To Use The Pocket Generator™ To Boost Vehicle' s
Low Battery System
WARNING:
position, before using unit as Battery Booster. Failure to do so may cause damage
to the inverter, and will void manufacturer's warranty. Note: The Pocket Generator™
will not fully charge a completely dead battery, but it can be used to boost a
vehicle's weak battery system, or to provide auxiliary power for the onboard
electrical systems and selected memory settings for electronics (A/C, seats, radio,
etc.). Using the adapter cord with two cigarette lighter-type plugs, insert one end
of the cord into the vehicle's cigarette lighter receptacle, and the other end into the
corresponding receptacle on the Pocket Generator™ . When power assist is
completed, disconnect the adapter cord's plugs from the vehicle's cigarette lighter
receptacle and the Pocket Generator™ .
To Use The Pocket Generator™ As A Memory Saver For
Onboard Systems And Pre-Sets
WARNING: Be sure that the ON/OFF switch on the inverter is in the OFF
position, before using unit as Memory Saver. Failure to do so may cause damage
to the inverter, and will void manufacturer's warranty. When the vehicle's battery
system is to be disconnected for repair or maintenance, the Pocket Generator™
will provide auxiliary power to maintain the selected memory settings and other
onboard electrical systems, until power is restored. BEFORE the vehicle's battery
system is disconnected: using the adapter cord with two cigarette lighter-type plugs,
insert one end of the cord into the vehicle's cigarette lighter receptacle, and the
other end into the corresponding receptacle on the Pocket Generator™ . Onboard
power will be maintained. AFTER the vehicle's battery system is reconnected,
disconnect the adapter cord's plugs from the vehicle's cigarette lighter receptacle
and the Pocket Generator™ .

Fuse Replacement

Main Fuse
1. Open the top flap of the Pocket Generator™ ,
carrying case. The main fuse holder's
screw-on/off cap will immediately be visible.
2. Unscrew the fuse holder cap and remove the fuse.
3. Replace with a new 10-amp fuse, if needed.
4. Screw fuse holder cap back on.
5. Close case securely.
Be sure that the ON/OFF switch on the inverter is in the OFF
1
Fig. B.
6
2
3
4
