from the DUT is listed in the left pane, the output pane.
  • Page 273 Opcode and Parameters Displays the selected operation code (opcode) of the CEC command that is sent by the R&S VTS. Depending on the selected opcode, the input of additional parameters in hexadecimal format is required. User Manual 2116.1228.02 ─ 14...
  • Page 274: Hdmi Analyzer Application

    ® HDMI Applications R&S HDMI Analyzer Application Click this button to select another opcode in the "CEC Opcodes" dialog. The available opcodes are listed in Chapter 10.4.4, "CEC Communication", on page 356. Remote command: on page 760 CONFigure<hw>:HDGenerator:CEC:OPCode on page 761 CONFigure<hw>:HDGenerator:CEC:OPCode:PARam:LENGth on page 760 CONFigure<hw>:HDGenerator:CEC:OPCode:PARam...
  • Page 275: Main Dialog Of The Application

    ® HDMI Applications R&S HDMI Analyzer Application The HDMI analyzer application measures in real-time. 10.2.1 Main Dialog of the Application The parameters are grouped on tabs. If a measured parameter is displayed in red color, the value does not meet the requirements of the HDMI specification. Default favorites Parameters that are often needed are provided as default favorites below the tab title.
  • Page 276 ® HDMI Applications R&S HDMI Analyzer Application Signal........................276 HDCP (HDMI TX 300 MHz module)................276 HDCP (HDMI RX/TX 600 MHz module)..............277 User Defined EDID......................277 HDMI +5V Power......................277 PCLK Locked......................277 HDCP State.........................278 TMDS Char. Clk......................278 Pixel Clock........................278 Video Code........................278 Video Feature......................278...
  • Page 277 ® HDMI Applications R&S HDMI Analyzer Application If the source sends a signal with HDCP, the R&S VTS uses HDCP. ● "Off" R&S VTS does not use HDCP. Remote command: on page 882 CONFigure<hw>:HDMI:INPut:HDCP HDCP (HDMI RX/TX 600 MHz module) Only available if "HDMI 600 MHz [<module slot>]"...
  • Page 278 ® HDMI Applications R&S HDMI Analyzer Application HDCP State Only available if "HDMI [<module slot>]" or "HDMI 600 MHz [<module slot>]" is set under "Input" on page 279. Displays the HDCP status. Remote command: on page 932 READ<hw>[:SCALar]:HDMI:INPut:HDCP? TMDS Char. Clk. Displays the TMDS character clock rate in MHz.
  • Page 279: Video Subtab

    HDMI RX/TX 600 MHz module (R&S VT-B2363) This module also requires the HDMI RX option (R&S VT-K2364). Note: To indicate the input at your R&S VTS, click "Indicate". A flashing LED indicates the input until you click "OK". Remote command: on page 950 ROUTe<hw>:HDMI:MODule:CATalog?
  • Page 280 ® HDMI Applications R&S HDMI Analyzer Application Video Code........................280 Pixel Clock........................280 Video Format.......................281 Vertical Frequency...................... 281 Horizontal Frequency....................281 Horizontal Video Parameters..................281 └ H Total Pixels....................281 └ H Active Pixels....................281 └ H Front Porch Pixels..................281 └...
  • Page 281 ® HDMI Applications R&S HDMI Analyzer Application Video Format Displays the video format of the HDMI video content. Remote command: on page 946 READ<hw>[:SCALar]:HDMI:VIDeo:VFORmat? Vertical Frequency Displays the measured vertical frequency of the HDMI video content. Remote command: on page 946 READ<hw>[:SCALar]:HDMI:VIDeo:VFRequency? Horizontal Frequency Displays the measured horizontal frequency of the HDMI video content.
  • Page 282: Audio Subtab

    ® HDMI Applications R&S HDMI Analyzer Application Vertical Video Parameters Groups the measured vertical video parameters of the HDMI video content. V Total Lines ← Vertical Video Parameters Displays the number of vertical total pixels. Remote command: on page 949 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:TOTal? V Active Lines ←...
  • Page 283 ® HDMI Applications R&S HDMI Analyzer Application N..........................283 CTS..........................283 Audio Coding.......................284 Layout......................... 284 Channel Status Bits.....................284 └ Application....................284 └ Audio Sample....................284 └ Copyright.......................284 └ Pre-emphasis....................284 └ Mode......................284 └ Category Code....................284 └ Source Number.....................284 └ Channel Number...................285 └ fs........................285 └...
  • Page 284 ® HDMI Applications R&S HDMI Analyzer Application Audio Coding Displays the audio coding type derived from the audio InfoFrame. Remote command: on page 887 READ<hw>[:SCALar]:HDMI:AUDio:ACODe? Layout Displays the layout value derived from the audio sample packet. Remote command: on page 890 READ<hw>[:SCALar]:HDMI:AUDio:LAYout? Channel Status Bits Groups the content of the channel status bits derived from the audio sample packets.
  • Page 285: Hdcp Subtab

    ® HDMI Applications R&S HDMI Analyzer Application Remote command: on page 892 READ<hw>[:SCALar]:HDMI:AUDio:NSOurce? Channel Number ← Channel Status Bits Displays the channel number. Remote command: on page 892 READ<hw>[:SCALar]:HDMI:AUDio:NCHannel? fs ← Channel Status Bits Displays the f value. Remote command: on page 890 READ<hw>[:SCALar]:HDMI:AUDio:FS? Clock Accuracy ←...
  • Page 286 ® HDMI Applications R&S HDMI Analyzer Application HDCP Mode........................ 286 HDCP State.........................286 Re-Authentication button.....................286 <HDCP version 1.4 parameters>................286 └ AKSV......................287 └ BKSV......................287 └ Ri'........................287 └ An........................287 <HDCP version 2.2 parameters>................287 └ r(rx)....................... 287 └ r(tx)........................287 └ r(n)........................ 287 └...
  • Page 287 ® HDMI Applications R&S HDMI Analyzer Application ● "On" is set under "HDCP (HDMI TX 300 MHz module)" on page 276 AKSV ← <HDCP version 1.4 parameters> Displays the key selection vector of the transmitter. Remote command: on page 896 READ<hw>[:SCALar]:HDMI:HDCP:AKSV? BKSV ←...
  • Page 288: Infoframe Subtab

    ® HDMI Applications R&S HDMI Analyzer Application L ← <HDCP version 2.2 parameters> Displays the locality check hash value calculated by the receiver of the locality check. Remote command: on page 898 READ<hw>[:SCALar]:HDMI:HDCP:L? 10.2.6 InfoFrame Subtab Only available if "HDMI [<module slot>]" or "HDMI 600 MHz [<module slot>]" is set under "Input"...
  • Page 289 ® HDMI Applications R&S HDMI Analyzer Application ● "Dynamic Range and Mastering InfoFrame" Only available if "HDMI 600 MHz [<module slot>]" is set under "Input" on page 279. <AVI InfoFrame parameters> Only available if "AVI InfoFrame" is set under "Packet Type" on page 288.
  • Page 290: Scdc Subtab

    OUI ← <Manufacturer-specific registers set by the sink> Organizationally unique identifier manufacturer Remote command: on page 937 READ<hw>[:SCALar]:HDMI:SCDC:OUI? Identifier ← <Manufacturer-specific registers set by the sink> Identifier of the R&S VTS Remote command: on page 937 READ<hw>[:SCALar]:HDMI:SCDC:IDENtifier? User Manual 2116.1228.02 ─ 14...
  • Page 291 941 READ<hw>[:SCALar]:HDMI:SCDC:SWVersion? <Versions> Displays version information. Sink Version ← <Versions> Sink software version; always set to "1" for R&S VTS. Remote command: on page 941 READ<hw>[:SCALar]:HDMI:SCDC:SINKversion? Source Version ← <Versions> Source software version; always set to "1" for R&S VTS.
  • Page 292 ® HDMI Applications R&S HDMI Analyzer Application Update CED ← <Update flags> Enabled by the sink if any error counter value: ● Increments by more than 4 in 1 second. ● Reaches its maximum value. Remote command: on page 941 READ<hw>[:SCALar]:HDMI:SCDC:UPDate:CED? Update Status ←...
  • Page 293: Cts Subtab

    ® HDMI Applications R&S HDMI Analyzer Application the source reads these values, the registers are reset. The register values of the accumulated character errors are not shown on the "SCDC" tab. ● <Value in right column> Highest value of detected character errors since: –...
  • Page 294 ® HDMI Applications R&S HDMI Analyzer Application on page 896 READ<hw>[:SCALar]:HDMI:CTS:REPort:COUNt? <Test case> button......................299 └ Test Case dialog................... 299 CTS Configuration dialog.................... 300 └ 7-16: Legal Codes..................300 └ Video Format..................300 └ Test Length..................300 └ Number of Frames................300 └ 7-17: Basic Protocol..................300 └...
  • Page 295 ® HDMI Applications R&S HDMI Analyzer Application └ Setup..................302 └ Pixel Encoding..................302 └ Test Length..................303 └ Number of Frames................303 └ 7-25: Video Format Timing................303 └ Video Format..................303 └ Test Length..................303 └ Number of Frames................303 └ 7-26: Pixel Repetition..................303 └...
  • Page 296 ® HDMI Applications R&S HDMI Analyzer Application └ Test Length..................306 └ 7-37: One Bit Audio..................306 └ Test Length..................306 └ 7-38: 3D Video Format Timing..............306 └ Video Format..................306 └ Format...................306 └ HDMI VSDB..................306 └ Test Length..................307 └...
  • Page 297 ® HDMI Applications R&S HDMI Analyzer Application └ EDID Setup..................310 └ Test Length..................310 └ Number of Frames................310 └ HF1-21: TMDS Prot 6G - Non-2160p Legal Codes........311 └ Video Format..................311 └ Test Length..................311 └ Number of Frames................311 └...
  • Page 298 ® HDMI Applications R&S HDMI Analyzer Application └ Color Depth..................314 └ Test Length..................315 └ Number of Frames................315 └ HF1-35: Video Timing - 21:9 (64:27).............315 └ Video Format..................315 └ Test Length..................315 └ Number of Frames................315 └ HF1-36: 3D Audio (L-PCM) - Packet Format..........
  • Page 299 ® HDMI Applications R&S HDMI Analyzer Application └ Number of Frames................319 └ HF1-47: HDMI-VSIF - 3D OSD Disparity............319 └ Video Format..................319 └ EDID Setup..................319 └ Test Length..................319 └ Number of Frames................319 └ HF1-48: HDMI-VSIF - Dual-View..............319 └...
  • Page 300 Sets the video format that is applied to the selected test. ● "Auto Detect" Automatic video format detection. ● <Video format> Presets the video format. The R&S VTS signals this video format as exclusively supported video format to the DUT. See also Chapter 10.4.3, "Video Codes", on page 345.
  • Page 301 ® HDMI Applications R&S HDMI Analyzer Application Number of Frames ← 7-17: Basic Protocol ← CTS Configuration dialog "Number of Frames" on page 300. 7-18: Extended Control Period ← CTS Configuration dialog Only available if "HDMI 600 MHz" or "HDMI" is set under "Input"...
  • Page 302 ® HDMI Applications R&S HDMI Analyzer Application CDF Setup ← 7-23: Pixel Encoding - RGB to RGB-only Sink ← CTS Configuration dialog Sets whether the source supports the transmission of "AVI InfoFrames". Configure the test according to the DUT capabilities declared in the CDF form. ●...
  • Page 303 ® HDMI Applications R&S HDMI Analyzer Application Test Length ← 7-24: Pixel Encoding - YCbCr to YCbCr Sink ← CTS Configuration dialog "Test Length" on page 300. Number of Frames ← 7-24: Pixel Encoding - YCbCr to YCbCr Sink ← CTS Config- uration dialog "Number of Frames"...
  • Page 304 ® HDMI Applications R&S HDMI Analyzer Application Number of Frames ← 7-27: AVI InfoFrame ← CTS Configuration dialog "Number of Frames" on page 300. 7-28: IEC 60958 / IEC 61937 ← CTS Configuration dialog Only available if "HDMI 600 MHz" or "HDMI" is set under "Input"...
  • Page 305 ® HDMI Applications R&S HDMI Analyzer Application Number of Frames ← 7-32: Audio Sample Packet Layout ← CTS Configuration dialog "Number of Frames" on page 300. 7-33: Interoperability with DVI ← CTS Configuration dialog Only available if "HDMI 600 MHz" or "HDMI" is set under "Input"...
  • Page 306 ® HDMI Applications R&S HDMI Analyzer Application Test Length ← 7-34: Deep Color ← CTS Configuration dialog "Test Length" on page 300. Number of Frames ← 7-34: Deep Color ← CTS Configuration dialog "Number of Frames" on page 300. 7-35: Gamut Metadata Transmission ← CTS Configuration dialog Only available if "HDMI 600 MHz"...
  • Page 307 ● "Auto Detect" Automatic video format detection. ● <4K video format> Presets the video format. The R&S VTS signals this video format as exclusively supported video format to the DUT. Remote command: on page 880 CONFigure<hw>:HDMI:CTS:VFORmat:FK Test Length ← 7-39: 4K x 2K Video Format Timing ← CTS Configuration dialog "Test Length"...
  • Page 308 ® HDMI Applications R&S HDMI Analyzer Application Video Format ← HF1-10: TMDS Prot 6G - TMDS Bit Clock Ratio ← CTS Configu- ration dialog "Video Format" on page 300. HF1-11: TMDS Prot 6G - 2160p Legal Codes ← CTS Configuration dialog Only available if "HDMI 600 MHz"...
  • Page 309 ® HDMI Applications R&S HDMI Analyzer Application EDID Setup ← HF1-13: TMDS Prot - Scrambling <= 3.4Gbps ← CTS Configuration dialog Enables or disables scrambling for TMDS character rates at or below 340 Mcsc. ● "LTE 340 Mcsc Scrambling No" Only available if "Yes"...
  • Page 310 ® HDMI Applications R&S HDMI Analyzer Application Remote command: on page 875 CONFigure<hw>:HDMI:CTS:EDID:TMDS Test Length ← HF1-15: Video Timing 6G - 2160p Deep Color ← CTS Configura- tion dialog "Test Length" on page 300. Number of Frames ← HF1-15: Video Timing 6G - 2160p Deep Color ← CTS Con- figuration dialog "Number of Frames"...
  • Page 311 ® HDMI Applications R&S HDMI Analyzer Application HF1-21: TMDS Prot 6G - Non-2160p Legal Codes ← CTS Configuration dialog Only available if "HDMI 600 MHz" or "HDMI CTS" is set under "Input" on page 279. Video Format ← HF1-21: TMDS Prot 6G - Non-2160p Legal Codes ← CTS Config- uration dialog "Video Format"...
  • Page 312 ® HDMI Applications R&S HDMI Analyzer Application Video Format ← HF1-25: Video Timing 6G - Non-2160p Deep Color ← CTS Con- figuration dialog "Video Format" on page 300. Color Depth ← HF1-25: Video Timing 6G - Non-2160p Deep Color ← CTS Config- uration dialog "Color Depth"...
  • Page 313 ® HDMI Applications R&S HDMI Analyzer Application EDID Setup ← HF1-28: AVI InfoFrame 6G - Non-2160p ← CTS Configuration dia- "EDID Setup" on page 310. Test Length ← HF1-28: AVI InfoFrame 6G - Non-2160p ← CTS Configuration dia- "Test Length" on page 300.
  • Page 314 ® HDMI Applications R&S HDMI Analyzer Application Color Depth ← HF1-32: Pix Enc - YCbCr 4:2:0 Deep Color - TMDS ← CTS Config- uration dialog "Color Depth" on page 305. EDID Setup ← HF1-32: Pix Enc - YCbCr 4:2:0 Deep Color - TMDS ← CTS Configu- ration dialog Enables or disables the support of 4:2:0 deep color with 30 bit, 36 bit and 48 bit in the HF-VSDB.
  • Page 315 ® HDMI Applications R&S HDMI Analyzer Application Test Length ← HF1-34: Video Timing - YCbCr 4:2:0 Deep Color ← CTS Configura- tion dialog "Test Length" on page 300. Number of Frames ← HF1-34: Video Timing - YCbCr 4:2:0 Deep Color ← CTS Configuration dialog "Number of Frames"...
  • Page 316 ® HDMI Applications R&S HDMI Analyzer Application Number of Frames ← HF1-36: 3D Audio (L-PCM) - Packet Format ← CTS Config- uration dialog "Number of Frames" on page 300. HF1-37: 3D Audio (One Bit) - Packet Format ← CTS Configuration dialog Only available if "HDMI 600 MHz"...
  • Page 317 ® HDMI Applications R&S HDMI Analyzer Application Sampling Frequency ← HF1-39: MS Audio (One Bit) - Packet Format ← CTS Con- figuration dialog "Sampling Frequency" on page 304. Audio Streams ← HF1-39: MS Audio (One Bit) - Packet Format ← CTS Configura- tion dialog "Audio Streams"...
  • Page 318 ® HDMI Applications R&S HDMI Analyzer Application Number of Frames ← HF1-41: 3D Audio - IEC Sample Packet ← CTS Configura- tion dialog "Number of Frames" on page 300. HF1-42: MS Audio - IEC Sample Packet ← CTS Configuration dialog Only available if "HDMI 600 MHz"...
  • Page 319 ® HDMI Applications R&S HDMI Analyzer Application Number of Frames ← HF1-45: Basic Audio - Allowed Rate ← CTS Configuration dialog "Number of Frames" on page 300. HF1-47: HDMI-VSIF - 3D OSD Disparity ← CTS Configuration dialog Only available if "HDMI 600 MHz" or "HDMI CTS" is set under "Input"...
  • Page 320 ® HDMI Applications R&S HDMI Analyzer Application HF1-49: HDMI-VSIF - Independent-View ← CTS Configuration dialog Only available if "HDMI 600 MHz" or "HDMI CTS" is set under "Input" on page 279. Video Format ← HF1-49: HDMI-VSIF - Independent-View ← CTS Configuration dialog "Video Format"...
  • Page 321 ® HDMI Applications R&S HDMI Analyzer Application Remote command: on page 873 CONFigure<hw>:HDMI:CTS:EDID EDID Colorimetry Setup ← HF1-52: AVI InfoFrame - YCbCr 4:2:0 BT.2020 ← CTS Configuration dialog Sets the colorimetry support that the EDID of the test equipment indicates to the DUT. ●...
  • Page 322 ® HDMI Applications R&S HDMI Analyzer Application To use a previously saved file. Click "Load" to select the file for analysis, see "Load button" on page 322. To configure the data source, click Remote command: on page 871 CONFigure<hw>:HDMI:CTS:DATA Data Source Config dialog ← Data Source Sets the amount of data that are saved in a file.
  • Page 323: Cec Subtab

    The R&S VTS itself participates in the CEC communication and acts as a 'TV' set. Depending on the mode, the R&S VTS listens to all CEC traffic or only to the CEC traf- fic dedicated to the 'TV' set. Each received command or reply from the DUT is listed in the left pane, the output pane.
  • Page 324 Opcode and Parameters Displays the selected operation code (opcode) of the CEC command that is sent by the R&S VTS. Depending on the selected opcode, the input of additional parameters in hexadecimal format is required. Click this button to select another opcode in the "CEC Opcodes" dialog. The available opcodes are listed in Chapter 10.4.4, "CEC...
  • Page 325: Cec/Ddc Analyzer Application

    ® HDMI Applications R&S CEC/DDC Analyzer Application Remote command: on page 865 CONFigure<hw>:HDMI:CEC:OPCode on page 865 CONFigure<hw>:HDMI:CEC:OPCode:PARam on page 866 CONFigure<hw>:HDMI:CEC:OPCode:PARam:LENGth Save button Saves the protocol trace in a file. Remote command: on page 884 MMEMory<hw>:HDMI:CEC:DATA:STORe Send button Only available if the protocol trace has been started ("Start button"...
  • Page 326: Main Dialog Of The Application

    ® HDMI Applications R&S CEC/DDC Analyzer Application 10.3.1 Main Dialog of the Application The parameters are grouped on tabs. Displayed information "HDMI IN" displays information on the HDMI IN port. ● Status information: – "DDC Tracer Passive", "CEC Tracer Passive" Displayed if the HDMI pass-through adapter (R&S VT-Z2390) is connected to the port.
  • Page 327 ® HDMI Applications R&S CEC/DDC Analyzer Application Tracer Settings......................327 └ Data Channel....................327 └ VT-B2363 HDMI Port..................327 Standard........................327 Logical Address......................328 └ HDMI IN......................328 └ HDMI OUT....................328 └ <Status message>..................328 Tracer Settings Groups the setup parameters. Data Channel ←...
  • Page 328: Command Subtab

    ® HDMI Applications R&S CEC/DDC Analyzer Application Remote command: on page 969 ROUTe<hw>:CECDdc:SELect:VERSion Logical Address Groups the parameters to configure the logical addresses. Note: Make sure to assign only free addresses in order to avoid address conflicts. HDMI IN ← Logical Address Sets the DUT type addressed at the HDMI IN port of the HDMI RX/TX 600 MHz mod- ule (R&S VT-B2363).
  • Page 329 ® HDMI Applications R&S CEC/DDC Analyzer Application Type..........................330 <CEC user command parameters>................330 └ Destination....................330 └ Mode......................330 └ <CEC command> button................330 └ Opcode button....................331 └ CEC Opcodes dialog..................331 └ Preset tab (Quick mode)..............331 └ User Defined tab (Quick mode)............
  • Page 330 Only available if "CEC User Command" is set under "Type" on page 330. Destination ← <CEC user command parameters> Sets the logical address of the DUT that should receive the CEC messages sent by the R&S VTS. ● Parameter values see Table 10-1 Remote command: on page 955 CONFigure<hw>:CECDdc:COMMand:CEC:DESTination...
  • Page 331 ® HDMI Applications R&S CEC/DDC Analyzer Application Displays the selected CEC command. Click this button to select another CEC command, see "CEC Opcodes dialog" on page 331. Below this button, information on the opcode and the operands of the CEC command are displayed.
  • Page 332 ® HDMI Applications R&S CEC/DDC Analyzer Application Remote command: on page 957 CONFigure<hw>:CECDdc:COMMand:CEC:OPERands Parameter 1 to 14 ← <CEC user command parameters> Only available if "Advanced" is set under "Mode" on page 330. Depending on the selected opcode, the input of additional parameters in hexadecimal format is required.
  • Page 333 ® HDMI Applications R&S CEC/DDC Analyzer Application Send button ← <CEC user command parameters> Sends a command: ● According to the type set under "Type" on page 330 ● At the port set under "Port" on page 332 Remote command: on page 961 CONFigure<hw>:CECDdc:COMMand:SEND CEC Debugger Settings dialog ←...
  • Page 334 ® HDMI Applications R&S CEC/DDC Analyzer Application Remote command: on page 958 CONFigure<hw>:CECDdc:COMMand:EDID:READ Save button ← <Read EDID parameters> Opens the "File" dialog to save the read EDID data in binary format. See also Chap- ter 5.3, "File Dialog", on page 82. Remote command: on page 965 MMEMory<hw>:CECDdc:COMMand:EDID:DATA:STORe...
  • Page 335: Tracer Subtab

    ® HDMI Applications R&S CEC/DDC Analyzer Application Remote command: on page 960 CONFigure<hw>:CECDdc:COMMand:SCDC:WRITe:BYTes Write SCDC button ← <SCDC write parameters> Starts writing the SCDC registers using the HDMI OUT port. Remote command: on page 960 CONFigure<hw>:CECDdc:COMMand:SCDC:WRITe 10.3.4 Tracer Subtab Displays the details of data packets along with the waveforms captured on the CEC and DDC buses of the HDMI IN/OUT ports of the bus tester.
  • Page 336 ® HDMI Applications R&S CEC/DDC Analyzer Application └ Destination column..................336 └ Packet Type column..................336 └ Port column....................336 <Description>......................336 <Waveform scope>..................... 337 <Tracer settings> button..................... 337 Clear button.........................337 Save button......................... 337 Stop button........................337 Start button........................337 Tracer Settings dialog....................337 └...
  • Page 337 ® HDMI Applications R&S CEC/DDC Analyzer Application <Waveform scope> Displays the waveform scope of the row selected in the "<Packet data table>" on page 336. Depending on the packet type, displays 1 waveform (CEC packets) or 2 waveforms (EDID or SCDC packets). You can use zooming. Remote command: on page 969 READ<hw>:CECDdc:TRACer:TRACe?
  • Page 338: Addressing The Dut

    ® HDMI Applications R&S CEC/DDC Analyzer Application Packet ← Tracer Settings dialog Used to monitor only specific packet types. ● "All" ● "CEC" ● "EDID" ● "SCDC" ● "HDCP" ● "DDC" Remote command: on page 963 CONFigure<hw>:CECDdc:TRACer:PACKet Status ← Tracer Settings dialog Used to check for errors.
  • Page 339: Customizing Cec Command Hotkeys

    ® HDMI Applications R&S Content and Codes Parameter value Remote command parameter "Specific Use (14)" SPECific "Unregistered (15)" or "Broadcast (15)" UORBroadcast 10.3.6 Customizing CEC Command Hotkeys For commands that you need often but that are not available as ready-made hotkeys in the quick mode, you can define your own set of hotkeys.
  • Page 340: Patterns

    ® HDMI Applications R&S Content and Codes 10.4.1 Patterns The HDMI generator application provides the patterns described in Table 10-2. To select a pattern 1. On the "Signal" subtab, click the content selection button, see "Content Selection" on page 215. The "Content Selection"...
  • Page 341 ® HDMI Applications R&S Content and Codes Content Name Used as string in remote command "White" "Black" "Gray 75%" "Gray 50%" "Gray 25%" "Gray 10%" "Gray 5%" "Gray Ramp" "Chess Board 16:9" "Chess Board 4:3" "Cross Hatch" "Crosstalk Side by Side" "Crosstalk Top Bottom"...
  • Page 342: Hdr Signals

    ® HDMI Applications R&S Content and Codes Content Name Used as string in remote command "V Ramp RGB444" "H Ramp" "MACBETH 16:9 Babel Color" "MACBETH 16:9 Color Checker" "SMPTE Colorbar 16:9" "YCbCr 4:2:0 Test Image" 10.4.2 HDR Signals The HDMI generator application provides the high dynamic range (HDR) signals described in Table 10-3.
  • Page 343 ® HDMI Applications R&S Content and Codes Content Name Description "HDR 0to01_1_10_100_1k_2k_3k cd" Luminance steps based on the optical output level (cd/ ), coded with SMPTE ST 2084 1st row (bottom): 0 cd/m (left) to 0.1 cd/m (right) 2nd row: 0 cd/m (left) to 1 cd/m (right) 3rd row: 0 cd/m...
  • Page 344 ® HDMI Applications R&S Content and Codes Content Name Description "Plain Magenta" "Plain Red" "Plain White" "Plain Yellow" "Vertical Line 100%" Contrast, maximum luminance "V Ramp" Vertical ramp 10.4.2.1 Application Examples for HDR Source Testing Does the video source interpret the HDR meta data block of the EDID correctly? 1.
  • Page 345: Video Codes

    ® HDMI Applications R&S Content and Codes 10.4.2.2 Application Examples for HDR Sink Testing Does the sink DUT provide the HDR static meta data block in the EDID correctly? 1. Use the EDID interpreter. 2. Perform the HF1-54 test case according to the compliance test specifications (CTS).
  • Page 346 ® HDMI Applications R&S Content and Codes Table 10-5: Video codecs: VIC for HDMI 1.4b Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 640x480p 59.94 Hz/60 Hz 720x480p 59.94 Hz/60 Hz 720x480p 59.94 Hz/60 Hz 16:9 32:27...
  • Page 347 ® HDMI Applications R&S Content and Codes Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 1440x576p 50 Hz 8:15 or 16:15 1440x576p 50 Hz 16:9 32:45 or 64:45 1920x1080p 50 Hz 16:9 1920x1080p 23.97 Hz/24 Hz 16:9...
  • Page 348 ® HDMI Applications R&S Content and Codes Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 720x480p 239.76 Hz/240 Hz 16:9 32:27 720(1440)x480i 239.76 Hz/240 Hz 720(1440)x480i 239.76 Hz/240 Hz 16:9 32:27 1280x720p 23.97 Hz/24 Hz 16:9 1280x720p...
  • Page 349 ® HDMI Applications R&S Content and Codes Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 2880x480i 59.94 Hz/60 Hz 16:9 8:27 to 80:27 2880x240p 59.94 Hz/60 Hz C12A|C12B 1:9 to 10:9 2880x240p 59.94 Hz/60 Hz 16:9 C13A|C13B...
  • Page 350 ® HDMI Applications R&S Content and Codes Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 2880x576p 50 Hz 16:9 16:45, 32:45, or 64:45 1920x1080i (1250 total) 50 Hz 16:9 1920x1080i 100 Hz 16:9 1280x720p 100 Hz...
  • Page 351 ® HDMI Applications R&S Content and Codes Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 1280x720p 23.98 Hz/24 Hz 64:27 1280x720p 25 Hz 64:27 1280x720p 29.97 Hz/30 Hz 64:27 1280x720p 50 Hz 64:27 1280x720p 59.94 Hz/60 Hz...
  • Page 352 ® HDMI Applications R&S Content and Codes Format Field rate Picture aspect Pixel aspect ratio Remote command ratio (H:V) (H:V) parameter (<video format>) 2560x1080p 119.88 Hz/120 Hz 64:27 3840x2160p 23.98 Hz/24 Hz 16:9 3840x2160p 25 Hz 16:9 3840x2160p 29.97 Hz/30 Hz 16:9 3840x2160p 50 Hz...
  • Page 353 ® HDMI Applications R&S Content and Codes exception to this is the 640x480 format, which is always sent as 4x3 data, and is ren- dered according to the characteristics of the sink. Channel allocation Figure 10-2: Speaker placement Label Location Front left Front center Front right...
  • Page 354 ® HDMI Applications R&S Content and Codes FLW/FRW are front perimeter speakers, outside of the front main speakers. FLH/FCH/FRH are front elevated speakers, generally above the front main speakers. TC is an upper surround or overhead speaker, directly above overhead. Data byte 4 contains information that describes how various speaker locations are allo- cated to transmission channels.
  • Page 355 ® HDMI Applications R&S Content and Codes Channel number (binary) (hex) 0x18 0x19 0x1A 0x1B 0x1C 0x1D 0x1E 0x1F 0x20 0x21 0x22 0x23 0x24 0x25 0x26 0x27 0x28 0x29 0x2A 0x2B 0x2C 0x2D 0x2E 0x2F 0x30 0x31 0x32 Reserved 0xFF User Manual 2116.1228.02 ─...
  • Page 356: Cec Communication

    ® HDMI Applications R&S Content and Codes 10.4.4 CEC Communication CEC operation codes used in the CEC communication. Shortened, they are called opc- odes. The remote command parameter in the following table only applies to the HDMI ana- lyzer and HDMI generator applications. In the CEC/DDC analyzer application, the opcode is addressed by 2 parameters as described in on page 957.
  • Page 357 ® HDMI Applications R&S Content and Codes CEC feature Operation code Remote command parameter (<opcode>) Clear Digital Timer (0x99) TP99 Clear External Timer (0xA1) TPA1 Set External Timer (0xA2) TPA2 System information Polling Message SIPM Set Menu Language (0x32) SI32 Give Physical Address (0x83) SI83 Report Physical Address (0x84)
  • Page 358 ® HDMI Applications R&S Content and Codes CEC feature Operation code Remote command parameter (<opcode>) User Control Released (0x45) RC45 Power status Give Device Power Status (0x8F) PS8F Report Power Status (0x90) PS90 General protocol messages Feature Abort (0x00) GP00 Abort (Reserved for Testing) (0xFF) GPFF System audio control...
  • Page 359 ® HDMI Applications R&S Content and Codes Type Remote command parameters <Group> "<String>" User Control Pressed: Pause User Control Pressed: Power On Function User Control Pressed: Power Off Function Active Source Image View On Standby Record On Record Off Give Physical Address Get CEC Version Set Menu Language: [ENG] Menu Request: Activate...
  • Page 360: Time Domain Analyzer Application

    ® Time Domain Analyzer Application R&S 11 Time Domain Analyzer Application Requires the following options: ● TMDS time domain analyzer module (R&S VT-B2380) Chapter 4.2.2.12, "TMDS Time Domain Analyzer Module (R&S VT-B2380)", on page 74 ● HDMI type A TPA (plug) (R&S VT-Z2385) Chapter 4.2.3.1, "HDMI Type A TPA (Plug) (R&S VT-Z2385)", on page 75...
  • Page 361: Main Dialog Of The Application

    ® Time Domain Analyzer Application R&S Main Dialog of the Application 11.1 Main Dialog of the Application The parameters are grouped on tabs. Default favorites Parameters that are often needed are provided as default favorites below the tab title. ● "Probe (default favorite)"...
  • Page 362: Input Subtab

    ® Time Domain Analyzer Application R&S Input Subtab TMDS Char Clk (default favorite) Displays the measured value of the TMDS character clock in MHz. The TMDS charac- ter clock is always 1/10th of the TMDS bit rate. TMDS character clock is equal to the TMDS clock rate for all HDMI 1.4 modes, but in 6G mode (HDMI 2.0) or with MHL, it is 4 times the TMDS clock rate.
  • Page 363 ® Time Domain Analyzer Application R&S Input Subtab └ TMDS Character Clock................. 363 └ User-Defined EDID..................363 └ Load......................363 └ EDID.....................363 └ Reconnect button..................363 EDID Groups the extended display identification data (EDID). TMDS Character Clock ← EDID Sets an EDID to force the DUT to produce the test frequencies. The range depends on the standard.
  • Page 364: Scope Subtab

    ® Time Domain Analyzer Application R&S Scope Subtab 11.3 Scope Subtab Displays the measurement results depending on the selected view. The scope mea- surement display depends on the setting of the channels to be measured. As descri- bed under "Channel (default favorite)" on page 365, the voltage scaling depends on the measurement type: single ended or differential.
  • Page 365 ® Time Domain Analyzer Application R&S Scope Subtab └ ......................367 C2-C1 Mask View........................367 └ Violations...................... 367 └ Mask......................367 Horizontal Histogram View..................368 └ Right - Left (H2 - H1)..................368 └ Left Histogram (H1), Right Histogram (H2)...........368 Vertical Histogram View....................369 └...
  • Page 366 ® Time Domain Analyzer Application R&S Scope Subtab For TMDS signals, the positive and the negative lines have a DC offset of about 2.9 V and a peak-to-peak voltage of 400 mV (+/- 200 mV). Because the negative line shows the inverted signal of the positive line, there is a differential peak-to-peak voltage of 800 mV (+/- 400 mV), with the DC offset eliminated.
  • Page 367 ® Time Domain Analyzer Application R&S Scope Subtab Remote command: on page 986 READ<hw>[:SCALar]:TDA:SCOPe:CURSor:DIFFerence? ← Cursor View C2-C1 Displays the time difference between the cursors. Remote command: on page 986 READ<hw>[:SCALar]:TDA:SCOPe:CURSor:DIFFerence? ← Cursor View C2-C1 Displays the frequency difference between the cursors. Remote command: on page 986 READ<hw>[:SCALar]:TDA:SCOPe:CURSor:DIFFerence?
  • Page 368 ® Time Domain Analyzer Application R&S Scope Subtab Remote command: on page 977 CONFigure<hw>:TDA:SCOPe:MASK on page 977 CONFigure<hw>:TDA:SCOPe:MASK:RESet Horizontal Histogram View The horizontal histogram shows the appearances of samples on the 0 volt line at the 2 crossing points of the signal (edges). The occurrence at these points ideally shows hills with a Gaussian distribution.
  • Page 369 ® Time Domain Analyzer Application R&S Scope Subtab A description of the distribution is defined by the following parameters: ● "Mean" Middle of all occurrences ● "Max" ● "Min" ● "Standard Deviation" Square root of all squares of the distance to the mean value times number of occurrence divided by the total number of occurrences Remote command: on page 986...
  • Page 370 ® Time Domain Analyzer Application R&S Scope Subtab Remote command: on page 989 READ<hw>[:SCALar]:TDA:SCOPe:VHIStogram? Upper Histogram, Lower Histogram ← Vertical Histogram View The upper histogram is a statistical calculation of the sampling distribution in the upper part of the eye mid point. The lower histogram is a statistical calculation of the sam- pling distribution in the lower part of the eye mid point.
  • Page 371 ® Time Domain Analyzer Application R&S Scope Subtab Span ← Common ← Scope Settings dialog Sets the range of the scan over the TMDS data bit. Unit interval (UI) is the time for 1 bit transmitted. ● "1.2 UI" 1 TMDS data bit +/-10 % ●...
  • Page 372: Cts Subtab

