ADC ACE-COM L1 User Manual page 25

LTPH-UM-1088-02, Issue 2
Table 1. T1/E1 Receive Pin Assignments (Continued)
Pin Number
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
ThinMux Chassis
Description
DSX_RX_RING7
DSX_RX_RING8
DSX_RX_RING9
DSX_RX_RING10
DSX_RX_RING11
DSX_RX_RING12
DSX_RX_RING13
DSX_RX_RING14
DSX_RX_RING15
DSX_RX_RING16
DSX_RX_RING17
DSX_RX_RING18
DSX_RX_RING19
DSX_RX_RING20
DSX_RX_RING21
DSX_RX_RING22
DSX_RX_RING23
DSX_RX_RING24
DSX_RX_RING25
DSX_RX_RING26
DSX_RX_RING27
DSX_RX_RING28
N/C
N/C
N/C
N/C
January 3, 2002
Appendix A - Pin Assignments
Pin Number
39 DSX_RX_TIP7
40 DSX_RX_TIP8
41 DSX_RX_TIP9
42 DSX_RX_TIP10
43 DSX_RX_TIP11
44 DSX_RX_TIP12
45 DSX_RX_TIP13
46 DSX_RX_TIP14
47 DSX_RX_TIP15
48 DSX_RX_TIP16
49 DSX_RX_TIP17
50 DSX_RX_TIP18
51 DSX_RX_TIP19
52 DSX_RX_TIP20
53 DSX_RX_TIP21
54 DSX_RX_TIP22
55 DSX_RX_TIP23
56 DSX_RX_TIP24
57 DSX_RX_TIP25
58 DSX_RX_TIP26
59 DSX_RX_TIP27
60 DSX_RX_TIP28
61
62
63
64 Chassis Ground
Description
N/C
N/C
N/C
15
