Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
I218-422
I218-402
HARDWARE LIST: I218-422
Description
No.
Bolt Ø5/16" x 2"
A
Lock Washer Ø5/16"
B
Flat Washer Ø5/16" x 3/4"
C
D Allen Wrench M4
HARDWARE LIST: I218-402
Description
No.
Hanger Bolt Ø5/16" x 3"
E
Half Moon Washer Ø5/16"
F
Hex Nut Ø5/16"
G
Hex Wrench 13mm
H
Wood Screw #4 x 1-1/4"
I
Wood Screw #4 x 3/4"
J
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/6
Queen Uph HB
Queen Low Profile FB
Queen Rails w/ Decking
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
I218-403
Quantity
Sketch
6 PCS
6 PCS
6 PCS
1 PC
Quantity
Sketch
8 PCS
8 PCS
8 PCS
1 PC
8 PCS
16 PCS
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.
COMPONENTS LIST: I218-422
Description
No.
1 Headboard
Left Leg
2
3
Right Leg
COMPONENTS LIST: I218-402
Description
No.
1 Bed rails
Slats
2
Decking
3
COMPONENTS LIST: I218-403
Description
No.
1 Footboard
2 Support Leg (for slats)
Quantity
Sketch
1 PC
1 PC
1 PC
Quantity
Sketch
2 PCS
4 PCS
8 PCS
Quantity
Sketch
1 PC
4 PCS
01-02-2020