    ® Time Domain Analyzer Application R&S CTS Subtab Start button Starts the measurement. Remote command: on page 979 INITiate<hw>:TDA 11.4 CTS Subtab Requires the HDMI CTS source test (elec.) option (R&S VT-K2385). Divided into two panes. The left pane displays the compliance test results. You can select between: ●...
  • Page 373 ® Time Domain Analyzer Application R&S CTS Subtab Channel (default favorite)....................374 <Test Case> button..................... 376 └ Test Case dialog................... 376 CTS Configuration dialog.................... 376 └ 7-2: TMDS -V ....................376 └ Channel....................376 └ Sink Supports Pixel Clock > 165 MHz..........376 └...
  • Page 374 ® Time Domain Analyzer Application R&S CTS Subtab └ 7-15: CEC Line Degradation.................378 └ CDF CEC Protocol................378 └ Standby Power Mode Exists...............378 └ HF 1-1: TMDS 6G V and V ..............378 Swing └ Channel....................379 └ HF 1-2: TMDS 6G T ................379 Rise Fall...
  • Page 375 ® Time Domain Analyzer Application R&S CTS Subtab Test case Channel value "Data 2- and GND" "Data 0+ and 0-" "Data 1+ and 1-" "Data 2+ and 2-" "Data 0 and 1" "Data 1 and 2" "Data 0 and 2" "Clock+ and GND"...
  • Page 376 ® Time Domain Analyzer Application R&S CTS Subtab <Test Case> button Displays the selected test case. Click this button to select another test case, see "Test Case dialog" on page 376. Click to configure the selected test, see "CTS Configuration dialog" on page 376.
  • Page 377 ® Time Domain Analyzer Application R&S CTS Subtab 7-3: TMDS-V ← CTS Configuration dialog HDMI 1.4 test case, see also Chapter 11.5.1.3, "7-3: TMDS-V ", on page 382. Channel ← 7-3: TMDS-VOff ← CTS Configuration dialog "Channel (default favorite)" on page 374. Standby Power Mode Exists ←...
  • Page 378 ® Time Domain Analyzer Application R&S CTS Subtab 7-10: Data Eye Diagram ← CTS Configuration dialog HDMI 1.4 test case, see also Chapter 11.5.1.9, "7-10: Data Eye Diagram", on page 389. Channel ← 7-10: Data Eye Diagram ← CTS Configuration dialog "Channel (default favorite)"...
  • Page 379 ® Time Domain Analyzer Application R&S CTS Subtab Channel ← HF 1-1: TMDS 6G VL and VSwing ← CTS Configuration dialog "Channel (default favorite)" on page 374. HF 1-2: TMDS 6G T ← CTS Configuration dialog Rise Fall HDMI 2.0 test case, see also Chapter 11.5.2.2, "HF 1-2: TMDS 6G T ", Rise...
  • Page 380: Compliance Tests

    ® Time Domain Analyzer Application R&S Compliance Tests The file format is MHTML, short for MIME HTML. This is a web page archive format used to combine the HTML code and its companion resources in a single document. These report files include test report and the corresponding waveforms of the per- formed tests.
  • Page 381 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-1: Test report 11.5.1.2 7-2: TMDS -V The DC voltage levels on the HDMI link are within specified limits for each TMDS sig- nal. This measurement evaluates the most common low level voltage of each TMDS line. To reduce the influence of attenuation of higher frequencies on the lines, perform this test with the lowest supported TMDS character clock of the DUT: CEA 1 (640x480p/ 59.94Hz).
  • Page 382 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-2: Test report Figure 11-3: Waveform 11.5.1.3 7-3: TMDS-V A disabled TMDS link only allows leakage currents within the specified limits. Requires different states for the DUT. During the test, you need to perform actions when prompted.
  • Page 383 ® Time Domain Analyzer Application R&S Compliance Tests ● DUT in power-off mode The remaining current must not exceed 0.2 mA, which causes a voltage of 10 mV at 50 Ω. The compliance test results are displayed as test report only. Figure 11-4: Test report 11.5.1.4 7-4: TMDS-T...
  • Page 384 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-5: Test report Figure 11-6: Waveform 11.5.1.5 7-6: TMDS Inter Pair Skew The measurement calculates the delay (skew) between the differential TMDS data line pairs. To get most accurate measurement values, perform this test with the highest supported TMDS character clock of the DUT: CEA code 63 (1920x1080p/120Hz).
  • Page 385 ® Time Domain Analyzer Application R&S Compliance Tests Restriction The time domain analyzer application performs the eye diagram measurement only. This means that the application is not able to trigger on sync words as it is required in the meaning of CTS. In fact, a delay between data lines of ±2 T is allowed.
  • Page 386 ® Time Domain Analyzer Application R&S Compliance Tests 11.5.1.6 7-7: TMDS Intra Pair Skew Any skew within any one differential pair in the TMDS portion of the HDMI link does not exceed the limits in the specification. To get most accurate measurement values, perform this test with the highest supported TMDS character clock of the DUT: CEA code 63 (1920x1080p/120Hz).
  • Page 387 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-10: Waveform 11.5.1.7 7-8: Clock Duty Cycle The duty cycle of the differential TMDS clock does not exceed the limits allowed by the specification. The waveform of the differential clock lines is captured, and the duty cycle of the clock pulses calculated.
  • Page 388 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-12: Waveform 11.5.1.8 7-9: TMDS Clock Jitter The TMDS clock does not carry excessive jitter. This measurement runs not with the original clock lines but with a recovered clock sig- nal, because CTS requires a clock recovery unit (CRU). Thus, the recovered clock is sampled, measured and displayed.
  • Page 389 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-13: Test report Figure 11-14: Waveform 11.5.1.9 7-10: Data Eye Diagram The differential signal on each TMDS differential data pair has an "eye opening" that meets or exceeds the limits on eye opening in the specification. For this measurement, an eye mask is defined in the CTS.
  • Page 390 ® Time Domain Analyzer Application R&S Compliance Tests ported frequency. You can control the DUT frequency using "TMDS Character Clock" on page 363. Figure 11-15: Test report User Manual 2116.1228.02 ─ 14...
  • Page 391 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-16: Waveform 11.5.1.10 7-11: +5 V Power The +5V power signal meets voltage and current capacity requirements. This test measures the +5 V power pin of the DUT. It should provide at least 4.8 V while 55 mA are drawn.
  • Page 392 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-17: Test report 11.5.1.11 7-12: Hotplug Detect The source load on the hot plug pin allows the signal to meet the specified require- ments. This measurement determines that the hot plug pin is terminated according to the stan- dard.
  • Page 393 ® Time Domain Analyzer Application R&S Compliance Tests 11.5.1.12 7-13: DDC/CEC Capacitance The capacitance load on the DDC and CEC lines does not exceed the limit in the spec- ification and that DDC and CEC pull-ups are the correct voltage. Depending on the setting under "Source DDC Cap Power On"...
  • Page 394: Hdmi 2.0

    ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-20: Test report 11.5.2 HDMI 2.0 Describes all compliance tests available for HDMI 2.0. 11.5.2.1 HF 1-1: TMDS 6G V and V Swing The DC voltage levels on the HDMI link are within specified limits for each TMDS sig- nal.
  • Page 395 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-21: Test report Figure 11-22: Waveform (2/6) 11.5.2.2 HF 1-2: TMDS 6G T Rise Fall The rise times and fall times on the TMDS differential signals fall within the limits of the specification.
  • Page 396 ® Time Domain Analyzer Application R&S Compliance Tests data lines in general, but is also continuously available on single lines for problem eval- uation. The limits for rise and fall times are given by the CTS 2.0 specification, the times must be equal or longer than 42.5 ps.
  • Page 397 ® Time Domain Analyzer Application R&S Compliance Tests To get most accurate measurement values, perform this test with the highest supported TMDS character clock of the DUT: VIV96 (3840x2160p/50Hz). Restriction The time domain analyzer application performs the eye diagram measurement only. This means that the application is not able to trigger on sync words as it is required in the meaning of CTS.
  • Page 398 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-26: Waveform (1/1) 11.5.2.4 HF 1-4: TMDS 6G Intra Pair Skew Any skew within any one differential pair in the TMDS portion of the HDMI link does not exceed the limits in the specification. To get most accurate measurement values, perform this test with the highest supported TMDS character clock of the DUT: VIV96 (3840x2160p/50Hz).
  • Page 399 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-27: Test report Figure 11-28: Waveform (3/3) 11.5.2.5 HF 1-5: TMDS 6G Differential Voltage The differential signal on each TMDS differential pair does not exceed the maximum/ minimum differential voltage. This measurement evaluates the minimum low and maximum high level voltages of each TMDS line pair.
  • Page 400 ® Time Domain Analyzer Application R&S Compliance Tests Limits for the amplitude (differential voltage): -780 mV to 780 mV Figure 11-29: Test report Figure 11-30: Waveform (2/3) 11.5.2.6 HF 1-6: TMDS 6G Clock Duty Cycle The duty cycle of the differential TMDS clock does not exceed the limits allowed by the specification.
  • Page 401 ® Time Domain Analyzer Application R&S Compliance Tests Figure 11-31: Test report Figure 11-32: Waveform 11.5.2.7 HF 1-7: TMDS 6G Clock Jitter The TMDS clock does not carry excessive jitter. This measurement runs not with the original clock lines but with a recovered clock sig- nal, because CTS requires a clock recovery unit (CRU).
  • Page 402 ® Time Domain Analyzer Application R&S Compliance Tests Restriction Due to bandwidth limitations, the accuracy of this measurement is also limited, but a tendency of clock jitter is clearly visible. A failed test result does not mean that the DUT will fail in an accurate measurement, but a passed test shows that there is no relevant jitter on the TMDS clock.
  • Page 403: Mhl Applications

    ® MHL Applications R&S MHL Generator Application 12 MHL Applications ● MHL Generator Application...................403 ● MHL Analyzer Application..................437 12.1 MHL Generator Application Requires the following options: ● HDMI RX/TX 600 MHz module (R&S VT-B2363) or MHL RX/TX module (R&S VT- B2350) ●...
  • Page 404 Enables or disables the output. ● "On" ● "Off" Note: To indicate the output at your R&S VTS, click "Indicate". A flashing LED indicates the output until you click "OK". Remote command: READ<hw>:AVGen:OUTPut:HPDout<1 to 4>[:STATe]? CONFigure<hw>:AVGen:OUTPut:MHLout<1 to 4>[?] OFF|ON HDCP Enables or disables the HDCP encryption.
  • Page 405: Signal Subtab

    ® MHL Applications R&S MHL Generator Application ● "DDC Error" ● "Unavailable" ● "Bad Key" ● "Init" ● "Sync" ● "Init Keys" ● "Active" Remote command: READ<hw>:AVGen:OUTPut:HDCPstate<1 to 4>? Hot Plug Detect Displays the status of the hot plug detect connection. ●...
  • Page 406 ® MHL Applications R&S MHL Generator Application Video Code........................407 Format Filter........................407 └ Resolution..................... 408 └ Frame Rate....................408 └ Aspect Ratio....................408 Video Configuration.....................408 └ Video Configuration dialog................408 └ Component Format................408 └ Quantization Range................408 └ Pixelshift Vertical.................409 └ Vertical....................409 └...
  • Page 407 ® MHL Applications R&S MHL Generator Application └ H. Sync. Polarity................... 415 └ Pixel Repetition..................... 416 └ Pixel Frequency.................... 416 └ V. Active Lines....................416 └ V. Front Porch Lines..................416 └ V. Sync. Lines....................416 └ V. Back Porch Lines..................416 └...
  • Page 408 ® MHL Applications R&S MHL Generator Application Resolution ← Format Filter Click the button to open the "Resolution" dialog and select the resolution in the format filter. If you want to choose a predefined parameter, click the corresponding parameter but- ton to enable the filter function for the "Video Code"...
  • Page 409 ® MHL Applications R&S MHL Generator Application Pixelshift Vertical ← Video Configuration dialog ← Video Configuration Scrolls the screen contents in the selected velocity and direction. ● "On" ● "Off" Remote command: CONFigure<hw>:AVGen:SIGNal:VIDConf:PIXVertical[?] OFF|ON Vertical ← Video Configuration dialog ← Video Configuration Selects the scroll velocity and direction.
  • Page 410 ® MHL Applications R&S MHL Generator Application Note: This setting only effects the video signal. It has no has no impact on the setting of the MHL interface. Example: If a 12 bit signal is selected and the resolution clipping is set to 8 bit, the sig- nal is transmitted as a 12 bit signal, but the lower four bits of the signal are set to zero.
  • Page 411 ® MHL Applications R&S MHL Generator Application Remote command: CONFigure<hw>:AVGen:SIGNal:VIDConf:LEVel:B[?] 0.0 PCT to 200.0 PCT Y Level ← Video Configuration dialog ← Video Configuration Only available if "YCbCr x:x:x" is set under "Component Format" on page 408. Sets the individual variation of the signal components amplitude. ●...
  • Page 412 ® MHL Applications R&S MHL Generator Application Adds a DC offset to the green signal. ● "0.0" to "100.0" Percentage of the nominal picture level that is used as offset. Remote command: CONFigure<hw>:AVGen:SIGNal:VIDConf:GOFFset[?] 0.0 PCT to 100.0 PCT B Offset ← Video Configuration dialog ← Video Configuration Only available if "RGB"...
  • Page 413 ® MHL Applications R&S MHL Generator Application The gray label indicates the most important settings of the audio configuration. Audio Configuration dialog ← Audio Configuration Groups the parameters to configure the audio signal. Audio ← Audio Configuration dialog ← Audio Configuration Sets the audio source.
  • Page 414 ® MHL Applications R&S MHL Generator Application Channel Allocation ← Audio Configuration dialog ← Audio Configuration Only available if "Generator" is set under "Audio" on page 413. Specifies the speaker allocation. ● "0" to "31" Successive abbreviations see Table 10-7. The list is in accordance with the CEA-861-E specification.
  • Page 415 ® MHL Applications R&S MHL Generator Application User Defined Video Timing Configuration dialog Groups the parameters to define the video timing configuration. To open the dialog, see "Resolution" on page 408. H. Active Pixels ← User Defined Video Timing Configuration dialog Sets the number of horizontal active pixels.
  • Page 416 ® MHL Applications R&S MHL Generator Application Pixel Repetition ← User Defined Video Timing Configuration dialog Sets the number of repeated pixels. ● "None" to "10" Remote command: CONFigure<hw>:AVGen:SIGNal:VICD:CUSTom:PXRepetition[?] 1 to 10 (1 = "None") Pixel Frequency ← User Defined Video Timing Configuration dialog Sets the actual pixel frequency.
  • Page 417: Infoframe Subtab

    ® MHL Applications R&S MHL Generator Application V. Sync. Polarity ← User Defined Video Timing Configuration dialog Sets the vertical synchronization polarity. ● "Positive" ● "Negative" Remote command: CONFigure<hw>:AVGen:SIGNal:VICD:CUSTom:VPOLarity[?] POSitive|NEGative Video Format ← User Defined Video Timing Configuration dialog Sets the video format. ●...
  • Page 418 ® MHL Applications R&S MHL Generator Application Packet Type........................ 419 <Common InfoFrame parameters>................419 └ Type Number (hex)..................419 └ Version......................419 └ Length of InfoFrame..................420 └ Checksum (hex)....................420 <AVI InfoFrame parameters>..................420 └ Component Format..................420 └ Active Format Information Present............... 420 └...
  • Page 419 ® MHL Applications R&S MHL Generator Application └ Code Extension.....................425 └ Channel Allocation..................425 └ Downmix Inhibit.....................425 └ Level Shift Value................... 425 └ LFE Playback Level..................425 <SPD InfoFrame parameters>..................425 └ Active......................425 └ Vendor Name....................426 └ Product Description..................426 └...
  • Page 420 ® MHL Applications R&S MHL Generator Application Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:VERSion? CONFigure<hw>:AVGen:INFoframe:AUDio:VERSion? CONFigure<hw>:AVGen:INFoframe:SPD:VERSion? CONFigure<hw>:AVGen:INFoframe:MPEG:VERSion? CONFigure<hw>:AVGen:INFoframe:VSIF:VERSion? Length of InfoFrame ← <Common InfoFrame parameters> Displays the length of the Info Frame. Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:LENGth[?] CONFigure<hw>:AVGen:INFoframe:AUDio:LENGth[?] CONFigure<hw>:AVGen:INFoframe:SPD:LENGth[?] CONFigure<hw>:AVGen:INFoframe:MPEG:LENGth[?] CONFigure<hw>:AVGen:INFoframe:VSIF:LENGth[?] Checksum (hex) ← <Common InfoFrame parameters> Displays the checksum hexadecimal.
  • Page 421 ® MHL Applications R&S MHL Generator Application ● "Both Bars" Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:BARinfo[?] NONE|HORZ|VERT|BOTH Scan Information ← <AVI InfoFrame parameters> ● "No Data" ● "Overscan" ● "Underscan" Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:SCANinfo[?] 0 to 2 (0 = "No Data",1 = "Overscan", 2 = "Underscan") Colorimetry ←...
  • Page 422 ® MHL Applications R&S MHL Generator Application IT Content ← <AVI InfoFrame parameters> ● "On" ● "Off" Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:ITContent[?] OFF|ON Extended Colorimetry ← <AVI InfoFrame parameters> ● "xvYCC 601" ● "xvYCC 709" ● "sYCC 601" ● "Adobe YCC 601" ●...
  • Page 423 ® MHL Applications R&S MHL Generator Application ● "Full Range" Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:YCCQuant[?] 0 to 1 (0 = "Limited Range", 1 = "Full Range") Content Type ← <AVI InfoFrame parameters> ● "Graphics" ● "Photo" ● "Cinema" ● "Game" Remote command: CONFigure<hw>:AVGen:INFoframe:AUX:CONTenttype[?] GRAPhics|PHOTo|CINema| GAME Line Number of Top Bar End ←...
  • Page 424 ® MHL Applications R&S MHL Generator Application ● "Enhanced AC-3" ● "DTS-HD" ● "MAT" (MLP) ● "DST" ● "WMA Pro" ● "Extended" Remote command: CONFigure<hw>:AVGen:INFoframe:AUDio:CODE:TYPE[?] 0 to 15 (0 = "Stream Header", 1 = "PCM", 2 = "AC-3", 3 = "MPEG-1", 4 = "MP3", 5 = "MPEG-2", 6 = "AAC LC", 7 = "DTS", 8 = "ATRAC", 9 = "One bit Audio", 10 = "Enhanced AC-3", 11 = "DTS-HD", 12 = "MAT", 13 = "DST", 14 = "WMA Pro", 15 = "Extended")
  • Page 425 ® MHL Applications R&S MHL Generator Application Code Extension ← <Audio InfoFrame parameters> ● "Coding Type" ● "MPEG-4 HE ACC" ● "MPEG-4 HE ACC v2" ● "MPEG-4 ACC LC" ● "DRA" ● "MPEG-4 HE ACC + MPEG Surround" ● "MPEG-4 AAC LC + MPEG Surround" = 10 Remote command: CONFigure<hw>:AVGen:INFoframe:AUDio:CODE:EXTension[?] 0 to 10 (0 = "Coding Type", 4 = "MPEG-4 HE ACC", 5 = "MPEG-4 HE ACC v2", 6 = "MPEG-4...
  • Page 426 ® MHL Applications R&S MHL Generator Application Remote command: CONFigure<hw>:AVGen:INFoframe:SPD:ACTive[?] OFF|ON Vendor Name ← <SPD InfoFrame parameters> ● "Read only" Remote command: CONFigure<hw>:AVGen:INFoframe:SPD:VENDor[?] "<string>" Product Description ← <SPD InfoFrame parameters> ● "Read only" Remote command: CONFigure<hw>:AVGen:INFoframe:SPD:PRODuct[?] "<string>" Source Information ← <SPD InfoFrame parameters> ●...
  • Page 427 ® MHL Applications R&S MHL Generator Application Remote command: CONFigure<hw>:AVGen:INFoframe:MPEG:BITRate[?] 0 to 2^31 Field Repeat (for 3:2 Pull-Down) ← <MPEG InfoFrame parameters> ● "On" ● "Off" Remote command: CONFigure<hw>:AVGen:INFoframe:MPEG:FREPeat[?] OFF|ON MPEG Frame ← <MPEG InfoFrame parameters> Enables or disables the MPEG InfoFrame. ●...
  • Page 428: Edid Reader Subtab

    ® MHL Applications R&S MHL Generator Application Remote command: CONFigure<hw>:AVGen:INFoframe:VSIF:VSVersion[?] 0 to 255 3D Format Type ← <Vendor specific InfoFrame parameters> ● "Frame Sequential" ● "Top Bottom" ● "Left Right" HB0 to HB2 Header bytes 0 to 2; "HB0" is read-only, except if "Gamut Boundary Data", "ISRC1" or "ISCR2"...
  • Page 429 ® MHL Applications R&S MHL Generator Application Select Output......................429 Save EDID Data......................429 Update.........................429 <SCPI EDID binary read out>..................429 Select Output Sets the output for the EDID reading. ● "MHL Out 1" ● "MHL Out 2" ● "MHL Out 3" ●...
  • Page 430: Cts Subtab

    ® MHL Applications R&S MHL Generator Application 12.1.6 CTS Subtab Requires an additional option for the MHL CTS sink test: R&S VT-K355. See also the data sheet. Executes sink and dongle tests according to the compliance test specifications (CTS). Divided into two panes. The left pane displays the compliance test results. Remote commands to query measurement results READ<hw>[:SCALar]:AVGen:CTS:REPort:COUNt? READ<hw>[:SCALar]:AVGen:CTS:REPort? <integer>|MINimum|MAXimum|UP|DOWN...
  • Page 431 ® MHL Applications R&S MHL Generator Application <Test case> button Displays the selected test case. The test case name consists of: ● Chapter number of the MHL compliance test specifications where the test case is described. ● Test case identifier Click this button to select another test case, see "Test Case dialog"...
  • Page 432 ® MHL Applications R&S MHL Generator Application Table 12-2: Dongle tests Test case name Remote command parameter (<test case>) 5.2.1.1/3 Character Synchronization M011_csync 5.2.1.1/3 Packet Types M012_ptype 5.2.2.1/4 Video Formats M013_vformat 5.2.2.2/5 Pixel Encoding M014_pixel 5.2.2.3 Video Quantization Range M015_vqrange 5.2.3.1 IEC60958 / IEC61937 M016_iec6 5.2.3.2 Audio Clock Regeneration...
  • Page 433 ® MHL Applications R&S MHL Generator Application Presets the video format. If this setting does not match the actual video format of the input signal, the test result will be "Failed". Remote command: CONFigure<hw>:AVGen:CTS:VFORmat[?] <test case>,C2|C3|C4|C5|C6|C7|C17|C18| C19|C20|C21|C22|C34|C1|C32|C31|C16 with <test case> see "<Test cases>"...
  • Page 434: Cbus Subtab

    ® MHL Applications R&S MHL Generator Application Remote command: CONFigure<hw>:AVGen:CTS:NVALue[?] <test case>,NMIN|NMAX with <test case> see "<Test cases>" on page 431 Key ID ← CTS Configuration dialog Relevant for the following tests: ● "4/5.2.6.1 RCP Sub-Commands Receiving Test" ● "4/5.2.6.2 RCP Sub-Commands Transmitting Test" Sets the RCP key ID that is used for the selected test.
  • Page 435 ® MHL Applications R&S MHL Generator Application Remote commands to query results READ<hw>[:SCALar]:AVGen:CBUS:REPort:COUNt? READ<hw>[:SCALar]:AVGen:CBUS:REPort? <integer>|MINimum|MAXimum|UP| DOWN READ<hw>[:SCALar]:AVGen:OUTPut:CBUS? Layer........................... 435 Command and Parameters..................436 Send button.........................436 Start button........................436 Stop button........................436 Save button......................... 437 Layer Depending on the selected protocol layer, various commands and command parame- ters are supported.
  • Page 436 ® MHL Applications R&S MHL Generator Application Used to send or receive commands based on the UCP (UTF-8 character protocol) protocol layer. See also "Command and Parameters" on page 436. Remote command: CONFigure<hw>:AVGen:CBUS:LAYer[?] MSC|RAP|RCP|UCP Command and Parameters For the MSC, RCP and RAP protocol layers, a button with the selected command is displayed.
  • Page 437: Mhl Analyzer Application

    ® MHL Applications R&S MHL Analyzer Application Save button Opens the "File" dialog to save the protocol trace in a file. See also Chapter 5.3, "File Dialog", on page 82. Remote command: MMEMory<hw>:AVGen:CBUS:DATA:STORe[?] "<filename>" 12.2 MHL Analyzer Application Requires the following options: ●...
  • Page 438: Input Subtab

    ® MHL Applications R&S MHL Analyzer Application ROUTe<hw>:MHL:ISELect:VERSion[?] 12|21 ROUTe<hw>:MHL:ISELect[?] MHL13|MHL12|MHL|MHL21|MHL20 12.2.2 Input Subtab Displays the input parameters and the present video signal. ► To enlarge the thumbnail picture to full-screen size, click the picture. You can also add the thumbnail picture to your favorites. Signal........................438 HDCP..........................
  • Page 439 R&S MHL Analyzer Application HDCP Enables or disables the HDCP encryption. ● "On" If the source sends a signal with HDCP, the R&S VTS uses HDCP. ● "Off" R&S VTS does not use HDCP. Remote command: CONFigure<hw>:MHL:INPut:HDCP[?] OFF|ON User Defined EDID Changes the EDID settings.
  • Page 440: Video Subtab

    HDMI RX/TX 600 MHz module (R&S VT-B2363) or MHL RX/TX module (R&S VT- B2350) Used for all MHL signals that are encoded in normal mode (24-bit per pixel mode). Note: To indicate the input at your R&S VTS, click "Indicate". A flashing LED indicates the input until you click "OK". Remote command: ROUTe<hw>:MHL:MODule:SELect[?] "<module name>"...
  • Page 441 ® MHL Applications R&S MHL Analyzer Application Video Code........................441 Pixel Clock........................441 Vertical Frequency...................... 441 Horizontal Frequency....................441 Horizontal Video Parameters..................441 └ H. Total Pixels....................441 └ H. Active Pixels..................... 442 └ H. Front Porch Pixels..................442 └ H. Sync. Pixels....................442 └...
  • Page 442 ® MHL Applications R&S MHL Analyzer Application H. Active Pixels ← Horizontal Video Parameters Displays the number of horizontal active pixels. Remote command: READ<hw>[:SCALar]:MHL:VIDeo:HPIXel:ACTive? H. Front Porch Pixels ← Horizontal Video Parameters Displays the number of horizontal front porch pixels. Remote command: READ<hw>[:SCALar]:MHL:VIDeo:HPIXel:FPORch? H.
  • Page 443: Audio Subtab

    ® MHL Applications R&S MHL Analyzer Application V. Back Porch Lines ← Vertical Video Parameters Displays the number of vertical back porch pixels. Remote command: READ<hw>[:SCALar]:MHL:VIDeo:VLINe:BPORch? V. Sync. Polarity ← Vertical Video Parameters Displays the vertical synchronization polarity. Remote command: READ<hw>[:SCALar]:MHL:VIDeo:VLINe:SYNC:POLarity? 12.2.4 Audio Subtab Displays all audio related measurement values.
  • Page 444 ® MHL Applications R&S MHL Analyzer Application └ Clock Accuracy..................... 445 └ Max. Audio Length..................445 └ Audio Length....................445 Displays the N value derived from the audio clock regeneration packet. The formula for calculation is displayed at the right of the field. Remote command: READ<hw>[:SCALar]:MHL:AUDio:N? Displays the CTS (cycle timestamp) value derived from the audio clock regeneration...
  • Page 445 ® MHL Applications R&S MHL Analyzer Application Remote command: READ<hw>[:SCALar]:MHL:AUDio:COPYright? Preemphasis ← Channel Status Bits Displays the preemphasis. Remote command: READ<hw>[:SCALar]:MHL:AUDio:PREemphasis? Mode ← Channel Status Bits Displays the mode. Remote command: READ<hw>[:SCALar]:MHL:AUDio:MODE? Category Code ← Channel Status Bits Displays category code. Remote command: READ<hw>[:SCALar]:MHL:AUDio:CATegory? Source Number ←...
  • Page 446: Hdcp Subtab

    ® MHL Applications R&S MHL Analyzer Application 12.2.5 HDCP Subtab Displays all HDCP content protection related measurement values. See the HDCP specification. Authentication......................446 HDCP.......................... 446 AKSV...........................446 BKSV...........................446 '..........................447 ..........................447 Re-Authentication button.....................447 Authentication Displays if an HDCP authentication was attempted by the MHL source. Remote command: READ<hw>[:SCALar]:MHL:HDCP:AUTHentic? HDCP...
  • Page 447: Infoframe Subtab

    ® MHL Applications R&S MHL Analyzer Application Remote command: READ<hw>[:SCALar]:MHL:HDCP:BKSV? Displays the current link synchronization verification values. Remote command: READ<hw>[:SCALar]:MHL:HDCP:RI? Displays the session random number. Remote command: READ<hw>[:SCALar]:MHL:HDCP:AN? Re-Authentication button Each time the button is pressed, triggers the source's re-authentication by clearing the current R ' value.
  • Page 448 ® MHL Applications R&S MHL Analyzer Application Packet Type Sets the InfoFrame packet filter for one of the following InfoFrames. All other parame- ters that are displayed relate information about this InfoFrame. ● "AVI InfoFrame (0x82)" Contains all video related information, e.g. video code or pixel encoding. The usage of this InfoFrame is mandatory for MHL source devices.
  • Page 449 ® MHL Applications R&S MHL Analyzer Application Parameter Remote command Content Type READ<hw>[:SCALar]:MHL:INFO:AVI:CTYPe? Pixel Repetition READ<hw>[:SCALar]:MHL:INFO:AVI:PREPetition? Line Number of Top Bar End READ<hw>[:SCALar]:MHL:INFO:AVI:LINE:END? Line Number of Bottom Bar READ<hw>[:SCALar]:MHL:INFO:AVI:LINE:STARt? Start Pixel Number of Left Bar End READ<hw>[:SCALar]:MHL:INFO:AVI:PIXel:LEFT? Pixel Number of Right Bar Start READ<hw>[:SCALar]:MHL:INFO:AVI:PIXel:RIGHt? <Audio InfoFrame parameters>...
  • Page 450: Cts Subtab

    ® MHL Applications R&S MHL Analyzer Application <MPEG InfoFrame parameters> Parameter Remote command HB0 to HB3 (header bytes) READ<hw>[:SCALar]:MHL:INFO:MPEG:PDATa? PB0 to PB10 (packet bytes) Version READ<hw>[:SCALar]:MHL:INFO:MPEG:VERSion? Checksum READ<hw>[:SCALar]:MHL:INFO:MPEG:CSUM? Length READ<hw>[:SCALar]:MHL:INFO:MPEG:LENGth? MPEG Bit Rate READ<hw>[:SCALar]:MHL:INFO:MPEG:MPEG:BRATe? Field Repeat (for 3:2 Pull- READ<hw>[:SCALar]:MHL:INFO:MPEG:FREPeat? Down) MPEG Frame READ<hw>[:SCALar]:MHL:INFO:MPEG:MPEG:FRAMe?
  • Page 451 ® MHL Applications R&S MHL Analyzer Application <Test case> button......................451 └ Test Case dialog................... 452 └ <Test cases>....................452 CTS Configuration dialog.................... 453 └ Video Format....................453 └ Pixel Encoding....................453 └ Test Pattern....................453 └ Video Quantization Ranges Test Setup............454 └...
  • Page 452 ® MHL Applications R&S MHL Analyzer Application Click to configure the selected test, see "CTS Configuration dialog" on page 453. Test Case dialog ← <Test case> button Displays all available test cases, see "<Test cases>" on page 452. The availability of some tests depends on the following settings: ●...
  • Page 453 Sets the video format that is applied to the selected test. ● "Auto Detect" Automatic video format detection. ● <Video format> Presets the video format. R&S VTS signals this video format as exclusively suppor- ted video format to the DUT. Remote command: CONFigure<hw>:MHL:CTS:VFORmat[?] <test case>,AUTO|C1|C2|C3|C4|C5|C6|C7| C17|C18|C19|C20|C21|C22|C32|C34|C31|C16 with <test case> see "<Test cases>"...
  • Page 454 Relevant for the following test: "3.2.3.4 Video Quantization Ranges" Sets the test setup that is applied to this test. ● "YCbCr QY = 0" QY bit is set to 0 in the R&S VTS's EDID. DUT output: YCbCr 4:2:2 or YCbCr 4:4:4 signal. ● "YCbCr QY = 1"...
  • Page 455 ® MHL Applications R&S MHL Analyzer Application ● "3.2.3.4 Video Quantization Ranges" ● "3.2.4.1 IEC60958 / IEC61937" ● "3.2.4.2 Audio Clock Regeneration" ● "3.2.4.3 Audio InfoFrame" Sets the length of the MHL sequence for analysis. ● "Frames" Number of video frames that are analyzed. ●...
  • Page 456 ® MHL Applications R&S MHL Analyzer Application Data Source Sets the source of the data to be analyzed. ● "Automatic Capture" The MHL data is automatically captured and tested. After the test has been fin- ished, you can save the data in a file, see "Save button"...
  • Page 457: Cbus Subtab

    ® MHL Applications R&S MHL Analyzer Application Save button (Test Output) Opens the "File" dialog to save the test output. See also Chapter 5.3, "File Dialog", on page 82. The 3 TMDS characters for channel 0, channel 1 and channel 2 are stored in a 4 byte word as shown in Figure 12-1.
  • Page 458 ® MHL Applications R&S MHL Analyzer Application READ<hw>[:SCALar]:MHL:CBUS:REPort? <integer>|MINimum|MAXimum|UP|DOWN Layer........................... 458 Command and Parameters..................459 Send button.........................459 Start button........................459 Stop button........................459 Save button......................... 459 Layer Depending on the selected protocol layer, various commands and command parame- ters are supported. See the MHL specification for information on the purpose and the syntax of each command.
  • Page 459 ® MHL Applications R&S MHL Analyzer Application Command and Parameters For the MSC, RCP and RAP protocol layers, a button with the selected command is displayed. Click this button to select another command. For UCP protocol layers, enter the UCP command as text string. For the MSC protocol layers, depending on the selected command, additional configu- ration parameters may be required to complete the command.
  • Page 460: Remote Control Basics

    Commands and responses are transmitted on the data lines, with the attention line being active (LOW). They are used to communicate between the controller and the R&S VTS and are distinguished by the direction they are sent. For information on the supported commands, see Chapter 14, "Remote Command...
  • Page 461: Scpi Command Syntax

    SCPI Command Syntax Instrument responses Instrument responses (response messages and service requests) are sent from the R&S VTS to the controller after a query. They can contain measurement results, set- tings and information on the status. 13.2 SCPI Command Syntax The commands consist of a so-called header and, in most cases, one or more parame- ters.
  • Page 462 Some command systems permit certain mnemonics to be optionally inserted into the header or omitted. These mnemonics are marked by square brackets in this manual. The R&S VTS must recognize the long command to comply with the SCPI standard. Some commands are considerably shortened by omitting optional mnemonics.
  • Page 463 ® Remote Control Basics R&S SCPI Command Syntax Numeric suffixes in angle brackets If a command can be applied to multiple instances of an object, for example several inputs, the required instances is specified by a suffix added to the command. Numeric suffixes are indicated by angle brackets (<1...4>, <n>, <i>) and are replaced by a sin- gle value in the command.
  • Page 464 Numerical values can contain a sign or decimal point. Values exceeding the resolution of the R&S VTS are rounded up or down. The mantissa may comprise up to 255 char- acters, the values must be in the value range -9.9 x 10 to 9.9 x 10...
  • Page 465 ® Remote Control Basics R&S SCPI Command Syntax Represents the value 9.91E37. Only sent as device response. This value is not defined. Possible causes are division by zero, subtraction or addition of infinite and the representation of missing values. Boolean parameters "Parameters"...
  • Page 466 ® Remote Control Basics R&S SCPI Command Syntax 13.2.2.2 Overview of the Syntax Elements Syntax element Description The colon separates the mnemonics of a command. In a command line, the sep- arating semicolon marks the uppermost command level. The semicolon separates two commands of a command line. It does not alter the path.
  • Page 467 ® Remote Control Basics R&S SCPI Command Syntax Example: SOURce:IQCoder:DVBT:DATA ON;:SOURce:IQCoder:DVBT:FFT:MODE M2K This command line is represented in its full length and contains 2 commands separa- ted from each other by the semicolon. Both commands are part of the SOURce com- mand system, IQCODER, DVBT subsystem, that means they have 3 common levels.
  • Page 468: Command Sequence And Synchronization

    Use one of commands in Table 13-1 to synchronize controller and R&S VTS. All three commands cause a certain action only to be carried out after the hardware has been set and has settled. By suitable programming, the controller can be forced to wait for the respective action to occur.
  • Page 469: Hierarchy Of Status Registers

