aspenhome
ah
ITEM NO: I222-422-1
I222-402-1
I222-403-1
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
I222-422-1
I222-402-1
HARDWARE LIST: I222-422-1
Description
No.
Bolt Ø5/16" x 1-1/2"
A
Lock Washer Ø5/16"
B
Flat Washer Ø5/16" x 3/4"
C
D
Allen Wrench M4
Bolt Ø1/4" x 1-1/4"
E
Lock Washer Ø1/4"
F
Flat Washer Ø1/4" x 3/4"
G
HARDWARE LIST: I222-402-1
Description
No.
Hanger Bolt Ø5/16" x 3"
H
Half Moon Washer Ø5/16"
I
Hex Nut Ø5/16"
J
K
Hex Wrench 13mm
L
Wood Screw #4 x 1-1/4"
M
Wood Screw #4 x 3/4"
Bolt Ø1/4" x 1-1/4"
N
Lock Washer Ø1/4"
O
Flat Washer Ø1/4" x 3/4"
P
Q
Allen Wrench 4mm
WARNING! Before using this product, please read, understand, and follow these instructions. Failure to follow
each of these assembly instructions precisely may result in damage to the product and / or injury to the consumer.
Page 1/5
Queen Uph HB
Queen Rails w/ Decking
Queen Low Profile FB
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
I222-403-1
Quantity
Sketch
10 PCS
10 PCS
10 PCS
1 PC
4 PCS
4 PCS
4 PCS
Quantity
Sketch
8 PCS
8 PCS
8 PCS
1 PC
12 PCS
16 PCS
10 PCS
10 PCS
10 PCS
1 PC
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST: I222-422-1
Description
No.
1
Headboard
Left Leg
2
3
Right Leg
4
Wood Stretcher
Center Support Leg
5
COMPONENTS LIST: I222-402-1
Description
No.
1
Bed rails
2
Slats
3
Decking
4
Support Leg (for center rail)
5
Center rail
COMPONENTS LIST: I222-403-1
Description
No.
1
Footboard
Quantity
Sketch
1 PC
1 PC
1 PC
1 PC
1 PC
Quantity
Sketch
2 PCS
6 PCS
8 PCS
3 PCS
1 PC
Quantity
Sketch
1 PC
11-22-2023
Advertisement
Related Manuals for aspenhome I222-422-1
Summary of Contents for aspenhome I222-422-1
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: I222-422-1 Queen Uph HB I222-402-1 Queen Rails w/ Decking I222-403-1 Queen Low Profile FB Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment.
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: I222-422-1 Queen Uph HB I222-402-1 Queen Rails w/ Decking I222-403-1 Queen Low Profile FB STEP 1: Lay the headboard face down on a soft surface. Attach the left leg and right leg to headboard by using 6 bolts (A), lock washers (B) and flat washers (C).
- Page 3 ASSEMBLY INSTRUCTIONS ITEM NO: I222-422-1 Queen Uph HB I222-402-1 Queen Rails w/ Decking I222-403-1 Queen Low Profile FB STEP 4: Screw the bolts (H) into HB & FB. Make sure the slat bearer is in the UPPER position. Align the bolts with the holes in the end of side rails and attach the side rails to HB & FB using half moon Washer (I) and hex nuts (J).Then use a hex wrench (K) to tighten all the nuts.
- Page 4 ASSEMBLY INSTRUCTIONS ITEM NO: I222-422-1 Queen Uph HB I222-402-1 Queen Rails w/ Decking I222-403-1 Queen Low Profile FB STEP 7: Arrange slats on the slat bearers. Make sure the slats are placed within the notches of each bearer and secured completely with wood screws (L).
- Page 5 ASSEMBLY INSTRUCTIONS ITEM NO: I222-422-1 Queen Uph HB I222-402-1 Queen Rails w/ Decking I222-403-1 Queen Low Profile FB FUNCTIONALITY INSTRUCTION I222-422-1 Single Powered USB Port for Charging on both sides I222-402-1 I222-403-1 Page 5/5 MADE IN VIETNAM 11-22-2023...
- Page 6 ASSEMBLY INSTRUCTIONS ITEM NO: I222-425-1 King Uph HB I222-406-1 King Rails w/ Decking I222-410-1 Cal King Rails w/ Decking I222-407-1 King Low Profile FB Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment.
