- Page 1 SPACE SAVER SHOWER CHAIR RG555H September 2019 PATENT PENDING USER MANUAL Please read and keep these instructions redgumbrand.com.au...
- Page 2 REDGUM Brand owns the copyright to the Space Saver Shower Chair user manual. Any information contained in this user manual shall not be photocopied, reproduced or translated into any other languages without the prior written consent of REDGUM Brand. REDGUM Brand strives to provide the highest quality products possible.
- Page 3 ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS ASSEMBLY - LEG ASSEMBLY ASSEMBLY - LEG INSTALLATION ASSEMBLY - HANDLE INSTALLATION ASSEMBLY - BACKREST INSTALLATION USAGE GUIDELINES - DO’s + DON’Ts PRODUCT CARE - INSPECTIONS / CLEANING WARRANTY REDGUM BRAND PRODUCT RANGE NOTES redgumbrand.com.au...
- Page 4 INTRODUCTION Thank you for purchasing this quality REDGUM Brand product. If you have any issues or questions about the Space Saver Shower Chair please contact your supplier or REDGUM Brand direct: T: +61 8 9248 4180 F: +61 8 9248 9452 E: orders@for-de.com.au...
- Page 5 Hole 4: 560mm Hole 5: 585mm Hole 6: 610mm Handle Height: 155mm (seat to top of armrest) Product Weight: 3.1kg Maximum User Weight: 130kg Please contact REDGUM Brand if you would like any further information on your Space Saver Shower Chair. redgumbrand.com.au...
- Page 6 ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS Ensure you have been supplied with the following parts: PARTS: 1 x SEAT 1 x RIGHT 1 x LEFT HANDLE HANDLE 1 x BACKREST 4 x ADJUSTABLE LEGS 4 x THUMBSCREWS (not shown to scale) 4 x SURE LOCK LEG CLIPS (not shown to scale) IMPORTANT NOTE...
- Page 7 ASSEMBLY - LEG ASSEMBLY Each adjustable leg needs to be assembled prior to fitting to seat: 1. Pull out the inner leg. 2. Line up the holes at the required setting (setting can be changed at any time). 3. Insert sure lock leg clip into hole and push clip until it locates around tube. 4.
- Page 8 ASSEMBLY - LEG INSTALLATION Each adjustable leg needs to be installed to seat: 1. Place seat upside down as shown below. 2. Insert assembled leg into socket. 3. Line up red press button with hole in wall of socket. Line up press button 4.
- Page 9 ASSEMBLY - HANDLE INSTALLATION Each handle needs to be installed to seat (if required): 1. Ensure angled front of handle is facing toward front of seat. 2. Insert ends of handle into sockets on side of seat. 3. Insert thumbscrew into hole on underside of seat. 4.
- Page 10 ASSEMBLY - BACKREST INSTALLATION The backrest needs to be installed to seat: 1. Locate the backrest onto seat as shown. 2. Press down on backrest until a ‘CLICK’ is heard. 3. Visually check to ensure the backrest has fully located into position. IMPORTANT NOTE: Clip on backrest MUST locate over ledge on seat...
- Page 11 USAGE GUIDELINES - DO’s + DON’TS Please follow these guidelines to get the optimal benefit from your Space Saver Shower Chair. Failure to follow these guidelines may result in damage to the Space Saver Shower Chair and put the user at risk. 130kg Maximum User Weight.
- Page 12 PRODUCT CARE - INSPECTIONS / SERVICING / CLEANING INSPECTIONS We suggest that you check your Space Saver Shower Chair visually periodically for signs of damage or wear prior to use. Overall check that no components are loose or worn. Withdraw the Space Saver Shower Chair immediately if you suspect damage or any other fault.
- Page 13 WARRANTY Your REDGUM Brand RG555H - Space Saver Shower Chair is covered by a 12 Month Warranty from the date of purchase. If the product has any manufacturing faults during this period contact the place of purchase for assessment. Failures as a result of ACCIDENTAL MISUSE, MODIFICATION OR WEAR AND TEAR ARE NOT COVERED BY THIS WARRANTY.
- Page 14 Electric Beds Portable / Fixed Aluminium Ramps Exercisers Personal Alarms REDGUM Brand stock a large range of Spare Parts for all REDGUM brand products. Please contact REDGUM Brand for further information: T: +61 8 9248 4180 F: +61 8 9248 9452 E: orders@for-de.com.au...
- Page 15 NOTES redgumbrand.com.au...
- Page 16 DISTRIBUTOR: Proudly Australian Owned and Operated redgumbrand.com.au...