    The event status register (ESR) which is also defined in IEEE 488.2 with the asso- ciated mask register standard event status enable (ESE). ● STATus:OPERation and STATus:QUEStionable which are defined by SCPI and contain detailed information on the R&S VTS. User Manual 2116.1228.02 ─ 14...
  • Page 470: Structure Of A Scpi Status Register

    ® Remote Control Basics R&S Status Reporting System The individual status flag (IST), like the SRQ, combines the entire instrument status in a single bit. The parallel poll enable register (PPE) fulfills the same function for the IST flag as the SRE for the service request. The output buffer contains the messages the instrument returns to the controller.
  • Page 471 Indicates whether an event has occurred since the last reading, it is the "memory" of the CONDition part. It only indicates events passed on by the transition filters. It is permanently updated by the R&S VTS. This part is read-only. Reading the register clears it. This part is often equated with the entire register.
  • Page 472: Contents Of The Status Registers

    ® Remote Control Basics R&S Status Reporting System Sum bit Is obtained from the EVENt and ENABle part for each register. The result is entered into a bit of the CONDition part of the higher-order register. The instrument automatically generates the sum bit for each register. Thus an event can lead to a service request throughout all levels of the hierarchy.
  • Page 473 The bit is set if an EVENt bit is set in the OPERation status register and the associ- ated ENABle bit is set to 1. A set bit indicates that the R&S VTS is just performing an action. The type of action can be queried by polling the OPERation status register.
  • Page 474 Meaning Query error This bit is set if either the controller wants to read data from the R&S VTS without hav- ing sent a query, or if it does not fetch requested data and sends new instructions to the R&S VTS instead. The cause is often a query which is faulty and hence cannot be executed.
  • Page 475: Application Of The Status Reporting System

    After its settings have been completed, the instrument generates an SRQ. The SRQ is the only possibility for the R&S VTS to become active on its own. Each controller program should set the R&S VTS such that a service request is initiated in the case of malfunction.
  • Page 476 ® Remote Control Basics R&S Status Reporting System Parallel poll Using a single command, the controller requests up to eight instruments to transmit one bit of information each on the data lines, that means to set the data line allocated to each instrument to a logical "0"...
  • Page 477: Reset Values Of The Status Reporting Systems

    ® Remote Control Basics R&S General Programming Recommendations 13.3.5 Reset Values of the Status Reporting Systems The following table contains the different commands and events causing the status reporting system to be reset. With the exception of *RST and SYSTem:PRESet, no command influences the functional instrument settings.
  • Page 478 ® Remote Control Basics R&S General Programming Recommendations adapted. Therefore, control programs should always define an initial instrument status (e.g. using the *RST command) and then implement the required settings. Command sequence As a general rule, send commands and queries in different program messages. Other- wise, the result of the query may vary depending on which operation is performed first (see also Preventing Overlapping Execution).
  • Page 479: Remote Command Reference

    Notation 14 Remote Command Reference This chapter describes all remote control commands of the R&S VTS. For each appli- cation, the commands are first listed for quick access, followed by a description of each command. An alphabetic list of all commands is given at the end of the manual.
  • Page 480: Addressing Module Slots

    [<module slot>] with <module slot> = L1 Make sure that the string parameters match the installed options of the remote control- led R&S VTS. Example: ROUTe<hw>:HDMI:MODule:SELect[?] "HDMI [L1]" Selects the HDMI CTS RX/TX 600 MHz module (R&S VT-B2362) in slot L1 as input.
  • Page 481: Common Commands

    ® Remote Command Reference R&S Common and General Commands ● Common Commands.................... 481 ● CALibration Subsystem..................486 ● DIAGnostic Subsystem..................486 ● HCOPy Subsystem....................486 ● INSTrument Subsystem..................487 ● MMEMory Subsystem................... 489 ● SENSe Subsystem....................496 ● SOURce Subsystem..................... 497 ● STATus Subsystem....................
  • Page 482 Event status read Returns the content of the event status register and sets the register to zero. Return values: <Content> Decimal form Usage: Query only *IDN? Identification query Returns the identification of the R&S VTS: <Manufacturer>,<ProductType>,<PartSerialNumber>,<FirmwareVersion> User Manual 2116.1228.02 ─ 14...
  • Page 483 Common and General Commands Return values: <Manufacturer> Manufacturer, for example Rohde & Schwarz <ProductType> Product type, for example R&S VTS <PartSerialNumber> <part number>/<serial number> If this information is not available, 0 is returned. <FirmwareVersion> Firmware version If this information is not available, 0 is returned.
  • Page 484 485 *SAV ● on page 496 MMEMory:STORe:STATe Setting parameters: <Memory> Number that corresponds to the intermediate memory stored under: D:\VTS\UserData\Quick Range: 1 to 5 Example: *RCL 2 Loads the Quick2.savrcl file. Usage: Setting only Manual operation: "Quick Device dialog"...
  • Page 485 ® Remote Command Reference R&S Common and General Commands *RST Reset Resets the R&S VTS, that means sets it to a defined default status. Usage: Setting only *SAV <Memory> Save Saves the current instrument data in an intermediate memory. To load the saved data, use on page 484.
  • Page 486: Calibration Subsystem

    ® Remote Command Reference R&S Common and General Commands Triggers all actions waiting for a trigger event. Usage: Event *TST? Self-test query Triggers all self-tests of the instrument and outputs an error code in decimal form. Return values: <Result> Passed Failed Usage: Query only...
  • Page 487: Instrument Subsystem

    Setting parameters: <Path> Path including the filename. The file extension is specified by HCOPy:DEVice:FORMat on page 487. Example: HCOP:FILE "D: \VTS\UserData\Hardcopy\measurement1" Usage: Setting only Manual operation: "File Name" on page 85 14.2.5 INSTrument Subsystem Managing applications. User Manual 2116.1228.02 ─ 14...
  • Page 488 ® Remote Command Reference R&S Common and General Commands Table 14-1: Application names Application Remote control string ("<Application>") Audio analyzer AUDIO AV distortion analyzer AVDA CEC/DDC analyzer HDMI analyzer HDMIRX HDMI generator HDMITX MHL analyzer MHLRX MHL generator MHLTX Time Domain Analyzer VIDEO Video analyzer .....................488...
  • Page 489: Mmemory Subsystem

    ® Remote Command Reference R&S Common and General Commands 14.2.6 MMEMory Subsystem Manages files and directories. Loads and saves instrument and user data. To change and query the current directory, use on page 491. MMEMory:CDIRectory Further information: ● Available file types see Table 5-1 ●...
  • Page 490 List containing strings of all files and their attributes in the speci- fied path: "<Filename1>,<FileAttribute1>","<Filename2>,<FileAttri- bute2>",... The first 2 strings are related to the parent directory. MMEM:ATTR "D:\VTS\UserData\*.log", "-R" Example: Deletes the write protection for all *.log files in the D:\VTS\UserData directory. Example: MMEM:ATTR? "D:\VTS\UserData\Hardcopy\*.*"...
  • Page 491 MMEM:CAT? "D:\VTS\UserData\Hardcopy" Query 77615,261375090688,".,DIR,0","..,DIR,0", "des.png,BIN,36460" Response: used disk space: 77.615 kbyte; remaining disk space: 261.375090688 Gbyte; no files in the UserData direc- tory (".,DIR,0") and the VTS directory ("..,DIR,0"); des.png file, binary, 36.460 kbyte ("des.png,BIN,36460") Usage: Query only Manual operation: "<Folders>"...
  • Page 492 Writes the <BinaryBlock> data to a file specified by <PathFile>. Set the GPIB bus ter- minator to EOI in order to ensure correct data transfer. The associated query transfers the specified file from the R&S VTS to the control com- puter. Make sure that the intermediate memory on the control computer is large enough to receive the file.
  • Page 493 Path and filename including the extension. If the path is omitted, the current directory is used. Example: MMEM:DATA "D:\VTS\UserData\test1.txt",#15hallo Writes the binary block data to the test1.txt file. <number> = 1, <length entry> = 5, <block data> = hallo Manual operation: "File Name"...
  • Page 494 Common and General Commands Parameters for setting and query: <PathFile> Path and filename including the extension. If the path is omitted, the current directory is used. Example: MMEM:DEL "D:\VTS\UserData\Hardcopy\test.png" Deletes the test.png file in the D:\VTS\UserData\Hardcopy directory. Usage: Setting only Manual operation: "Delete button"...
  • Page 495 ® Remote Command Reference R&S Common and General Commands MMEMory:MDIRectory <PathDirectory> Creates a new subdirectory or directory tree in a directory. Setting parameters: <PathDirectory> Directory name or directory tree; if the path is omitted, the cur- rent directory is used. Example: MMEM:MDIR "MyFiles\New"...
  • Page 496: Sense Subsystem

    <PathFile> Path and filename including the extension. If the path is omitted, the current directory is used. <Msus> Example: MMEM:STOR:STAT 4,"D:\VTS\UserData\test4.savrcl" Saves the instrument settings from intermediate memory 4 in the test4.savrcl file . Usage: Setting only 14.2.7 SENSe Subsystem Configures the reference frequency.
  • Page 497: Source Subsystem

    ® Remote Command Reference R&S Common and General Commands SENSe:ROSCillator[:INTernal]:ADJust[:STATe] <Enable> on page 497 [SOURce<hw>:]ROSCillator[:INTernal]:ADJust[:STATe] 14.2.8 SOURce Subsystem Configures the following: ● Reference frequency ....................497 [SOURce<hw>:]ROSCillator ............497 [SOURce<hw>:]ROSCillator[:INTernal]:ADJust:VALue ............497 [SOURce<hw>:]ROSCillator[:INTernal]:ADJust[:STATe] [SOURce<hw>:]ROSCillator <ReferenceFreq> Sets the reference frequency source. Alias: SENSe:ROSCillator:SOURce Suffix: <hw>...
  • Page 498: Status Subsystem

    STATus:OPERation:CONDition? Queries the content of the CONDition part of the STATus:OPERation register. Provides information about the action currently executed by the R&S VTS. After the readout, the content is retained because it is the current hardware status. User Manual 2116.1228.02 ─ 14...
  • Page 499 All events are forwarded. STATus:OPERation[:EVENt]? Queries the content of the EVENt part of the STATus:OPERation register. Provides information about the actions executed by the R&S VTS since the last read- out. After the readout, the content is deleted. Return values: <RegisterValue>...
  • Page 500 Event STATus:QUEStionable:CONDition? Queries the content of the CONDition part of the STATus:QUEStionable register. Provides information about the action currently executed by the R&S VTS. After the readout, the content is retained because it is the current hardware status. Return values: <RegisterValue>...
  • Page 501 STATus:QUEStionable[:EVENt]? Queries the content of the EVENt part of the STATus:QUEStionable register. Provides information about the actions executed by the R&S VTS since the last read- out. After the readout, the content of the EVENt part is deleted. Return values: <RegisterValue>...
  • Page 502: System Subsystem

    ® Remote Command Reference R&S Common and General Commands Alias: on page 508 SYSTem:ERRor[:NEXT]? Return values: <ErrorCode> 1 to n Positive error number: device-specific error No error, error queue is empty. -n to -1 Negative error number: SCPI error message <ErrorDescription>...
  • Page 503 89 SYSTem:COMMunicate:NET:GATeway? Queries the default gateway. Example: SYST:COMM:NET:GAT? Query "12.345.67.8" Response Usage: Query only Manual operation: "Gateways" on page 89 SYSTem:COMMunicate:NET:HOSTname? Queries the hostname (computer name). Return values: <ComputerName> Example: SYST:COMM:NET:HOST? Query "VTS-100104" Response User Manual 2116.1228.02 ─ 14...
  • Page 504 ® Remote Command Reference R&S Common and General Commands Usage: Query only Manual operation: "Host Name" on page 88 SYSTem:COMMunicate:NET:IPADdress? Queries the IP address. The TCP/IP protocol is pre-installed with the IP address 10.0.0.10. Example: SYST:COMM:NET:IPAD? Query "172.29.201.85" Response Usage: Query only Manual operation: "IP Addresses"...
  • Page 505 5025 Example: SYST:COMM:SOCK:PORT 5025 Manual operation: "Data Port" on page 91 SYSTem:COMMunicate:SOCKet<inst>:VRESource? Queries the resource name used by the programs for identification and control of the R&S VTS. Suffix: <inst> 1..* Selects the connection. Return values: <Name> TCPIP::host name::data port::SOCKET...
  • Page 506 <Path> Folder where the XML file is saved. Return values: <DeviceFootprint> Contents of the XML file as string. Example: SYST:DFPR "D:\VTS\UserData\Footprint" SYSTem:DISPlay:UPDate <Enable> Enables or disables updating the display. When changing to manual control, updating is automatically enabled. Parameters: <Enable>...
  • Page 507 ® Remote Command Reference R&S Common and General Commands <ErrorDescription> on page 501. STATus:QUEue[:NEXT]? Example: SYST:ERR:ALL? Query 0,"No error" Response Usage: Query only Manual operation: "[-350] Queue overflow" on page 1005 SYSTem:ERRor:CODE:ALL? Queries all entries in the error queue and deletes them. Only the error code is returned.
  • Page 508 501. STATus:QUEue[:NEXT]? Return values: <ErrorCode> <ErrorDescription> Usage: Query only SYSTem:HELP:HEADers? [<Parser>] Lists all possible remote commands of the R&S VTS together with their usage. Query parameters: <Parser> Return values: <SyntaxUsage> <dblock> #<number><length entry> <command syntax>[/<usage>] <com- mand syntax>[/<usage>], ...
  • Page 509 ® Remote Command Reference R&S Common and General Commands #<number><length entry> <command syntax> <command syn- tax>, ... Comes always first. <number> Indicates how many digits the subsequent length entry has. (5 in the example) <length entry> Indicates the number of subsequent characters. (91079 in the example) <command syntax>...
  • Page 510 Both FUNCtional and VALid Return values: <OptionList> Response string; see example Example: SYST:OPT:LIST? FWA,FUNC Query "FWA AudioAnalyzer,FWA HDMIGenerator" Response Usage: Query only SYSTem:REBoot Reboots the R&S VTS. Example: SYST:REB Usage: Event SYSTem:RESTart Restarts the firmware Example: SYST:REST Usage: Event SYSTem:SERRor? Returns a list of all errors that are currently present.
  • Page 511: Test Subsystem

    Each error is listed with its number and a short description. Example: SYST:SERR? Query 0,"No error" Response Usage: Query only SYSTem:SHUTdown Shuts down the R&S VTS. Example: SYST:SHUT Usage: Event 14.2.11 TEST Subsystem For service purposes only. 14.3 AV Distortion Analyzer Application These commands correlate to the functions provided in Chapter 7, "AV Distortion Ana-...
  • Page 512: Clear Subsystem

    ® Remote Command Reference R&S AV Distortion Analyzer Application Usage: Event Manual operation: "Stop button" on page 107 14.3.2 CLEar Subsystem CLEar<hw>:AVDA Clears all measurement results. Suffix: <hw> Irrelevant Usage: Event Manual operation: "Clear button" on page 107 14.3.3 CONFigure Subsystem ●...
  • Page 513 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <ColorModel> RGB | YPBPr *RST: Example: CONF:AVDA:COL:ANAL YPBP Manual operation: "Color" on page 122 14.3.3.3 CONFigure<hw>:AVDA:LIST Subsystem Commands with 2 Boolean parameters The first Boolean parameter enables or disables the parameter for the measurement. The second Boolean parameter enables or disables the parameter display on the "Trace"...
  • Page 514 ® Remote Command Reference R&S AV Distortion Analyzer Application ..........526 CONFigure<hw>:AVDA:LIST:FPOint:PICTure:PERiod:TOTal ............526 CONFigure<hw>:AVDA:LIST:FPOint:PICTure[:STATe] ............527 CONFigure<hw>:AVDA:LIST:FPOint:VERRor:DEFault ............ 527 CONFigure<hw>:AVDA:LIST:FPOint:VERRor:DURation ............528 CONFigure<hw>:AVDA:LIST:FPOint:VERRor:PSNR ............528 CONFigure<hw>:AVDA:LIST:FPOint:VERRor:SSIM ............528 CONFigure<hw>:AVDA:LIST:FPOint:VERRor[:STATe] ............529 CONFigure<hw>:AVDA:LIST:FREeze:APLThreshold ............. 529 CONFigure<hw>:AVDA:LIST:FREeze:DETecttime ............529 CONFigure<hw>:AVDA:LIST:LDETection:TIME:LIMit ............. 530 CONFigure<hw>:AVDA:LIST:LDETection:TIME[:STATe] ..............530 CONFigure<hw>:AVDA:LIST:LDETection[:STATe] .................530...
  • Page 515 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:APL:RESYnc <Value> Sets the threshold for APL resynchronization (PSNR). Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.0 to 100.0 *RST: 15.0 Default unit: dB Example: CONF:AVDA:LIST:APL:RESY 50 Sets 50.0 dB. Manual operation: "Optional measurement parameters"...
  • Page 516 ® Remote Command Reference R&S AV Distortion Analyzer Application <Upper (1 to 8)> Enter a value for each channel: <CH1>,<CH2>,<CH3>,<CH4>,<CH5>,<CH6>,<CH7>,<CH8> Range: -99.9,-99.9,-99.9,-99.9,-99.9,-99.9,-99.9,-99.9 to 99.9,99.9,99.9,99.9,99.9,99.9,99.9,99.9 *RST: 10.0,10.0,10.0,10.0,10.0,10.0,10.0,10.0 Default unit: dB Example: CONF:AVDA:LIST:AUD:LEV:LIM -10, -10, -10, 20, 20, 20, 20, 20, 80, 80, 80, 80, 80, 80, 80, 80 Channel 1 to 3: sets -10.0 dB as lower limit.
  • Page 517 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <Threshold (1 to 8)> Enter a value for each channel: <CH1>,<CH2>,<CH3>,<CH4>,<CH5>,<CH6>,<CH7>,<CH8> Range: -99.9,-99.9,-99.9,-99.9,-99.9,-99.9,-99.9,-99.9 to 0.0,0.0,0.0,0.0,0.0,0.0,0.0,0.0 *RST: -40.0,-40.0,-40.0,-40.0,-40.0,-40.0,-40.0,-40.0 Default unit: dBFS Example: CONF:AVDA:LIST:AUD:LOSS:ADV -10.0, -10.0, -10.0, -10.0, -20.0, -20.0, -20.0, -20.0 Channel 1 to 4: sets -10.0 dBFS.
  • Page 518 ® Remote Command Reference R&S AV Distortion Analyzer Application <Trace (1 to 8)> OFF | ON Enables or disables the display in the status trace. Enter a value for each channel: <CH1>,<CH2>,<CH3>,<CH4>,<CH5>,<CH6>,<CH7>,<CH8> *RST: OFF,OFF,OFF,OFF,OFF,OFF,OFF,OFF Example: CONF:AVDA:LIST:AUD:LOSS ON, ON, ON, ON, ON, ON, ON, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF Shows channel 1 to 7 on the "List"...
  • Page 519 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:AVDelay[:STATe] <List (1 to 8)>, <Trace (1 to 8)> Shows or hides the channel parameters (AV delay measurement). Suffix: <hw> Irrelevant Parameters: <List (1 to 8)> OFF | ON Enables or disables the display on the "List" tab. Enter a value for each channel: <CH1>,<CH2>,<CH3>,<CH4>,<CH5>,<CH6>,<CH7>,<CH8>...
  • Page 520 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:AVTest:DEFault Resets the following optional settings: ● on page 543 CONFigure<hw>:AVDA:LIST:STILlimage:SYNC ● on page 542 CONFigure<hw>:AVDA:LIST:STILlimage:RESYnc ● on page 515 CONFigure<hw>:AVDA:LIST:APL:SYNC ● on page 515 CONFigure<hw>:AVDA:LIST:APL:RESYnc ● on page 520 CONFigure<hw>:AVDA:LIST:AVTest:TCTone ●...
  • Page 521 ® Remote Command Reference R&S AV Distortion Analyzer Application Example: CONF:AVDA:LIST:AVT:TTP 5.5 Sets 5.500 s. Manual operation: "Optional measurement parameters" on page 120 CONFigure<hw>:AVDA:LIST:BFRame:APL <Value> Sets the upper limit of the average picture level (APL) for the "Black Frame" parameter (video measurement).
  • Page 522 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: CONF:AVDA:LIST:CNUM ON Example: Manual operation: "<General parameters>" on page 114 CONFigure<hw>:AVDA:LIST:CTIMe:LIMit <Lower>, <Upper> Sets the upper and lower limits for the "Cycle Time" parameter (general measurement). Suffix: <hw>...
  • Page 523 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <Upper> Range: 0 to 9999 *RST: Example: CONF:AVDA:LIST:FDR:LIM 2 Manual operation: "<Video parameters>" on page 115 CONFigure<hw>:AVDA:LIST:FDRopped[:STATe] <List>, <Trace> Shows or hides the "Dropped Frames" parameter (video measurement). Suffix: <hw>...
  • Page 524 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:FPOint:AUDio:DURation <Value> Sets the length of the test period for the "Audio Failure Point" parameter (failure point measurement). Suffix: <hw> Irrelevant Parameters: <Value> Range: 1000 to 60000 *RST: 15000 Default unit: ms CONF:AVDA:LIST:FPO:AUD:DUR 1000 Example: Sets 1000 ms.
  • Page 525 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Setting parameters: <Settings> QMP1 | 0 QMP1 QMP2 | 1 QMP2 MBRai | 2 MBRAI DBOok | 3 D-book Example: CONF:AVDA:LIST:FPO:PICT:DEF 2 Sets MBRAI. Usage: Setting only Manual operation: "<Picture failure point parameters>"...
  • Page 526 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <Value> Range: Platform-specific *RST: 0 for NorDig QMP1 and NorDig QMP2; 1 for MBRAI and D-Book Example: CONF:AVDA:LIST:FPO:PICT:PER:ALL 0 Manual operation: "<Picture failure point parameters>" on page 117 CONFigure<hw>:AVDA:LIST:FPOint:PICTure:PERiod:GAP <Value> Sets the gap between periods for the "Picture Failure Point"...
  • Page 527 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: <Trace> OFF | ON Enables or disables the display in the status trace. *RST: Example: CONF:AVDA:LIST:FPO:PICT OFF,ON Manual operation: "<Failure point parameters>"...
  • Page 528 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:FPOint:VERRor:PSNR <Value> Sets the PSNR Y threshold for the "Visible Error" parameter (failure point measure- ment). Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.0 to 100.0 *RST: 35.0 for digital video; 25.0 for analog video Default unit: dB CONF:AVDA:LIST:FPO:VERR:PSNR 80 Example:...
  • Page 529 ® Remote Command Reference R&S AV Distortion Analyzer Application Manual operation: "<Failure point parameters>" on page 114 CONFigure<hw>:AVDA:LIST:FREeze:APLThreshold <Value> Sets the APL threshold beneath which a change of luminance is not assessed as movement. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.00 to 10.00 *RST: 0.03...
  • Page 530 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:LDETection:TIME[:STATe] <List> Shows or hides the "Detection Time" parameter (general measurement). Suffix: <hw> Irrelevant Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: Example: CONF:AVDA:LIST:LDET:TIME OFF Manual operation: "<General parameters>"...
  • Page 531 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: <Trace> OFF | ON Enables or disables the display in the result trace. *RST: Example: CONF:AVDA:LIST:MOSV OFF,OFF...
  • Page 532 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:PSNR:CB[:STATe] <List>, <Trace> Shows or hides the "PSNR Cb" parameter (video measurement). Peak signal-to-noise ratio (PSNR) Suffix: <hw> Irrelevant Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: <Trace>...
  • Page 533 ® Remote Command Reference R&S AV Distortion Analyzer Application Example: CONF:AVDA:LIST:PSNR:CR:LIM 50 Sets 50.0 dB. Manual operation: "<Video parameters>" on page 115 CONFigure<hw>:AVDA:LIST:PSNR:CR[:STATe] <List>, <Trace> Shows or hides the "PSNR Cr" parameter (video measurement). Peak signal-to-noise ratio (PSNR) Suffix: <hw> Irrelevant Parameters: <List>...
  • Page 534 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <Lower> Range: 0.0 to 99.9 *RST: 25.0 Default unit: dB Example: CONF:AVDA:LIST:PSNR:Y:LIM 50 Sets 50.0 dB. Manual operation: "<Video parameters>" on page 115 CONFigure<hw>:AVDA:LIST:PSNR:Y[:STATe] <List>, <Trace> Shows or hides the "PSNR Y" parameter (video measurement). Peak signal-to-noise ratio (PSNR) Suffix: <hw>...
  • Page 535 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: <Trace> OFF | ON Enables or disables the display in the result trace. *RST: Example: CONF:AVDA:LIST:PXER:CB ON,ON...
  • Page 536 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:PXERror:Y:LIMit <Upper> Sets the upper limit for the "Pixel Error Y" parameter (video measurement). Suffix: <hw> Irrelevant Parameters: <Upper> Range: 0 to 2073600 *RST: 1000 Example: CONF:AVDA:LIST:PXER:Y:LIM 2000 Manual operation: "<Video parameters>" on page 115 CONFigure<hw>:AVDA:LIST:PXERror:Y[:STATe] <List>, <Trace>...
  • Page 537 ® Remote Command Reference R&S AV Distortion Analyzer Application Example: CONF:AVDA:LIST:RFR:LIM 10,80 Sets the lower limit to 10.00 %, and the upper limit to 80.00 %. Manual operation: "<Video parameters>" on page 115 CONFigure<hw>:AVDA:LIST:RFReeze[:STATe] <List> Shows or hides the "Relative Picture Freeze" parameter (video measurement). Suffix: <hw>...
  • Page 538 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <Value> Range: 1 to 99 *RST: Default unit: s Example: CONF:AVDA:LIST:RRAT:AVER:SDW 30 Sets 30 s. Manual operation: "<Rendering rate parameters>" on page 119 CONFigure<hw>:AVDA:LIST:RRATe:AVERage[:STATe] <List> Shows or hides the "AVG Rend Rate" parameter (video measurement). Suffix: <hw>...
  • Page 539 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:RRATe:STDeviation:LIMit <Lower>, <Upper> Sets the upper and lower limits for the "STD Rend Rate" parameter (video measure- ment). Suffix: <hw> Irrelevant Parameters: <Lower> Range: 0.00 to 999.99 *RST: 0.00 Default unit: Hz <Upper>...
  • Page 540 ® Remote Command Reference R&S AV Distortion Analyzer Application NOMinal Enables the nominal value. Set the value under CONFigure<hw>:AVDA:LIST:RRATe:STDeviation: on page 539. RNOMinal *RST: RRATeavg Example: CONF:AVDA:LIST:RRAT:STD:RSEL NOM Manual operation: "<Rendering rate parameters>" on page 119 CONFigure<hw>:AVDA:LIST:RRATe:STDeviation[:STATe] <List> Shows or hides the "STD Rend Rate" parameter (video measurement). Suffix: <hw>...
  • Page 541 ® Remote Command Reference R&S AV Distortion Analyzer Application Parameters: <List> OFF | ON Enables or disables the display on the "List" tab. *RST: <Trace> OFF | ON Enables or disables the display in the result trace. *RST: Example: CONF:AVDA:LIST:RRAT ON,ON Manual operation: "<Video parameters>"...
  • Page 542 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <Lower> Range: 0.000 to 1.000 *RST: 0.600 Example: CONF:AVDA:LIST:SSIM:LIM 0.5 Manual operation: "<Video parameters>" on page 115 CONFigure<hw>:AVDA:LIST:SSIM[:STATe] <List>, <Trace> Shows or hides the "SSIM" parameter (video measurement). Structural similarity (SSIM).
  • Page 543 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:LIST:STILlimage:SYNC <Value> Sets the threshold for still image synchronization (PSNR). Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.0 to 100.0 *RST: 38.0 Default unit: dB Example: CONF:AVDA:LIST:STIL:SYNC 50 Sets 50.0 dB. Manual operation: "Optional measurement parameters"...
  • Page 544 ® Remote Command Reference R&S AV Distortion Analyzer Application 14.3.3.4 CONFigure<hw>:AVDA:LOG Subsystem CONFigure<hw>:AVDA:LOG:OPTions <LogData>, <Separator> Suffix: <hw> Irrelevant Parameters: <LogData> ALL | LVIolation *RST: <Separator> COMMa | DOT *RST: COMMa Example: CONF:AVDA:LOG:OPT LVI,DOT Manual operation: "Log Data" on page 130 "Decimal Point in csv File"...
  • Page 545 ® Remote Command Reference R&S AV Distortion Analyzer Application CONFigure<hw>:AVDA:REFerence:DETection:TIME <Interval> Sets the time interval for monitoring a signal to detect a loop. Suffix: <hw> Irrelevant Parameters: <Interval> Range: 0.0 to 300.0 *RST: 60.0 Default unit: s Example: CONF:AVDA:REF:DET:TIME 10 Sets 10.0 s.
  • Page 546 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <Mode> LAPL | SAPL | TCODe | SPICture | SREFerence *RST: SREF Example: CONF:AVDA:REF:SYNC LAPL Sets loop average picture level (APL). Manual operation: "Synchronization" on page 109 CONFigure<hw>:AVDA:REFerence:TIMecode:MFRames <MissingFrames>...
  • Page 547 ® Remote Command Reference R&S AV Distortion Analyzer Application Example: CONF:AVDA:REF:TIM:WIND:SIZE 30,70,50,60 Manual operation: "TC Window Top, TC Window Bottom, TC Window Left, TC Window Right" on page 111 14.3.3.6 CONFigure<hw>:AVDA:TTVideo Subsystem ..................547 CONFigure<hw>:AVDA:TTVideo ............. 547 CONFigure<hw>:AVDA:TTVideo:APL:HYSTerese ..............547 CONFigure<hw>:AVDA:TTVideo:APL:SLOPe .............
  • Page 548: Display Subsystem

    ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Parameters: <Slope> RISE | FALL *RST: RISE Example: CONF:AVDA:TTV:APL:SLOP RISE Manual operation: "APL Trigger Slope" on page 119 CONFigure<hw>:AVDA:TTVideo:APL:THReshold <Threshold> Sets the threshold for detecting an APL transition as a triggering event. Suffix: <hw>...
  • Page 549: Initiate Subsystem

    <hw> Irrelevant Parameters: <PathFolder> Folder name. If the path is omitted, the current directory is used. Example: MMEM:AVDA:LOG:DATA:SAVE "D:\VTS\UserData\MyLog" Creates the MyLog folder in the D:\VTS\UserData directory. Manual operation: "Save Log button" on page 130 User Manual 2116.1228.02 ─ 14...
  • Page 550 Filename including the extension. If the path is omitted, the cur- rent directory is used. Example: MMEM:AVDA:REF:DATA:LOAD "D: \VTS\UserData\test1.avr" Loads test1.avr from the D:\VTS\UserData directory. Manual operation: "Load button" on page 112 MMEMory<hw>:AVDA:REFerence:DATA:LOAD:STATe? Queries the loading status of the reference file.
  • Page 551: Read Subsystem

    ® Remote Command Reference R&S AV Distortion Analyzer Application MMEMory<hw>:AVDA:REFerence:DATA:SAVE:STATe? Queries the saving status of the reference file. Suffix: <hw> Irrelevant Return values: <Status> IDLE | RUNNing | READy | ERRor Example: MMEM:AVDA:REF:DATA:SAVE:STAT? Query IDLE Response Usage: Query only Manual operation: "Save button"...
  • Page 552 ® Remote Command Reference R&S AV Distortion Analyzer Application Manual operation: "<Counter>" on page 124 READ<hw>[:SCALar]:AVDA:DETection[:STATe]? Queries the status of the measurement. Suffix: <hw> Irrelevant Return values: <Result> STOP | RUNNing | PASSed | ABORted Example: READ:AVDA:DET? Query PASS Response Usage: Query only Manual operation:...
  • Page 553 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:INPut:AUDio:CH:COUNt? Queries the number of audio channels of the input signal. Suffix: <hw> Irrelevant Return values: <MeasValue> Numeric value Example: READ:AVDA:INP:AUD:CH:COUN? Query Response Usage: Query only Manual operation: "Input column" on page 122 READ<hw>[:SCALar]:AVDA:INPut:COLor:DEPTh? Queries the color depth of the input signal.
  • Page 554 ® Remote Command Reference R&S AV Distortion Analyzer Application RGB | YPBPr Analog input signal Example: READ:AVDA:INP:COMP:FORM? Query YCBC Response Usage: Query only Manual operation: "Input column" on page 122 READ<hw>[:SCALar]:AVDA:INPut:COMPonent:SAMPling? Queries the component sampling of the input signal. Suffix: <hw>...
  • Page 555 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:INPut:RESolution? Queries the resolution of the input signal. Suffix: <hw> Irrelevant Return values: <MeasValue> String Example: READ:AVDA:INP:RES? Query "1920x1080" Response Usage: Query only Manual operation: "Input column" on page 122 READ<hw>[:SCALar]:AVDA:INPut:SYNC[:STATe]? Queries the synchronization state of the input signal.
  • Page 556 ® Remote Command Reference R&S AV Distortion Analyzer Application ..............562 READ<hw>[:SCALar]:AVDA:LIST:LDETection? ................ 562 READ<hw>[:SCALar]:AVDA:LIST:MOSV? ..............562 READ<hw>[:SCALar]:AVDA:LIST:PSNR:CB? ..............563 READ<hw>[:SCALar]:AVDA:LIST:PSNR:CR? ..............563 READ<hw>[:SCALar]:AVDA:LIST:PSNR:Y? ..............564 READ<hw>[:SCALar]:AVDA:LIST:PXERror:CB? ............... 564 READ<hw>[:SCALar]:AVDA:LIST:PXERror:CR? ..............564 READ<hw>[:SCALar]:AVDA:LIST:PXERror:Y? ..............565 READ<hw>[:SCALar]:AVDA:LIST:RFReeze? ................565 READ<hw>[:SCALar]:AVDA:LIST:RRATe? ............566 READ<hw>[:SCALar]:AVDA:LIST:RRATe:AVERage? ............. 566 READ<hw>[:SCALar]:AVDA:LIST:RRATe:STDeviation? ...............
  • Page 557 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Return values: <Current (1 to 8)> OK | FAIL Current test result. <CH1>,<CH2>,<CH3>,<CH4>,<CH5>,<CH6>,<CH7>,<CH8> <Worst (1 to 8)> OK | FAIL Worst test result within the running test period. <CH1>,<CH2>,<CH3>,<CH4>,<CH5>,<CH6>,<CH7>,<CH8>...
  • Page 558 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:LIST:AVPL? Queries the results of the "Avg. Picture Level" parameter (video measurement). Suffix: <hw> Irrelevant Return values: <Current> Current test result. Default unit: % Example: READ:AVDA:LIST:AVPL? Query 1.973084E+001 Response Usage: Query only Manual operation: "<Video results>"...
  • Page 559 ® Remote Command Reference R&S AV Distortion Analyzer Application <Worst> Worst test result within the running test period. READ:AVDA:LIST:CNUM? Example: Query 8,NAV Response: <Current>,<Worst> Usage: Query only Manual operation: "<General results>" on page 125 READ<hw>[:SCALar]:AVDA:LIST:CTIMe? Queries the results of the "Cycle Time" parameter (general measurement). Suffix: <hw>...
  • Page 560 ® Remote Command Reference R&S AV Distortion Analyzer Application Usage: Query only Manual operation: "<Video results>" on page 126 READ<hw>[:SCALar]:AVDA:LIST:FNUMber? Queries the results of the "Frame Number" parameter (general measurement). Suffix: <hw> Irrelevant Return values: <Current> Current test result. <Worst> Worst test result within the running test period.
  • Page 561 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:LIST:FPOint:PICTure? Queries the results of the "Picture Failure Point" parameter (failure point measure- ment). Suffix: <hw> Irrelevant Return values: <Current> OK | FAIL Current test result. <Worst> OK | FAIL Worst test result within the running test period. <Fault>...
  • Page 562 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:LIST:LDETection? on page 552. READ<hw>[:SCALar]:AVDA:DETection[:STATe]? Usage: Query only Manual operation: "<General results>" on page 125 READ<hw>[:SCALar]:AVDA:LIST:MOSV? Queries the results of the "Mos-V" parameter (video measurement). Suffix: <hw> Irrelevant Return values: <Current> Current test result.
  • Page 563 ® Remote Command Reference R&S AV Distortion Analyzer Application Manual operation: "<Video results>" on page 126 READ<hw>[:SCALar]:AVDA:LIST:PSNR:CR? Queries the results of the "PSNR Cr" parameter (video measurement). Suffix: <hw> Irrelevant Return values: <Current> Current test result. Default unit: dB <Worst> Worst test result within the running test period.
  • Page 564 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:LIST:PXERror:CB? Queries the results of the "Pixel Error Cb" parameter (video measurement). Suffix: <hw> Irrelevant Return values: <Current> Current test result. <Worst> Worst test result within the running test period. <Fault> Number of detected faults.
  • Page 565 ® Remote Command Reference R&S AV Distortion Analyzer Application Return values: <Current> Current test result. <Worst> Worst test result within the running test period. <Fault> Number of detected faults. Example: READ:AVDA:LIST:PXER:Y? Query 404021,407398,65946 Response: <Current>,<Worst>,<Fault> Usage: Query only Manual operation: "<Video results>"...
  • Page 566 ® Remote Command Reference R&S AV Distortion Analyzer Application <Worst> Worst test result within the running test period. Default unit: Hz <Fault> Number of detected faults. Example: READ:AVDA:LIST:RRAT? Query 2.500000E+001, 2.500000E+001, 0 Response: <Current>,<Worst>,<Fault> Usage: Query only Manual operation: "<Video results>" on page 126 READ<hw>[:SCALar]:AVDA:LIST:RRATe:AVERage? Queries the results of the "AVG Rend Rate"...
  • Page 567 ® Remote Command Reference R&S AV Distortion Analyzer Application <Fault> Number of detected faults. READ:AVDA:LIST:RRAT:STD? Example: Query 0.000000E+000, 0.000000E+000, 0 Response: <Current>,<Worst>,<Fault> Usage: Query only Manual operation: "<Video results>" on page 126 READ<hw>[:SCALar]:AVDA:LIST:SIGNal? Queries the synchronization state of the input signal. Suffix: <hw>...
  • Page 568 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:LIST:VFReeze? Queries the results of the "Freeze" parameter (video measurement). Suffix: <hw> Irrelevant Return values: <Current> OK | FAIL Current test result. <Worst> OK | FAIL Worst test result within the running test period. <Fault>...
  • Page 569 ® Remote Command Reference R&S AV Distortion Analyzer Application Usage: Query only Manual operation: "<Progress>" on page 112 READ<hw>[:SCALar]:AVDA:REFerence:COMMand:STATe? Queries the state of the reference setting. Suffix: <hw> Irrelevant Return values: <Learning> IDLE | LEARning | LOOPdetected | ACCepted IDLE No reference sequence is recorded or loaded.
  • Page 570 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:REFerence:INFO:FSIZe? Queries the reference file size. Suffix: <hw> Irrelevant Return values: <FileSize> Numeric value Default unit: MB Example: READ:AVDA:REF:INFO:FSIZ? Query Response Usage: Query only Manual operation: "Characteristics list" on page 111 READ<hw>[:SCALar]:AVDA:REFerence:INFO:LLENgth? Queries the reference loop length.
  • Page 571 ® Remote Command Reference R&S AV Distortion Analyzer Application Example: READ:AVDA:REF:INFO:NFR? Query Response Usage: Query only Manual operation: "Characteristics list" on page 111 READ<hw>[:SCALar]:AVDA:REFerence:INFO:NOTE? Queries reference note. Suffix: <hw> Irrelevant Return values: <Content> String Example: READ:AVDA:REF:INFO:NOTE? Query "---" Response Usage: Query only Manual operation: "Characteristics list"...
  • Page 572 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Return values: <RecordTime> String Example: READ:AVDA:REF:INFO:TIME? Query "17:31" Response Usage: Query only Manual operation: "Characteristics list" on page 111 14.3.7.5 READ<hw>[:SCALar]:AVDA:RINPut Subsystem ..............572 READ<hw>[:SCALar]:AVDA:RINPut:ARATio? ........... 572 READ<hw>[:SCALar]:AVDA:RINPut:AUDio:CH:COUNt? ............573 READ<hw>[:SCALar]:AVDA:RINPut:COLor:DEPTh? ...............
  • Page 573 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:RINPut:COLor:DEPTh? Queries the color depth of the reference signal. See READ<hw>[:SCALar]:AVDA: on page 553. INPut:COLor:DEPTh? Usage: Query only Manual operation: "Reference column" on page 123 READ<hw>[:SCALar]:AVDA:RINPut:COMMent? Queries the comment of the reference. Suffix: <hw>...
  • Page 574 ® Remote Command Reference R&S AV Distortion Analyzer Application Return values: <Name> Filename including the extension. Example: READ:AVDA:RINP:FILE? Query "tunnel car allfr.avr" Response Usage: Query only Manual operation: "Reference column" on page 123 READ<hw>[:SCALar]:AVDA:RINPut:FILE:TIME? Queries the date and time of the reference file. Suffix: <hw>...
  • Page 575 ® Remote Command Reference R&S AV Distortion Analyzer Application READ<hw>[:SCALar]:AVDA:RINPut:FITNess:VSYNc? Queries the video synchronization fitness of the reference. Suffix: <hw> Irrelevant Return values: <Result> ACCeptable | EXCellent Example: READ:AVDA:RINP:FITN:VSYN? Query Response Usage: Query only Manual operation: "Reference column" on page 123 READ<hw>[:SCALar]:AVDA:RINPut:FRAMe:COUNt? Queries the number of frames in the reference signal.
  • Page 576 ® Remote Command Reference R&S AV Distortion Analyzer Application Suffix: <hw> Irrelevant Return values: <Value> Numeric value Default unit: s Example: READ:AVDA:RINP:LOOP:COUN? Query 2.100000E+001 Response Usage: Query only Manual operation: "Reference column" on page 123 READ<hw>[:SCALar]:AVDA:RINPut:RESolution? Queries the resolution of the reference signal. See READ<hw>[:SCALar]:AVDA: on page 555.
  • Page 577 ® Remote Command Reference R&S AV Distortion Analyzer Application Return values: <Counter> Number of detected faults in the current counter loop. After reaching 127, the counter restarts at 0. Range: 0 to 127 Example: READ:AVDA:TTV:COUN? Query Response Usage: Query only Manual operation: "<Video results>"...
  • Page 578: Route Subsystem

