- Page 1 PRODUCT MANA Product code MANA DT SMA MANA DT SMA DOUBLE TECHNOLOGY AND RS485 OUTPUT PERIMETER BARRIER INSTALLATION AND MOUNTING MANUAL VERSION 3.1...
-
Page 2: Table Of Contents
18.Basic functions –MW section .. …………………………………………………………………………….……..……. ……… 30 18.1 Settings and basic programming - MANA RX board 19.Basic functions –IR section… ... …………………………………………………………………………………………. ……… 31 19.1 Basic settings and programming - MES9012 board 20.Intervention time adjustment…………………………………………………………..………………………………….…..32 MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 3 26.1 Serial port connection for each barrier 27.Appendix G: single barrier with optical synchronism …………………………………………………………… …… ..43 28.Technical specifications …………………..……………………………………………. …………………………………….…… ..44 29.FAQ ..............................45 30.Product disposal ………………………………………………………………………………………………. ……………….…….… .47 MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 4: Introduction
The system has been designed to detect intrusions and activate the alarm; it is not a device that prevents intrusion.Politec is not responsible for damage, injury or loss caused by accidents, theft, force majeure (including momentary lightning-induced overcurrent), abuse, improper or incorrect use, faulty installation or inadequate maintenance. -
Page 5: General Warnings
• Manufacturer's liability:Politec assumes no liability for failures resulting from incorrect installation; lack of maintenance, incorrect assembly or use. • Politec is also not liable for incorrect or incomplete operation of the product or failure to detect intrusion. • Warranty (summary of conditions):Politec guarantees its products for a period of 2 years from the production date.The warranty is applied to those purchasing directly from Politec;... -
Page 6: List Of Main Components
MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 7: Preparation For Installation
• Check that the surface chosen for the installation of the product is solid so as to ensure stable fixing and that it is adequately protected from possible impacts or atmospheric agents. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 8: Assembly And Positioning Of The Cable Pit
Insert the third side in the same way and Widen the two opposite walls of the cable pit so you tighten the screws can insert the last side Insert and fully tighten the missing screws of the two sides MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 9: Positioning Of The Cable Pit
Mana base is raised to achieve the appropriate vertical alignment. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 10: Column Transformer Assembly
N.B. it is advisable to position the transformer in the space intentionally left, so as to be able to easily screw the fixing screws to the column and have sufficient space for positioning the battery. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 11: Assembly On The Base Of The Cable Pit
If the column is set up with the kit for pole or wall fixing, use the cover under the base for the passage of the cables, following the instructions as above and finally fix it in the same way to the base.(see photo above) MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 12: Column Power Supply Connection
Power supply blue Blue - Brown brown Fuse (delayed) Red - Red black black Black - Black FUSE A: 5A-24Vac FUSE B: 0.8A-13.8Vac Make all electrical connections as shown on the diagram. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 13: Evaluations Before Installation
When a body approaches longitudinally until it crosses the lobe, the signal received by the receiving section is perturbed until an alarm is generated. Attenuation can be large or small depending on the mass and type of material that crosses the emission zone. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 14: Introduction To Barriers - Ir Section
TX and RX, thus ensuring a good amount of signal constantly, even in case of particular climatic conditions. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 15: Barrier Positioning
2 TX or 2 RX at each intersection, with different frequencies out of the 4 available. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 16: Precautions Before Installation - Ir Section
DO NOT place the barriers close to walls: the signal quality may decrease DO NOT place barriers close to roads: vehicle lights directed towards the RX could create disturbances DO NOT place barriers near automatic gates: photocell signals can create interference MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 17: Precautions Before Installation - Double Technology
IR section, or if you want to manage this function, as a signal, typically for the duration of the weather condition, it is necessary to create the opening of the alarm input, of the IR section on the alarm control panel. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 18: Wiring
N.B.The shielding of this cable must be connected to the negative of 13.8 Vdc of all the columns. 230Vac mains cable Sync cable + various signals (power supply) MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 19: Connections To The Mana Al214 Power Supply Board
3 – 4 Power connectors Infrared section power supply (terminal board of 24 Vac input 5 – 6 Cable coming out of the transformer 24 Vac output 7 – 8 Heater power supply MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 20 High impedance output if the voltage supplied by the transformer on the "24Vin" terminals is <18Vac. 120Ω output if the voltage supplied by the transformer on the "24Vin" terminals is > 18Vac. Not connected MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 21: Connections To The Mes9C Terminal Board
- SYNCHRONISM Output negative synchronism (TX synchronism (TX => RX) (- S.IN) (- S.OUT) => RX) Not used AME COAXIAL AME COAXIAL Not used Not used TRESSE COAXIAL TRESSE COAXIAL Not used MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 22: Wired Synchronism
2x0.22mm² cross section, connections up to 500 m can be made. In the event of joints, the braid and shield connections must also be restored. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 23: Barrier Alignment - Mw Section
1.Activate the cavities by setting the DIP on the back of each dish to OFF.This DIP must always remain in this position. 2.Select the same synchronisation channel, on the 4 DIP unit on the MW TX board and on the MW RX board MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 24 6.5-7.3 N.B.:To check the optimal orientation, press the dish with a finger pointing it towards a specific direction (right or left) checking if there is an increase in the signal level. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 25: Barrier Alignment - Ir Section
