Unwrap the enclosed fan module.
2
Align the fan with the slot located on the left side of the chassis and slide
the fan in as shown in
3
Insert the fan module until the connector is firmly seated in the
backplane.
ThinMux Chassis
F
AN
Fan module
ThinMux chassis
Figure 3. Installing the Fan Module (FB1)
Figure
January 3, 2002
M
(FB1)
ODULE
3.
Installation
7