    ® Remote Command Reference R&S AV Distortion Analyzer Application Example: READ:AVDA:TTV:VAL? Query -225 Response Usage: Query only Manual operation: "<Video results>" on page 126 14.3.8 ROUTe Subsystem Table 14-2: Addressing input types <Input type> Description Required option Composite Composite input signal Analog A/V RX module (R&S VT-B2370) Component Component input signal...
  • Page 579: Video Analyzer Application

    ® Remote Command Reference R&S Video Analyzer Application Return values: <Input> "<input type> [<module slot>], <input type> [<module slot>], ..." with <input type> see Table 14-2 and [<module slot>] see Chapter 14.1.1, "Addressing Module Slots", on page 480 Example: ROUT:AVDA:MOD:CAT? Query "HDMI 600MHz [L1], Composite [L3], Component [L3], HDMI [R1], MHL [R3]"...
  • Page 580: Parameters For Composite Input Signals

    ® Remote Command Reference R&S Video Analyzer Application The parameters differ depending on the input signal, parameter group and video stan- dard. For selecting the input signal use ROUTe<hw>:VIDeo:MODule:SELect on page 668. ● Parameters for Composite Input Signals.............. 580 ● Parameters for Component, HDMI, MHL Input Signal..........
  • Page 581 ® Remote Command Reference R&S Video Analyzer Application Parameter <ParameterName> Unit Limit range BG/PAL | M/NTSC BG/PAL | M/NTSC BG/PAL | M/NTSC -50.0 to 50.0 Sync Amplitude (bar) SARB Burst Amplitude (abs) BAA | BAI mV | IRE 60.0 to 600.0 | 10.0 to 80.0 -80.0 to 100.0 Burst Amplitude (nom) BARN...
  • Page 582 ® Remote Command Reference R&S Video Analyzer Application 14.4.1.3 Nonlinear Distortions (Composite Input Signal) Table 14-5: BG/PAL and M/NTSC parameters Parameter <ParameterName> Unit Limit range -1.0 to 50.0 C NL Gain pos GPOScnl -50.0 to 1.0 C NL Gain neg GNEGcnl -1.0 to 100.0 C NL Gain pp...
  • Page 583 ® Remote Command Reference R&S Video Analyzer Application Parameter <ParameterName> Unit Limit range -1.0 to 50.0 Diff Phase pos DPPos -50.0 to 1.0 Diff Phase neg DPNeg -100.0 to 100.0 Diff Phase pp DPPP -50.0 to 50.0 Diff Phase Step1 DP1Step -50.0 to 50.0 Diff Phase Step2...
  • Page 584 ® Remote Command Reference R&S Video Analyzer Application Parameter <ParameterName> Unit Limit range -100.0 to 50.0 Multiburst NTC7 0.5 (%) T05Pct -100.0 to 50.0 Multiburst NTC7 1.0 (%) T10Pct -100.0 to 50.0 Multiburst NTC7 2.0 (%) T20Pct -100.0 to 50.0 Multiburst NTC7 3.0 (%) T30Pct -100.0 to 50.0...
  • Page 585 ® Remote Command Reference R&S Video Analyzer Application Parameter <ParameterName> Unit Limit range -1000.0 to 1000.0 Sin x/x Group Delay pos SXGPos -1000.0 to 1000.0 Sin x/x Group Delay neg SXGNeg 14.4.1.5 Noise (Composite Input Signal) Table 14-9: BG/PAL and M/NTSC parameters Parameter <ParameterName>...
  • Page 586 ® Remote Command Reference R&S Video Analyzer Application 14.4.1.6 Timing (Composite Input Signal) Table 14-11: BG/PAL and M/NTSC parameters Parameter <ParameterName> Unit Limit range BG/PAL | M/NTSC Field Period First Field FPFirst 19970.0 to 20030.0 | 16653.0 to 16713.0 Field Period Second Field FPSecond 19970.0 to 20030.0 | 16653.0 to 16713.0...
  • Page 587: Parameters For Component, Hdmi, Mhl Input Signal

    ® Remote Command Reference R&S Video Analyzer Application 14.4.1.7 Jitter (Composite Input Signal) Table 14-13: BG/PAL and M/NTSC parameters Parameter <ParameterName> Unit Limit range -1000.0 to 30000.0 Field Jitter pos peak FJPos -30000.0 to 1000.0 Field Jitter neg peak FJNeg -1000.0 to 30000.0 Field Jitter pp FJPP...
  • Page 588 ® Remote Command Reference R&S Video Analyzer Application Table 14-15: Available channel numbers (component, HDMI, MHL input signal) Channel number YCbCr YPbPr Digital or analog video Digital video Analog video G green Y luminance Y luminance B blue Cb color difference (Y-B) Pb color difference (Y-B) R red Cr color difference (Y-R)
  • Page 589 ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> RGB | YPbPr/YCbCr Component RGB Component YPbPr/YCbCr -700.0 to 700.0 | -700.0 to 1400.0 Color Bar Ampl. Cyan R Color Bar Ampl. Cyan Cr/Pr CBACC3 -700.0 to 700.0 | -700.0 to 1400.0 Color Bar Ampl.
  • Page 590 ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> Component RGB Component YPbPr/YCbCr -1.0 to 100.0 2T Pulse k-Faktor B 2T Pulse k-Faktor Cb/Pb TTPKC2 -1.0 to 100.0 2T Pulse k-Faktor R 2T Pulse k-Faktor Cr/Pr TTPKC3 2T Pulse HAD G 2T Pulse HAD Y...
  • Page 591 ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> Component RGB Component YPbPr/YCbCr Nonlinearity Step1 R Nonlinearity Step1 Cr/Pr NL1stepC3 50.0 to 100.0 Nonlinearity Step2 G Nonlinearity Step2 Y NL2stepC1 50.0 to 100.0 Nonlinearity Step2 B Nonlinearity Step2 Cb/Pb NL2stepC2 50.0 to 100.0...
  • Page 592 ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> Component RGB Component YPbPr/YCbCr -100.0 to 100.0 Sweep Amplitude pos R Sweep Amplitude pos Cr/Pr SWEEPposC3 -100.0 to 100.0 Sweep Amplitude neg G Sweep Amplitude neg Y SWEEPnegC1 -100.0 to 100.0 Sweep Amplitude neg B...
  • Page 593 ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> Component RGB Component YPbPr/YCbCr -100.0 to 6.0 Multiburst 2 Ampl. B (dB) Multiburst 2 Ampl. Cb/Pb (dB) M2DbC2 -100.0 to 6.0 Multiburst 2 Ampl. R (dB) Multiburst 2 Ampl.
  • Page 594 ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> Component RGB Component YPbPr/YCbCr Multiburst 6 Freq. B Multiburst 6 Freq. Cb/Pb M6FRC2 0.01 to 100.00 Multiburst 6 Freq. R Multiburst 6 Freq. Cr/Pr M6FRC3 0.01 to 100.00 14.4.2.5 Noise (Component, HDMI, MHL Input Signal) Parameter...
  • Page 595: Test Signals

    ® Remote Command Reference R&S Video Analyzer Application Parameter <Parameter Unit Limit range Name> Component RGB Component YPbPr/YCbCr -1000.0 to 1000.0 Line Jitter pp Line Jitter pp LJPP Line Jitter Std. Deviation Line Jitter Std. Deviation LJSD 0.0 to 1000.0 14.4.3 Test Signals The available test signals depend on the input signal.
  • Page 596: Status Of Measured Parameters

    ® Remote Command Reference R&S Video Analyzer Application Test signal <TestSignalName> Available for video standard BG/PAL M/NTSC Mod Ramp TMODramp 250 kHz Pulse T250kpulse 2T Pulse TTTPulse Table 14-17: Component, HDMI, MHL input signal Test signal <TestSignalName> Color Bars TCBar Multiburst TMBurstline Sinx/x...
  • Page 597: Calculate Subsystem

    ® Remote Command Reference R&S Video Analyzer Application Status display <Status> Description "Underflow" UFLow Measured value is too small. "UL" Measured value exceeds the upper limit. "?????????" UNKNown Unspecified error "Wait..." WAIT Measured value is not yet settled. "Wrong Rcv" WRCV Internal error 14.4.5 CALCulate Subsystem...
  • Page 598 ® Remote Command Reference R&S Video Analyzer Application Parameters: <CursorType> OFF | LEVel | SLOPe Example: CONF:SCOP:TRAC:CURS2:TYPE LEV Measures the average level at the position of cursor 2. Manual operation: "C1, C2" on page 141 CONFigure<hw>:SCOPe:TRACe:CURSor<cursor>:X:LPOSition:PIXel <CLineNumber>, <CPosition>[, <CXSpan>, <FieldNumber>] Positions the cursor or cursor window.
  • Page 599 ® Remote Command Reference R&S Video Analyzer Application <cursor> Cursor number Parameters: <CLineNumber> Number of the line in which the cursor is positioned. Range: Depends on the selected standard. <CPosition> Cursor position within the line Default unit: us <CXSpan> Width of the cursor window. Applies only if SLOPe is set under CONFigure<hw>:SCOPe:TRACe:CURSor<cursor>:TYPE on page 597.
  • Page 600 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:SIGNal:ASPRatio:ANALog <AspectRatio> Sets the aspect ratio of the video picture. Suffix: <hw> Irrelevant Parameters: <AspectRatio> F4_3 | F16_9 Example: CONF:VID:SIGN:ASPR:ANAL F16_9 Sets 16:9. Manual operation: "Picture Aspect Ratio" on page 135 CONFigure<hw>:VIDeo:VECTor:TRACe:CURSor:LPOSition:PIXel <LineNumber>, <CPosition>[, <FieldNumber>] Sets the cursor position by defining the number of the TV line and the position in the line trace.
  • Page 601 ® Remote Command Reference R&S Video Analyzer Application Parameters: <LineNumber> Number of the line in which the cursor is positioned. Range: Depends on the selected standard. <CPosition> Cursor position within the line Default unit: us <FieldNumber> Selects the field. Range: 1 to 2 Example: CONF:VID:VECT:TRAC:CURS:LPOS:TIME 23,2.9...
  • Page 602 ® Remote Command Reference R&S Video Analyzer Application ..........606 CONFigure<hw>:VIDeo:MEASure:AMPDelay:PAL:SELect ..........606 CONFigure<hw>:VIDeo:MEASure:AMPDelay:NTSC:TSIGnal ..........606 CONFigure<hw>:VIDeo:MEASure:AMPDelay:PAL:TSIGnal ........607 CONFigure<hw>:VIDeo:MEASure:AMPDelay:RGB:LIMit:LOWer ..........607 CONFigure<hw>:VIDeo:MEASure:AMPDelay:Y:LIMit:LOWer .........607 CONFigure<hw>:VIDeo:MEASure:AMPDelay:RGB:LIMit:UPPer ..........607 CONFigure<hw>:VIDeo:MEASure:AMPDelay:Y:LIMit:UPPer ..........608 CONFigure<hw>:VIDeo:MEASure:AMPDelay:RGB:SELect .............608 CONFigure<hw>:VIDeo:MEASure:AMPDelay:Y:SELect ..........608 CONFigure<hw>:VIDeo:MEASure:AMPDelay:RGB:TSIGnal ........... 608 CONFigure<hw>:VIDeo:MEASure:AMPDelay:Y:TSIGnal ..........609 CONFigure<hw>:VIDeo:MEASure:COMPonent:ANALog:CLINe ..........609 CONFigure<hw>:VIDeo:MEASure:COMPonent:DIGital:CLINe ........610 CONFigure<hw>:VIDeo:MEASure:FRESponse:NTSC:LIMit:LOWer ........
  • Page 603 ® Remote Command Reference R&S Video Analyzer Application ............620 CONFigure<hw>:VIDeo:MEASure:LINDist:PAL:SELect ..........620 CONFigure<hw>:VIDeo:MEASure:LINDist:NTSC:TSIGnal ............ 620 CONFigure<hw>:VIDeo:MEASure:LINDist:PAL:TSIGnal ..........621 CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:LIMit:LOWer ..........621 CONFigure<hw>:VIDeo:MEASure:LINDist:Y:LIMit:LOWer ..........621 CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:LIMit:UPPer ...........621 CONFigure<hw>:VIDeo:MEASure:LINDist:Y:LIMit:UPPer ............ 622 CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:SELect ............622 CONFigure<hw>:VIDeo:MEASure:LINDist:Y:SELect ........... 622 CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:TSIGnal ............622 CONFigure<hw>:VIDeo:MEASure:LINDist:Y:TSIGnal ......... 623 CONFigure<hw>:VIDeo:MEASure:NLINdist:NTSC:LIMit:LOWer ..........623 CONFigure<hw>:VIDeo:MEASure:NLINdist:PAL:LIMit:LOWer ..........623 CONFigure<hw>:VIDeo:MEASure:NLINdist:NTSC:LIMit:UPPer...
  • Page 604 ® Remote Command Reference R&S Video Analyzer Application ............633 CONFigure<hw>:VIDeo:MEASure:RGB:SELect:ALL .............. 633 CONFigure<hw>:VIDeo:MEASure:Y:SELect:ALL .............633 CONFigure<hw>:VIDeo:MEASure:PAL:STANdard ..........633 CONFigure<hw>:VIDeo:MEASure:TIMing:NTSC:LIMit:LOWer ..........633 CONFigure<hw>:VIDeo:MEASure:TIMing:PAL:LIMit:LOWer ..........634 CONFigure<hw>:VIDeo:MEASure:TIMing:NTSC:LIMit:UPPer ..........634 CONFigure<hw>:VIDeo:MEASure:TIMing:PAL:LIMit:UPPer ........... 634 CONFigure<hw>:VIDeo:MEASure:TIMing:NTSC:SELect ............634 CONFigure<hw>:VIDeo:MEASure:TIMing:PAL:SELect ..........635 CONFigure<hw>:VIDeo:MEASure:TIMing:NTSC:TSIGnal ............. 635 CONFigure<hw>:VIDeo:MEASure:TIMing:PAL:TSIGnal ..........635 CONFigure<hw>:VIDeo:MEASure:TIMing:RGB:LIMit:LOWer ...........635 CONFigure<hw>:VIDeo:MEASure:TIMing:Y:LIMit:LOWer ..........
  • Page 605 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.1.1, "Amplitude and Delay (Composite Input Signal)", on page 580. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.1, "Amplitude and Delay (Composite Input Signal)",...
  • Page 606 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:AMPDelay:NTSC:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:AMPDelay:NTSC:SELect? [<ParameterName>] CONFigure<hw>:VIDeo:MEASure:AMPDelay:PAL:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:AMPDelay:PAL:SELect? [<ParameterName>] Enables or disables the measurement of the specified parameter for: ● Input signal: composite ● Parameter group: amplitude and delay ● Video standard: BG/PAL or M/NTSC Suffix: <hw>...
  • Page 607 ® Remote Command Reference R&S Video Analyzer Application Example: CONF:VID:MEAS:AMPD:PAL:TSIG? DCL Query "Quiet Line" Response: String as return value for the TQU text parameter. CONFigure<hw>:VIDeo:MEASure:AMPDelay:RGB:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:AMPDelay:RGB:LIMit:LOWer? <ParameterName> CONFigure<hw>:VIDeo:MEASure:AMPDelay:Y:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:AMPDelay:Y:LIMit:LOWer? <ParameterName> Configures the lower limit of the specified parameter for: ●...
  • Page 608 ® Remote Command Reference R&S Video Analyzer Application Parameters: <LimitValue> Specifies the upper limit for the parameter. See Chap- ter 14.4.2.1, "Amplitude and Delay (Component, HDMI, MHL Input Signal)", on page 588. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.1, "Amplitude and Delay (Component, HDMI, MHL Input Signal)",...
  • Page 609 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <TestSignalName> Specifies the test signal. See Table 14-17. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.1, "Amplitude and Delay (Component, HDMI, MHL Input Signal)", on page 588.
  • Page 610 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:FRESponse:NTSC:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:FRESponse:NTSC:LIMit:LOWer? [<ParameterName>] CONFigure<hw>:VIDeo:MEASure:FRESponse:PAL:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:FRESponse:PAL:LIMit:LOWer? [<ParameterName>] Configures the lower limit of the specified parameter for: ● Input signal: composite ● Parameter group: frequency response ● Video standard: BG/PAL or M/NTSC Suffix: <hw>...
  • Page 611 ® Remote Command Reference R&S Video Analyzer Application Parameters: <LimitValue> Specifies the upper limit for the parameter. See Chap- ter 14.4.1.4, "Frequency Response (Composite Input Signal)", on page 583. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.4, "Frequency Response (Composite Input Signal)", on page 583.
  • Page 612 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <TestSignalName> Specifies the test signal. See Table 14-16. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.4, "Frequency Response (Composite Input Signal)", on page 583. Example: CONF:VID:MEAS:FRES:PAL:TSIG M58P,T17C Sets the CCIR17 test signal for "Multiburst 5.8 (%)".
  • Page 613 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:FRESponse:RGB:LIMit:UPPer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:FRESponse:RGB:LIMit:UPPer? <ParameterName> CONFigure<hw>:VIDeo:MEASure:FRESponse:Y:LIMit:UPPer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:FRESponse:Y:LIMit:UPPer? <ParameterName> Configures the upper limit of the specified parameter for: ● Input signal: component, HDMI, MHL ● Parameter group: frequency response ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw>...
  • Page 614 ® Remote Command Reference R&S Video Analyzer Application Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.4, "Frequency Response (Component, HDMI, MHL Input Signal)", on page 591. Example: CONF:VID:MEAS:FRES:Y:SEL "SXGposC3",OFF CONFigure<hw>:VIDeo:MEASure:FRESponse:RGB:TSIGnal <ParameterName>, <TestSignalName> CONFigure<hw>:VIDeo:MEASure:FRESponse:RGB:TSIGnal? <ParameterName> CONFigure<hw>:VIDeo:MEASure:FRESponse:Y:TSIGnal <ParameterName>, <TestSignalName>...
  • Page 615 ® Remote Command Reference R&S Video Analyzer Application Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.1.7, "Jitter (Composite Input Signal)", on page 587. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.7, "Jitter (Compo- site Input Signal)", on page 587.
  • Page 616 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.7, "Jitter (Compo- site Input Signal)", on page 587. Example: CONF:VID:MEAS:JITT:PAL:SEL LJPP,OFF CONFigure<hw>:VIDeo:MEASure:JITTer:NTSC:TSIGnal <ParameterName>, <TestSignalName>...
  • Page 617 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.2.7, "Jitter (Component, HDMI, MHL Input Signal)", on page 594. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.7, "Jitter (Compo- nent, HDMI, MHL Input Signal)",...
  • Page 618 ® Remote Command Reference R&S Video Analyzer Application ● Parameter group: jitter ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.7, "Jitter (Compo- nent, HDMI, MHL Input Signal)", on page 594.
  • Page 619 ® Remote Command Reference R&S Video Analyzer Application ● Parameter group: linear distortions ● Video standard: BG/PAL or M/NTSC Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.1.2, "Linear Distortions (Composite Input Signal)", on page 581.
  • Page 620 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:LINDist:NTSC:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:LINDist:NTSC:SELect? [<ParameterName>] CONFigure<hw>:VIDeo:MEASure:LINDist:PAL:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:LINDist:PAL:SELect? [<ParameterName>] Enables or disables the measurement of the specified parameter for: ● Input signal: composite ● Parameter group: linear distortions ● Video standard: BG/PAL or M/NTSC Suffix: <hw>...
  • Page 621 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:LIMit:LOWer? <ParameterName> CONFigure<hw>:VIDeo:MEASure:LINDist:Y:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:LINDist:Y:LIMit:LOWer? <ParameterName> Configures the lower limit of the specified parameter for: ● Input signal: component, HDMI, MHL ● Parameter group: linear distortions ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw>...
  • Page 622 ® Remote Command Reference R&S Video Analyzer Application Example: CONF:VID:MEAS:LIND:Y:LIM:UPP "TTPAC1",99.0 Sets an upper limit of 99.0 % for "2T Pulse Amplitude Y". CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:LINDist:RGB:SELect? <ParameterName> CONFigure<hw>:VIDeo:MEASure:LINDist:Y:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:LINDist:Y:SELect? <ParameterName> Enables or disables the measurement of the specified parameter for: ●...
  • Page 623 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:NLINdist:NTSC:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:NLINdist:NTSC:LIMit:LOWer? [<ParameterName>] CONFigure<hw>:VIDeo:MEASure:NLINdist:PAL:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:NLINdist:PAL:LIMit:LOWer? [<ParameterName>] Configures the lower limit of the specified parameter for: ● Input signal: composite ● Parameter group: nonlinear distortions ● Video standard: BG/PAL or M/NTSC Suffix: <hw>...
  • Page 624 ® Remote Command Reference R&S Video Analyzer Application Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.3, "Nonlinear Dis- tortions (Composite Input Signal)", on page 582. Example: CONF:VID:MEAS:NLIN:PAL:LIM:UPP GNEG,-2.0 Sets an upper limit of -2.0 % for "C NL Gain neg". CONFigure<hw>:VIDeo:MEASure:NLINdist:NTSC:SELect <ParameterName>, <Enable>...
  • Page 625 ® Remote Command Reference R&S Video Analyzer Application Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.3, "Nonlinear Dis- tortions (Composite Input Signal)", on page 582. Example: CONF:VID:MEAS:NLIN:PAL:TSIG PPPC,T17C Sets the CCIR17 test signal for "C NL Phase pp". CONFigure<hw>:VIDeo:MEASure:NLINdist:RGB:LIMit:LOWer <ParameterName>, <LimitValue>...
  • Page 626 ® Remote Command Reference R&S Video Analyzer Application Parameters: <LimitValue> Specifies the upper limit for the parameter. See Chap- ter 14.4.2.3, "Nonlinear Distortions (Component, HDMI, MHL Input Signal)", on page 590. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.3, "Nonlinear Dis- tortions (Component, HDMI, MHL Input Signal)",...
  • Page 627 ® Remote Command Reference R&S Video Analyzer Application Parameters: <TestSignalName> Specifies the test signal. See Table 14-17. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.3, "Nonlinear Dis- tortions (Component, HDMI, MHL Input Signal)", on page 590. Example: CONF:VID:MEAS:NLIN:Y:TSIG "NLC3",TRAM Sets the "Ramp"...
  • Page 628 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:NOISe:NTSC:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:NOISe:NTSC:LIMit:LOWer? [<ParameterName>] CONFigure<hw>:VIDeo:MEASure:NOISe:PAL:LIMit:LOWer <ParameterName>, <LimitValue> CONFigure<hw>:VIDeo:MEASure:NOISe:PAL:LIMit:LOWer? [<ParameterName>] Configures the lower limit of the specified parameter for: ● Input signal: composite ● Parameter group: noise ● Video standard: BG/PAL or M/NTSC Suffix: <hw>...
  • Page 629 ® Remote Command Reference R&S Video Analyzer Application Example: CONF:VID:MEAS:NOIS:PAL:LIM:UPP LNLB,700.0 Sets an upper limit of 700.0 dB for "Lum Noise lumw (bar)". CONFigure<hw>:VIDeo:MEASure:NOISe:NTSC:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:NOISe:NTSC:SELect? [<ParameterName>] CONFigure<hw>:VIDeo:MEASure:NOISe:PAL:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:NOISe:PAL:SELect? [<ParameterName>] Enables or disables the measurement of the specified parameter for: ●...
  • Page 630 ® Remote Command Reference R&S Video Analyzer Application Example: CONF:VID:MEAS:NOIS:PAL:TSIG CSIB,T17C Sets the CCIR17 test signal for "C/SND Intermod (bar)". CONFigure<hw>:VIDeo:MEASure:NOISe:NTSC:WEIGhting <Weighting> Applies a weighting curve for: ● Input signal: composite ● Parameter group: noise, "Lum Noise" parameters ● Video standard: NTSC Suffix: <hw>...
  • Page 631 ® Remote Command Reference R&S Video Analyzer Application ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.2.5, "Noise (Component, HDMI, MHL Input Signal)", on page 594. Parameters for setting and query: <ParameterName>...
  • Page 632 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:NOISe:RGB:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:NOISe:RGB:SELect? <ParameterName> CONFigure<hw>:VIDeo:MEASure:NOISe:Y:SELect <ParameterName>, <Enable> CONFigure<hw>:VIDeo:MEASure:NOISe:Y:SELect? <ParameterName> Enables or disables the measurement of the specified parameter for: ● Input signal: component, HDMI, MHL ● Parameter group: noise ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw>...
  • Page 633 ® Remote Command Reference R&S Video Analyzer Application CONFigure<hw>:VIDeo:MEASure:NTSC:SELect:ALL <Enable> CONFigure<hw>:VIDeo:MEASure:PAL:SELect:ALL <Enable> CONFigure<hw>:VIDeo:MEASure:RGB:SELect:ALL <Enable> CONFigure<hw>:VIDeo:MEASure:Y:SELect:ALL <Enable> Enables/disables the measurement of all parameter at once. Suffix: <hw> Irrelevant Setting parameters: <Enable> OFF | ON Example: CONF:VID:MEAS:Y:SEL:ALL OFF Usage: Setting only Manual operation: "Enable All, Disable All button"...
  • Page 634 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.1.6, "Timing (Composite Input Signal)", on page 586. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.6, "Timing (Compo- site Input Signal)",...
  • Page 635 ® Remote Command Reference R&S Video Analyzer Application ● Video standard: BG/PAL or M/NTSC Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.6, "Timing (Compo- site Input Signal)", on page 586. Example: CONF:VID:MEAS:TIM:PAL:SEL LSRT,OFF CONFigure<hw>:VIDeo:MEASure:TIMing:NTSC:TSIGnal <ParameterName>,...
  • Page 636 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.2.6, "Timing (Component, HDMI, MHL Input Signal)", on page 594. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.6, "Timing (Compo- nent, HDMI, MHL Input Signal)",...
  • Page 637 ® Remote Command Reference R&S Video Analyzer Application ● Parameter group: timing ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.2.6, "Timing (Compo- nent, HDMI, MHL Input Signal)", on page 594.
  • Page 638 ® Remote Command Reference R&S Video Analyzer Application <line> 1 to 10 Location cursor number Parameters: <Value> The unit is set under UNIT<hw>:VIDeo:MEASure:TSIGnal: on page 671. LOCation Example: CONF:VID:MEAS:TSIG:LOC:CURS2:SPAN 675.0 Location cursor 2: Sets 675.0. Manual operation: "Location table" on page 155 CONFigure<hw>:VIDeo:MEASure:TSIGnal:NTSC:LINE <TestSignalName>, <FieldNumber>, <LineNumber>...
  • Page 639 ® Remote Command Reference R&S Video Analyzer Application Parameters: <LineNumber> Specifies the individual video line. Range: 6 (1st field) | 318 (2nd field) to 309 (1st field) | 622 (2nd field) Parameters for setting and query: <TestSignalName> Specifies the test signal. See Table 14-16.
  • Page 640 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Parameters: <LimitValue> Specifies the lower limit for the parameter. See Chap- ter 14.4.1.8, "Video Data (Composite Input Signal)", on page 587. Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.8, "Video Data (Composite Input Signal)",...
  • Page 641: Display Subsystem

    ® Remote Command Reference R&S Video Analyzer Application ● Parameter group: video data ● Video standard: BG/PAL or M/NTSC Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON Parameters for setting and query: <ParameterName> Specifies the parameter. See Chapter 14.4.1.8, "Video Data (Composite Input Signal)", on page 587.
  • Page 642 ® Remote Command Reference R&S Video Analyzer Application DISPlay<hw>:VIDeo:SELect:TAB <Tab> Selects the measurement. If the measurement is not already running, it is started. Suffix: <hw> Irrelevant Parameters: <Tab> INPut | AUTO | SCOPe | VECTor Corresponds to the tabs in the manual operation. Example: DISP:VID:SEL:TAB SCOP DISPlay<hw>[:WINDow]:SCOPe:TRACe:SELect <View>...
  • Page 643 ® Remote Command Reference R&S Video Analyzer Application Example: DISP:SCOP:TRAC:X:LPOS:PIX 56,100,500 Sets line number = 56, position = 100 px, display width = 500 px Manual operation: "<Chart display>" on page 137 "Line" on page 140 "Field" on page 140 "Span"...
  • Page 644: Initiate Subsystem

    ® Remote Command Reference R&S Video Analyzer Application Example: DISP:SCOP:TRAC:Y:POS -0.7,2.8 Shows -0.7 V to 2.1 V of the y-axis. Manual operation: "Y" on page 141 14.4.8 INITiate Subsystem ....................... 644 INITiate<hw>:VIDeo ................ 644 INITiate<hw>:VIDeo:MEASure:LOCation? ...............645 INITiate<hw>:VIDeo:MEASure:LOCation:DOWN ............645 INITiate<hw>:VIDeo:MEASure:LOCation:NTSC:UP ..............645 INITiate<hw>:VIDeo:MEASure:LOCation:PAL:UP .............645 INITiate<hw>:VIDeo:MEASure:LOCation:RGB:UP...
  • Page 645 ® Remote Command Reference R&S Video Analyzer Application Example: INIT:VID:MEAS:LOC? Query UP,"LBAA",PAL Response: <Status>,<ParameterName>,<Standard> Usage: Query only Manual operation: "Location table" on page 155 INITiate<hw>:VIDeo:MEASure:LOCation:DOWN Closes the location editor. Suffix: <hw> Irrelevant Example: INIT:VID:MEAS:LOC:DOWN Usage: Event Manual operation: "Location table" on page 155 INITiate<hw>:VIDeo:MEASure:LOCation:NTSC:UP <ParameterName>...
  • Page 646: Mmemory Subsystem

    MMEMory<hw>:VIDeo:MEASure:RESult:RGB:STORe <PathFile> MMEMory<hw>:VIDeo:MEASure:RESult:Y:STORe <PathFile> Saves the current measurement results as a CSV file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a new directory using MMEMory:MDIRectory on page 495.
  • Page 647 MMEMory<hw>:VIDeo:MEASure:SETTings:Y:STORe <PathFile> Saves the current auto and measurement settings as a binary VMVTX file in the speci- fied directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a new directory using MMEMory:MDIRectory on page 495.
  • Page 648: Read Subsystem