It is sufficient to apply the filter only on the TX, there is no need to repeat the operation also on the RX. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 26: Alignment
The maximum alignment condition will be reached when the high intensity LEDs are on steady and the buzzer will emit a continuous sound, for this reason, it may be necessary to act with small movements also on the RX optic. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 27 TRANSMITTER optic with your hand: if the RECEIVER continues to give a continuous beep, it means that it sees another infrared source that must be turned off and eliminated. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 28: Parallel Beam Calibration
WARNING: too close a distance RX 4 TX 4 between the TX and RX columns does not allow calibration with the crossing function. RX 3 TX 3 RX 2 TX 2 RX 1 TX 1 MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 29: Optical Synchronism
N.B.:Optical synchronism requires greater attention during the installation phases, in particular, that the receiving column is not affected by other sources of IR light, such as other barriers of the same system, gate photocells etc. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 30: Basic Functions -Mw Section
Low: risk of non-detection • DLY:Turn clockwise to decrease system sensitivity.High: requires a large mass to generate alarm Low: requires a small mass to generate alarm MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 31: Basic Functions -Ir Section
12 DIP UNIT FOR CONFIGURATION • AND RANDOM: DIP 9 • AND ON BEAM 1-2: DIP 8 • BEAM 1 DEACTIVATION: DIP 7 • BEAM 1-2 DEACTIVATION: DIP 6 • DISQUALIFICATION FUNCTION: DIP 5 MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 32: Intervention Time Adjustment
(e.g. animal crossing). By adjusting the potentiometer clockwise, the intervention time decreases down to 50ms.In this condition, the alarm of a person crossing the barrier running at maximum speed is guaranteed. ALARM MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 33: Appendix A:dt3 Sensor
ADEBUS concentrator, it will be much easier to manage all the information of the entire system and each component, including the DT3 sensor. More details are on page 42 or in the ADEBUS & ADEBUS EXPLORER manual. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 34: Appendix B:mw Details
Active Walk Test (buzzer) It shows automatic gain value SENS It displays sensitivity value (SENS) It displays 5V power supply It displays 9V power supply It displays 13.8V power supply VOLT It enables DISPLAY MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 35: Appendix C: Motherboard Setting And Programming (Mes9012)
SYNC Yellow TRIMMER Intervention time adjustment DISQ1 12 DIP SWITCH UNIT Function selector 4 DIP SWITCH UNIT TX Function selector 4 DIP SWITCH UNIT RX Function selector TAMPER Column tamper connection MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 36: Led Signal Operation
Normally off, when on the heating is active. SYNC LED The SYNC LED indicates by continuous flashing the correct LED confirming the operation of the wiring and functioning of the synchronisms between synchronism system transmitters and receivers. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 37: Features And Settings
In the ON position it closes the RS485 communication.To finish it is RS485 necessary to put ON only on the board of the furthest column of the entire line. LEDS In the ON position it activates the LEDs. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 38 If the disqualification function has been activated on DIP SWITCH 12 via DIP 5 in ON, in some cases and particular geographical areas, it may be useful to increase the sensitivity of the disqualification by setting jumper J7 to ON. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 39: Transmitter Optic
The power supply of the heaters is set by default to 24V; this voltage is supplied directly by the power supply present in the MANA series columns. N.B.:The settings relating to the addressing of the optics are already set by default. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 40: Receiver Optic
N.B.:The settings relating to the addressing of the optics are already set by default. N.B.:The barrier can result in an alarm even if the WEAK SIGNAL LED is off.The cause may be the lack of synchronism or a misaligned transmitter. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 41: Appendix E: Configuration With 3/2 Receivers
Set to ON DIP 6 of the 12 unit on the MES9012 motherboard Receivers side to exclude RX1 + RX2 2 3 4 5 6 7 8 9 10 11 12 MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 42: Appendix F: Serial Connection To The Adebus Concentrator
Connect microwave alarm signal, DT3, or any external sensor to terminals 14, 15 or 16, by balancing at 30k.For details, refer to the Adebus manual Black Adebus Braid Board Green White MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.2.5.4... -
Page 43: Appendix G: Single Barrier With Optical Synchronism
TX 1 TX 1 RX 1 RX 1 Barrier 1 Barrier 2 TX channel TX channel 2 3 4 2 3 4 RX channel RX channel 2 3 4 2 3 4 MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 44: Technical Specifications
300 mm * PROFILE DIMENSIONS WxDxH *Upon request, it is supplied with a special base and with accessories for pole or wall fixing WARRANTY 2 years MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... -
Page 45: Faq
(see chap. 12), otherwise the alarm will not be constant, then recheck the connections making sure that the terminal board is well inserted. Use the shielded cable for synchronism by connecting the braiding to the earth. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 46 For more precise alignment, position one side of the column cover in front of the lenses in order to have two surfaces interposed between TX and RX to double the attenuation of the beam. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
-
Page 47: Product Disposal
Warning!- Local regulations can impose heavy penalties for incorrect disposal of these products. MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1... - Page 48 For technical support, contact your security systems distributor MANA DT SMA POLITEC | INSTALLATION MANUAL - VER.3.1...
