- Page 1 INSTRUCTION MANUAL Counter Height Dining Table Set SKY3885 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between bestchoiceproducts.com quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality &...
- Page 3 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Firmly secure all bolts, screws, and knobs before use. •...
- Page 4 TABLE PARTS SHELF SIDE I SHELF SIDE II SHELF SUPPORT I 1 PC 1 PC 2 PCS SHELF SUPPORT II SHELF BACK PANEL 1 PC 3 PCS 1 PC TABLETOP SIDE FRAME SUPPORT 1 PC 1 PC 1 PC BRACKET 2 PCS...
- Page 5 PRODUCT ASSEMBLY - TABLE Screw thirty-two part K cam bolts into the part A and part B shelf sides, sixteen cam bolts per shelf side.
- Page 6 PRODUCT ASSEMBLY - TABLE Attach two part C and a part D shelf support to the part A shelf side with six part L cam locks.
- Page 7 PRODUCT ASSEMBLY - TABLE Attach three part E shelves with six part L cam locks.
- Page 8 PRODUCT ASSEMBLY - TABLE Flip assembly over. Attach part F back panel with four part L cam locks.
- Page 9 PRODUCT ASSEMBLY - TABLE Attach the part B shelf side with sixteen part L cam locks.
- Page 10 PRODUCT ASSEMBLY - TABLE Attach two part J brackets and part I support to the part H side frame with six part M screws. Attach the assembled frame to the part G tabletop with four part M screws and two part N screws. Screw in six part K cam bolts.
- Page 11 PRODUCT ASSEMBLY - TABLE Attach the shelves with six part L cam locks and two part M screws.
- Page 12 CHAIR HARDWARE M6 X 45MM M6 X 25MM M6 X 20MM M6 X 12MM SCREW SCREW BOLT SCREW 16 PCS 4 PCS 4 PCS 4 PCS M6 SLEEVE 4 PCS CHAIR PARTS BACKREST RIGHT LEG LEFT LEG 2 PCS 2 PCS 2 PCS BOTTOM SUPPORT FRONT SUPPORT...
- Page 13 PRODUCT ASSEMBLY - CHAIR Attach part E front support to part B right leg and part C left leg with two part H screws. Attach legs to part A backrest with two part J screws, two part I bolts, and two part K sleeve nuts.
- Page 14 PRODUCT ASSEMBLY - CHAIR Attach part D bottom support with four part G screws.
- Page 15 PRODUCT ASSEMBLY - CHAIR Attach part F seat with four part G screws. Repeat to build another chair.
- Page 16 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