    ® Remote Command Reference R&S Video Analyzer Application Example: MMEM:VID:MEAS:SETT:PAL:STOR "D: \VTS\UserData\MySettings.vmvtx" Saves MySettings.vmvtx in the D:\VTS\UserData direc- tory. MMEMory<hw>:VIDeo:MEASure:STORe:SEParator <Type> Defines the column delimiter and decimal separator used in the CSV file saved by: ● on page 646 MMEMory<hw>:VIDeo:MEASure:RESult:NTSC:STORe ●...
  • Page 649 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Query parameters: <View> YGReen | CBBLue | CRRed | CCVS | SYNC CCVS For composite input signals YGReen | CBBLue | CRRed | SYNC For component input signals Return values: <y-Values>...
  • Page 650 ® Remote Command Reference R&S Video Analyzer Application Return values: <x- and y-Values> <dblock> Response consists of #535200, list of all x-values and list of all y-values. Each x- and y-value is a 8 byte floating point value. Usage: Query only Manual operation: "<Chart display>"...
  • Page 651 ® Remote Command Reference R&S Video Analyzer Application Usage: Query only Manual operation: "C1, C2" on page 141 READ<hw>[:SCALar]:VIDeo:AVERage:COUNt? Queries the current averaging level. Suffix: <hw> Irrelevant Return values: <Current> The number changes until the set level is reached. Example: READ:VID:AVER:COUN? Query 3.200000E+001...
  • Page 652 ® Remote Command Reference R&S Video Analyzer Application Example: READ:VID:COMP:FORM:DIG? Query Response Usage: Query only Manual operation: "Component Format" on page 135 READ<hw>[:SCALar]:VIDeo:FORMat? Queries the video resolution of the input signal. Suffix: <hw> Irrelevant Return values: <Lines> Number of vertical total pixels <Pixels>...
  • Page 653 ® Remote Command Reference R&S Video Analyzer Application Usage: Query only Manual operation: "Quantization" on page 134 "Quantization Range" on page 134 READ<hw>[:SCALar]:VIDeo:RESolution? Queries the current video resolution of the measured input signal. Suffix: <hw> Irrelevant Return values: <Current> "<horizontal resolution>x<vertical resolution> <frame rate>" Example: READ:VID:RES? Query...
  • Page 654 ® Remote Command Reference R&S Video Analyzer Application Example: READ:VID:STAN? Query Response Usage: Query only Manual operation: "Video Standard" on page 133 14.4.10.3 READ<hw>[:SCALar]:VIDeo:MEASure Subsystem Queries the results of the measured parameters..........654 READ<hw>[:SCALar]:VIDeo:MEASure:AMPDelay:NTSC? ............654 READ<hw>[:SCALar]:VIDeo:MEASure:AMPDelay:PAL? ...........655 READ<hw>[:SCALar]:VIDeo:MEASure:AMPDelay:RGB? ............655 READ<hw>[:SCALar]:VIDeo:MEASure:AMPDelay:Y? ..........656 READ<hw>[:SCALar]:VIDeo:MEASure:FRESponse:NTSC?
  • Page 655 ® Remote Command Reference R&S Video Analyzer Application ● Parameter group: amplitude and delay ● Video standard: BG/PAL or M/NTSC Suffix: <hw> Irrelevant Query parameters: <ParameterName> Specifies the parameter. See Chapter 14.4.1.1, "Amplitude and Delay (Composite Input Signal)", on page 580. Return values: <MeasValue>...
  • Page 656 ® Remote Command Reference R&S Video Analyzer Application READ<hw>[:SCALar]:VIDeo:MEASure:FRESponse:NTSC? <ParameterName> READ<hw>[:SCALar]:VIDeo:MEASure:FRESponse:PAL? <ParameterName> Queries the measured value of the specified parameter for: ● Input signal: composite ● Parameter group: frequency response ● Video standard: BG/PAL or M/NTSC Suffix: <hw> Irrelevant Query parameters: <ParameterName>...
  • Page 657 ® Remote Command Reference R&S Video Analyzer Application Example: READ:VID:MEAS:FRES:Y? "SXAposC1" Query 1.812717E+000,OK Response for "SINx/x Amplitude pos Y": measured value = 1.812717 dB, status = OK Usage: Query only READ<hw>[:SCALar]:VIDeo:MEASure:JITTer:NTSC? <ParameterName> READ<hw>[:SCALar]:VIDeo:MEASure:JITTer:PAL? <ParameterName> Queries the measured value of the specified parameter for: ●...
  • Page 658 ® Remote Command Reference R&S Video Analyzer Application Return values: <MeasValue> Measured value or INV if invalid. <Status> Specifies the status. See Table 14-18. Example: READ:VID:MEAS:JITT:Y? "LJPOS" Query 9.907014E-002,OK Response for "Line Jitter pos peak": measured value = 0.09907014 ns, status = OK Usage: Query only READ<hw>[:SCALar]:VIDeo:MEASure:LINDist:NTSC? <ParameterName>...
  • Page 659 ® Remote Command Reference R&S Video Analyzer Application Query parameters: <ParameterName> Specifies the parameter. See Chapter 14.4.2.2, "Linear Distor- tions (Component, HDMI, MHL Input Signal)", on page 589. Return values: <MeasValue> Measured value or INV if invalid. <Status> Specifies the status. See Table 14-18.
  • Page 660 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Query parameters: <ParameterName> Specifies the parameter. See Chapter 14.4.2.3, "Nonlinear Dis- tortions (Component, HDMI, MHL Input Signal)", on page 590. Return values: <MeasValue> Measured value or INV if invalid. <Status>...
  • Page 661 ® Remote Command Reference R&S Video Analyzer Application READ<hw>[:SCALar]:VIDeo:MEASure:NOISe:RGB? <ParameterName> READ<hw>[:SCALar]:VIDeo:MEASure:NOISe:Y? <ParameterName> Queries the measured value of the specified parameter for: ● Input signal: component, HDMI, MHL ● Parameter group: noise ● Video standard: component RGB or component YPbPr/YCbCr Suffix: <hw>...
  • Page 662 ® Remote Command Reference R&S Video Analyzer Application Example: READ:VID:MEAS:TIM:PAL? FPDE Query 2.35054678E+000,OK Response for "Equalizing Pulse Duration": measured value = 2.35054678 µs, status = OK Usage: Query only READ<hw>[:SCALar]:VIDeo:MEASure:TIMing:RGB? <ParameterName> READ<hw>[:SCALar]:VIDeo:MEASure:TIMing:Y? <ParameterName> Queries the measured value of the specified parameter for: ●...
  • Page 663 ® Remote Command Reference R&S Video Analyzer Application Manual operation: "Location table" on page 155 READ<hw>[:SCALar]:VIDeo:MEASure:TSIGnal:LOCation:CURSor<line>:NAME? Queries the name of the location where the cursor is positioned. Suffix: <hw> Irrelevant <Cursor> 1 to 10 Number of the measurement location Return values: <LocationName>...
  • Page 664 ® Remote Command Reference R&S Video Analyzer Application 14.4.10.4 READ<hw>[:SCALar]:VIDeo:VECTor Subsystem Queries the results of the vector measurement..............664 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR? ............664 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:BLACk? ............664 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:BLUE? ............664 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:CYAN? ............665 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:GREen? ............. 665 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:MAGenta? ............665 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:RED? ............665 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:WHITe? ............665 READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:YELLow? ..............665 READ<hw>[:SCALar]:VIDeo:VECTor:CURSor?
  • Page 665 ® Remote Command Reference R&S Video Analyzer Application READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:GREen? READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:MAGenta? READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:RED? READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:WHITe? READ<hw>[:SCALar]:VIDeo:VECTor:CBAR:YELLow? Queries the current measurement results for the given color. Suffix: <hw> Irrelevant Return values: <LumAmpl> Measured value of the luminance amplitude Default unit: mV <ChrAmpl> Measured value of the chrominance amplitude Default unit: mV <ChrPhase>...
  • Page 666 ® Remote Command Reference R&S Video Analyzer Application Example: READ:VID:VECT:CURS? Query 168,82,174 Response: luminance amplitude = 168 mV, chrominance ampli- tude = 82 mV, chrominance phase = 174 deg Usage: Query only Manual operation: "<Measurement results table>" on page 143 READ<hw>[:SCALar]:VIDeo:VECTor:CURSor:VPHase? Queries the current measurement results at the cursor position for the PAL standard.
  • Page 667: Route Subsystem

    ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Return values: <x-Values> <dblock> Response consists of #515360 and a list of all x-values. Each x- value is a 8 byte floating point value. Usage: Query only Manual operation: "<Chart display>"...
  • Page 668 ® Remote Command Reference R&S Video Analyzer Application Suffix: <hw> Irrelevant Return values: <Input> "<input type> [<module slot>], <input type> [<module slot>], ..." with <input type> see Table 14-19 and [<module slot>] see Chapter 14.1.1, "Addressing Module Slots", on page 480 Example: ROUT:VID:MOD:CAT? Query...
  • Page 669: Sense Subsystem

    ® Remote Command Reference R&S Video Analyzer Application 14.4.12 SENSe Subsystem ................669 SENSe<hw>:MEASure:VIDeo:FREeze ..........669 SENSe<hw>:VIDeo:VECTor:CORRection:GAIN[:INPut]:PHASe ........669 SENSe<hw>:VIDeo:VECTor:CORRection:GAIN[:INPut][:MAGNitude] SENSe<hw>:MEASure:VIDeo:FREeze <Enable> If enabled, retains measurement results for documentation. Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON *RST: Example: SENS:MEAS:VID:FRE OFF Measurement results are changing continuously. Manual operation: "Freeze"...
  • Page 670: Unit Subsystem

    ® Remote Command Reference R&S Video Analyzer Application Example: SENS:VID:VECT:CORR:GAIN 2 Sets an expansion of factor 2. Manual operation: "Gain" on page 145 14.4.13 UNIT Subsystem ............670 UNIT<hw>:VIDeo:MEASure:COMPonent:ANALog ...............670 UNIT<hw>:VIDeo:MEASure:COMPonent:DIGital ..............671 UNIT<hw>:VIDeo:MEASure:TSIGnal:LOCation UNIT<hw>:VIDeo:MEASure:COMPonent:ANALog <Unit> Sets the unit for the lower and upper limit for: ●...
  • Page 671: Audio Analyzer Application

    ® Remote Command Reference R&S Audio Analyzer Application UNIT<hw>:VIDeo:MEASure:TSIGnal:LOCation <Unit> Sets the unit for the measurement locations. Suffix: <hw> Irrelevant Parameters: <Unit> PIXel | US *RST: PIXel Example: UNIT:VID:MEAS:TSIG:LOC US Sets µs. Manual operation: "Location Unit" on page 155 14.5 Audio Analyzer Application These commands correlate to the functions provided in Chapter 9, "Audio Analyzer Application",...
  • Page 672: Calculate Subsystem

    ® Remote Command Reference R&S Audio Analyzer Application 14.5.2 CALCulate Subsystem ..........672 CALCulate<hw>:AUDio:CROSstalk:AVERage:ALGorithm ..........672 CALCulate<hw>:AUDio:CROSstalk:AVERage:SETTling:TIME ............672 CALCulate<hw>:AUDio:CROSstalk:AVERage:STATe ............672 CALCulate<hw>:AUDio:CROSstalk:AVERage:TIME ..........673 CALCulate<hw>:AUDio:CROSstalk:AVERage:TOLerance ............673 CALCulate<hw>:AUDio:FRESponse:AVERage:COUNt ..............673 CALCulate<hw>:AUDio:FRESponse:GRAPhics ..............673 CALCulate<hw>:AUDio:FRESponse:MODE ..............674 CALCulate<hw>:AUDio:FRESponse:PKHold ............674 CALCulate<hw>:AUDio:IPHase:AVERage:ALGorithm ..........674 CALCulate<hw>:AUDio:IPHase:AVERage:SETTling:TIME ..............674 CALCulate<hw>:AUDio:IPHase:AVERage:STATe ...............
  • Page 673 ® Remote Command Reference R&S Audio Analyzer Application Manual operation: "Averaging button" on page 189 CALCulate<hw>:AUDio:CROSstalk:AVERage:TOLerance <Setting> on page 676. CALCulate<hw>:AUDio:LEVel:AVERage:TOLerance Manual operation: "Averaging button" on page 189 CALCulate<hw>:AUDio:FRESponse:AVERage:COUNt <Value> Sets the number of FFT measurements to be averaged for the chart display. Suffix: <hw>...
  • Page 674 ® Remote Command Reference R&S Audio Analyzer Application Example: CALC:AUD:FRES:MODE FSW Sets FFT spectrum. Manual operation: "Mode" on page 181 CALCulate<hw>:AUDio:FRESponse:PKHold <Enable> Enables or disables the peak hold. Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON *RST: Example: CALC:AUD:FRES:PKH ON Manual operation: "Peak Hold"...
  • Page 675 ® Remote Command Reference R&S Audio Analyzer Application CALCulate<hw>:AUDio:LEVel:AVERage:ALGorithm <Setting> Sets the algorithms for smoothing the measurement results. Suffix: <hw> Irrelevant Parameters: <Setting> AVERage | FLAT *RST: AVERage Example: CALC:AUD:LEV:AVER:ALG FLAT Reduces the effect of outlying measurements. Manual operation: "Algorithm" on page 176 CALCulate<hw>:AUDio:LEVel:AVERage:SETTling:TIME <Setting>...
  • Page 676 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Parameters: <Setting> Range: 0.000 to 10.000 *RST: 0.100 Default unit: s Example: CALC:AUD:LEV:AVER:TIME 0.01 Sets 0.010 s. Manual operation: "Average Time" on page 176 CALCulate<hw>:AUDio:LEVel:AVERage:TOLerance <Setting> Sets the tolerance range. Suffix: <hw>...
  • Page 677: Configure Subsystem

    ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Parameters: <Time> Range: 0.001 to 10.000 *RST: 0.001 Default unit: s Example: CALC:AUD:LEV:INT:TIME 3 Manual operation: "Interval Time Config dialog" on page 177 CALCulate<hw>:AUDio:THDN:AVERage:ALGorithm <Setting> on page 675. CALCulate<hw>:AUDio:LEVel:AVERage:ALGorithm Manual operation: "Averaging button"...
  • Page 678 ® Remote Command Reference R&S Audio Analyzer Application ............679 CONFigure<hw>:AUDio:FRESponse:RESult:CLEar ..............680 CONFigure<hw>:AUDio:FRESponse:SELect ................. 680 CONFigure<hw>:AUDio:INPut:COUPling ............... 680 CONFigure<hw>:AUDio:INPut:IMPedance ..............681 CONFigure<hw>:AUDio:IPHase:REFerence ............681 CONFigure<hw>:AUDio:QC:CALibrate:AUTO:DELay ............681 CONFigure<hw>:AUDio:QC:CALibrate:AUTO:GAIN ..............682 CONFigure<hw>:AUDio:QC:CALibrate:DELay ..............682 CONFigure<hw>:AUDio:QC:CALibrate:GAIN ...........682 CONFigure<hw>:AUDio:QC:CALibrate:REFerence:GAIN ................683 CONFigure<hw>:AUDio:QC:REFerence ..............683 CONFigure<hw>:AUDio:QC:RESult:SELect ................683 CONFigure<hw>:AUDio:SNR:NLENgth ................
  • Page 679 ® Remote Command Reference R&S Audio Analyzer Application CONFigure<hw>:AUDio:FRESponse:CURSor:STEP <Direction> Moves the cursor one step in the defined direction. Suffix: <hw> Irrelevant Parameters: <Direction> PREViousfreq | NEXTfreq Example: CONF:AUD:FRES:CURS:STEP PREV Moves the cursor to the next lower frequency value. Manual operation: "Cursor"...
  • Page 680 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Example: CONF:AUD:FRES:RES:CLE Usage: Event Manual operation: "Clear button" on page 185 CONFigure<hw>:AUDio:FRESponse:SELect <Enable> Enables or disables the display of each input channel trace in the chart. Suffix: <hw> Irrelevant Parameters: <Enable>...
  • Page 681 ® Remote Command Reference R&S Audio Analyzer Application Parameters: <Value> HIGH | R600 *RST: HIGH Example: CONF:AUD:INP:IMP R600 Sets 600 Ω. Manual operation: "Impedance" on page 160 CONFigure<hw>:AUDio:IPHase:REFerence <Channel> Sets the signal source channel. Suffix: <hw> Irrelevant Parameters: <Channel> "CH1" to "<highest channel for selected input source>" *RST: "CH1"...
  • Page 682 ® Remote Command Reference R&S Audio Analyzer Application Example: CONF:AUD:QC:CAL:AUTO:GAIN ON Manual operation: "Auto Gain" on page 194 CONFigure<hw>:AUDio:QC:CALibrate:DELay <Setting> Sets the delay between measurement starting and capture starting. Suffix: <hw> Irrelevant Parameters: <Setting> Range: 0.000 to 5.000 *RST: 0.000 Default unit: s Example: CONF:AUD:QC:CAL:DEL 1...
  • Page 683 ® Remote Command Reference R&S Audio Analyzer Application Example: CONF:AUD:QC:CAL:REF:GAIN 3 Sets 3.00 dB. Manual operation: "Gain" on page 194 CONFigure<hw>:AUDio:QC:REFerence <Channel> Sets the channel used for audio capture. Suffix: <hw> Irrelevant Parameters: <Channel> "CH1" to "<highest channel for selected input source>" *RST: "CH1"...
  • Page 684 ® Remote Command Reference R&S Audio Analyzer Application Manual operation: "Noise Length" on page 187 CONFigure<hw>:AUDio:SNR:SLENgth <Signal> Sets the signal length that is analyzed for each cycle. Suffix: <hw> Irrelevant Parameters: <Signal> S1 | S2 | S3 | S4 | S5 *RST: Example: CONF:AUD:SNR:SLEN S2...
  • Page 685: Display Subsystem

    ® Remote Command Reference R&S Audio Analyzer Application 14.5.4 DISPlay Subsystem ................685 DISPlay<hw>:AUDio:FRESponse:UNIT ..................685 DISPlay<hw>:AUDio:SELect:TAB ................685 DISPlay<hw>:AUDio:WAVeform:ZOOM DISPlay<hw>:AUDio:FRESponse:UNIT <Chart> Sets the unit used for the y-axis of the frequency response chart. Suffix: <hw> Irrelevant Parameters: <Chart> VRMS | DBV | DBU | DBRA | DBRB | DB1Spl | DB2Spl | VPP The available units depend on the selected device: analog or digital.
  • Page 686: Initiate Subsystem

    ...............687 MMEMory<hw>:AUDio:QC:REPort:STORe MMEMory<hw>:AUDio:FRESponse:RESult:STORe <PathFile> Saves the current measurement results as a CSV file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 687 196 MMEMory<hw>:AUDio:QC:REPort:STORe <PathFile> Saves the test report as a TXT file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 688: Read Subsystem

    <PathFile> Filename including the extension. If the path is omitted, the cur- rent directory is used. Example: MMEM:AUD:QC:REP:STOR "D: \VTS\UserData\AUDIOANALYZER\MyTestFile.txt" Saves MyTestFile.txt in the D:\VTS\UserData\AUDIOANALYZER directory. Manual operation: "Save button" on page 193 14.5.7 READ Subsystem .............. 691 READ<hw>:ARRay:AUDio:FRESponse:TRACe? ..............691 READ<hw>:ARRay:AUDio:QC:RESult:TRACe?
  • Page 689 ® Remote Command Reference R&S Audio Analyzer Application ..707 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:AUDiomode? ..707 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:CATegorycode? .....707 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:CHANnel? ....708 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:CLKacc? ..... 708 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:COPYbit? ..... 709 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:CSMode? ....709 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:LBIT? ..709 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:MWLength? ....710 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:OSRate? ..710 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:PREemphasis? ..... 710 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:SOURce? ....711 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:SRATe? .... 711 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:WLENgth? ......
  • Page 690 ® Remote Command Reference R&S Audio Analyzer Application ..725 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:MCMControl? ...726 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:MCMNumber? ..726 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:MCNumber? ..726 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:ORData? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: ....................727 PREemphasis? ..727 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:REFSignal? ..728 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:SADDress? .... 728 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:SRATe? ..728 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:SRSCale? ..729 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:TODaddress? ..729 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:UBLength? ..730 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:UBManage? ..730 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA:VALidflag? ..
  • Page 691 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: ....................742 PREemphasis? ... 742 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity:REFSignal? ... 742 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity:SADDress? ..743 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity:SRATe? ..743 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity:SRSCale? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: ...................... 744 TODaddress? ..744 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity:UBLength? READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: ......................744 UBManage? ..745 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity:WLENgth? ....745 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:WLENgth? ......745 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:VALidity:MODE? ..........
  • Page 692 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:ARR:AUD:QC:RES:TRAC? Query #511200 Response Usage: Query only Manual operation: "<Results graphs>" on page 195 READ<hw>:ARRay:AUDio:QC:WAVeform:TRACe? Queries the x- and y-trace of the waveform display. Suffix: <hw> Irrelevant Return values: <x- and y-Values> <dblock>...
  • Page 693 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Measurement> NONE | LEVel | THDN | SNR | CROSstalk | IPHase | FRESponse | QC Example: READ:AUD:COMM:STAT? Query FRES Response: frequency response measurement Usage: Query only READ<hw>[:SCALar]:AUDio:CROSstalk:COMMand:PROGress? Queries the progress of the crosstalk measurement.
  • Page 694 ® Remote Command Reference R&S Audio Analyzer Application Query parameters: <ChannelNumber> Return values: <Crosstalk> Unit is set by SENSe<hw>:AUDio:CROSstalk:UNIT on page 749. <Level> Unit depends on the input device: on page 756 SENSe<hw>:AUDio:UNIT:LEVel:ANALog on page 756. SENSe<hw>:AUDio:UNIT:LEVel:DIGitial <Frequency> Unit is set by SENSe<hw>:AUDio:UNIT:FREQuency on page 756.
  • Page 695 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:DLEVel:MEASure:VALue? <ChannelNumber> Queries the measured RMS difference level and the corresponding frequency for each channel. Suffix: <hw> Irrelevant Query parameters: <ChannelNumber> Range depends on the input signal. Return values: <Level> Unit depends on the input device: on page 756 SENSe<hw>:AUDio:UNIT:LEVel:ANALog on page 756.
  • Page 696 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:FRES:COMM:PROG? Query Response Usage: Query only READ<hw>[:SCALar]:AUDio:IPHase:COMMand:PROGress? Queries the progress of the interchannel phase measurement. A detailed response is only available if ON is set under CALCulate<hw>:AUDio:IPHase:AVERage:STATe on page 674. Suffix: <hw>...
  • Page 697 ® Remote Command Reference R&S Audio Analyzer Application <Frequency> Unit is set by SENSe<hw>:AUDio:UNIT:FREQuency on page 756. Example: READ:AUD:IPH:MEAS:VAL? 1 Query 0.000000E+000,-2.000972E+001,2.000017E+004 Response for channel 1: phase = 0.000000 deg, level = -20.00972 dBV, frequency = 20 000.17 Hz Usage: Query only Manual operation: "<Channel table>"...
  • Page 698 ® Remote Command Reference R&S Audio Analyzer Application <Frequency> Unit is set by SENSe<hw>:AUDio:UNIT:FREQuency on page 756. Example: READ:AUD:LEV:MEAS:VAL? 1 Query -2.001000E+001,2.000017E+004 Response for channel 1: level = -20.01000 dBV, frequency = 20 000.17 Hz Usage: Query only Manual operation: "<Channel table>"...
  • Page 699 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:QC:MEASure:MOS? Queries the final mean opinion score (MOS) after a successful measurement has been completed. Suffix: <hw> Irrelevant Return values: <MeasValue> MOS value Example: READ:AUD:QC:MEAS:MOS? Query 2.105680E+000 Response Usage: Query only Manual operation: "MOS Score"...
  • Page 700 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:QC:REF:LENG? Query 5.760000E+008 Response Usage: Query only Manual operation: "Load button" on page 196 READ<hw>[:SCALar]:AUDio:QC:REFerence:VALFile? Queries the validity of the reference file. Suffix: <hw> Irrelevant Return values: <Validity> OK | ERRor | UNSupported Example: READ:AUD:QC:REF:VALF? Query...
  • Page 701 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:QC:REPort:COUNt? Queries the number of entry lines in the audio quality test report. Suffix: <hw> Irrelevant Return values: <Entries> Total number of lines Example: READ:AUD:QC:REP:COUN? Query Response Usage: Query only Manual operation: "<Test report>"...
  • Page 702 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:QC:RES:YSC? Query -1.390500E+000,5.000000E+000 Response Usage: Query only Manual operation: "<Results graphs>" on page 195 READ<hw>[:SCALar]:AUDio:QC:WAVeform:XSCale? Queries the x-scale of the waveform display. Suffix: <hw> Irrelevant Return values: <Min> Minimum value of the x-scale. <Max>...
  • Page 703 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SAMPle:FORMat? Queries the current sample bit size. Suffix: <hw> Irrelevant Return values: <Value> Bit size Example: READ:AUD:SAMP:FORM? Query Response Usage: Query only Manual operation: "Sample Format" on page 161 READ<hw>[:SCALar]:AUDio:SAMPle:RATE? Queries the current sample rate from the selected audio source. Suffix: <hw>...
  • Page 704 ® Remote Command Reference R&S Audio Analyzer Application Usage: Query only READ<hw>[:SCALar]:AUDio:SNR:COMMand:PROGress? Queries the progress of the signal to noise ratio (SNR) measurement. Suffix: <hw> Irrelevant Return values: <Indicator> Measurement progress in % Example: READ:AUD:SNR:COMM:PROG? Query Response: 33 % Usage: Query only READ<hw>[:SCALar]:AUDio:SNR:MEASure:VALue? <ChannelNumber>...
  • Page 705 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:CONS:AUD? Query Response: linear PCM Usage: Query only Manual operation: "Audio Mode" on page 165 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer: CATegorycode? Queries the category code. For consumer mode. Suffix: <hw> Irrelevant Return values: <Setting> GENeral | LASer | DCSP | MAGTape | BRDCst | MIC-w/o | MIC-w/ | ADC-w/o | ADC-w/ | SSMP | REServed Example: READ:AUD:SPD:CHAN:STAT:CONS:CAT?
  • Page 706 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:CLKacc? Queries the clock accuracy. For consumer mode. Suffix: <hw> Irrelevant Return values: <Setting> LEV1 | LEV2 | LEV3 | NONE Example: READ:AUD:SPD:CHAN:STAT:CONS:CLK? Query LEV1 Response Usage: Query only Manual operation: "Clock Accuracy" on page 167 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:COPYbit? Queries the copy bit.
  • Page 707 ® Remote Command Reference R&S Audio Analyzer Application Usage: Query only Manual operation: "Channel Status Mode" on page 167 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA: AUDiomode? Queries the audio mode data. For consumer mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:CONS:DATA:AUD? Query Response Usage: Query only...
  • Page 708 ® Remote Command Reference R&S Audio Analyzer Application Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:CONS:DATA:CHAN? Query Response Usage: Query only Manual operation: "Channel Number" on page 167 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:CLKacc? Queries the clock accuracy data. For consumer mode. Suffix: <hw> Irrelevant Return values: <Value>...
  • Page 709 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA: CSMode? Queries the channel status mode data. For consumer mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:CONS:DATA:CSM? Query Response Usage: Query only Manual operation: "Channel Status Mode" on page 167 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:LBIT? Queries the L-bit data.
  • Page 710 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:CONS:DATA:MWL? Query Response Usage: Query only Manual operation: "Maximum Word Length" on page 169 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:OSRate? Queries the original sampling frequency data. For consumer mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:CONS:DATA:OSR? Query...
  • Page 711 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:CONS:DATA:SOUR? Query Response Usage: Query only Manual operation: "Source Number" on page 171 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:DATA:SRATe? Queries the sampling frequency data. For consumer mode. Suffix: <hw>...
  • Page 712 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:LBIT? Queries the L-bit. For consumer mode. Suffix: <hw> Irrelevant Return values: <Setting> NONE | PRERec Example: READ:AUD:SPD:CHAN:STAT:CONS:LBIT? Query NONE Response Usage: Query only Manual operation: "L-Bit" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:MWLength? Queries the maximal word length. For consumer mode. Suffix: <hw>...
  • Page 713 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:CONS:OSR? Query HZ88200 Response Usage: Query only Manual operation: "Original Sampling Frequency" on page 170 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:PREemphasis? Queries the pre-emphasis. For consumer mode. Suffix: <hw> Irrelevant Return values: <Setting> NONE | 50/15 | REServed Example: READ:AUD:SPD:CHAN:STAT:CONS:PRE? Query...
  • Page 714 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Setting> HZ22050 | HZ44100 | HZ88200 | HZ176400 | HZ24000 | HZ48000 | HZ96000 | HZ192000 | HZ32000 | NOTindicated Example: READ:AUD:SPD:CHAN:STAT:CONS:SRAT? Query HZ44100 Response Usage: Query only Manual operation: "Sampling Frequency"...
  • Page 715 ® Remote Command Reference R&S Audio Analyzer Application Usage: Query only Manual operation: "Category Code" on page 166 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: CHANnel? Queries the channel number validity. For consumer mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:CONS:VAL:CHAN? Query Response Usage: Query only...
  • Page 716 ® Remote Command Reference R&S Audio Analyzer Application Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:CONS:VAL:COPY? Query Response Usage: Query only Manual operation: "Copy Bit" on page 167 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: CSMode? Queries the channel status mode validity. For consumer mode. Suffix: <hw>...
  • Page 717 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: MWLength? Queries the maximal word length validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:CONS:VAL:MWL? Query Response Usage: Query only Manual operation: "Maximum Word Length" on page 169 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: OSRate?
  • Page 718 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:CONS:VAL:PRE? Query Response Usage: Query only Manual operation: "Pre-Emphasis" on page 170 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: SOURce? Queries the source number validity. For consumer mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:CONS:VAL:SOUR? Query...
  • Page 719 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:VALidity: WLENgth? Queries the word length validity. For consumer mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:CONS:VAL:WLEN? Query Response Usage: Query only Manual operation: "Word Length" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:CONSumer:WLENgth? Queries the word length.
  • Page 720 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:DATA:MODE? Query Response: enabled Usage: Query only Manual operation: "Channel Status Mode" on page 165 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:MODE? Queries the mode. Suffix: <hw> Irrelevant Return values: <Setting> CONSumer | PROFessional Example: READ:AUD:SPD:CHAN:STAT:MODE? Query PROF Response Usage:...
  • Page 721 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Setting> PCM | OTHer Example: READ:AUD:SPD:CHAN:STAT:PROF:AUD? Query Response: linear PCM Usage: Query only Manual operation: "Audio Mode" on page 165 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: CHANmode? Queries the channel mode. For professional mode. Suffix: <hw>...
  • Page 722 ® Remote Command Reference R&S Audio Analyzer Application Manual operation: "Channel Number" on page 167 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:CRCFlag? Queries the cyclic redundancy check (CRC) flag. For professional mode. Suffix: <hw> Irrelevant Return values: <Setting> OK | NOT Example: READ:AUD:SPD:CHAN:STAT:PROF:CRCF? Query Response Usage: Query only Manual operation: "Cyclic Redundancy Check Character"...
  • Page 723 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:AUD? Query Response Usage: Query only Manual operation: "Audio Mode" on page 165 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: CHANmode? Queries the encoded channel mode data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:CHAN? Query...
  • Page 724 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: CRCFlag? Queries the cyclic redundancy check (CRC) flag data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:CRCF? Query Response Usage: Query only Manual operation: "Cyclic Redundancy Check Character" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: DEData?
  • Page 725 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:ESR? Query Response Usage: Query only Manual operation: "Encoded Sampling Frequency" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: LOCK? Queries the lock indication data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:LOCK? Query...
  • Page 726 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: MCMNumber? Queries the multichannel mode number data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:MCMN? Query Response Usage: Query only Manual operation: "Multichannel Mode" on page 169 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: MCNumber? Queries the multichannel number data.
  • Page 727 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:ORD? Query 281474976710655 Response Usage: Query only Manual operation: "Origin Data" on page 170 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: PREemphasis? Queries the pre-emphasis data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:PRE? Query...
  • Page 728 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: SADDress? Queries the local sample address code data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:SADD? Query 2147483647 Response Usage: Query only Manual operation: "Local Address" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: SRATe?
  • Page 729 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:SRSC? Query Response Usage: Query only Manual operation: "Sampling Frequency Scaling" on page 171 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: TODaddress? Queries the time-of-day sample address code data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value>...
  • Page 730 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: UBManage? Queries the encoded user bits management data. For professional mode. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:UBM? Query Response Usage: Query only Manual operation: "User Bits Management" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DATA: VALidflag?
  • Page 731 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:DATA:WLEN? Query Response Usage: Query only Manual operation: "Word Length" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:DEData? Queries the destination data. For professional mode. Suffix: <hw> Irrelevant Return values: <Setting> Example: READ:AUD:SPD:CHAN:STAT:PROF:DED? Query "Destination" Response Usage: Query only...
  • Page 732 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Setting> OK | NOT Example: READ:AUD:SPD:CHAN:STAT:PROF:FLAG? Query Response Usage: Query only Manual operation: "Valid Flag" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:LOCK? Queries the lock indication. For professional mode. Suffix: <hw>...
  • Page 733 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: MCMNumber? Queries the multichannel mode number. For professional mode. Suffix: <hw> Irrelevant Return values: <Setting> 0 | 1 | 2 | 3 | NONE Example: READ:AUD:SPD:CHAN:STAT:PROF:MCMN? Query Response Usage: Query only Manual operation: "Multichannel Mode"...
  • Page 734 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:ORD? Query "Origin" Response Usage: Query only Manual operation: "Origin Data" on page 170 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: PREemphasis? Queries the pre-emphasis. For professional mode. Suffix: <hw> Irrelevant Return values: <Setting> NOTindicated | 50/15 | ITU-t | NONE Example: READ:AUD:SPD:CHAN:STAT:PROF:PRE? Query...
  • Page 735 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Setting> String Example: READ:AUD:SPD:CHAN:STAT:PROF:SADD? Query 2147483647 Response Usage: Query only Manual operation: "Local Address" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:SRATe? Queries the sampling frequency. For professional mode. Suffix: <hw> Irrelevant Return values: <Setting>...
  • Page 736 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional: TODaddress? Queries the time-of-day sample address code. For professional mode. Suffix: <hw> Irrelevant Return values: <Setting> Numeric value Example: READ:AUD:SPD:CHAN:STAT:PROF:TOD? Query 2147483647 Response Usage: Query only Manual operation: "Time of Day" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:UBLength? Queries the encoded use of auxiliary sample bits.
  • Page 737 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:UBM? Query B192 Response Usage: Query only Manual operation: "User Bits Management" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: ALIGnment? Queries the alignment level validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:ALIG?
  • Page 738 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: CHANmode? Queries the encoded channel mode validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:CHAN? Query Response Usage: Query only Manual operation: "Channel Mode" on page 166 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: CHNumber? Queries the channel number validity.
  • Page 739 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:CRCF? Query Response Usage: Query only Manual operation: "Cyclic Redundancy Check Character" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: DEData? Queries the channel destination data validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result>...
  • Page 740 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: LOCK? Queries the lock indication validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:LOCK? Query Response Usage: Query only Manual operation: "Lock Indication" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: MCMControl? Queries the multichannel mode control validity.
  • Page 741 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:MCMN? Query Response Usage: Query only Manual operation: "Multichannel Mode" on page 169 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: MCNumber? Queries the multichannel number validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:MCN? Query...
  • Page 742 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: PREemphasis? Queries the pre-emphasis validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:PRE? Query Response Usage: Query only Manual operation: "Pre-Emphasis" on page 170 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: REFSignal? Queries the reference signal validity.
  • Page 743 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:SADD? Query Response Usage: Query only Manual operation: "Local Address" on page 168 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: SRATe? Queries the sampling frequency validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:SRAT? Query...
  • Page 744 ® Remote Command Reference R&S Audio Analyzer Application READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: TODaddress? Queries the time-of-day sample address code validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:TOD? Query Response Usage: Query only Manual operation: "Time of Day" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: UBLength?
  • Page 745 ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:SPD:CHAN:STAT:PROF:VAL:UBM? Query Response Usage: Query only Manual operation: "User Bits Management" on page 172 READ<hw>[:SCALar]:AUDio:SPDif:CHANnel:STATus:PROFessional:VALidity: WLENgth? Queries the encoded audio sample word length validity. For professional mode. Suffix: <hw> Irrelevant Return values: <Result>...
  • Page 746 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Return values: <Status> VALid | ERRoneous Example: READ:AUD:SPD:CHAN:STAT:VAL:MODE? Query Response Usage: Query only Manual operation: "Channel Status Mode" on page 165 READ<hw>[:SCALar]:AUDio:SPDif:SOURce:SUPPorted? Queries if the audio source supports the IEC 60958 protocol. Suffix: <hw>...
  • Page 747: Route Subsystem

    ® Remote Command Reference R&S Audio Analyzer Application Example: READ:AUD:THDN:COMM:PROG? Query Response Usage: Query only READ<hw>[:SCALar]:AUDio:THDN:MEASure:VALue? <ChannelNumber> Queries the measured THD+N, the RMS level and the corresponding frequency for each channel. Suffix: <hw> Irrelevant Query parameters: <ChannelNumber> Range depends on the input signal. Return values: <THD+N>...
  • Page 748 ® Remote Command Reference R&S Audio Analyzer Application <Input type> Description Required option HDMI 600MHz Audio return channel (ARC) from HDMI RX/TX 600 MHz module (R&S VT-B2363) HDMI generator output HDMI 600MHz Digital audio interface via HDMI RX/TX 600 MHz module (R&S VT-B2363) S/PDIF TOSLINK HDMI Tx Arc...
  • Page 749: Sense Subsystem

