Seneca MyALARM2 User Manual

Advanced datalogger gsm/gprs with built-in i/o and remote control functions
Hide thumbs Also See for MyALARM2:
Table of Contents

Advertisement

Quick Links

USER MANUAL

MyALARM2
Advanced Datalogger GSM/GPRS
With built-in I/O and remote control functions
This document is property of SENECA srl. Duplication and reproduction of its are forbidden (though partial), if not
authorized. Contents of present documentation refers to products and technologies described in it. Though we strive for
reach perfection continually, all technical data contained in this document may be modified or added due to technical and
commercial needs; it's impossible eliminate mismatches and discordances completely. Contents of present
documentation is anyhow subjected to periodical revision. If you have any questions don't hesitate to contact our
structure or to write us to e-mail addresses as above mentioned.
MI003441
Page 1
