Tru Vue TVFMU Installation Manual page 6

Mounting the Flat Panel Screen
3
Hook the top of brackets (M) onto the top flange of wall plate (L). Then swing the screen down.
Tighten the safety screw on each bracket to lock the screen into place.
warning: Always use an assistant or mechanical lifting equipment to safely lift and position heavy
equipment.
SCrEEN
L
M
• Failure to lock brackets (M) with safety screws
can cause screen to come off mount if hit
accidentally.
6 of 24
warning
SAFETy
SCrEw
ISSUED: 09-11-09 SHEET #: 202-9372-1
