- Page 1 VUHDIPE-8 VUHDIPE-16 NETWORK VIDEO RECORDER QUICK START GUIDE Technical Documents NETWORK VIDEO RECORDER QUICK START GUIDE...
-
Page 2: What's In The Box
1. WHAT’S IN THE BOX? Packaging Contents Network Video Recorder x1 Quick Start Guide x1 DC48V Power Adapter x1 (VUHDIPE-16 only) AC Power Cord x1 6-Pin Terminal Block x2 USB Mouse x1 (x2 for VUHDIPE-16) Remote Control x1 Cable Clamp x 1 Cable Clamp Screws x2 Remote Control Batteries x2 8CH PoE Hub x1... - Page 3 CA M1 CA M3 CA M5 CA M7 IP Camera WA N( UP LIN CA M2 CA M4 CA M6 CA M8 LA N (D OW AU DI NL IN O IN HD MO NI TO VG A AL AR M OU INTERNET RS -48...
-
Page 4: Getting Started
3. GETTING STARTED Setup Wizard The Setup Wizard will help configure important system settings when the device is first booted up. Create a new, complex password to properly secure the device. This step is highly recommended for device security. This step is highly recommended for device security, however please be sure to remember the password in order to prevent becoming locked out of the NVR. - Page 5 1. The log-in screen will appear after the system boots up. 2. Select a user ID and enter the corresponding password. The default user ID is “ADMIN” and the default password is “1234”. 3. Click <OK>. For security purposes, please change the password to a more complex, secure password after logging in the first time.
- Page 6 4. AUTOMATIC RECORDING PROFILES 1. Press [MENU] on the remote control and use the direction buttons to select <RECORD SETUP>, then press [ENTER]. Alternatively, select <MENU> - <RECORD SETUP> from the status bar. 2. Set <RECORD SETUP MODE> to <AUTO CONFIGURATION> and select a desired recording profile: - CONTINUOUS RECORD: Always record video.
-
Page 7: Searching Recorded Video
5. SEARCHING RECORDED VIDEO 1. From the <SEARCH> menu, select <TIME SEARCH>. 2. Specify the date and time from the calendar. 3. Identify the type of recording data by the colour in the bar. - Light Green: Pre-Recording - Green: Continuous Recording - Blue: Motion Recording - Red: Alarm Recording - Yellow: Panic Recording... - Page 8 To use video analytics, you must first ensure the license is recognised by the recorder. To do this, first connect the camera to the Concept Pro recorder over the network or through its PoE ports. Then, through the recorder user interface, navigate to <MENU> - <SYSTEM SETUP>...
- Page 9 A corresponding DLVA Search menu is also available to quickly search video for desired objects. Some Concept Pro cameras can also be used with select Concept Pro recorders to provide highly accurate deep learning video analytics, including human, animal, and/or vehicle intrusion detection and illegal parking detection.
- Page 10 To configure VBR+ from the Concept Pro NVR, navigate to <MENU> - <SYSTEM SETUP> - <CAMERA> - <CAMERA SETUP> - <STREAM SETUP>. Select the desired channel and bit rate control scheme, then press <APPLY>.
- Page 11 8. Archiving Recorded Video Click <MENU> and select <ARCHIVING>. This can be selected from either the Live or Playback screens. From <ARCHIVING>, select <NEW ARCHIVING>. Select a date for the archive from the calendar to the left. Any dates containing recorded data will be coloured boxes.FIRST: Automatically select the first date with recorded video.LAST: Automatically select the last date with recorded video.Check the <START>...
- Page 12 9. ACCESSING FROM THE WEB 1. Note the device IP address and HTTP port number from the Network Status menu. From a PC connected to the network, open Internet Explorer and enter the device address in the address bar. Internet Explorer is recommended for the best web access experience, however other web browsers such as Firefox and Chrome are supported with reduced functionality.
-
Page 13: App Setup
Concept Pro Viewer SEQURINET REGISTER / LOGIN You will need to register your details with Sequrinet to set up any recording devices. You can login or set up your Securinet account with the Concept Pro App. Already registered? Complete the fields Click OK. -
Page 14: Nvr Setup
NVR SETUP Ensure that Sequrinet is enabled by navigating to Menu, System Setup, Network, DDNS. On the bottom, check that Sequrinet Cloud Service is Enabled, then select Apply. Select Menu at the bottom left hand corner of the screen and select Sequrinet at the top of the list. A QR code will appear. - Page 15 NETWORK VIDEO RECORDER QUICK START GUIDE...
- Page 16 MV68AU01_Rev01 Design and specification are subject to change without notice.
