SPECIFICATIONS

Input
Input 4/6-wire strain gauge, 1–5mV/V
Power HV= 85–265V AC / 95–370V DC,
or LV= 15–48V AC / 10–72V DC
Max power 5W, fully optioned,
8 loadcells
Excitation 5V DC excitation supplied
(powers up to 8 x 350Ω loadcells)
Sampling rate Up to 60Hz
Resolution 18 bit
Accuracy 0.005% of reading
Temperature drift Typically 3ppm/°C
Relay Output
Number of relay outputs None, 2, or 4
Relay output type 5A form A (3A 240V
AC max or 3A 30V DC max)
Analog Output
Number of analog outputs None or 1
Analog output type Isolated 16 bit
4–20mA/0–10V
Comm Port
Number of comm ports None or 1
PRO-WEI100-MAN-19V01 (0225)
Comm port options
S2R= Isolated RS232, RJ terminal, or
S4S= Isolated RS485, screw terminal
Serial output Custom ASCII, Modbus
RTU slave, Gedge, Ranger A, or Print
Programming
Front panel buttons Up, Down, Prog,
plus 2 Function Buttons for menu access
Factory calibrated for 0–10,000 counts
(2mV/V sensor gain at full scale). 2 cal
sets for saving/restoring calibrations
Security Input and setpoint setups are
independently PIN protected
OPTIONAL
Display
Display type LED display, 5 buttons
LED indicators 6 setpoint indicator LED's
Digits 1 row of 6 digits, 13mm (0.5"),
OPTIONAL 14 segment alphanumeric LED
Construction
IP65 dust/splash proof (face only)
Dimensions (H x W x D)
OPTIONAL 96 x 48 x 120mm (3.78 x 1.89 x 4.72")
Panel cutout 92 x 45mm (3.62 x 1.77")
