Tools needed for assembly

• stud finder ("edge to edge" stud finder i s recommended)
• phillips screwdriver
• drill
• 3/8" (10 mm) bit for concrete wall
• 3/16" (5 mm) bit for wood stud wall
• ratchet
• 10 mm socket
• level
• hammer (optional)
M ( 2 )
M6 x 16 mm
M4 x 12 mm
M4 x 16 mm M5 x 16 mm
a ( 4 ) B ( 4 ) C ( 4 ) D ( 4 )
M6 x 36 mm
M5 x 36 mm
E F g
( 4 ) ( 4 ) ( 4 )
H ( 6 ) i ( 6 )
J ( 6 ) K ( 4 ) L ( 1 )