    ® Remote Command Reference R&S Audio Analyzer Application Parameters: <Input> "<input type> [<module slot>]" with <input type> see Table 14-20 and [<module slot>] see Chapter 14.1.1, "Addressing Module Slots", on page 480 Example: ROUT:AUD:MOD:SEL "Analog L/R [L1]" Selects the analog audio input signal, slot 1. Manual operation: "Input"...
  • Page 750 ® Remote Command Reference R&S Audio Analyzer Application Suffix: <hw> Irrelevant Parameters: <Chart> XY | PCT | PPM | DB Table 9-6. *RST: Example: SENS:AUD:CROS:UNIT PPM Sets ppm. Manual operation: "Crosstalk" on page 188 SENSe<hw>:AUDio:FRESponse:FILTer<index> <FilterName> on page 750. SENSe<hw>:AUDio:LEVel:FILTer<Index> Manual operation: "Settings dialog"...
  • Page 751 ® Remote Command Reference R&S Audio Analyzer Application <Index> Sets the filter index. Parameters: <FilterName> "Disabled" | "A Weighting" | "C Message" | "CCITT" | "CCIR 1k/ ITU468" | "CCIR 2k" | "De-Emphasis 50 15" | "De-Emphasis 50" | "De-Emphasis 75" | "IEC Tuner" | "JITTW" | "Pre-Emphasis 50 15"...
  • Page 752 ® Remote Command Reference R&S Audio Analyzer Application Manual operation: "<Results graphs>" on page 195 SENSe<hw>:AUDio:QC:WAVeform:CATalog <Type> Sets the waveform that is displayed. Suffix: <hw> Irrelevant Parameters: <Type> REFerence | CAPTured *RST: Example: SENS:AUD:QC:WAV:CAT CAPT Displays the captured audio waveform. Manual operation: "<Waveform display>"...
  • Page 753 ® Remote Command Reference R&S Audio Analyzer Application SENSe<hw>:AUDio:REFerence:ANALog:DBSPl<source> <Level> Sets the reference level for measuring the sound pressure level. For analog input devi- ces. Suffix: <hw> Irrelevant <source> Sets the sound source. Parameters: <Level> Range: 0.0000 to 10.0000 *RST: 1.0000 Default unit: V(rms) Example:...
  • Page 754 ® Remote Command Reference R&S Audio Analyzer Application SENSe<hw>:AUDio:REFerence:DIGital:DBRA <RefLevel> Sets the reference level for input using dBrA. For digital input devices. Suffix: <hw> Irrelevant Parameters: <RefLevel> Range: 0.000 to 1.000 *RST: 1.000 Default unit: FS Example: SENS:AUD:REF:DIG:DBRA 0.08 Manual operation: "dBrA Reference "...
  • Page 755 ® Remote Command Reference R&S Audio Analyzer Application SENSe<hw>:AUDio:REFerence:DIGital:OFFSet:DBRA <RefOffset> Sets the reference offset level for input using dBrA. For digital input devices. Suffix: <hw> Irrelevant Parameters: <RefOffset> Range: -180.000 to 180.000 *RST: 0.000 Default unit: dB Example: SENS:AUD:REF:DIG:OFFS:DBRA 2 Manual operation: "dBrA Offset"...
  • Page 756 ® Remote Command Reference R&S Audio Analyzer Application Example: SENS:AUD:SNR:UNIT XY Sets x/y. Manual operation: "SNR" on page 186 SENSe<hw>:AUDio:THDN:FILTer<index> <FilterName> on page 750. SENSe<hw>:AUDio:LEVel:FILTer<Index> Manual operation: "Filter" on page 179 SENSe<hw>:AUDio:UNIT:FREQuency <Unit> Sets the unit for the measured frequency. Suffix: <hw>...
  • Page 757: Hdmi Generator Application

    ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Unit> FS | PCTFs | DBFS | DBRA | DBRB | DB1Spl | DB2Spl Table 9-3. Default unit: DBFS Example: SENS:AUD:UNIT:LEV:DIG FS Sets full-scale. Manual operation: "<Unit selector>" on page 174 SENSe<hw>:AUDio:UNIT:THDN <Chart>...
  • Page 758: Abort Subsystem

    ® Remote Command Reference R&S HDMI Generator Application 14.6.1 ABORt Subsystem ..................758 ABORt<hw>:HDGenerator:CEC ..................758 ABORt<hw>:HDGenerator:CTS ABORt<hw>:HDGenerator:CEC Stops the running CEC measurement. Suffix: <hw> Irrelevant Example: ABOR:HDG:CEC Usage: Event Manual operation: "Stop button" on page 274 ABORt<hw>:HDGenerator:CTS Stops the running CTS measurement. Suffix: <hw>...
  • Page 759 RD = recording device, TUN = tuner, PD = playback device, R = reserved *RST: Example: CONF:HDG:CEC:DEST RD2 Manual operation: "Destination" on page 273 CONFigure<hw>:HDGenerator:CEC:LADDress <Address> Sets the logical address of the R&S VTS. Suffix: <hw> Irrelevant User Manual 2116.1228.02 ─ 14...
  • Page 760 *RST: Example: CONF:HDG:CEC:LADD RD2 Manual operation: "Logical Address" on page 273 CONFigure<hw>:HDGenerator:CEC:OPCode <OperationCode> Sets the operation code (opcode) of the CEC command that is sent by the R&S VTS. Suffix: <hw> Irrelevant Parameters: <OperationCode> Specifies the operation code. See Chapter 10.4.4, "CEC Com- munication",...
  • Page 761 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:CEC:OPCode:PARam:LENGth <OperationCode>, <Number> CONFigure<hw>:HDGenerator:CEC:OPCode:PARam:LENGth? <OperationCode> Sets the number of parameters for the specified operation code. Suffix: <hw> Irrelevant Parameters: <Number> Parameters for setting and query: <OperationCode> Specifies the operation code. See Chapter 10.4.4, "CEC Com- munication", on page 356.
  • Page 762 ® Remote Command Reference R&S HDMI Generator Application Test case name Remote command Available for following outputs parameter "Rx/Tx 600MHz" "Tx "CTS Rx/Tx (<test case>) 300MHz" 600MHz" "8-19 Pixel Encoding Requirements" M004_pixelen "8-20 Video Format Timing" M005_vformat "8-21 Audio Clock Regeneration" M006_audiocl "8-22 Audio Sample Packet Jitter"...
  • Page 763 ® Remote Command Reference R&S HDMI Generator Application Test case name Remote command Available for following outputs parameter "Rx/Tx 600MHz" "Tx "CTS Rx/Tx (<test case>) 300MHz" 600MHz" "HF2-53 HF-VSDB" H253_hfvsdb "HF2-54 HDR Static Metadata Data Block" H254_smdb ..............763 CONFigure<hw>:HDGenerator:CTS:AFORmat ..............763 CONFigure<hw>:HDGenerator:CTS:CDEPth ..............764...
  • Page 764 ® Remote Command Reference R&S HDMI Generator Application Parameters: <ColorDepth> B10 | B12 | B16 Value in bit Parameters for setting and query: <TestCase> Specifies the test case. See Table 14-21. Example: CONF:HDG:CTS:CDEP M011, B12 Manual operation: "Color Depth" on page 264 CONFigure<hw>:HDGenerator:CTS:CDFSink <TestCase>, <CDF>, <Support>...
  • Page 765 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:CTS:CDFS M001, "SupportsAI", NO Manual operation: "<CDF sink parameters>" on page 261 "<CDF sink parameters>" on page 262 "<CDF sink parameters>" on page 268 "<CDF sink parameters>" on page 269 "<CDF sink parameters>" on page 269 "<CDF sink parameters>"...
  • Page 766 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Numerator> MINimum | MAXimum *RST: MINimum Parameters for setting and query: <TestCase> M006 Applies only to "8-21 Audio Clock Regeneration". Example: CONF:HDG:CTS:NVAL M006, MAX Manual operation: "N Value" on page 263 CONFigure<hw>:HDGenerator:CTS:OUTPut <Port>...
  • Page 767 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:CTS:PCL:FREQ M005, MIN Manual operation: "Pixel Clock Frequency" on page 262 CONFigure<hw>:HDGenerator:CTS:PIXelencode <TestCase>, <PixelEncoding> CONFigure<hw>:HDGenerator:CTS:PIXelencode? <TestCase> Sets the color format and the chroma sampling that is used for the selected test. Suffix: <hw>...
  • Page 768 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:CTS:SEL M005 Manual operation: "CTS Sink Tests dialog" on page 260 CONFigure<hw>:HDGenerator:CTS:SIGNal <CDFSink> Configures the signal. Applies only to "HF2-54 HDR Static Metadata Data Block". Suffix: <hw> Irrelevant Parameters: <CDFSink> SDR | HDR | SMPTe *RST: Example: CONF:HDG:CTS:SIGN HDR...
  • Page 769 ® Remote Command Reference R&S HDMI Generator Application Parameters: <VideoFormat> C1 | C2 | C3 | C4 | C5 | C6 | C7 | C8A | C8B | C9A | C9B | C10 | C11 | C12A | C12B | C13A | C13B | C14 | C15 | C16 | C17 | C18 | C19 | C20 | C21 | C22 | C23A | C23B | C23C | C24A | C24B | C24C | C25 | C26 | C27A | C27B | C27C | C28A | C28B | C28C | C29 | C30 | C31 | C32 | C33 | C34 | C35 | C36 | C37 |...
  • Page 770 ..............771 CONFigure<hw>:HDGenerator:EDID:UPDate CONFigure<hw>:HDGenerator:EDID:SAVE <PathFile> Saves the read EDID data as a BIN file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 771 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Port> <numeric_value> | OUT1 | OUT2 | OUT3 | OUT4 Sets one of the 4 HDMI outputs of the HDMI TX 300 MHz mod- ule (R&S VT-B360). Instead of the parameter, you can use the numeric value, for example 1 instead of OUT1.
  • Page 772 ® Remote Command Reference R&S HDMI Generator Application ● CONFigure<hw>:HDGenerator:INFoframe:MPEG Subsystem......803 ● CONFigure<hw>:HDGenerator:INFoframe:SPD Subsystem........805 ● CONFigure<hw>:HDGenerator:INFoframe:VSIF Subsystem....... 808 CONFigure<hw>:HDGenerator:INFoframe:AUDio Subsystem Configures the audio InfoFrame.......772 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CHANnel:ALLocation ........772 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CHANnel:COUNt ........773 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CODE:EXTension ..........773 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CODE:TYPE ..........774 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CSUM? ..........775 CONFigure<hw>:HDGenerator:INFoframe:AUDio:DEFault ............775 CONFigure<hw>:HDGenerator:INFoframe:AUDio:DMI .........
  • Page 773 ® Remote Command Reference R&S HDMI Generator Application 2 channels 8 channels *RST: Example: CONF:HDG:INF:AUD:CHAN:COUN 6 Manual operation: "Channel Count" on page 236 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CODE:EXTension <Value> Sets the code extension. Suffix: <hw> Irrelevant Parameters: <Value> Coding type MPEG-4 HE ACC MPEG-4 HE ACC v2 MPEG-4 ACC LC MPEG-4 HE ACC + MPEG surround MPEG-4 AAC LC + MPEG surround...
  • Page 774 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Value> Stream header AC-3 MPEG-1 MPEG-2 AAC LC ATRAC 1-bit audio Enhanced AC-3 DTS-HD WMA pro Extended *RST: Example: CONF:HDG:INF:AUD:CODE:TYPE 11 Manual operation: "Coding Type" on page 236 CONFigure<hw>:HDGenerator:INFoframe:AUDio:CSUM? Queries the checksum.
  • Page 775 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: CONF:HDG:INF:AUD:CSUM? Query Response Usage: Query only Manual operation: "Checksum (hex)" on page 236 CONFigure<hw>:HDGenerator:INFoframe:AUDio:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:INFoframe:AUDio subsystem. Suffix: <hw> Irrelevant Example: CONF:HDG:INF:AUD:DEF...
  • Page 776 ® Remote Command Reference R&S HDMI Generator Application <port> Number of the header byte Parameters: <Byte> Decimal value Range: 0 to 255 Example: CONF:HDG:INF:AUD:HBYT2 10 Header byte 2: Sets 10. Manual operation: "HB0 to HB2" on page 250 CONFigure<hw>:HDGenerator:INFoframe:AUDio:LENGth? Queries the length of the InfoFrame. Suffix: <hw>...
  • Page 777 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:AUDio:LSValue <Value> Sets the level shift value Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 15 *RST: Default unit: dB Example: CONF:HDG:INF:AUD:LSV 2 Sets 2 dB. Manual operation: "Level Shift Value" on page 237 CONFigure<hw>:HDGenerator:INFoframe:AUDio:PBYTe<port>...
  • Page 778 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:AUDio:SAMPling:SIZE <SamplingSize> Sets the sampling size. Suffix: <hw> Irrelevant Parameters: <SamplingSize> STReamheader | B16 | B20 | B24 *RST: STReamheader Example: CONF:HDG:INF:AUD:SAMP:SIZE B16 Sets 16 bit. Manual operation: "Sampling Size" on page 237 CONFigure<hw>:HDGenerator:INFoframe:AUDio:VERSion? Queries the version.
  • Page 779 ® Remote Command Reference R&S HDMI Generator Application ..........784 CONFigure<hw>:HDGenerator:INFoframe:AUX:LENGth? ..........784 CONFigure<hw>:HDGenerator:INFoframe:AUX:NUSCaling ..........784 CONFigure<hw>:HDGenerator:INFoframe:AUX:PBYTe<port> ..........784 CONFigure<hw>:HDGenerator:INFoframe:AUX:PICTurear ..........785 CONFigure<hw>:HDGenerator:INFoframe:AUX:PXRepetition ............785 CONFigure<hw>:HDGenerator:INFoframe:AUX:RBAR ..........785 CONFigure<hw>:HDGenerator:INFoframe:AUX:RGBQrange ..........786 CONFigure<hw>:HDGenerator:INFoframe:AUX:SCANinfo ............786 CONFigure<hw>:HDGenerator:INFoframe:AUX:TBAR ..........787 CONFigure<hw>:HDGenerator:INFoframe:AUX:VERSion? ............787 CONFigure<hw>:HDGenerator:INFoframe:AUX:VIC ..........787 CONFigure<hw>:HDGenerator:INFoframe:AUX:YCCQuant CONFigure<hw>:HDGenerator:INFoframe:AUX:AFPResent <Enable>...
  • Page 780 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Value> Range: 0 to 9999 *RST: Example: CONF:HDG:INF:AUX:BBAR 20 Manual operation: "Line Number of Bottom Bar Start" on page 235 CONFigure<hw>:HDGenerator:INFoframe:AUX:COLorimetry <Type> Sets the colorimetry. Suffix: <hw> Irrelevant Parameters: <Type> NONE | SMPTe170m | ITU709 | EXTended *RST: NONE Example:...
  • Page 781 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:AUX:CONTenttype <Content> Sets the content type. Suffix: <hw> Irrelevant Parameters: <Content> GRAPhics | PHOTo | CINema | GAME *RST: GRAPhics Example: CONF:HDG:INF:AUX:CONT PHOT Manual operation: "Content Type" on page 235 CONFigure<hw>:HDGenerator:INFoframe:AUX:CSUM? on page 776. CONFigure<hw>:HDGenerator:INFoframe:AUDio:LENGth? Usage: Query only...
  • Page 782 ® Remote Command Reference R&S HDMI Generator Application Adobe YCC 601 Adobe RGB ITU-R BT.2020 Y’ C’ C’ TR-R BT.2020 Y’ C’ C’ *RST: CONF:HDG:INF:AUX:EXTC 1 Example: Manual operation: "Extended Colorimetry" on page 234 CONFigure<hw>:HDGenerator:INFoframe:AUX:FORMatar <AspectRatio> Sets the active format aspect ratio Suffix: <hw>...
  • Page 783 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "Active Format Aspect Ratio" on page 233 CONFigure<hw>:HDGenerator:INFoframe:AUX:HBYTe<port>? Queries the header bytes. Suffix: <hw> Irrelevant <port> Number of the header byte Return values: <Byte> Decimal value Example: CONF:HDG:INF:AUX:HBYT2? Query Header byte 2: Response Usage: Query only Manual operation:...
  • Page 784 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:AUX:LENGth? on page 776. CONFigure<hw>:HDGenerator:INFoframe:AUDio:LENGth? Usage: Query only Manual operation: "Length of InfoFrame" on page 232 CONFigure<hw>:HDGenerator:INFoframe:AUX:NUSCaling <Scaling> Sets the nonuniform picture scaling. Suffix: <hw> Irrelevant Parameters: <Scaling> NONE | HORZ | VERT | BOTH *RST: NONE Example:...
  • Page 785 ® Remote Command Reference R&S HDMI Generator Application No data 16:9 *RST: Example: CONF:HDG:INF:AUX:PICT 2 Manual operation: "Picture Aspect Ratio" on page 233 CONFigure<hw>:HDGenerator:INFoframe:AUX:PXRepetition <Value> Sets the pixel repetition. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 9 *RST: Example: CONF:HDG:INF:AUX:PXR 1 Sends pixel 2 times.
  • Page 786 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Quantization> Default Limited range Full range *RST: Example: CONF:HDG:INF:AUX:RGBQ 2 Manual operation: "RGB Quantization Range" on page 234 CONFigure<hw>:HDGenerator:INFoframe:AUX:SCANinfo <Type> Sets the scan information. Suffix: <hw> Irrelevant Parameters: <Type>...
  • Page 787 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:AUX:VERSion? on page 778. CONFigure<hw>:HDGenerator:INFoframe:AUDio:VERSion? Usage: Query only Manual operation: "Version Number" on page 232 CONFigure<hw>:HDGenerator:INFoframe:AUX:VIC <Value> Sets the video identification code. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 255 *RST: Example: CONF:HDG:INF:AUX:VIC 127 Manual operation:...
  • Page 788 ® Remote Command Reference R&S HDMI Generator Application .............790 CONFigure<hw>:HDGenerator:INFoframe:DRMI:EOTF ............790 CONFigure<hw>:HDGenerator:INFoframe:DRMI:FALL .......... 791 CONFigure<hw>:HDGenerator:INFoframe:DRMI:HBYTe<port> .............791 CONFigure<hw>:HDGenerator:INFoframe:DRMI:LMAX ............791 CONFigure<hw>:HDGenerator:INFoframe:DRMI:LMIN ............791 CONFigure<hw>:HDGenerator:INFoframe:DRMI:PBNull ..........792 CONFigure<hw>:HDGenerator:INFoframe:DRMI:PBYTe<byte> ............792 CONFigure<hw>:HDGenerator:INFoframe:DRMI:SMD ............792 CONFigure<hw>:HDGenerator:INFoframe:DRMI:WPX ............792 CONFigure<hw>:HDGenerator:INFoframe:DRMI:WPY CONFigure<hw>:HDGenerator:INFoframe:DRMI:ACTive <Enable> Enables or disables the HDR and colorimetry data. Suffix: <hw>...
  • Page 789 ® Remote Command Reference R&S HDMI Generator Application Usage: Event Manual operation: "Default button" on page 251 CONFigure<hw>:HDGenerator:INFoframe:DRMI:DPX<idx> <Value> Sets the x-coordinate of display primary 1 and 2. Suffix: <hw> Irrelevant <idx> Number of the display primary Parameters: <Value> Range: 0.00000 to 1.00000 *RST: 0.60000 (X[1]) | 0.90000 (X[2])
  • Page 790 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:INF:DRMI:DPY2 0.70000 Display primary 2: Sets 0.70000. Manual operation: "Display Primaries Y[1]" on page 245 "Display Primaries Y[2]" on page 245 CONFigure<hw>:HDGenerator:INFoframe:DRMI:DPYNull <Value> Sets the y-coordinate of display primary 0. Suffix: <hw>...
  • Page 791 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:DRMI:HBYTe<port> <Byte> CONFigure<hw>:HDGenerator:INFoframe:AUDio:HBYTe<port> on page 775. Manual operation: "HB0 to HB2" on page 250 CONFigure<hw>:HDGenerator:INFoframe:DRMI:LMAX <Value> Sets the maximum display mastering luminance. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 65535 *RST: Example: CONF:HDG:INF:DRMI:LMAX 500 Manual operation:...
  • Page 792 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:DRMI:PBYTe<byte> <Byte> CONFigure<hw>:HDGenerator:INFoframe:VSIF:PBYTe<port> on page 817. Manual operation: "PB0 to PB27" on page 251 CONFigure<hw>:HDGenerator:INFoframe:DRMI:SMD <Descriptor> Sets the static metadata descriptor. Suffix: <hw> Irrelevant Parameters: <Descriptor> SMD1 Example: CONF:HDG:INF:DRMI:SMD SMD1 Manual operation: "Static Metadata Descriptor"...
  • Page 793 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:GBD Subsystem Configures the Gamut boundary data InfoFrame............. 793 CONFigure<hw>:HDGenerator:INFoframe:GBD:ACTive ........... 793 CONFigure<hw>:HDGenerator:INFoframe:GBD:BLACk<port> ...........794 CONFigure<hw>:HDGenerator:INFoframe:GBD:COLPrecision ..........794 CONFigure<hw>:HDGenerator:INFoframe:GBD:COLSpace ........... 794 CONFigure<hw>:HDGenerator:INFoframe:GBD:DEFault ..........795 CONFigure<hw>:HDGenerator:INFoframe:GBD:FACetmode ...........795 CONFigure<hw>:HDGenerator:INFoframe:GBD:FORMat ........... 795 CONFigure<hw>:HDGenerator:INFoframe:GBD:HBYTe<port> ..........795 CONFigure<hw>:HDGenerator:INFoframe:GBD:MAXBlue ..........795 CONFigure<hw>:HDGenerator:INFoframe:GBD:MAXGreen ..........795...
  • Page 794 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant <port> x/y/z-coordinate Parameters: <Value> Range: 0 to 4095 *RST: Example: CONF:HDG:INF:GBD:BLAC2 100 y-coordinate: Sets 100. Manual operation: "Black Point" on page 249 CONFigure<hw>:HDGenerator:INFoframe:GBD:COLPrecision <ColorDepth> Sets the color precision. Suffix: <hw>...
  • Page 795 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Example: CONF:HDG:INF:GBD:DEF Usage: Event Manual operation: "Default button" on page 251 CONFigure<hw>:HDGenerator:INFoframe:GBD:FACetmode <Enable> Enables or disables the facet mode. Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:GBD:FAC ON Manual operation: "Facet Mode"...
  • Page 796 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Value> Range: -4.0000 to 4.0000 *RST: Example: CONF:HDG:INF:GBD:MAXR 0.1000 Manual operation: "Maximum Red" on page 248 CONFigure<hw>:HDGenerator:INFoframe:GBD:MINBlue CONFigure<hw>:HDGenerator:INFoframe:GBD:MINGreen CONFigure<hw>:HDGenerator:INFoframe:GBD:MINRed <Value> Sets the minimum for blue/green/red. Suffix: <hw> Irrelevant Parameters: <Value>...
  • Page 797 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:GBD:NOGB ON Manual operation: "No Current GBD" on page 247 CONFigure<hw>:HDGenerator:INFoframe:GBD:NUMFacets <Value> Sets the number of facets. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 65535 *RST: Example: CONF:HDG:INF:GBD:NUMF 300...
  • Page 798 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Value> Range: 0 to 4095 *RST: Example: CONF:HDG:INF:GBD:PRED3 200 z-coordinate: Sets 200. Manual operation: "Red Primary" on page 249 CONFigure<hw>:HDGenerator:INFoframe:GBD:PBNull <Byte> on page 791. CONFigure<hw>:HDGenerator:INFoframe:DRMI:PBNull Manual operation: "PB0 to PB27" on page 251 CONFigure<hw>:HDGenerator:INFoframe:GBD:PBYTe<port>...
  • Page 799 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:GBD:SEQCurrent <Value> Sets the current sequence number. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 15 *RST: Example: CONF:HDG:INF:GBD:SEQC 5 Manual operation: "Current Sequence Num" on page 247 CONFigure<hw>:HDGenerator:INFoframe:ISRC Subsystem Configures the international standard recording code 1 InfoFrame.............799 CONFigure<hw>:HDGenerator:INFoframe:ISRC:ACTive ..........799...
  • Page 800 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:ISRC:CONT ON Manual operation: "ISRC Continued" on page 249 CONFigure<hw>:HDGenerator:INFoframe:ISRC:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:INFoframe:ISRC subsystem. Suffix: <hw> Irrelevant Example: CONF:HDG:INF:ISRC:DEF Usage: Event Manual operation: "Default button"...
  • Page 801 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:ISRC:PBYTe<port> <Byte> CONFigure<hw>:HDGenerator:INFoframe:VSIF:PBYTe<port> on page 817. Manual operation: "PB0 to PB27" on page 251 CONFigure<hw>:HDGenerator:INFoframe:ISRC:STATus <Info> Sets the ISRC status. Suffix: <hw> Irrelevant Parameters: <Info> UNKNown | STARt | INTermediate | END *RST: INTermediate Example:...
  • Page 802 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:ISRTwo:ACTive <Enable> Enables or disables the international standard recording code 2. Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:ISRT:ACT ON Manual operation: "Active" on page 250 CONFigure<hw>:HDGenerator:INFoframe:ISRTwo:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:INFoframe:ISRT subsystem.
  • Page 803 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:ISRTwo:PBYTe<port> <Byte> CONFigure<hw>:HDGenerator:INFoframe:VSIF:PBYTe<port> on page 817. Manual operation: "PB0 to PB27" on page 251 CONFigure<hw>:HDGenerator:INFoframe:MPEG Subsystem Configures the MPEG InfoFrame...........803 CONFigure<hw>:HDGenerator:INFoframe:MPEG:ACTive ..........803 CONFigure<hw>:HDGenerator:INFoframe:MPEG:BITRate ..........804 CONFigure<hw>:HDGenerator:INFoframe:MPEG:CSUM? ..........804 CONFigure<hw>:HDGenerator:INFoframe:MPEG:DEFault ..........804 CONFigure<hw>:HDGenerator:INFoframe:MPEG:FREPeat .........804 CONFigure<hw>:HDGenerator:INFoframe:MPEG:HBYTe<port>...
  • Page 804 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "MPEG Bit Rate" on page 239 CONFigure<hw>:HDGenerator:INFoframe:MPEG:CSUM? on page 774. CONFigure<hw>:HDGenerator:INFoframe:AUDio:CSUM? Usage: Query only Manual operation: "Checksum (hex)" on page 239 CONFigure<hw>:HDGenerator:INFoframe:MPEG:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:INFoframe:MPEG subsystem. Suffix: <hw>...
  • Page 805 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "Length of InfoFrame" on page 239 CONFigure<hw>:HDGenerator:INFoframe:MPEG:MPEGframe <arg> Enables or disables the MPEG InfoFrame. Suffix: <hw> Irrelevant Parameters: <arg> UNKNown | I_Picture | B_Picture | P_Picture *RST: I_Picture Example: CONF:HDG:INF:MPEG:MPEG P_P Manual operation: "MPEG Frame"...
  • Page 806 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:SPD:ACT OFF Manual operation: "Active" on page 238 CONFigure<hw>:HDGenerator:INFoframe:SPD:CSUM? on page 774. CONFigure<hw>:HDGenerator:INFoframe:AUDio:CSUM? Usage: Query only Manual operation: "Checksum (hex)" on page 238 CONFigure<hw>:HDGenerator:INFoframe:SPD:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:INFoframe:SPD sub- system.
  • Page 807 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant <port> Number of the packet byte Parameters: <Byte> Decimal value Range: 0 to 255 Example: CONF:HDG:INF:SPD:PBYT25 0 Header byte 25: Sets 0. Manual operation: "PB0 to PB27" on page 251 CONFigure<hw>:HDGenerator:INFoframe:SPD:PRODuct <Description>...
  • Page 808 ® Remote Command Reference R&S HDMI Generator Application Video CD Game PC general Blu-ray disc Super audio CD HD DVC *RST: Unknown Example: CONF:HDG:INF:SPD:SOUR 2 Manual operation: "Source Information" on page 238 CONFigure<hw>:HDGenerator:INFoframe:SPD:VENDor <Name> Sets the vendor name. Suffix: <hw> Irrelevant Parameters: <Name>...
  • Page 809 ® Remote Command Reference R&S HDMI Generator Application For all vendor-specific InfoFrames, the same commands are used. To address an indi- vidual vendor-specific InfoFrame, use CONFigure<hw>:HDGenerator:INFoframe: on page 814. VSIF:IDX See also details on "Max. number of active InfoFrames" on page 228.............
  • Page 810 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:INF:VSIF:ACT V20 Sets HDMI 2.0. Manual operation: "Active" on page 240 CONFigure<hw>:HDGenerator:INFoframe:VSIF:ADDinfo <Enable> Enables or disables the 3D additional information present. Suffix: <hw> Irrelevant Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:VSIF:ADD ON Manual operation: "3D Additional Info Present"...
  • Page 811 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Value> Range: -128 to 127 *RST: Example: CONF:HDG:INF:VSIF:DIPM 0 Manual operation: "Max Picture Disparity" on page 244 CONFigure<hw>:HDGenerator:INFoframe:VSIF:DIRegion<region> <Value> Sets the minimum disparity region 1 to 15. Suffix: <hw> Irrelevant <region> 1-15 Number of the region Parameters:...
  • Page 812 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:INF:VSIF:DISP ON Manual operation: "3D Disparity Present" on page 241 CONFigure<hw>:HDGenerator:INFoframe:VSIF:DIVersion <Value> Sets the disparity version. Suffix: <hw> Irrelevant Parameters: <Value> None Range hint Multi region Multi region + range hint *RST: Example:...
  • Page 813 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Value> Range: -2048 to 2047 *RST: Example: CONF:HDG:INF:VSIF:DMIN 0 Manual operation: "Video Min Disparity Hint" on page 243 CONFigure<hw>:HDGenerator:INFoframe:VSIF:DREF <Value> Sets the D value. Suffix: <hw> Irrelevant Parameters: <Value>...
  • Page 814 ® Remote Command Reference R&S HDMI Generator Application Horizontal odd/left, even right Horizontal even/left, odd right Horizontal even/left, even right Quincunx odd/left, odd right Quincunx odd/left, even right Quincunx even/left, odd right Quincunx even/left, even right *RST: Example: CONF:HDG:INF:VSIF:EXTD 5 Manual operation: "3D Ext Data"...
  • Page 815 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Selection> DEFault | VSIF2 | VSIF3 | VSIF4 *RST: Example: CONF:HDG:INF:VSIF:IDX VSIF2 Sets vendor-specific InfoFrame 2. Manual operation: "<Vendor-specific InfoFrame 1 to 4 parameters>" on page 240 CONFigure<hw>:HDGenerator:INFoframe:VSIF:LENGth <Value> Sets the length of the InfoFrame. Suffix: <hw>...
  • Page 816 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:INF:VSIF:MET RSV Sets reserved. Manual operation: "Metadata Type" on page 243 CONFigure<hw>:HDGenerator:INFoframe:VSIF:NREGions <Number> Sets the number of regions. Suffix: <hw> Irrelevant Parameters: <Number> R0 | R1 | R2 | R3 | R4 | R9 | R16 | RSV *RST: Example: CONF:HDG:INF:VSIF:NREG R3...
  • Page 817 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:INFoframe:VSIF:PARZero <Value> Sets the parallax zero. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 65535 *RST: Example: CONF:HDG:INF:VSIF:PARZ 5 Manual operation: "Parallax Zero" on page 243 CONFigure<hw>:HDGenerator:INFoframe:VSIF:PBYTe<port> <Byte> Sets the packet bytes. Suffix: <hw>...
  • Page 818 ® Remote Command Reference R&S HDMI Generator Application L + depth L + depth + graphics + graphics-depth Top and bottom Side by side (half) *RST: Example: CONF:HDG:INF:VSIF:STR 8 Manual operation: "3D Structure" on page 242 CONFigure<hw>:HDGenerator:INFoframe:VSIF:VALid <Enable> Enables or disables the 3D validation. Suffix: <hw>...
  • Page 819 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Format> NONE | EXTended | FO3D *RST: Example: CONF:HDG:INF:VSIF:VID FO3D Sets 3D format. Manual operation: "Video Format" on page 241 CONFigure<hw>:HDGenerator:INFoframe:VSIF:VSVersion <Value> Sets the vendor-specific InfoFrame version. Suffix: <hw> Irrelevant Parameters: <Value>...
  • Page 820 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:INF:VSIF:VWPR LEFT Sets the left view. Manual operation: "3D Preferred 2D View" on page 242 CONFigure<hw>:HDGenerator:INFoframe:VSIF:WREF <Value> Sets the W value. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0 to 65535 *RST: Example: CONF:HDG:INF:VSIF:WREF 50 Manual operation:...
  • Page 821 ® Remote Command Reference R&S HDMI Generator Application <port> Outputs of the HDMI TX 300 MHz module (R&S VT-B360); irrel- evant for the HDMI RX/TX 600 MHz module (R&S VT-B2363). Parameters: <Encryption> OFF | ON | HDCP14 | HDCP22 OFF | ON HDMI TX 300 MHz module (R&S VT-B360) OFF | ON | HDCP14 | HDCP22 HDMI RX/TX 600 MHz module (R&S VT-B2363)
  • Page 822 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:OUTP:SCRD UHD Sets 600 MHz only. Manual operation: "Scrambling Determination (HDMI RX/TX 600 MHz mod- ule)" on page 212 14.6.2.7 CONFigure<hw>:HDGenerator:SCDC Subsystem ..............822 CONFigure<hw>:HDGenerator:SCDC:MODE ..........822 CONFigure<hw>:HDGenerator:SCDC:SCRambling:RESet ..............822 CONFigure<hw>:HDGenerator:SCDC:UPDate CONFigure<hw>:HDGenerator:SCDC:MODE <Update>...
  • Page 823 ® Remote Command Reference R&S HDMI Generator Application 14.6.2.8 CONFigure<hw>:HDGenerator:SIGNal Subsystem ● CONFigure<hw>:HDGenerator:SIGNal:AUDConf Subsystem......823 ● CONFigure<hw>:HDGenerator:SIGNal:VICD Subsystem........826 ● CONFigure<hw>:HDGenerator:SIGNal:VIDConf Subsystem.......832 ● CONFigure<hw>:HDGenerator:SIGNal:... Subsystem......... 839 CONFigure<hw>:HDGenerator:SIGNal:AUDConf Subsystem Configures the video signal. See also "Audio Configuration" on page 221..........823 CONFigure<hw>:HDGenerator:SIGNal:AUDConf:CH<port>...
  • Page 824 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "Channel Allocation (hex)" on page 222 CONFigure<hw>:HDGenerator:SIGNal:AUDConf:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:SIGNal:AUDConf subsystem. Suffix: <hw> Irrelevant Example: CONF:HDG:SIGN:AUDC:DEF Usage: Event Manual operation: "Default button" on page 222 CONFigure<hw>:HDGenerator:SIGNal:AUDConf:FREQ:CH<port> <Value> Sets the frequency of the specified channel.
  • Page 825 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:SIGNal:AUDConf:LEVel:CH<port> <Value> Sets the audio level of the specified channel. Suffix: <hw> Irrelevant <port> Audio channel Parameters: <Value> Range: -99.9 to 0.0 *RST: -20.0 Default unit: DBFS Example: CONF:HDG:SIGN:AUDC:LEV:CH2 -10 Audio channel 2: Sets -10 dBFS. Manual operation: "<Audio channels>"...
  • Page 826 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:SIGNal:AUDConf:SELect <Source> Sets the audio source. Suffix: <hw> Irrelevant Parameters: <Source> MUTE | VIDeofile | GENerator *RST: GENerator Example: CONF:HDG:SIGN:AUDC:SEL MUTE Manual operation: "Audio" on page 221 CONFigure<hw>:HDGenerator:SIGNal:VICD Subsystem ..............826 CONFigure<hw>:HDGenerator:SIGNal:VICD ......... 827 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:DEFault ........
  • Page 827 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:DEFault Sets each user-defined value to its default value. Suffix: <hw> Irrelevant Example: CONF:HDG:SIGN:VICD:CUST:DEF Usage: Event Manual operation: "Default button" on page 225 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:HACTive <Value> Sets the number of horizontal active pixels. Suffix: <hw>...
  • Page 828 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Value> Range: 5 to 4096 *RST: Example: CONF:HDG:SIGN:VICD:CUST:HFP 30 Manual operation: "H. Front Porch Pixels" on page 223 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:HPOLarity <Horizontal> Sets the horizontal synchronization polarity. Suffix: <hw> Irrelevant Parameters: <Horizontal> POSitive | NEGative *RST: NEGative Example:...
  • Page 829 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "Video Format" on page 225 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:PXFRequency <Value> Sets the actual pixel frequency. Suffix: <hw> Irrelevant Parameters: <Value> Range depends on the module set using ROUTe<hw>: on page 862. HDGenerator:MODule:SELect Range: 25.000 to 300.000 (TX300) | 600.000 (TX600) *RST: 25.17500...
  • Page 830 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:VBPorch <Value> Sets the number of vertical back porch lines. Suffix: <hw> Irrelevant Parameters: <Value> Range: 1 to 512 *RST: Example: CONF:HDG:SIGN:VICD:CUST:VBP 50 Manual operation: "V. Back Porch Lines" on page 224 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:VFPorch <Value>...
  • Page 831 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Vertical> POSitive | NEGative *RST: NEGative Example: CONF:HDG:SIGN:VICD:CUST:VPOL POS Manual operation: "V. Sync. Polarity" on page 225 CONFigure<hw>:HDGenerator:SIGNal:VICD:CUSTom:VSYNc <Value> Sets the number of vertical sync lines. Suffix: <hw> Irrelevant Parameters: <Value>...
  • Page 832 ® Remote Command Reference R&S HDMI Generator Application Example: CONF:HDG:SIGN:VICD:VCOD 44 Manual operation: "Video Code" on page 216 CONFigure<hw>:HDGenerator:SIGNal:VIDConf Subsystem Configures the video signal. See also "Video Configuration" on page 217..........832 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:ADJustment ........833 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:AMPL:CHRoma ..........833 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:AMPL:RGB ...........833 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:AMPL:YCBCr ..........
  • Page 833 ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:SIGNal:VIDConf:AMPL:CHRoma <Value> Sets the common variation of the all chroma signal level. Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.000 to 2.000 *RST: 1.000 Example: CONF:HDG:SIGN:VIDC:AMPL:CHR 0.500 Manual operation: "Chroma Amplification" on page 219 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:AMPL:RGB <Value>...
  • Page 834 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.0 to 100.0 *RST: Default unit: PCT Example: CONF:HDG:SIGN:VIDC:ROFF 50 Sets 50.0 %. Manual operation: "R Offset, G Offset, B Offset" on page 220 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:CBOFfset CONFigure<hw>:HDGenerator:SIGNal:VIDConf:CROFfset <Value> Adds a DC offset to the luminance signal.
  • Page 835 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Parameters: <PixelEncoding> RGB | Y444 | Y422 | Y420 *RST: Example: CONF:HDG:SIGN:VIDC:COMP:FORM Y444 Sets YCbCr 4:4:4. Manual operation: "Component Format" on page 217 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:DEFault Resets all commands of the CONFigure<hw>:HDGenerator:SIGNal:VIDConf subsystem.
  • Page 836 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Value> Range: 0.0 to 200.0 *RST: 100.0 Default unit: PCT Example: CONF:HDG:SIGN:VIDC:LEVel:R 50 Manual operation: "R Level, G Level, B Level" on page 219 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:LEVel:CB CONFigure<hw>:HDGenerator:SIGNal:VIDConf:LEVel:CR CONFigure<hw>:HDGenerator:SIGNal:VIDConf:LEVel:Y <Value> Sets the individual variation of the signal components amplitude for Y, Cb/Pb, Cr/Pr signals.
  • Page 837 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Value> Range: -63 to 63 *RST: Default unit: lines/frame Example: CONF:HDG:SIGN:VIDC:PIX:HOR 10 Moves the image 10 lines/frame to the left. Manual operation: "Horizontal" on page 218 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:PIXelshift:VERTical <Value> Sets the scroll velocity and direction. Suffix: <hw>...
  • Page 838 ® Remote Command Reference R&S HDMI Generator Application Parameters: <Enable> OFF | ON *RST: Example: CONF:HDG:SIGN:VIDC:PIXV ON Manual operation: "Pixelshift Vertical" on page 217 CONFigure<hw>:HDGenerator:SIGNal:VIDConf:QUANtization <Range> Enables or disables the full color range. Suffix: <hw> Irrelevant Parameters: <Range> LIMited | FULL *RST: Example: CONF:HDG:SIGN:VIDC:QUAN FULL...
  • Page 839 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "Y Offset" on page 220 CONFigure<hw>:HDGenerator:SIGNal:... Subsystem ............. 839 CONFigure<hw>:HDGenerator:SIGNal:ASPRatio ............839 CONFigure<hw>:HDGenerator:SIGNal:COMMand ..............839 CONFigure<hw>:HDGenerator:SIGNal:FRAM ..............840 CONFigure<hw>:HDGenerator:SIGNal:NOBLack ............840 CONFigure<hw>:HDGenerator:SIGNal:PLAY:FILE ............841 CONFigure<hw>:HDGenerator:SIGNal:PLAY:PATT CONFigure<hw>:HDGenerator:SIGNal:ASPRatio <Value> Sets the aspect ratio in the format filter. Suffix: <hw>...
  • Page 840 Parameters: <PathFile> Filename including the extension. If the path is omitted, the cur- rent directory is used. Example: CONF:HDG:SIGN:PLAY:FILE "D: \VTS\UserData\RefSWB.avg" Loads RefSWB.avg from the D:\VTS\UserData directory. Manual operation: "Content Selection dialog" on page 215 User Manual 2116.1228.02 ─ 14...
  • Page 841: Display Subsystem

