- Page 1 INSTALLATION MANUAL MYALARM2 Rev4 Remote control GSM/GPRS advanced device SENECA s.r.l. Via Austria, 26 – 35127 – PADOVA – ITALY Tel. +39.049.8705355 - 8705359 - Fax +39.049.8706287 For manuals in other languages and the configuration software, visit www.seneca.it/myalarm2 MI00567-0-EN...
-
Page 2: Module Layout
WARNING: The full content of this manual must be read before any operation. The module must only be used by qualified electricians. Specific documentation is available at www.seneca.it/myalarm2 The module must be repaired and damaged parts replaced by the Manufacturer. -
Page 3: Technical Specifications
Quad band (850 / 900 / 1800 / 1900 MHz) STANDARDS ETSI EN 301 489-7 - EN301 511 - EN301 489-1 - IEC / EN 60950 ENVIRONMENTAL CONDITIONS Seneca recommends use at 0 to 45 ° C for correct operation. Temperature With the power supply present: -20 .. +55°C With use of the battery (when discharged): -20 .. -
Page 4: Inserting The Sim Card And Sd Card
INITIAL POWERING ON OF THE DEVICE MyAlarm2 is supplied in “shipping mode”. This mode prevents any unnecessary discharge of the battery during transport as well as any accidental switch-ons. To exit this mode, simply power the device via the cable supplied. -
Page 5: Safety Information
ASSEMBLY RULES FOR VERSION WITH GPS (OPTIONAL) For optimal reception of the GPS signal given by the satellites, MyAlarm2 should be positioned in an area not covered by metal structures. If this is not possible or if the satellite reception is no good, an optional external antenna with 3m cable (code A-GPS) is available. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS INSERTION AND EXTRACTION FROM TERMINALS WITH A PUSH-WIRE CONNECTION Insertion of a rigid cable Insertion of a thin cable Extraction of a rigid cable A: press with a A: press with a screwdriver screwdriver Press down Recommended B: insert B: extract flaying: 8-9 mm the cable... - Page 7 DISPLAY FUNCTIONS AND USE The main MyAlarm2 display page provides the following information: A - GSM signal level B - output 1 status C - output 2 status D - digital input 1 status E - digital input 2 status...
-
Page 8: Contact Information
Product information sales@seneca.it This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised. The content of this document corresponds to the described products and technologies. Stated data may be modified or supplemented for technical and/or sales purposes.
