Jump-Start System
IF YOU SHOULD EXPERIENCE A PROBLEM WITH YOUR
PURCHASE CALL TOLL FREE 866-584-5504. IN MOST
CASES A SERVICE REPRESENTATIVE CAN RESOLVE
KEY INFORMATION YOU SHOULD
• Jump-start any engine system
with a standard 12 volt DC
battery
• Easy-to-read series of LED
charge indicators
• Jump-Start System can be
recharged from any standard
110/120 volt AC power
source
• Built-in Emergency Area Light
BEFORE RETURNING THIS PRODUCT FOR ANY REASON,
THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY,
OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ
CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE.
7/31/06
12 VOLT DC POWER SUPPLY
YOUR PROBLEM OVER THE PHONE.
KNOW:
PLEASE CALL TOLL FREE 866-584-5504
OWNER'S MANUAL AND
WARRANTY INFORMATION
4140 S.W. 30th Ave., Ft. Lauderdale, FL 33312
Toll Free: 866-584-5504
6:36 PM
Page 1
VEC022
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEC022 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vector VEC022

Summary of Contents for Vector VEC022

  • Page 1 OWNER’S MANUAL AND WARRANTY INFORMATION THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING SAFETY, OPERATION, MAINTENANCE AND STORAGE OF THIS PRODUCT. READ CAREFULLY BEFORE USE, AND RETAIN FOR FUTURE REFERENCE. 4140 S.W. 30th Ave., Ft. Lauderdale, FL 33312 Toll Free: 866-584-5504 VEC022...

  • Page 2: Table Of Contents

    CONTENTS 1. INTRODUCTION ...5 2. SAFETY WARNINGS ...7 2.1 Jump-starting Instructions ...8 3. CHARGING/RECHARGING ...9 3.1 110/120 Volt AC Charging ...10 3.2 12 Volt DC Charging ...10 3.3 Replace Fuse...10 3.4 Estimated Battery Life ...11 4. OPERATING AS A PORTABLE POWER SUPPLY...11 5.

  • Page 3: Safety Information Warning

    SAFETY INFORMATION WARNING: Warning statements identify conditions or practices that may result in personal injury or loss of life 1. When working with lead acid batteries, always make sure immediate assistance is available in case of accident or emergency. 2. Always use protective eyewear when using this product: contact with battery acid may cause blindness and/or severe burns, be aware of first aid procedures in case of accidental contact with battery acid.
  • Page 4 10. Check unit periodically for wear and tear. Replace worn or defective parts immediately. Contact Vector Customer Service department toll-free 866-584-5504. 11. Do not attempt to jump-start a frozen battery.

  • Page 5: Introduction

    AC power supply. It can also be used as a safe, portable source of 12 volt DC electric power in remote locations and/or emergency situations. It is ideal for use with Vector 12 volt DC cordless, portable, rechargeable products and MAXXSST DC/AC Power Inverters.
  • Page 6 FIGURE 1A (FRONT VIEW) 12 Volt DC Outlets AC Recharge Adapter Barrel Connector Receptacle Built-in LED Emergency/Area light Negative (-) Black Clamp Positive (+) Red Clamp LED Indicators Area light ON/OFF Pushbutton ON/OFF Safety Power Switch Battery Level Status Pushbutton FIGURE 1B (REAR VIEW)

  • Page 7: Additional Features

    6. Check unit periodically for wear and tear. Replace worn or defective parts immediately; contact Vector Customer Service Department toll-free: 866-584- 5504 or through our Internet address: www.vectormfg.com. 7. Do not attempt to jump-start a frozen battery.

  • Page 8: Jump-Starting Instructions

    5. Excessive engine cranking can damage the vehicle’s starter motor. If the engine fails to start after the recommended number of attempts, discontinue jump-start procedure and look for other problems that may need to be corrected. 6. This VECTOR jump-starter is equipped with a manual ON/OFF switch. Once ®...

  • Page 9: First Aid

    15 minutes and SEEK IMMEDIATE MEDICAL ATTENTION 3. CHARGING/RECHARGING For maximum battery life, we recommend the VECTOR charged at all times. If the battery is allowed to remain in a discharged state, battery life will be shortened.

  • Page 10: 110/120 Volt Ac Charging

    4. When charging is complete and the FULL light lights, remove the AC/DC charger plug and store in a safe place. NOTE: The unit cannot be overcharged using the AC method. The VECTOR system also comes with a DC/DC charging adapter for recharging the unit from a 12 volt DC accessory outlet in a vehicle or boat.

  • Page 11: Estimated Battery Life

    For replacement parts (bulbs, batteries, fuses, etc.), contact Vector Customer Service: 954-584-4446 or toll-free 866-584-5504. 6.1 BATTERY REPLACEMENT It is recommended that the unit be returned to Vector Customer Service for battery replacement: Contact 954-584-4446 or toll-free 866-584-5504. WARNING: • Do not dispose of the battery in fire as this may result in an explosion •...

  • Page 12: Battery Disposal

    For more information on recycling this battery, call toll- free 877-288-7722. 7. SPECIFICATIONS Model ...VEC022 Boost Ampere ...450 Instantaneous Cranking Amps Battery Type ...Sealed, high energy density, AGM, lead-acid, ...rechargeable, maintenance-free, 12 volt DC, 19 Amp-hour Area Light ...Light Emitting Diode (LED)

  • Page 13: Warranty

    Products, Inc. within 30 days of the date of purchase will be replaced free of charge. If such a product is returned more than 30 days but less than two years from the purchase date, Vector Products, Inc. will repair the unit or, at its option, replace it free of charge.