    ® Remote Command Reference R&S HDMI Generator Application CONFigure<hw>:HDGenerator:SIGNal:PLAY:PATT <Name> Sets the signal with the specified name. Suffix: <hw> Irrelevant Parameters: <Name> Specifies the signal name. You can choose from all signals available in the database. See also Chapter 10.4, "Content and Codes", on page 339.
  • Page 842: Mmemory Subsystem

    ............842 MMEMory<hw>:HDGenerator:CTS:REPort:STORe MMEMory<hw>:HDGenerator:CEC:DATA:STORe <PathFile> Saves the CEC traffic report as a TXT file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 843: Read Subsystem

    Parameters: <PathFile> Filename including the extension. If the path is omitted, the cur- rent directory is used. Example: MMEM:HDG:CTS:REP:STOR "D: \VTS\UserData\MyReport.txt" Saves MyReport.txt in the D:\VTS\UserData directory. Manual operation: "Save button" on page 271 14.6.6 READ Subsystem ● READ<hw>:HDGenerator:CEC Subsystem............843 ●...
  • Page 844 ® Remote Command Reference R&S HDMI Generator Application Example: READ:HDG:CEC:REP? 1 Query 1,0x0000,"TV: Present" Response: Contents of second line. Usage: Query only READ<hw>:HDGenerator:CEC:REPort:COUNt? Queries the number of entry lines in the CEC traffic report. Suffix: <hw> Irrelevant Return values: <Lines> Total number of lines Example: READ:HDG:CEC:REP:COUN?
  • Page 845 ® Remote Command Reference R&S HDMI Generator Application READ<hw>:HDGenerator:CTS:CONTrol:STATe? Queries the status of the CTS measurement. Suffix: <hw> Irrelevant Return values: <Meas> IDLE | CAPTuring | RUNNing | FINished Example: READ:HDG:CTS:CONT:STAT? Query IDLE Response Usage: Query only Manual operation: "<Status display>" on page 272 READ<hw>:HDGenerator:CTS:REPort? <Line>...
  • Page 846 ® Remote Command Reference R&S HDMI Generator Application Example: READ:HDG:CTS:REP:COUN? Query Response Usage: Query only 14.6.6.3 READ<hw>:HDGenerator:EDID Subsystem READ<hw>:HDGenerator:EDID:DUMP? Queries the binary data of the EDID on the chosen output. Suffix: <hw> Irrelevant Return values: <BinaryBlock> <dblock> Response consists of #<number> and EDID data #<number>...
  • Page 847 ® Remote Command Reference R&S HDMI Generator Application Return values: <Value> <dblock> Data block Example: READ:HDG:HDCP:AKSV? Query OK,5E73CC6B02 Response Usage: Query only Manual operation: "AKSV" on page 227 READ<hw>:HDGenerator:HDCP:AN? Queries the session random number. Suffix: <hw> Irrelevant Return values: <Value> <dblock>...
  • Page 848 ® Remote Command Reference R&S HDMI Generator Application READ<hw>:HDGenerator:HDCP:H? Queries the hash value calculated by the receiver of the authentication protocol. Suffix: <hw> Irrelevant Return values: <Value> <dblock> 8 data blocks Example: READ:HDG:HDCP:H? Query OK,6FB30D9BA70B86ED807B5FB5DFEDD2FE 243619983C1DBFD5F6B0A4308026EA8F Response Usage: Query only Manual operation: "H"...
  • Page 849 ® Remote Command Reference R&S HDMI Generator Application Return values: <Value> <dblock> Data block Example: READ:HDG:HDCP:RI? Query OK,2FF8 Response Usage: Query only Manual operation: "Ri'" on page 227 READ<hw>:HDGenerator:HDCP:RN? Queries the pseudo-random value of the locality check. Suffix: <hw> Irrelevant Return values: <Value>...
  • Page 850 ® Remote Command Reference R&S HDMI Generator Application READ<hw>:HDGenerator:HDCP:RTX? Queries the pseudo-random value of the authentication protocol. Suffix: <hw> Irrelevant Return values: <Value> <dblock> 2 data blocks Example: READ:HDG:HDCP:RTX? Query OK,DB71756E6E51B2D6 Response Usage: Query only Manual operation: "r(tx)" on page 227 14.6.6.5 READ<hw>:HDGenerator:OUTPut Subsystem ..............850...
  • Page 851 ® Remote Command Reference R&S HDMI Generator Application Example: READ:HDG:OUTP:HDCP? Query "HDCP 1.4 Active" Response Usage: Query only Manual operation: "HDCP State (HDMI TX module and HDMI RX/TX 600 MHz module)" on page 212 "HDCP State" on page 226 READ<hw>:HDGenerator:OUTPut:HPDout<port>[:STATe]? Queries the status of the hot plug detect connection.
  • Page 852 ® Remote Command Reference R&S HDMI Generator Application Manual operation: "Scrambling State (HDMI RX/TX 600 MHz module)" on page 212 14.6.6.6 READ<hw>:HDGenerator:SCDC Subsystem ..............852 READ<hw>:HDGenerator:SCDC:CDIVide? ..............852 READ<hw>:HDGenerator:SCDC:HWVersion? ..............853 READ<hw>:HDGenerator:SCDC:IDENtifier? ................853 READ<hw>:HDGenerator:SCDC:OUI? ..............854 READ<hw>:HDGenerator:SCDC:RRENable? ........... 854 READ<hw>:HDGenerator:SCDC:SCRambling:CH<channel>? ............. 854 READ<hw>:HDGenerator:SCDC:SCRambling:CHNull? .............855 READ<hw>:HDGenerator:SCDC:SCRambling:CLOCk?
  • Page 853 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Return values: <String> Version Example: READ:HDG:SCDC:HWV? Query "15.15" Response Usage: Query only Manual operation: "Hardware Version" on page 255 READ<hw>:HDGenerator:SCDC:IDENtifier? Queries the identifier. Suffix: <hw> Irrelevant Return values: <String> Identifier Example: READ:HDG:SCDC:IDEN?
  • Page 854 ® Remote Command Reference R&S HDMI Generator Application READ<hw>:HDGenerator:SCDC:RRENable? Queries the read request enable status. Suffix: <hw> Irrelevant Return values: <Enable> OFF | ON Example: READ:HDG:SCDC:RREN? Query Response Usage: Query only Manual operation: "Read Request Enable" on page 255 READ<hw>:HDGenerator:SCDC:SCRambling:CH<channel>? Queries the channel 1 or 2 locked status.
  • Page 855 ® Remote Command Reference R&S HDMI Generator Application Example: READ:HDG:SCDC:SCR:CHN? Query Response Usage: Query only Manual operation: "Channel 0 Locked, Channel 1 Locked, Channel 2 Locked" on page 256 READ<hw>:HDGenerator:SCDC:SCRambling:CLOCk? Queries the clock detected status. Suffix: <hw> Irrelevant Return values: <Enable>...
  • Page 856 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Return values: <Enable> OFF | ON Example: READ:HDG:SCDC:SCR:ENAB? Query Response Usage: Query only Manual operation: "Scrambling Enable" on page 255 READ<hw>:HDGenerator:SCDC:SCRambling:ERR<channel>? Queries the errors in channel 1 or 2. Suffix: <hw>...
  • Page 857 ® Remote Command Reference R&S HDMI Generator Application Usage: Query only Manual operation: "Last Read Checksum" on page 257 READ<hw>:HDGenerator:SCDC:SCRambling:ERRNull? Queries the errors in channel 0. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDG:SCDC:SCR:ERRN? Query 32767 Response Usage: Query only Manual operation: "Errors Channel 0, Errors Channel 1, Errors Channel 2"...
  • Page 858 ® Remote Command Reference R&S HDMI Generator Application Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDG:SCDC:SCR:SUMN? Query 65534 Response for channel 2 Usage: Query only Manual operation: "Errors Channel 0, Errors Channel 1, Errors Channel 2" on page 256 READ<hw>:HDGenerator:SCDC:SINKversion? Queries the sink version.
  • Page 859 ® Remote Command Reference R&S HDMI Generator Application READ<hw>:HDGenerator:SCDC:SWVersion? Queries the software version. Suffix: <hw> Irrelevant Return values: <String> Version Example: READ:HDG:SCDC:SWV? Query "255.255" Response Usage: Query only Manual operation: "Software Version" on page 255 READ<hw>:HDGenerator:SCDC:UPDate:CED? Queries the CED update flag. Suffix: <hw>...
  • Page 860 ® Remote Command Reference R&S HDMI Generator Application Usage: Query only Manual operation: "Update Read Request" on page 256 READ<hw>:HDGenerator:SCDC:UPDate:STATus? Queries the update status flag. Suffix: <hw> Irrelevant Return values: <Enable> OFF | ON Example: READ:HDG:SCDC:UPD:STAT? Query Response Usage: Query only Manual operation: "Update Status"...
  • Page 861 ® Remote Command Reference R&S HDMI Generator Application READ<hw>:HDGenerator:SIGNal:VICD:CUSTom:HBLank? Queries the number of horizontal blanking pixels. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDG:SIGN:VICD:CUST:HBL? Query Response Usage: Query only Manual operation: "H. Blanking Pixels" on page 223 READ<hw>:HDGenerator:SIGNal:VICD:CUSTom:HTOPixel? Queries the number of horizontal total pixels.
  • Page 862: Route Subsystem

    ® Remote Command Reference R&S HDMI Generator Application Usage: Query only Manual operation: "V. Blanking Lines" on page 225 READ<hw>:HDGenerator:SIGNal:VICD:CUSTom:VTOLines? Queries the number of vertical total lines. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDG:SIGN:VICD:CUST:VTOL? Query Response Usage: Query only Manual operation: "V.
  • Page 863: Hdmi Analyzer Application

    ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Parameters: <Standard> HDMI14 | HDMI20 *RST: HDMI20 Example: ROUT:HDG:OSEL:VERS HDMI14 Sets HDMI 1.4. 14.7 HDMI Analyzer Application These commands correlate to the functions provided in Chapter 10.2, "HDMI Analyzer Application", on page 274.
  • Page 864: Configure Subsystem

    Irrelevant Example: CONF:HDMI:CEC:COMM:SEND Usage: Event Manual operation: "Send button " on page 325 CONFigure<hw>:HDMI:CEC:DESTination <Address> Sets the logical address of the DUT that receives the CEC messages sent by the R&S VTS. Suffix: <hw> Irrelevant User Manual 2116.1228.02 ─ 14...
  • Page 865 *RST: Example: CONF:HDMI:CEC:DEST RD2 Manual operation: "Destination" on page 324 CONFigure<hw>:HDMI:CEC:OPCode <OperationCode> Sets the operation code (opcode) of the CEC command that is sent by the R&S VTS. Suffix: <hw> Irrelevant Parameters: <OperationCode> Specifies the operation code. See Chapter 10.4.4, "CEC Com- munication",...
  • Page 866 ® Remote Command Reference R&S HDMI Analyzer Application CONFigure<hw>:HDMI:CEC:OPCode:PARam:LENGth <OperationCode>, <Number> CONFigure<hw>:HDMI:CEC:OPCode:PARam:LENGth? <OperationCode> Sets the number of parameters for the specified operation code. Suffix: <hw> Irrelevant Parameters: <Number> Parameters for setting and query: <OperationCode> Specifies the operation code. See Chapter 10.4.4, "CEC Com- munication", on page 356.
  • Page 867 ® Remote Command Reference R&S HDMI Analyzer Application Test case Remote command Available for following inputs parameter "HDMI 600 MHz" "HDMI" "HDMI CTS" (<test case>) "7-33: Interoperability with DVI" M016_dvi "7-33a: Interoperability with multiple VSDB" M024_vsdb "7-34: Deep Color" M017_deepc "7-35: Gamut Metadata Transmission"...
  • Page 868 ® Remote Command Reference R&S HDMI Analyzer Application Test case Remote command Available for following inputs parameter "HDMI 600 MHz" "HDMI" "HDMI CTS" (<test case>) "HF1-37: 3D Audio (One Bit) - Packet Format" H137_ae "HF1-38: MS Source Audio Encoding (L-PCM and H138_ae 61937) Packet Format"...
  • Page 869 ® Remote Command Reference R&S HDMI Analyzer Application ............878 CONFigure<hw>:HDMI:CTS:PENCode:YCBCr:SETup ..............878 CONFigure<hw>:HDMI:CTS:PTYPe:SETup ................878 CONFigure<hw>:HDMI:CTS:SELect ............879 CONFigure<hw>:HDMI:CTS:TESTlength:FRAMes ...............879 CONFigure<hw>:HDMI:CTS:TESTlength:MODE ............879 CONFigure<hw>:HDMI:CTS:TMDS:SCRambling:CDF ................880 CONFigure<hw>:HDMI:CTS:VFORmat ............... 880 CONFigure<hw>:HDMI:CTS:VFORmat:FK ............881 CONFigure<hw>:HDMI:CTS:VFORmat:HDEXtension ............881 CONFigure<hw>:HDMI:CTS:VSIFs:DUALview:CDF CONFigure<hw>:HDMI:CTS:AFORmat <TestCase>, <AudioFormat> CONFigure<hw>:HDMI:CTS:AFORmat? <TestCase> Sets the audio format. Suffix: <hw>...
  • Page 870 ® Remote Command Reference R&S HDMI Analyzer Application Example: CONF:HDMI:CTS:AUD:CHAN:TYPE H136, CHT322 Manual operation: "Channel Type" on page 315 CONFigure<hw>:HDMI:CTS:AUD:SAMPling:FREQuency <TestCase>, <Value> CONFigure<hw>:HDMI:CTS:AUD:SAMPling:FREQuency? <TestCase> Sets the audio sampling frequency. Suffix: <hw> Irrelevant Parameters: <Value> HZ32000 | HZ44100 | HZ48000 | HZ88200 | HZ96000 | HZ176400 | HZ192000 Value in Hz Parameters for setting and query:...
  • Page 871 ® Remote Command Reference R&S HDMI Analyzer Application Parameters: <Content> PHOTo | CINema | GAME | UNDefined *RST: PHOTo Example: CONF:HDMI:CTS:AVI:CTYP CIN Manual operation: "Content Type" on page 303 CONFigure<hw>:HDMI:CTS:CDEPth <TestCase>, <ColorDepth> CONFigure<hw>:HDMI:CTS:CDEPth? <TestCase> Sets the color depth. Suffix: <hw> Irrelevant Parameters: <ColorDepth>...
  • Page 872 ® Remote Command Reference R&S HDMI Analyzer Application Parameters: <Data> Number of frames; cannot exceed the length of 2 seconds. *RST: Example: CONF:HDMI:CTS:DATA:STOR:SIZE:FRAM 90 Manual operation: "Number of Frames" on page 322 CONFigure<hw>:HDMI:CTS:DATA:STORe:SIZE:MODE <Data> Sets the amount of data that are saved in a file. Suffix: <hw>...
  • Page 873 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Parameters: <Length> DVI | EQ5 | GT5 Parameters for setting and query: <TestCase> Specifies the test case. See Table 14-22. Example: CONF:HDMI:CTS:DVI:VSDB M016, EQ5 Manual operation: "HDMI VSDB" on page 305 "HDMI VSDB"...
  • Page 874 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Parameters: <Support> NO | ITUR101 | ITUR110 Parameters for setting and query: <TestCase> Specifies the test case. See Table 14-22. Example: CONF:HDMI:CTS:EDID:COL H118, ITUR101 Manual operation: "EDID Setup" on page 310 "EDID Colorimetry Setup"...
  • Page 875 ® Remote Command Reference R&S HDMI Analyzer Application Manual operation: "EDID Setup" on page 315 CONFigure<hw>:HDMI:CTS:EDID:ODISparity <TestCase>, <3DMode> CONFigure<hw>:HDMI:CTS:EDID:ODISparity? <TestCase> Sets the 3D mode indication in the EDID. Suffix: <hw> Irrelevant Parameters: <3DMode> D2 | D3Nosig | D3Withsig *RST: Parameters for setting and query: <TestCase>...
  • Page 876 ® Remote Command Reference R&S HDMI Analyzer Application GT425 Only "HF1-15: Video Timing 6G - 2160p Deep Color": 425 Mcsc LT340 Only "HF1-25: Video Timing 6G - Non-2160p Deep Color": < 340 Mcsc Parameters for setting and query: <TestCase> Specifies the test case. See Table 14-22.
  • Page 877 ® Remote Command Reference R&S HDMI Analyzer Application CONFigure<hw>:HDMI:CTS:PENCode:RGB:SETup <Test> Selects the CTS subtest. Applies only to "7-23: Pixel Encoding - RGB to RGB-only Sink". Suffix: <hw> Irrelevant Parameters: <Test> PENCode | YQ *RST: PENCode Example: CONF:HDMI:CTS:PENC:RGB:SET YQ Manual operation: "Test Setup"...
  • Page 878 ® Remote Command Reference R&S HDMI Analyzer Application CONFigure<hw>:HDMI:CTS:PENCode:YCBCr:SETup <Test> Selects the CTS subtest. Applies only to "7-24: Pixel Encoding - YCbCr to YCbCr Sink". Suffix: <hw> Irrelevant Parameters: <Test> PENCode | YQ *RST: PENCode Example: CONF:HDMI:CTS:PENC:YCBC:SET YQ Manual operation: "Test Setup"...
  • Page 879 ® Remote Command Reference R&S HDMI Analyzer Application CONFigure<hw>:HDMI:CTS:TESTlength:FRAMes <TestCase>, <Value> CONFigure<hw>:HDMI:CTS:TESTlength:FRAMes? <TestCase> Sets the number of video frames that are analyzed. Suffix: <hw> Irrelevant Parameters: <Value> Parameters for setting and query: <TestCase> Specifies the test case. See Table 14-22. Example: CONF:HDMI:CTS:TEST:FRAM M002, 80 Manual operation:...
  • Page 880 ® Remote Command Reference R&S HDMI Analyzer Application CONFigure<hw>:HDMI:CTS:VFORmat <TestCase>, <VideoFormat> CONFigure<hw>:HDMI:CTS:VFORmat? <TestCase> Sets the video format. Suffix: <hw> Irrelevant Parameters: <VideoFormat> AUTO | NONCea | C1 | C2 | C3 | C17 | C18 | C4 | C19 | C5 | C20 | C32 | C34 | C31 | C16 | C6 | C7 | C21 | C22 | C60 | C62 | C63 | C64 | C65 | C66 | C67 | C68 | C69 | C70 | C71 | C72 | C73 | C74 | C75 | C76 | C77 | C78 | C79 | C80 | C81 | C82 |...
  • Page 881 ® Remote Command Reference R&S HDMI Analyzer Application Example: CONF:HDMI:CTS:VFOR:FK M022, C1 Manual operation: "Video Format" on page 307 CONFigure<hw>:HDMI:CTS:VFORmat:HDEXtension <TestCase>, <3DFormat> CONFigure<hw>:HDMI:CTS:VFORmat:HDEXtension? <TestCase> Sets the 3D format. Suffix: <hw> Irrelevant Parameters: <3DFormat> AUTO | FPACking | TBOTtom | SBSide Parameters for setting and query: <TestCase>...
  • Page 882 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Parameters: <Settings> OFF | FILE | AUX | ON *RST: Example: CONF:HDMI:INP:EDID:USER FILE Manual operation: "User Defined EDID" on page 277 CONFigure<hw>:HDMI:INPut:HDCP <Encryption> Enables or disables the HDCP encryption. For the HDMI RX/TX 600 MHz module (R&S VT-B2363), also sets the HDCP version.
  • Page 883: Display Subsystem

    ® Remote Command Reference R&S HDMI Analyzer Application 14.7.2.4 CONFigure<hw>:HDMI:SCDC Subsystem CONFigure<hw>:HDMI:SCDC:SCRambling:RESet <Enable> Resets the peak value of the detected character errors every time the command is sent. Afterwards, the measurement continues automatically. Parameters: <arg> OFF | ON The command requires a parameter, but both parameters have the same result - they cause a reset.
  • Page 884: Mmemory Subsystem

    .............. 886 MMEMory<hw>:HDMI:INPut:EDID:DATA:STORe MMEMory<hw>:HDMI:CEC:DATA:STORe <PathFile> Saves the CEC traffic report as a TXT file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 885 322 MMEMory<hw>:HDMI:CTS:DATA:STORe <PathFile> Saves the captured data as a *.hdmi file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 886 277 MMEMory<hw>:HDMI:INPut:EDID:DATA:STORe <PathFile> Saves the user-defined EDID as a *.bin file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a directory using on page 495.
  • Page 887: Read Subsystem

