LTPH-UM-1088-02, Issue 2
L
F
IST OF
IGURES
1. Backplane Interfaces (rear view) .......................................................... 2
2. ThinMux Chassis in a CO Rack............................................................ 6
3. Installing the Fan Module (FB1)........................................................... 7
4. Wire-Wrap Pin Positions/Common Access Panel (rear view).............. 8
5. Installing Line Terminators................................................................... 9
6. Battery Supply Connector (rear view) ................................................ 10
7. DS3 or STS-1 Shelf Configuration ..................................................... 12
8. Male Cable Connector Into Female Backplane Connector................. 14
L
T
IST OF
ABLES
1. T1/E1 Receive Pin Assignments......................................................... 14
2. T1/E1 Transmit Pin Assignments ....................................................... 16
3. RS-232 Craft Interface Pin Assignments ............................................ 17
4. Ethernet 10/100BASE-T Pin Assignments ......................................... 17
ThinMux Chassis
December 7, 2001
List of Figures
vii
