WK120
MANUALE TECNICO ELETTRONICA
TECHNICAL MANUAL ELECTRONICS
MANUEL TECHNIQUE ELECTRONICS
MANUAL TÉCNICO ELECTRONICS
LBT0428 Electronics
WK120
Page 1 | 26
Rev.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WK120 and is the answer not in the manual?

Questions and answers

Related Manuals for Aprimatic WK120

Summary of Contents for Aprimatic WK120

  • Page 1 WK120 MANUALE TECNICO ELETTRONICA TECHNICAL MANUAL ELECTRONICS MANUEL TECHNIQUE ELECTRONICS MANUAL TÉCNICO ELECTRONICS LBT0428 Electronics WK120 Page 1 | 26 Rev.02...

  • Page 2: Table Of Contents

    3.9 Legend and check of the LEDs 4.0 Switching on 4.1 SELF-learning procedure 4.2 Operating mode 5.0 Edit parameters 6.0 Obstacle detection 7.0 SAFETY devices 8.0 Settings with special CODES 9.0 Errors 10.0 Displays: 11.0 Maintenance Schedule LBT0428 Electronics WK120 Page 2 | 26 Rev.02...

  • Page 3: Purpose Of This Manual

    1.1 ABOUT THIS MANUAL Information these instructions concern only the electrical installation and the use of the system WK120 for the control of automatic doors with sliding wings. For mechanical installation please see the special instructions supplied. During assembly and installation operations of the automatic device and test operations of the door, hazardous situations might arise if the safety warnings contained in the instructions are not followed.
  • Page 4 At the end of the job the installer must check the installation and the correct operation of the automation device. WK120 complies with EN60335 and EN16005, if safety devices are not monitored and properly connected to test inputs, the installer must set the automation device in such a way that parameters correspond to those indicated in the table below.

  • Page 5: Intended Use And Field Of Application

    You should note the operating restrictions specified in the installation manual supplied with the operator. Do NOT tamper with or modify the product in any way. The product must only be installed using APRIMATIC material. Aprimatic S.r.l. declines all liability for damages caused by failure to follow these instructions.
  • Page 6 Opening Cycles Test 1,000,000 Cycles Certification Compliance EN61000, EN60335 compliance EN16005 ELEMENTS OF THE BASIC SYSTEM See fig.1. • Control equipment CONTROL WK120 • POWER SUPPLY unit • 24VDC gear motor • ACCESSORY DEVICES For available ACCESSORY devices see fig.2.

  • Page 7: System Preparation

    4 ) internal emergency manual release 6) passage detection radar 7) selector / programmer (5x0.22 mm cable - MAX length 15 m) 8) Electric lock 9) STOP with mechanical emergency opening device ACCESSORY ARRANGEMENT fig.2 LBT0428 Electronics WK120 Page 7 | 26 Rev.02...
  • Page 8 INTERNAL RADAR EXTERNAL RADAR 24VDC MOTOR BLACK COMMAND INPUTS FIRST INPUT START TRANSFORMER 12 V (2-7Ah) LEAD BATTERY 12 V (2-7Ah) LEAD BATTERY PRIMARY NETWORK SEC. FUSE TRANSF. BATTERY FUSE BLAC WHITE GREEN RESET push-button OPENING SLOWDOWN PHOTOCELLS CAPACITIVE FUNCTION SELECTOR INTERLOCKED DOOR CONNECTION SLAVE BOARD If not using...
  • Page 9 CN6 terminal block NOTE Safety devices must be connected in SERIES Closing safety device CN6 terminal block connections 1- Start / First Input (N.O.) 2- Stop (N.C.) 3- Photocell Safety Device (N.C.) 4- Internal Radar (N.O.) 5- External Radar (N.O.) 6- Slow Opening Radar Safety Device (N.C) EXTERNAL RADAR INTERNAL RADAR...
  • Page 10 CN8 terminal block CN8 terminal block connections 10- Test 2 (see details in chap.8.0) NOTE To connect and set «TEST» inputs for compliance 11- Test 1 (see details in chap.8.0) with EN16005, see the dedicated diagram in chapter 3.7 12- Close (N.O.) and 3.8 13- Open (N.O) 14- Common...
  • Page 11 CN7 terminal block Use of the terminal block for connecting interlocked doors MASTER door SLAVE door CN7terminal block connections CN7terminal block connections 17- Int. contact I (N.O) _________________ 17- Int. contact I (N.O) _________ 18- Int. contact I (N.O) _________________ 18- Int.
  • Page 12 CN5 terminal block Selector connection Qty.1 PRO Selector a Qty. 1 BASIC selector can be connected in parallel to CN5 terminal block. Both «BASIC» and «PRO» selectors can coexist RESET A=OPT (not used) H=AS + B=L.D. (not used) G=AS – push- C=R.H.
  • Page 13 M= GREEN Signal A M= WHITE Signal A L= Signal B L= YELLOW Signal B L= GREEN Signal B I= Power supply Positive + I= RED Power supply Positive + I= RED Power supply Positive + LBT0428 Electronics WK120 Page 13 | 26...