    ® Remote Command Reference R&S HDMI Analyzer Application 14.7.6 READ Subsystem ● READ<hw>[:SCALar]:HDMI:AUDio Subsystem........... 887 ● READ<hw>[:SCALar]:HDMI:CEC Subsystem............894 ● READ<hw>[:SCALar]:HDMI:CTS Subsystem............894 ● READ<hw>[:SCALar]:HDMI:HDCP Subsystem............896 ● READ<hw>[:SCALar]:HDMI:INFO:AUDio Subsystem..........900 ● READ<hw>[:SCALar]:HDMI:INFO:AVI Subsystem..........905 ● READ<hw>[:SCALar]:HDMI:INFO:DRMI Subsystem........... 912 ● READ<hw>[:SCALar]:HDMI:INFO:HFVendor Subsystem........917 ● READ<hw>[:SCALar]:HDMI:INFO:MPEG Subsystem..........924 ●...
  • Page 888 ® Remote Command Reference R&S HDMI Analyzer Application Usage: Query only Manual operation: "Audio Coding" on page 284 READ<hw>[:SCALar]:HDMI:AUDio:APPLication? Queries the application. Suffix: <hw> Irrelevant Return values: <String> Application name <String> Binary value Example: READ:HDMI:AUD:APPL? Query OK,"Consumer","0b0" Response Usage: Query only Manual operation: "Application"...
  • Page 889 ® Remote Command Reference R&S HDMI Analyzer Application Return values: <String> Category name <String> Binary value Example: READ:HDMI:AUD:CAT? Query OK,"General","0b00000000" Response Usage: Query only Manual operation: "Category Code" on page 284 READ<hw>[:SCALar]:HDMI:AUDio:COPYright? Queries the copyright. Suffix: <hw> Irrelevant Return values: <String>...
  • Page 890 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:AUDio:FS? Queries the f value. Suffix: <hw> Irrelevant Return values: <String> Value <String> Binary value Example: READ:HDMI:AUD:FS? Query OK,"44.1 kHz","0b0000" Response Usage: Query only Manual operation: "fs" on page 285 READ<hw>[:SCALar]:HDMI:AUDio:LAYout? Queries the layout value derived from the audio sample packet. Suffix: <hw>...
  • Page 891 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:AUD:LENG? Query OK,"16 bits","0b001" Response Usage: Query only Manual operation: "Audio Length" on page 285 READ<hw>[:SCALar]:HDMI:AUDio:LENGth:MAX? Queries the maximum audio length. Suffix: <hw> Irrelevant Return values: <String> Value <String> Binary value Example: READ:HDMI:AUD:LENG:MAX? Query...
  • Page 892 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:AUDio:N? Queries the N value derived from the audio clock regeneration packet. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDMI:AUD:N? Query OK,6272 Response Usage: Query only Manual operation: "N" on page 283 READ<hw>[:SCALar]:HDMI:AUDio:NCHannel? Queries the channel number.
  • Page 893 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:AUD:NSO? Query OK,"Ignore","0b0000" Response Usage: Query only Manual operation: "Source Number" on page 284 READ<hw>[:SCALar]:HDMI:AUDio:PREemphasis? Queries the pre-emphasis. Suffix: <hw> Irrelevant Return values: <String> Indication <String> Binary value Example: READ:HDMI:AUD:PRE? Query OK,"No","0b000"...
  • Page 894 ® Remote Command Reference R&S HDMI Analyzer Application 14.7.6.2 READ<hw>[:SCALar]:HDMI:CEC Subsystem Queries the CEC communication results. See also Chapter 10.2.9, "CEC Subtab", on page 323................ 894 READ<hw>[:SCALar]:HDMI:CEC:REPort? ............894 READ<hw>[:SCALar]:HDMI:CEC:REPort:COUNt? READ<hw>[:SCALar]:HDMI:CEC:REPort? <Line> Queries the content of the specified entry line in the CEC traffic report. Suffix: <hw>...
  • Page 895 ® Remote Command Reference R&S HDMI Analyzer Application .............895 READ<hw>[:SCALar]:HDMI:CTS:CONTrol:PROGress? ............895 READ<hw>[:SCALar]:HDMI:CTS:CONTrol:STATe? ................895 READ<hw>[:SCALar]:HDMI:CTS:REPort? ............896 READ<hw>[:SCALar]:HDMI:CTS:REPort:COUNt? READ<hw>[:SCALar]:HDMI:CTS:CONTrol:PROGress? Queries the current measurement progress. Suffix: <hw> Irrelevant Return values: <Value> Measurement progress in % Example: READ:HDMI:CTS:CONT:PROG? Query Response Usage: Query only Manual operation: "<Status display>"...
  • Page 896 ® Remote Command Reference R&S HDMI Analyzer Application Query parameters: <Line> Number of the entry line in the CTS test report. You can query the total number of lines using READ<hw>[:SCALar]:HDMI: on page 896. CTS:REPort:COUNt? Range: 0 (= first line) to total number Return values: <Result>...
  • Page 897 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Return values: <Value> <dblock> Data block Example: READ:HDMI:HDCP:AKSV? Query OK,868E2ECF31 Response Usage: Query only Manual operation: "AKSV" on page 287 READ<hw>[:SCALar]:HDMI:HDCP:AN? Queries the session random number. Suffix: <hw> Irrelevant Return values: <Value>...
  • Page 898 ® Remote Command Reference R&S HDMI Analyzer Application Manual operation: "HDCP State" on page 286 READ<hw>[:SCALar]:HDMI:HDCP:BKSV? Queries the key selection vector of the receiver. Suffix: <hw> Irrelevant Return values: <Value> <dblock> Data block Example: READ:HDMI:HDCP:BKSV? Query OK,538B03565F Response Usage: Query only Manual operation: "BKSV"...
  • Page 899 ® Remote Command Reference R&S HDMI Analyzer Application Return values: <Value> <dblock> 8 data blocks Example: READ:HDMI:HDCP:L? Query OK,E03DCA43225CE23CD0209FC115A8E0DF BA8CAF89C52F41AC02C396A82F6D11EA Response Usage: Query only Manual operation: "L" on page 288 READ<hw>[:SCALar]:HDMI:HDCP:RI? Queries the current link synchronization verification values. Suffix: <hw> Irrelevant Return values: <Value>...
  • Page 900 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:HDCP:RRX? Queries the pseudo-random value of the authentication protocol. Suffix: <hw> Irrelevant Return values: <Value> <dblock> 2 data blocks Example: READ:HDMI:HDCP:RRX? Query OK,03BEB88CD4326327 Response Usage: Query only Manual operation: "r(rx)" on page 287 READ<hw>[:SCALar]:HDMI:HDCP:RTX? Queries the pseudo-random value of the authentication protocol.
  • Page 901 ® Remote Command Reference R&S HDMI Analyzer Application ............902 READ<hw>[:SCALar]:HDMI:INFO:AUDio:LENGth? ..............903 READ<hw>[:SCALar]:HDMI:INFO:AUDio:LFE? ..............903 READ<hw>[:SCALar]:HDMI:INFO:AUDio:LSHift? .............903 READ<hw>[:SCALar]:HDMI:INFO:AUDio:PDATa? ........904 READ<hw>[:SCALar]:HDMI:INFO:AUDio:SAMPling:FREQuency? ..........904 READ<hw>[:SCALar]:HDMI:INFO:AUDio:SAMPling:SIZE? ............904 READ<hw>[:SCALar]:HDMI:INFO:AUDio:VERSion? READ<hw>[:SCALar]:HDMI:INFO:AUDio:CEXTension? Queries the code extension. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AUD:CEXT? Query "Refer to Audio Coding Type field" Response Usage: Query only...
  • Page 902 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:AUDio:CSUM? Queries the checksum. Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: READ:HDMI:INFO:AUD:CSUM? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AUDio:CTYPe? Queries the coding type. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AUD:CTYP? Query "Refer to Stream Header" Response Usage: Query only...
  • Page 903 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AUD:LENG? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AUDio:LFE? Queries the LFE playback level. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AUD:LFE? Query "Unknown or refer to other information" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AUDio:LSHift? Queries the level shift value.
  • Page 904 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INFO:AUD:PDAT? Query -124, 1, 10, 87, 7, 0, 0, 19, 0, 0, 0, 0, 0, 0 Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AUDio:SAMPling:FREQuency? Queries the sampling frequency. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AUD:SAMP:FREQ? Query "Refer to Stream Header"...
  • Page 905 ® Remote Command Reference R&S HDMI Analyzer Application 14.7.6.6 READ<hw>[:SCALar]:HDMI:INFO:AVI Subsystem Queries the parameters of the AVI InfoFrame measurement. See also Chapter 10.2.6, "InfoFrame Subtab", on page 288.............. 905 READ<hw>[:SCALar]:HDMI:INFO:AVI:AFARatio? ..............905 READ<hw>[:SCALar]:HDMI:INFO:AVI:AFINfo? ..............906 READ<hw>[:SCALar]:HDMI:INFO:AVI:ARATio? ..............906 READ<hw>[:SCALar]:HDMI:INFO:AVI:BINFo? ............906 READ<hw>[:SCALar]:HDMI:INFO:AVI:COLormetry? ..........
  • Page 906 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INFO:AVI:AFIN? Query "Active Format Information present" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:ARATio? Queries the picture aspect ratio. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:ARAT? Query "4:3" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:BINFo? Queries the bar information. Suffix: <hw>...
  • Page 907 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:AVI:COMPonent:FORMat? Queries the component format. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:COMP:FORM? Query "RGB" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:CSUM? Queries the checksum. Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: READ:HDMI:INFO:AVI:CSUM? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:CTYPe?
  • Page 908 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:ECOL? Query "xvYCC601" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:ITContent? Queries the IT content. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:ITC? Query "IT Content" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:LENGth? Queries the length. Suffix: <hw>...
  • Page 909 ® Remote Command Reference R&S HDMI Analyzer Application Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:LINE:STARt? Queries the line number of the bottom bar start. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:LINE:STAR? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:NUPScaling? Queries the nonuniform picture scaling. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:NUPS? Query...
  • Page 910 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:AVI:PIXel:LEFT? Queries the pixel number of the left bar end. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:PIX:LEFT? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:PIXel:RIGHt? Queries the pixel number of the right bar start. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:PIX:RIGH?
  • Page 911 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INFO:AVI:RGBQ? Query "Limited Range" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:SINFo? Queries the scan information. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:SINF? Query "Composed for an underscanned display" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:AVI:VERSion? Queries the version. Suffix: <hw>...
  • Page 912 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:AVI:YCCQ? Queries the YCC quantization. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:AVI:YCCQ? Query "Limited Range" Response Usage: Query only 14.7.6.7 READ<hw>[:SCALar]:HDMI:INFO:DRMI Subsystem Requires the HDMI RX/TX 600 MHz module (R&S VT-B2363) as input, see on page 950.
  • Page 913 ® Remote Command Reference R&S HDMI Analyzer Application Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:CSUM? Queries the checksum. Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: READ:HDMI:INFO:DRMI:CSUM? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:DPX<idx>? Queries display primaries x[1|2]. Suffix: <hw> Irrelevant <idx> Primaries Example: READ:HDMI:INFO:DRMI:DPX1? Query...
  • Page 914 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:DRMI:DPY<idx>? Queries display primaries y[1|2]. Suffix: <hw> Irrelevant <idx> Primaries Example: READ:HDMI:INFO:DRMI:DPY2? Query 1.200000E-001 Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:DPYNull? Queries display primaries y[0]. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:DRMI:DPYN? Query 1.000000E-001 Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:EOTF? Queries the electro-optical transfer function.
  • Page 915 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:DRMI:FALL? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:LENGth? Queries the length. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:DRMI:LENG? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:LMAX? Queries the max. display mastering luminance. Suffix: <hw>...
  • Page 916 ® Remote Command Reference R&S HDMI Analyzer Application Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:PDATa? Queries the header and packet bytes. Suffix: <hw> Irrelevant Return values: <Bytes> <dblock> HB0, HB1, HB2, PB0, ... , PB27 in decimal values HB = header byte, PB = packet byte Example: READ:HDMI:INFO:DRMI:PDAT? Query...
  • Page 917 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:DRMI:WPX? Queries the white point X. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:DRMI:WPX? Query 5.000000E-001 Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:DRMI:WPY? Queries the white point Y. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:DRMI:WPY? Query 5.000000E-001 Response Usage: Query only 14.7.6.8 READ<hw>[:SCALar]:HDMI:INFO:HFVendor Subsystem...
  • Page 918 ® Remote Command Reference R&S HDMI Analyzer Application ..........923 READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDTMetadata? ............923 READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDValid? ..........923 READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDVDispdata? ............ 924 READ<hw>[:SCALar]:HDMI:INFO:HFVendor:VERSion? READ<hw>[:SCALar]:HDMI:INFO:HFVendor:CSUM? Queries the checksum. Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: READ:HDMI:INFO:HFV:CSUM? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:HFVersion? Queries the HF VSIF version.
  • Page 919 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:HFVendor:LENGth? Queries the length. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:LENG? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:PDATa? Queries the header and packet bytes. Suffix: <hw> Irrelevant Return values: <Bytes> <dblock> HB0, HB1, HB2, PB0, ... , PB27 in decimal values HB = header byte, PB = packet byte Example: READ:HDMI:INFO:HFV:PDAT?
  • Page 920 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDDMetadata? Queries the 3D meta present. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:TDDM? Query "00 00 00 00 00 00 00 00 " Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDDualview? Queries the 3D dual view. Suffix: <hw>...
  • Page 921 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INFO:HFV:TDF? Query OK,"Horizontal sub-sampling" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDFStructure? Queries the 3D F structure. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:TDFS? Query "Side-by-Side(Full)" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDLDispdata? Queries the 3D disparity data length. Suffix: <hw>...
  • Page 922 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDPaddinfo? Queries the 3D additional info present. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:TDP? Query "1" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDPDispdata? Queries the 3D disparity data. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:TDPD? Query "1" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDPMeta?
  • Page 923 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INFO:HFV:TDPR? Query "Use left 3D view" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDTMetadata? Queries the 3D metadata type. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:TDTM? Query "0" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:HFVendor:TDValid? Queries the 3D validity. Suffix: <hw>...
  • Page 924 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:HFVendor:VERSion? Queries the version. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:HFV:VERS? Query Response Usage: Query only 14.7.6.9 READ<hw>[:SCALar]:HDMI:INFO:MPEG Subsystem Queries the parameters of the MPEG InfoFrame measurement. See also Chapter 10.2.6, "InfoFrame Subtab", on page 288..............924 READ<hw>[:SCALar]:HDMI:INFO:MPEG:CSUM? ............
  • Page 925 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INFO:MPEG:FREP? Query "New field (picture)" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:MPEG:LENGth? Queries the length. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:MPEG:LENG? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:MPEG:MPEG:BRATe? Queries the MPEG bit rate. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:MPEG:MPEG:BRAT?
  • Page 926 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:MPEG:PDATa? Queries the header and packet bytes. Suffix: <hw> Irrelevant Return values: <Bytes> <dblock> HB0, HB1, HB2, PB0, ... , PB10 in decimal values HB = header byte, PB = packet byte Example: READ:HDMI:INFO:MPEG:PDAT? Query...
  • Page 927 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: READ:HDMI:INFO:SPD:CSUM? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:SPD:LENGth? Queries the length. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:SPD:LENG? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:SPD:PDATa? Queries the header and packet bytes. Suffix: <hw>...
  • Page 928 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:SPD:PRODuct? Queries the product description. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:SPD:PROD? Query "VTS" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:SPD:VENDor? Queries the vendor name. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:SPD:VEND? Query "R&S" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:SPD:VERSion?
  • Page 929 ® Remote Command Reference R&S HDMI Analyzer Application ............930 READ<hw>[:SCALar]:HDMI:INFO:VENDor:PDATa? ............930 READ<hw>[:SCALar]:HDMI:INFO:VENDor:TDData? ..........930 READ<hw>[:SCALar]:HDMI:INFO:VENDor:TDSTructure? ............930 READ<hw>[:SCALar]:HDMI:INFO:VENDor:VERSion? ...............931 READ<hw>[:SCALar]:HDMI:INFO:VENDor:VIC? ..........931 READ<hw>[:SCALar]:HDMI:INFO:VENDor:VIDeoformat? READ<hw>[:SCALar]:HDMI:INFO:VENDor:CSUM? Queries the checksum. Suffix: <hw> Irrelevant Return values: <Value> Decimal value Example: READ:HDMI:INFO:VEND:CSUM? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:VENDor:IEEE? Queries the IEEE registration ID.
  • Page 930 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INFO:VENDor:PDATa? Queries the header and packet bytes. Suffix: <hw> Irrelevant Return values: <Bytes> <dblock> HB0, HB1, HB2, PB0, ... , PB10 in decimal values HB = header byte, PB = packet byte Example: READ:HDMI:INFO:VEND:PDAT? Query...
  • Page 931 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:VEND:VERS? Query Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:VENDor:VIC? Queries the HDMI video code. Suffix: <hw> Irrelevant Example: READ:HDMI:INFO:VEND:VIC? Query "4K x 2K 23.98/24Hz SMPTE (4)" Response Usage: Query only READ<hw>[:SCALar]:HDMI:INFO:VENDor:VIDeoformat? Queries the HDMI video format.
  • Page 932 Response Usage: Query only Manual operation: "HDCP State" on page 278 READ<hw>[:SCALar]:HDMI:INPut:HPOWer? Queries whether the R&S VTS has detected a valid voltage at the HDMI input. For querying the detected voltage value, use READ<hw>[:SCALar]:HDMI:INPut: VOLTage?. User Manual 2116.1228.02 ─ 14...
  • Page 933 Response: 25.200 MHz Usage: Query only Manual operation: "Pixel Clock" on page 278 READ<hw>[:SCALar]:HDMI:INPut:PCLock:STATe? Queries whether the R&S VTS has detected a valid HDMI input clock. Suffix: <hw> Irrelevant Return values: <Status> LOCKed | UNLocked User Manual 2116.1228.02 ─ 14...
  • Page 934 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INP:PCL:STAT? Query LOCK Response Usage: Query only Manual operation: "PCLK Locked" on page 277 READ<hw>[:SCALar]:HDMI:INPut:TMDSclock? Queries the TMDS character clock rate. Suffix: <hw> Irrelevant Return values: <Rate> Value in MHz Example: READ:HDMI:INP:TMDS? Query 2.520018E+001...
  • Page 935 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:INPut:VCOLor? Queries the colorimetry derived from the AVI (auxiliary video information) InfoFrame and, for HDR, the electro optical transfer function derived from the dynamic range and mastering InfoFrame. Suffix: <hw> Irrelevant Return values: <String>...
  • Page 936 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:INP:VOLT? Query 5.036298E+000 Response: 5.04 V Usage: Query only Manual operation: "HDMI +5V Power" on page 277 14.7.6.13 READ<hw>[:SCALar]:HDMI:SCDC Subsystem Requires the HDMI RX/TX 600 MHz module (R&S VT-B2363) as input, see on page 950.
  • Page 937 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:SCDC:HWVersion? Queries the hardware version. Suffix: <hw> Irrelevant Example: READ:HDMI:SCDC:HWV? Query "0.1" Response Usage: Query only Manual operation: "Hardware Version" on page 291 READ<hw>[:SCALar]:HDMI:SCDC:IDENtifier? Queries the identifier. Suffix: <hw> Irrelevant READ:HDMI:SCDC:IDEN? Example: Query "R&S VTx"...
  • Page 938 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Example: READ:HDMI:SCDC:RREN? Query Response Usage: Query only Manual operation: "Read Request Enable" on page 291 READ<hw>[:SCALar]:HDMI:SCDC:SCRambling:CH<channel>? Queries the channel lock status of channel 1 and 2. Suffix: <hw> Irrelevant <channel>...
  • Page 939 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:SCDC:SCRambling:CLOCk? Queries the status of clock detected. Suffix: <hw> Irrelevant Example: READ:HDMI:SCDC:SCR:CLOC? Query Response Usage: Query only Manual operation: "Clock Detected" on page 292 READ<hw>[:SCALar]:HDMI:SCDC:SCRambling:DETect? Queries the status of scrambling detected. Suffix: <hw>...
  • Page 940 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant <channel> Channel number Example: READ:HDMI:SCDC:SCR:ERR2? Query Response Usage: Query only Manual operation: "Errors Channel 0, Errors Channel 1, Errors Channel 2" on page 292 READ<hw>[:SCALar]:HDMI:SCDC:SCRambling:ERRChecksum? Queries the errors checksum. Suffix: <hw>...
  • Page 941 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:SCDC:SINKversion? Queries the sink version. Suffix: <hw> Irrelevant Example: READ:HDMI:SCDC:SINK? Query Response Usage: Query only Manual operation: "Sink Version" on page 291 READ<hw>[:SCALar]:HDMI:SCDC:SRCVersion? Queries the source version. Suffix: <hw> Irrelevant READ:HDMI:SCDC:SRCV? Example: Query Response Usage:...
  • Page 942 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Example: READ:HDMI:SCDC:UPD:CED? Query Response Usage: Query only Manual operation: "Update CED" on page 292 READ<hw>[:SCALar]:HDMI:SCDC:UPDate:READreqest? Queries the status of the update read request. Suffix: <hw> Irrelevant Example: READ:HDMI:SCDC:UPD:READ? Query Response Usage: Query only...
  • Page 943 ® Remote Command Reference R&S HDMI Analyzer Application ..........945 READ<hw>[:SCALar]:HDMI:VIDeo:HPIXel:SYNC:POLarity? ............945 READ<hw>[:SCALar]:HDMI:VIDeo:HPIXel:TOTal? ..............945 READ<hw>[:SCALar]:HDMI:VIDeo:PCLock? ..............946 READ<hw>[:SCALar]:HDMI:VIDeo:VCODe? ..............946 READ<hw>[:SCALar]:HDMI:VIDeo:VFORmat? .............946 READ<hw>[:SCALar]:HDMI:VIDeo:VFRequency? ............947 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:ACTive? ............947 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:BPORch? ............948 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:FPORch? .............948 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:SYNC? ..........948 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:SYNC:POLarity? ............. 949 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:TOTal? READ<hw>[:SCALar]:HDMI:VIDeo:HFRequency? Queries the measured horizontal frequency of the HDMI video content.
  • Page 944 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:VIDeo:HPIXel:BPORch? Queries the number of horizontal back porch pixels. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDMI:VID:HPIX:BPOR? Query OK,48 Response Usage: Query only Manual operation: "H Back Porch Pixels" on page 281 READ<hw>[:SCALar]:HDMI:VIDeo:HPIXel:FPORch? Queries the number of horizontal front porch pixels.
  • Page 945 ® Remote Command Reference R&S HDMI Analyzer Application Usage: Query only Manual operation: "H Sync Pixels" on page 281 READ<hw>[:SCALar]:HDMI:VIDeo:HPIXel:SYNC:POLarity? Queries horizontal synchronization polarity. Suffix: <hw> Irrelevant Return values: <Polarity> POSitive | NEGative Example: READ:HDMI:VID:HPIX:SYNC:POL? Query OK,NEG Response Usage: Query only Manual operation: "H Sync Polarity"...
  • Page 946 ® Remote Command Reference R&S HDMI Analyzer Application Example: READ:HDMI:VID:PCL? Query OK,2.52002e+007 Response: 25.2002 MHz Usage: Query only Manual operation: "Pixel Clock" on page 280 READ<hw>[:SCALar]:HDMI:VIDeo:VCODe? Queries the video code derived from the AVI InfoFrame. Suffix: <hw> Irrelevant Return values: <String>...
  • Page 947 ® Remote Command Reference R&S HDMI Analyzer Application Suffix: <hw> Irrelevant Return values: <VerticalFreq> Value in Hz Example: READ:HDMI:VID:VFR? Query OK,60.0004 Response Usage: Query only Manual operation: "Vertical Frequency" on page 281 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:ACTive? Queries the number of vertical active pixels. Suffix: <hw>...
  • Page 948 ® Remote Command Reference R&S HDMI Analyzer Application READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:FPORch? Queries the number of vertical front porch pixels. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDMI:VID:VLIN:FPOR? Query OK,10 Response Usage: Query only Manual operation: "V Front Porch Lines" on page 282 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:SYNC? Queries the number of vertical synchronization pixels.
  • Page 949: Route Subsystem

    ® Remote Command Reference R&S HDMI Analyzer Application Usage: Query only Manual operation: "V Sync Polarity" on page 282 READ<hw>[:SCALar]:HDMI:VIDeo:VLINe:TOTal? Queries the number of vertical total pixels. Suffix: <hw> Irrelevant Return values: <Value> Numeric value Example: READ:HDMI:VID:VLIN:TOT? Query OK,525 Response Usage: Query only Manual operation:...
  • Page 950: Cec/Ddc Analyzer Application

    ® Remote Command Reference R&S CEC/DDC Analyzer Application ROUTe<hw>:HDMI:MODule:CATalog? Queries the available input types and the slot position of the corresponding module. Suffix: <hw> Irrelevant Return values: <Input> "<input type> [<module slot>], <input type> [<module slot>], ..." with <input type> see Table 14-23 and [<module slot>] see Chapter 14.1.1, "Addressing Module...
  • Page 951: Abort Subsystem

    ® Remote Command Reference R&S CEC/DDC Analyzer Application ● DISPlay Subsystem....................964 ● INITiate Subsystem....................964 ● MMEMory Subsystem................... 965 ● READ Subsystem....................966 ● ROUTe Subsystem....................969 14.8.1 ABORt Subsystem ABORt<hw>:CECDdc:TRACer Stops the tracer function. Suffix: <hw> Irrelevant Example: ABOR:CECD:TRAC Usage: Event Manual operation: "Stop button"...
  • Page 952 ® Remote Command Reference R&S CEC/DDC Analyzer Application ........953 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:DIRected:HEADer ........953 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:ONEBit:LOW ........954 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:ONEBit:TOTal ........954 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:STARtbit:LOW ........954 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:STARtbit:TOTal ........955 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:ZERobit:LOW ........955 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:ZERobit:TOTal ........... 955 CONFigure<hw>:CECDdc:COMMand:CEC:DESTination ............956 CONFigure<hw>:CECDdc:COMMand:CEC:HOTKey ............956 CONFigure<hw>:CECDdc:COMMand:CEC:MODE ............957 CONFigure<hw>:CECDdc:COMMand:CEC:OPCode ............. 957 CONFigure<hw>:CECDdc:COMMand:CEC:OPERands ..............958 CONFigure<hw>:CECDdc:COMMand:DEBug ...............
  • Page 953 ® Remote Command Reference R&S CEC/DDC Analyzer Application Example: CONF:CECD:COMM:CEC:DEB:BRO:HEAD OFF Manual operation: "Enable Acks" on page 333 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:DEFault Resets the debugger settings, that means all commands of the CONFigure<hw>:CECDdc:COMMand:CEC:DEBug subsystem. Suffix: <hw> Irrelevant Example: CONF:CECD:COMM:CEC:DEB:DEF Usage: Event Manual operation: "Default button"...
  • Page 954 ® Remote Command Reference R&S CEC/DDC Analyzer Application Suffix: <hw> Irrelevant Parameters: <Value> Range: 0.400000 to 0.800000 *RST: 0.600000 Default unit: ms Example: CONF:CECD:COMM:CEC:DEB:ONEB:LOW 0.795 Manual operation: "Control Timing" on page 333 CONFigure<hw>:CECDdc:COMMand:CEC:DEBug:ONEBit:TOTal <Value> Sets the one bit total period for debugging. Suffix: <hw>...
  • Page 955 Default unit: ms Example: CONF:CECD:COMM:CEC:DEB:ZER:TOT 2.6387 Manual operation: "Control Timing" on page 333 CONFigure<hw>:CECDdc:COMMand:CEC:DESTination <Address> Sets the logical address of the DUT that should receive the CEC messages sent by the R&S VTS. Suffix: <hw> Irrelevant User Manual 2116.1228.02 ─ 14...
  • Page 956 ® Remote Command Reference R&S CEC/DDC Analyzer Application Parameters: <Address> TV | RD1 | RD2 | TUN1 | PD1 | AUDiosystem | TUN2 | TUN3 | PD2 | RD3 | TUN4 | PD311 | R12 | R13 | SPECificuse | BROadcast | BAK1 | BAK2 with RD = recording device, TUN = tuner, PD = playback device, R = reserved...
  • Page 957 ® Remote Command Reference R&S CEC/DDC Analyzer Application Manual operation: "Mode" on page 330 CONFigure<hw>:CECDdc:COMMand:CEC:OPCode <Group>, <String> Sets the group and the CEC command/opcode. The mode is adjusted automatically (CONFigure<hw>:CECDdc:COMMand:CEC:MODE on page 956). Suffix: <hw> Irrelevant Parameters: <Group> OTP | RC | OTR | DC | TP | SI | CDC | TC | VSC | OD | DOT | DMC | RPC | PS | GP | SAC | ARC | AR | DL | PRESet | UDEFined | CUSTom Quick mode: PRESet | UDEFined...
  • Page 958 ® Remote Command Reference R&S CEC/DDC Analyzer Application Example: CONF:CECD:COMM:CEC:OPC RC,"0x80" Sets the "Routing Change (0x80)" opcode and adjusts to advanced mode, if necessary. CONF:CECD:COMM:CEC:OPER 4,#H00,#H00,#H00,#H00 Sets all 4 parameters to 0. Manual operation: "No. of Param." on page 331 "Parameter 1 to 14"...
  • Page 959 ® Remote Command Reference R&S CEC/DDC Analyzer Application CONFigure<hw>:CECDdc:COMMand:PORT <HDMI> Sets the port of the HDMI RX/TX 600 MHz module (R&S VT-B2363) at which the com- mands are send. Suffix: <hw> Irrelevant Parameters: <HDMI> HIN | HOUT *RST: Example: CONF:CECD:COMM:PORT HOUT Manual operation: "Port"...
  • Page 960 ® Remote Command Reference R&S CEC/DDC Analyzer Application Parameters: <Value> Range: #H0 to #HFF *RST: Example: CONF:CECD:COMM:SCDC:READ:OFFS #H2E Manual operation: "Offset" on page 334 CONFigure<hw>:CECDdc:COMMand:SCDC:WRITe Starts writing the SCDC registers using the HDMI OUT port. Suffix: <hw> Irrelevant Example: CONF:CECD:COMM:SCDC:WRIT Usage: Event Manual operation:...
  • Page 961 ® Remote Command Reference R&S CEC/DDC Analyzer Application Parameters: <Value> Range: #H0 to #HFF *RST: Example: CONF:CECD:COMM:SCDC:WRIT:OFFS #HA Manual operation: "Offset" on page 334 CONFigure<hw>:CECDdc:COMMand:SEND Sends a command as specified. Suffix: <hw> Irrelevant Example: CONF:CECD:COMM:SEND Usage: Event Manual operation: "Send button" on page 333 CONFigure<hw>:CECDdc:COMMand:TYPE <Setting>...
  • Page 962 ® Remote Command Reference R&S CEC/DDC Analyzer Application Parameters: <Sampling> CEC | DDC *RST: Example: CONF:CECD:CONF:CHAN DDC Manual operation: "Data Channel" on page 327 CONFigure<hw>:CECDdc:CONFigure:INITiator:HIN <Address> CONFigure<hw>:CECDdc:CONFigure:INITiator:HOUT <Address> Sets the DUT type addressed at the HDMI IN/HDMI OUT port of the HDMI RX/TX 600 MHz module (R&S VT-B2363).
  • Page 963 ® Remote Command Reference R&S CEC/DDC Analyzer Application ..............963 CONFigure<hw>:CECDdc:TRACer:PACKet ..............963 CONFigure<hw>:CECDdc:TRACer:STATus ............964 CONFigure<hw>:CECDdc:TRACer:TABLe:SELect CONFigure<hw>:CECDdc:TRACer:DEVice:ONE <Address> CONFigure<hw>:CECDdc:TRACer:DEVice:TWO <Address> Sets the device types. Used to monitor communications between 2 device types. Suffix: <hw> Irrelevant Parameters: <Address> ALL | TV | RD1 | RD2 | TUN1 | PD1 | AUDio | TUN2 | TUN3 | PD2 | RD3 | TUN4 | PD3 | R12 | R13 | SPECific | UORBroadcast | VTX | DUT | BAK1 | BAK2 with RD = recording device, TUN = tuner, PD = playback device,...
  • Page 964 ® Remote Command Reference R&S CEC/DDC Analyzer Application Parameters: <Error> ALL | NERRor | ERRor *RST: Example: CONF:CECD:TRAC:STAT ERR Manual operation: "Status" on page 338 CONFigure<hw>:CECDdc:TRACer:TABLe:SELect <Index> Selects the specified entry in the packet data table. If you specify the number of the selected entry, it is deselected.
  • Page 965 MMEMory<hw>:CECDdc:TRACer:DATA:STORe MMEMory<hw>:CECDdc:COMMand:EDID:DATA:STORe <PathFile> Saves the read EDID data as a BIN file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a new directory using MMEMory:MDIRectory on page 495.
  • Page 966 Parameters: <PathFile> Filename including the extension. If the path is omitted, the cur- rent directory is used. Example: MMEM:CECD:TRAC:DATA:STOR "D: \VTS\UserData\MyResults.txt" Saves MyResults.txt in the D:\VTS\UserData directory. Manual operation: "Save button" on page 337 14.8.7 READ Subsystem ..........966 READ<hw>:CECDdc:COMMand:CEC:QMODe:DESCription? ...............966...
  • Page 967 ® Remote Command Reference R&S CEC/DDC Analyzer Application Example: READ:CECD:COMM:OUTP? Query "Sent: <br></br><b>TV</b> -&gt; <b>TV</b> <br></br>Opcode: <b>0x44 (User Control Pressed)</b><br></br> Operands: <b>0x41 [UI Command] = Volume Up</b><br></br>Status: <b>Acknowledged</b><br></br>" Response Usage: Query only READ<hw>:CECDdc:STATus:IN? Queries the status of the HDMI IN port. Suffix: <hw>...
  • Page 968 ® Remote Command Reference R&S CEC/DDC Analyzer Application Suffix: <hw> Irrelevant Return values: <Result> Description of the row selected by CONFigure<hw>:CECDdc: on page 964. TRACer:TABLe:SELect Example: READ:CECD:TRAC:DESC? Query "Frame #10683 Packet Type: SCDC(I2C Address: 0xa8,WRITE) Raw Data: START 0xa8 0x41 Frame Error: None" Response Usage: Query only...
  • Page 969 ® Remote Command Reference R&S CEC/DDC Analyzer Application <Column> NUMBer | TIME | INITiator | DESTination | PACKet | PORT Return values: <CellContent> Content of the cell specified by index and column Example: READ:CECD:TRAC:TABL:ITEM? 182,TIME Query "16:28:51.480" Response Usage: Query only Manual operation: "<Packet data table>"...
  • Page 970 ® Remote Command Reference R&S Time Domain Analyzer Application Parameters: <Standard> HDMI14 | HDMI20 *RST: HDMI14 Example: ROUT:CECD:SEL:VERS HDMI20 Sets HDMI 2.0. Manual operation: "Standard" on page 327 14.9 Time Domain Analyzer Application These commands correlate to the functions provided in Chapter 11, "Time Domain Analyzer Application",...
  • Page 971 ® Remote Command Reference R&S Time Domain Analyzer Application 14.9.2.1 CONFigure<hw>:TDA:CTS Subsystem Configures the parameters of the CTS test cases. See also "CTS Configuration dialog" on page 376. Addressing test cases Table 14-24: HDMI 1.4 tests Test case Remote command parameter (<TestCase>) "7-1: EDID Related Behavior"...
  • Page 972 ® Remote Command Reference R&S Time Domain Analyzer Application ..........973 CONFigure<hw>:TDA:CTS:HDMI:LDEGradation:SPMexists ..............974 CONFigure<hw>:TDA:CTS:HDMI:SDCPower .................974 CONFigure<hw>:TDA:CTS:HDMI:SELect CONFigure<hw>:TDA:CTS:HDMI:CHANnel:SELect <TestCase>, <Channel> CONFigure<hw>:TDA:CTS:HDMI:CHANnel:SELect? <TestCase> Sets the channel of the measurement. Suffix: <hw> Irrelevant Parameters: <Channel> Not every channel value is available for every test case, see Table 11-1 Table 11-2.
  • Page 973 ® Remote Command Reference R&S Time Domain Analyzer Application CPCMinus Clock+ Clock- Parameters for setting and query: <TestCase> Specifies the test case. See "Addressing test cases" on page 971. Example: CONF:TDA:CTS:HDMI:CHAN:SEL H003,TD02 Manual operation: "Channel (default favorite)" on page 374 CONFigure<hw>:TDA:CTS:HDMI:HVL:HPCLck <Support>...
  • Page 974 ® Remote Command Reference R&S Time Domain Analyzer Application Suffix: <hw> Irrelevant Parameters: <Support> YES | NO *RST: Parameters for setting and query: <TestCase> H001_h0703 | H016_h0715 Specifies the test case. See "Addressing test cases" on page 971. Example: CONF:TDA:CTS:HDMI:LDEG:SPM H001,YES Manual operation: "Standby Power Mode Exists"...
  • Page 975 ® Remote Command Reference R&S Time Domain Analyzer Application 14.9.2.2 CONFigure<hw>:TDA:FREQuency Subsystem CONFigure<hw>:TDA:FREQuency <Value> Sets an EDID to force the DUT to produce the test frequencies. Suffix: <hw> Irrelevant Parameters: <Value> The range of test frequencies depends on the standard. 25175000 | 25200175 | 27000000 | 27027000 | 54000000 | 54054000 | 59341000 | 59400000 | 72000000 | 74176000 | 74250000 | 108000000 | 108108000 | 148352000 | 148500000 |...
  • Page 976 ® Remote Command Reference R&S Time Domain Analyzer Application ..............977 CONFigure<hw>:TDA:SCOPe:MASK:RESet ..............977 CONFigure<hw>:TDA:SCOPe:PERSistence ............978 CONFigure<hw>:TDA:SCOPe:PERSistence:COUNt ................978 CONFigure<hw>:TDA:SCOPe:RESolution ................978 CONFigure<hw>:TDA:SCOPe:SPAN CONFigure<hw>:TDA:SCOPe <Meas> Sets the measurement function of the scope. Suffix: <hw> Irrelevant Parameters: <Meas> CURSor | MASK | HHIStogram | VHIStogram *RST: CURSor Example:...
  • Page 977 ® Remote Command Reference R&S Time Domain Analyzer Application CONFigure<hw>:TDA:SCOPe:MASK <OuterVoltage>, <InnerVoltage>, <OuterTime>, <InnerTime> Configures the mask. Suffix: <hw> Irrelevant Parameters: <OuterVoltage> Range: 0 to 1.200 *RST: 0.780 Default unit: V <InnerVoltage> Range: 0 to 1.200 *RST: 0.200 Default unit: V <OuterTime>...
  • Page 978 ® Remote Command Reference R&S Time Domain Analyzer Application Parameters: <Setting> INFinite | LIMited *RST: LIMited Example: CONF:TDA:SCOP:PERS INF Manual operation: "Persistence" on page 370 CONFigure<hw>:TDA:SCOPe:PERSistence:COUNt <Value> Sets the memory time of samples. Suffix: <hw> Irrelevant Parameters: <Value> Range: 1 to 256 *RST: Example: CONF:TDA:SCOP:PERS:COUN 10...
  • Page 979 ..............980 MMEMory<hw>:TDA:INPut:EDID:DATA:LOAD MMEMory<hw>:TDA:CTS:DATA:STORe <PathFile> Saves the test report as a file in the specified directory. You can use D:\VTS\UserData as directory. The current directory is set using on page 491. MMEMory:CDIRectory Alternatively, you can create a new directory using MMEMory:MDIRectory on page 495.
  • Page 980 If file extension is *.mht, the file is written in MHTML format. Otherwise, a simple TXT file is written. Example: MMEM:TDA:CTS:DATA:STOR "D: \VTS\UserData\MyReport.mht" Saves MyReport.mht in the D:\VTS\UserData directory. Usage: Setting only Manual operation: "Save button" on page 379 MMEMory<hw>:TDA:INPut:EDID:DATA:LOAD <PathFile>...
  • Page 981 ® Remote Command Reference R&S Time Domain Analyzer Application ..........986 READ<hw>[:SCALar]:TDA:SCOPe:CURSor:DIFFerence? ..............986 READ<hw>[:SCALar]:TDA:SCOPe:HHIStogram? ..........987 READ<hw>[:SCALar]:TDA:SCOPe:HHIStogram:VALues? ............988 READ<hw>[:SCALar]:TDA:SCOPe:MASK:VIOLation? ..........989 READ<hw>[:SCALar]:TDA:SCOPe:PERSistence:COUNt? ..............989 READ<hw>[:SCALar]:TDA:SCOPe:VHIStogram? ..........990 READ<hw>[:SCALar]:TDA:SCOPe:VHIStogram:VALues? ...............991 READ<hw>[:SCALar]:TDA:SIGNal:STATe? READ<hw>:ARRay:TDA:SCOPe:EYE? Queries the measured values of the eye diagram (scope measurement). Suffix: <hw>...
  • Page 982 ® Remote Command Reference R&S Time Domain Analyzer Application Example: READ:TDA:CLOC:CHAR? Query OK,1.485000E+008 Response Usage: Query only READ<hw>[:SCALar]:TDA:COMMand:STATe? Queries which measurement is running. Suffix: <hw> Irrelevant Return values: <Measurement> NONE | SCOPe | CTS Example: READ:TDA:COMM:STAT? Query SCOP Response Usage: Query only READ<hw>[:SCALar]:TDA:CTS:CONTrol:PROGress? Queries the current measurement progress (CTS measurement).
  • Page 983 ® Remote Command Reference R&S Time Domain Analyzer Application Example: READ:TDA:CTS:CONT:STAT? Query Response Usage: Query only READ<hw>[:SCALar]:TDA:CTS:HDMI:SELect:NAME? Queries the name of the selected CTS test case. Suffix: <hw> Irrelevant Return values: <TestCase> Test case name as string Example: READ:TDA:CTS:HDMI:SEL:NAME? Query "7-2 TMDS VL"...
  • Page 984 ® Remote Command Reference R&S Time Domain Analyzer Application Suffix: <hw> Irrelevant Return values: <Lines> Total number of lines Example: READ:TDA:CTS:REP:COUN? Query Response Usage: Query only READ<hw>[:SCALar]:TDA:CTS:RESult? Queries the result of the last CTS test. Suffix: <hw> Irrelevant Return values: <Result>...
  • Page 985 ® Remote Command Reference R&S Time Domain Analyzer Application READ<hw>[:SCALar]:TDA:INPut:EDID? Queries the status of reading the EDID from the DUT. Suffix: <hw> Irrelevant Return values: <Status> READy | ISReading | COMPlete Example: READ:TDA:INP:EDID? Query COMP Response Usage: Query only Manual operation: "DDC EDID"...
  • Page 986 ® Remote Command Reference R&S Time Domain Analyzer Application Example: READ:TDA:LIST:INP? Query T0PM, T0PG, T0MG, T1PM, T1PG, T1MG, T2PM, T2PG, T2MG Response Usage: Query only Manual operation: "Channel (default favorite)" on page 365 READ<hw>[:SCALar]:TDA:SCOPe:CURSor:DIFFerence? Queries the differences between the cursors (scope measurement). Suffix: <hw>...
  • Page 987 ® Remote Command Reference R&S Time Domain Analyzer Application <(R-L)Max> Maximum value of the difference between the right histogram calculation and the left histogram calculation. Default unit: UI <LMean> Mean value of the left histogram. Default unit: UI <LMin> Minimum value of the left histogram. Default unit: UI <LMax>...
  • Page 988 ® Remote Command Reference R&S Time Domain Analyzer Application Example: READ:TDA:SCOP:HHIS:VAL? Query -6.000000E-001, 4.166667E-003, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 237, 674, 2081, 1915, 494, 29, 3, 0, 0, 0, 0, 22, 107, 217, 930, 2525, 1683, 211, 4, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,...
  • Page 989 ® Remote Command Reference R&S Time Domain Analyzer Application READ<hw>[:SCALar]:TDA:SCOPe:PERSistence:COUNt? Queries the number of the currently running scan (scope measurement). Suffix: <hw> Irrelevant Return values: <Scan> Numeric value Example: READ:TDA:SCOPe:PERS:COUN? Query Response Usage: Query only READ<hw>[:SCALar]:TDA:SCOPe:VHIStogram? Queries the values for the horizontal histogram (scope measurement). Suffix: <hw>...
  • Page 990 ® Remote Command Reference R&S Time Domain Analyzer Application Example: READ:TDA:SCOP:VHIS? Query 9.150000E+002, 5.080000E+002, 1.101400E+003, 4.470000E+002, 2.500000E+002, 5.234000E+002, 5.290000E+001, -4.680000E+002, -5.780000E+002, -2.578000E+002, 6.240000E+001 Response Usage: Query only Manual operation: "Upper - Lower" on page 369 "Upper Histogram, Lower Histogram" on page 370 READ<hw>[:SCALar]:TDA:SCOPe:VHIStogram:VALues? Queries the raw data of the vertical histogram (scope measurement).
  • Page 991 ® Remote Command Reference R&S Time Domain Analyzer Application Usage: Query only Manual operation: "Vertical Histogram View" on page 369 READ<hw>[:SCALar]:TDA:SIGNal:STATe? Queries if the TMDS time domain analyzer module (R&S VT-B2380) was able to syn- chronize to the detected HDMI or MHL input clock. Suffix: <hw>...
  • Page 992 ® Remote Command Reference R&S Time Domain Analyzer Application Suffix: <hw> Irrelevant Example: ROUT:TDA:REC Usage: Event Manual operation: "Reconnect button" on page 363 ROUTe<hw>:TDA:SCOPe:HDMI:CHANnel:SELect <Channel> Sets the channel (scope measurement). Suffix: <hw> Irrelevant Parameters: <Channel> T0PMinus | T0PGround | T0MGround | T1PMinus | T1PGround | T1MGround | T2PMinus | T2PGround | T2MGround on page 985.
  • Page 993 ® Remote Command Reference R&S MHL Applications 14.9.9 UNIT Subsystem ..................993 UNIT<hw>:TDA:SCOPe:TIME ................... 993 UNIT<hw>:TDA:SCOPe:VOLTage UNIT<hw>:TDA:SCOPe:TIME <Unit> Sets the unit for the time settings (scope measurement). Suffix: <hw> Irrelevant Parameters: <Unit> UI | NS | PS *RST: Example: UNIT:TDA:SCOP:TIME NS Manual operation: "Time"...
  • Page 994 894129. If the R&S VTS is connected to a network and if the login data under Windows 7 and on the network is identical, you log on to operating system and the network at the same time.
  • Page 995 Connect an external keyboard. If the instrument does not have a monitor, connect also an external monitor. To display the main dialog for backup and restore 1. Restart the R&S VTS. User Manual 2116.1228.02 ─ 14...
  • Page 996 ® Installed Software R&S Backup and Restore Application The boot screen is displayed. By default, "System" is selected. If you do not per- form the next step within 4 seconds, the dialog vanishes and the booting process continues. 2. Select the "Backup" partition and press [ENTER]. The main dialog is displayed.
  • Page 997 ® Installed Software R&S Backup and Restore Application Figure 15-1: Main dialog (example) (1) = Header showing instrument type (2) = Header showing instrument name (3) = Free memory space on backup partition (4) = List of backups already created (5) = Description of currently selected backup To continue, see one of the following chapters: ●...
  • Page 998 4. In the main dialog, select "Exit and Reboot". The backup and restore application is closed, and the R&S VTS is restarted. 15.3.2 Restoring a Selected Backup Version Using this function, you can restore the selected instrument installation and its configu- ration.
  • Page 999 ® Installed Software R&S Backup and Restore Application Note: If you activate "Keep open when finished", the progress information dialog remains open until you close it. 15.3.3 Deleting a Backup Using this function, you can delete the selected instrument installation and its configu- ration.
  • Page 1000 ® Troubleshooting R&S SCPI Error Messages 16 Troubleshooting This chapter gives information on issues, errors and warnings of the R&S VTS. If you need to transport or ship the product, see Chapter 17, "Transporting", on page 1007. 16.1 Issues Known issues are listed in the release notes of your firmware version. The release notes are delivered with the firmware, or you can download them from the Rohde &...

Table of Contents
