- Page 1 www.gkbpx.com 该文档是极速PDF编辑器生成， 如果想去掉该提示,请访问并下载： http://www.jisupdfeditor.com/ SIMATIC Communications processor CP 340 first commissioning steps Getting Started 04/2005 A5E00442606-01...
- Page 2 Trademarks All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
- Page 3 www.gkbpx.com 该文档是极速PDF编辑器生成， 如果想去掉该提示,请访问并下载： http://www.jisupdfeditor.com/ First commissioning steps Preface These instructions use a concrete example to guide you through the four commissioning steps and up to a functioning application with which you can transfer data via the serial interface and get to know and check the basic functions of your CP 340 in hardware and software.
- Page 4 www.gkbpx.com 该文档是极速PDF编辑器生成， 如果想去掉该提示,请访问并下载： http://www.jisupdfeditor.com/ First commissioning steps Install CP 340 and connect with the communication partner 1. Plug the connector supplied with the CP 340 into the bus connector of the CPU. 2. Mount the CP 340 on the rail, tilt it downwards and then screw it tight. 3.
- Page 5 Integrating in the user program 1. When installing the configuration package you installed the example project "zXX21_01_PtP_Com_CP34x" in the catalog Siemens\STEP7\Examples". 2. In the SIMATIC Manager open the example project with File → Open ... → Projects and double click on the subproject "CP340 PtP Connection".
- Page 6 www.gkbpx.com 该文档是极速PDF编辑器生成， 如果想去掉该提示,请访问并下载： http://www.jisupdfeditor.com/ First commissioning steps Receiving If you are sending data from your communication partner, these are received by CP340 in DB20 as the case may be. The destination specifications are created in the FC12 with the label "AO:" or "A1:". PEW0: to do this, on your "Input SM323"...