- Page 7 ASSEMBLY INSTRUCTIONS ITEM NO: I222-425-1 King Uph HB I222-406-1 King Rails w/ Decking I222-410-1 Cal King Rails w/ Decking I222-407-1 King Low Profile FB STEP 1: Lay the headboard face down on a soft surface. Attach the left leg and right leg to headboard by using 6 bolts (A), lock washers (B) and flat washers (C).
- Page 8 ASSEMBLY INSTRUCTIONS ITEM NO: I222-425-1 King Uph HB I222-406-1 King Rails w/ Decking I222-410-1 Cal King Rails w/ Decking I222-407-1 King Low Profile FB STEP 4: Screw the bolts (H) into HB & FB. Make sure the slat bearer is in the UPPER position.
- Page 9 ASSEMBLY INSTRUCTIONS ITEM NO: I222-425-1 King Uph HB I222-406-1 King Rails w/ Decking I222-410-1 Cal King Rails w/ Decking I222-407-1 King Low Profile FB STEP 7: Arrange slats on the slat bearers. Make sure the slats are placed within the notches of each bearer and secured completely with wood screws (L).
- Page 10 ASSEMBLY INSTRUCTIONS ITEM NO: I222-425-1 King Uph HB I222-406-1 King Rails w/ Decking I222-410-1 Cal King Rails w/ Decking I222-407-1 King Low Profile FB FUNCTIONALITY INSTRUCTION I222-425-1 Single Powered USB Port for Charging on both sides I222-406-1 I222-407-1 Standard king bed...
- Page 11 ASSEMBLY INSTRUCTIONS ITEM NO: I222-522-1 Twin Uph HB I222-503-1 Twin Low Profile FB I222-517-1 Twin Rails w/ Decking Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment.
- Page 12 ASSEMBLY INSTRUCTIONS ITEM NO: I222-522-1 Twin Uph HB I222-503-1 Twin Low Profile FB I222-517-1 Twin Rails w/ Decking STEP 1: Lay the headboard face down on a soft surface. Attach the left leg and right leg to headboard by using 6 bolts (A), lock washers (B) and flat washers (C).
- Page 13 ASSEMBLY INSTRUCTIONS ITEM NO: I222-522-1 Twin Uph HB I222-503-1 Twin Low Profile FB I222-517-1 Twin Rails w/ Decking STEP 3: Screw the bolts (E) into HB & FB. Make sure the slat bearer is in the UPPER position. Align the bolts with the holes in the end of side rails and attach the side rails to HB & FB using half moon Washer (F) and hex nuts (G).Then use a hex wrench to tighten all the nuts.
- Page 14 ASSEMBLY INSTRUCTIONS ITEM NO: I222-522-1 Twin Uph HB I222-503-1 Twin Low Profile FB I222-517-1 Twin Rails w/ Decking STEP 5: Put the decking over the slats, secure decking to the slats with wood screws (J) through the pre-drilled holes in the decking as shown below.
- Page 15 ASSEMBLY INSTRUCTIONS ITEM NO: I222-525-1 Full Uph HB I222-507-1 Full Low Profile FB I222-514-1 Full Rails w/ Decking Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment.
- Page 16 ASSEMBLY INSTRUCTIONS ITEM NO: I222-525-1 Full Uph HB I222-507-1 Full Low Profile FB I222-514-1 Full Rails w/ Decking STEP 1: Lay the headboard face down on a soft surface. Attach the left leg and right leg to headboard by using 6 bolts (A), lock washers (B) and flat washers (C).
- Page 17 ASSEMBLY INSTRUCTIONS ITEM NO: I222-525-1 Full Uph HB I222-507-1 Full Low Profile FB I222-514-1 Full Rails w/ Decking STEP 4: Screw the bolts (H) into HB & FB. Make sure the slat bearer is in the UPPER position. Align the bolts with the holes in the end of side rails and attach the side rails to HB & FB using half moon Washer (I) and hex nuts (J).Then use a hex wrench (K) to tighten all the nuts.
- Page 18 ASSEMBLY INSTRUCTIONS ITEM NO: I222-525-1 Full Uph HB I222-507-1 Full Low Profile FB I222-514-1 Full Rails w/ Decking STEP 7: Arrange slats on the slat bearers. Make sure the slats are placed within the notches of each bearer and secured completely with wood screws (L).
- Page 19 ASSEMBLY INSTRUCTIONS ITEM NO: I222-525-1 Full Uph HB I222-507-1 Full Low Profile FB I222-514-1 Full Rails w/ Decking FUNCTIONALITY INSTRUCTION I222-525-1 Single Powered USB Port for Charging on both sides I222-514-1 I222-507-1 Page 5/5 MADE IN VIETNAM...
