INSTALLATION MANUAL
MyALARM2-
3
Advanced GSM/GPRS device for telecontrol
EN
EN
SENECA s.r.l.
Headquarters: Via Austria, 26 – 35127 – PADOVA – ITALY
Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287
Manuals and configuration software are available at website: www.seneca.it
This document is property of SENECA Srl. Duplication and reproduction are forbidden, if not authorized.
Contents of the present documentation refers to products and technologies described in it.
This informations may be modified or integrated for technical and / or commercial requirements.
MI004930-E
THE ORIGINAL VERSION IS IN ITALIAN LANGUAGE
ENGLISH - 1/8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seneca MyALARM2-3
Summary of Contents for Seneca MyALARM2-3
- Page 1 Phone +39.049.8705355 - 8705359 - Fax +39.049.8706287 Manuals and configuration software are available at website: www.seneca.it This document is property of SENECA Srl. Duplication and reproduction are forbidden, if not authorized. Contents of the present documentation refers to products and technologies described in it.
-
Page 2: Module Layout
MODULE LAYOUT 80 mm 8 mm 32 mm Weight 150 g. Case Polycarbonate / ABS material. LED SIGNALLING ON FRONT PANEL Status LED’s meaning nnnnoooonnnnoooo Slow Blinking 0.8s ON n 0.8s OFF o MyAlarm2- is Connected to GSM Network (Yellow) nononononononono Fast Blinking 0.1s ON n 0.1s OFF o... -
Page 3: Motherboard Specifications
Lithium ions 3.7 V - 1000 mAh, rechargeable not replaceable. Dimensions: 53 mm x 34 mm x 6 mm ENVIRONMENTAL CONDITIONS Seneca recommends use from 0 to 45 ° C for proper operation. Temperature With external power supply: -20 – +55°C. -
Page 4: Installation Rules
TECHNICAL SPECIFICATIONS STANDARDS ETSI EN 301 489-7 EN301 511 EN301 489-1 IEC / EN 60950 CONNECTIONS Push-wire terminals, pitch 3,5 mm, Micro USB socket SMA connector for GSM Antenna. INCLUDED ACCESSORIES 12 V C power supply (with crimp terminals), DIN rail IEC EN 60715 support, Nr. -
Page 5: Preliminary Warnings
The module may only be used by qualified and skilled technicians in the field of electric installation. Specific documentation is available for download at website: www.seneca.it. Only the Manufacturer is authorized to repair the module or to replace damaged parts. -
Page 6: Safety Informations
SAFETY INFORMATIONS The MyALARM2- has 15 push-wire terminals inside of the case For access to the terminals: unscrew the screw in the center of the black top cover placed in the lower part of the case, lift and remove the cover. In the figure on side, the top cover has been removed. - Page 7 SIM-CARD AND SD-CARD INSERTION SIM CARD INSERTION MyALARM2- has a SIM slot, placed in the right side of the case. card Before inserting the SIM card into the slot, make sure that the SIM card’s contacts are facing to the left (as shown in the figure). card MICRO SD CARD INSERTION MyALARM...
-
Page 8: Order Codes
MY2 B S - 0 R - 0 - M - B G TYPE RELAYS COLOR B=Blue B=Base 0=Absent G=Grey S=Security R=Present EXAMPLE: «MY2B-R-0-M-G» MyALARM2- Base with two relay outputs, push-wire terminals and grey case. ORDER CODES Code Description CONTACTS Technical support support@seneca.it Product Informations sales@seneca.it MI004930-E ENGLISH - 8/8...
