Device description

2.3 Pin assignment

2.3 Pin assignment
P2 socket
Type: JST SM02B-SRSS-TB
Pin
1
2
P1 connector
Internal interface for production and manufacturing test, do not use.
2.4

LED status indicator

The operating states of the transponder are indicated by the LEDs. The states can be off ,
on
LED
10
Description / Function
3.3 V supply voltage
GND
and flashing .
Meaning
Flashes green every three seconds when the transponder is active
Is off when the transponder is inactive
Green and red LEDs light up for 1 second on system start
Flashes green every 0.1 seconds after a watchdog reset
SIMATIC RTLS PCB OEM AC
Operating Instructions, 03/2020, C79000-G8976-C519-03
