■ ZERO & SPAN ADJUSTMENTS
After the transmitter is installed and operational, fine zero
and span tuning can be performed as explained below. Both
zero and span are adjustable within ±15%.
1) Run Mode: Confirm that the green LED is blinking
(model M3LU2-x/A) or the green LED turns on (model
M3LU2-x/B).
2) Fine Zero Adjustment Mode: Hold down MODE button
for 1 or 2 seconds until the LD1 red LED is ON and the
LD2 green LED is blinking.
Use UP (increase) and DOWN (decrease) buttons to
adjust the output to 0%.
■ INPUT TYPE, RANGE & ACCURACY
INPUT TYPE MIN. SPAN
DC Current 1 mA
DC Millivolt 4 mV
DC Voltage 1 V
Potentiometer 2%
Resistance 10 Ω
Thermocouple
MIN.
SPAN
(PR) 20
K (CA) 20
E (CRC) 20
J (IC) 20
T (CC) 20
B (RH) 20
R 20
S 20
C (WRe 5-26) 20
N 20
U 20
L 20
P (Platinel II) 20
RTD
MIN. SPAN
Pt 100 (JIS '97, IEC) 20
Pt 200 20
Pt 300 20
Pt 400 20
Pt 500 20
Pt 1000 20
Pt 50 Ω (JIS '81) 20
JPt 100 (JIS '89) 20
Ni 100 20
Ni 120 20
Ni 508.4 Ω 20
Ni-Fe 604 20
Cu 10 @ 25°C 20
*1. DC, RTD, Resistance, Potentiometer input: Or ±0.1% of span, whichever is greater.
Thermocouple input: [Accuracy + Cold Junction Compensation Error 1.0°C (1.80.9°F)] or ±0.1% of span, whichever is greater.
For current output, overall accuracy degrades another 0.1% with spans ≤ 2 mA.
MAXIMUM RANGE
0 to 20 mA
-1000 to +1000 mV
-10 to +10 V
total resistance 80 to 4000 Ω
0 to 4000 Ω
°C
MAXIMUM CONFORMANCE
RANGE RANGE
0 to 1760 0 to 1760
-270 to +1370 -150 to +1370
-270 to +1000 -170 to +1000
-210 to +1200 -180 to +1200
-270 to +400 -170 to +400
100 to 1820 400 to 1760
-50 to +1760 200 to 1760
-50 to +1760 0 to 1760
0 to 2315 0 to 2315
-270 to +1300 -130 to +1300
-200 to +600 -200 to +600
-200 to +900 -200 to +900
0 to 1395 0 to 1395
°C
MAXIMUM RANGE
-200 to +850
-200 to +850
-200 to +850
-200 to +850
-200 to +850
-200 to +850
-200 to +649
-200 to +510
-80 to +260
-80 to +260
-50 to +200
-200 to +200
-50 to +250
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
3) Fine Span Adjustment Mode: Press MODE button and
confirm that the LD3 green LED instead of LD2 is
blinking.
Use UP (increase) and DOWN (decrease) buttons to
adjust the output to 100%.
4) Run Mode: When fine adjustment is completed, press
MODE button once and confirm that: the LD1 green LED
is blinking in case of M3LU2-x/A; and the LD1 green
LED is ON in case of M3LU2-x/B.
Note 1: Calibration steps can be skipped when not needed by
repeating pushing MODE buttons.
Note 2: There is no stated order of setting 0% and 100% levels
or no limitation of entering values for multiple times
within one step of Calibration Mode. Signal level is
stored each time the respective UP or DOWN button is
pressed.
ACCURACY*
±20 µA
±10 µV at F.S. input ≤ 50 mV
±40 µV at F.S. input ≤ 200 mV
±60 µV at F.S. input ≤ 500 mV
±80 µV at F.S. input > 500 mV
±0.1%
±0.1 Ω
±0.1 Ω
* MIN. MAXIMUM
ACCURACY 1
SPAN RANGE
±1.00 36 32 to 3200
±0.25 36 -454 to +2498
±0.20 36 -454 to +1832
±0.25 36 -346 to +2192
±0.25 36 -454 to +752
±0.75 36 212 to 3308
±0.50 36 -58 to +3200
±0.50 36 -58 to +3200
±0.25 36 32 to 4199
±0.30 36 -454 to +2372
±0.20 36 -328 to +1112
±0.25 36 -328 to +1652
±0.25 36 32 to 2543
ACCURACY * MIN. SPAN
1
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.15 36
±0.50 36
M3LU2
Table 12
1
°F
CONFORMANCE
ACCURACY
RANGE
32 to 3200 ±1.80
-238 to +2498 ±0.45
-274 to +1832 ±0.36
-292 to +2192 ±0.45
-274 to +752 ±0.45
752 to 3200 ±1.35
392 to 3200 ±0.90
32 to 3200 ±0.90
32 to 4199 ±0.45
-202 to +2372 ±0.54
-328 to +1112 ±0.36
-328 to +1652 ±0.45
32 to 2543 ±0.45
°F
MAXIMUM RANGE ACCURACY
-328 to +1562 ±0.27
-328 to +1562 ±0.27
-328 to +1562 ±0.27
-328 to +1562 ±0.27
-328 to +1562 ±0.27
-328 to +1562 ±0.27
-328 to +1200 ±0.27
-328 to +950 ±0.27
-112 to +500 ±0.27
-112 to +500 ±0.27
-58 to +392 ±0.27
-328 to +392 ±0.27
-58 to +482 ±0.90
EM-2653-A Rev.2 P. 8 / 9
*
