Valcom PagePro VIP-204B Quick Start Manual page 5

WHITE/BROWN
WHITE/GREEN
WHITE/ORANGE
WHITE/BLUE
Figure 2. VIP-204B Audio/Relay Connections (one per channel)
PORT 1 PORT 2 PORT 3
VIP-204B (REAR VIEW)
RJ-45 PATCH CABLE
RJ45
BROWN
BROWN
WHITE/BROWN BROWN
GREEN
GREEN
WHITE/GREEN
ORANGE
WHITE/ORANGE ORANGE
BLUE
WHITE/BLUE
BLUE
BLUE
VM-186
VALCOM
-24Vdc
POWER SUPPLY
Figure 3. Typical Connection to Valcom Self-amplified Speakers
PORT 1 PORT 2 PORT 3
RJ-45 PATCH CABLE
RJ45
BROWN
BROWN
BROWN
GREEN
GREEN
ORANGE
ORANGE
BLUE
BLUE
BLUE
VM-186
PORT4
AUX +24VDC
IN
WHITE-BLUE PAIR
AUDIO OUTPUT
WHITE-ORANGE/ORANGE PAIR
WHITE-BROWN / BROWN PAIR
WHITE-GREEN PAIR (UNUSED)
N/O RELAY OUTPUT
CAT 3/5/5e/6 CABLE
24VDC AC
- + Ground
5
PORT4
AUX
+24VDC
IN
VIP-204B (REAR VIEW)
AUDIO OUTPUT (TO SPEAKERS)
N/O RELAY OUTPUT
WHITE-BLUE
BLUE-WHITE
SELF-AMPLIFIED
TIP
RING
GND
-24Vdc
VALCOM
SPEAKER
947554