  • Page 14: Cn6 Terminal Block Connection

    Connecting safety devices with «surveillance» in compliance with Stop Closing safety Opening safety EN 16005 device device CN6terminal block connections N.C. 2- Stop (N.C.) N.C. 3- Photocell Safety Device (N.C.) 4- Internal Radar (N.O.) 5- External Radar N.C. 6- Slow Opening Radar Safety Device (N.O.) (N.C) Common...
  • Page 15 Connecting safety devices with «surveillance» in compliance with Test 2 Closing safety EN 16005 device Opening safety Stop Closing safety device device CN6terminal block connections N.C. 1- Start / First Input (N.O.) 2- Stop (N.C.) N.C. 3- Photocell Safety Device (N.C.) 4- Internal Radar (N.O.) 5- External Radar...
  • Page 16 RS 485 Normally FLASHING DL 1 Communicatio GREEN RESET HW DL 9 YELLOW DL 8 GREEN Normally ON START Input LED Normally OFF Input LED Master/ Slave DL 12 DL 3 GREEN STOP Input LED Normally ON Normally OFF Input LED DL 11 Photocell 1 Input LED Normally ON...

  • Page 17: Switching On

    Should you note, over time, that the slowdown spaces are no longer optimal, it is recommended to carry out a new saving procedure. At this point the door is ready to be operated. LBT0428 Electronics WK120 Page 17 | 26...

  • Page 18: Operating Mode

    4.2 Operating mode Operating modes can be selected and viewed only from selectors, WK120 display is normally off. bdIr - Bidirectional FrEE - Free NOTE The door can be operated also without any rInt - Output connected selector, rESt - Input (*)
  • Page 19 The STOP command immediately stops the door and, as long as it stays active, any other command is ignored. Exception made for the "OPEN" operation. PHOTO command (N.C.) The PHOTO command reopens the door if in closing phase and, as long as it stays active, does not allow its re-closing. LBT0428 Electronics WK120 Page 19 | 26...
  • Page 20 AUTS will be displayed. The next two door operations are required to save the slowdown spaces again if the door conditions (frictions, etc.) have changed from the previous saving LBT0428 Electronics WK120 Page 20 | 26...

  • Page 21: Edit Parameters

    3=It opens only if not in lock mode 4=It closes but does not lock Motion direction () (Facing door from the 0=It opens to the left 1=It opens to the right outside) Voltage with door closed (windproof) Absolute value LBT0428 Electronics WK120 Page 21 | 26...
  • Page 22 () After editing the "Motion direction" parameter the following first opening and closing operations will be performed at reduced speed. After editing parameters from 1 to 9, the message AUTS is displayed. The next two door operations are required to learn the door ideal conditions again. LBT0428 Electronics WK120 Page 22 | 26...

  • Page 23: Obstacle Detection

    2222:Selection A 2 Type K EXTRA EU motor code 2468:Start of cyclic test mode. code 1234:Enabling of special displays. (see chapter 10.0) code 3223:Reset to DEFAULT values (only points from 1 to 9 chap.5.0) LBT0428 Electronics WK120 Page 23 | 26...

  • Page 24: Errors

    STOP command monitored device test 1 failed E 18 STOP command monitored device test 2 failed E 19 Power electronics temperature too high. The equipment will attempt to restart operation only after being reset or switched off. LBT0428 Electronics WK120 Page 24 | 26...

  • Page 25: Displays

    This information is displayed each time the board parameters are edited and the next two door operations are required to check all parameters again. After 60 seconds of inactivity the display will show the operating mode again. LBT0428 Electronics WK120 Page 25 | 26...
  • Page 26 IN COMPLIANCE WITH MACHINERY DIRECTIVE 2006/42/EC AND WITH EUROPEAN STANDARD EN 16005. This maintenance record includes the technical references and the records of installation, maintenance, repair and editing operations and must be made available for any inspection by authorised organisations. LBT0428 Electronics WK120 Page 26 | 26...
