Explanation of parameters :

Placement:
Device name:
Device number:
Only HOME:
Partner device:
Number:
Password:
Only FACTORY:
Password:
Connect according to the tables PC, Internet, PLC/machine and establish with the PC with Internet rights
a connection to the Internet (e.g. "www.Google.com"). The configured devices then build a
connection to each other. Note LED S1!

Web interface:

Open the CONNECT web interface by clicking "http://192.168.1.1" in your browser with an active WIFI-
connection.
Click on the 3 stripes in the top left to open the device menu :
Overview
–
Status
–
Configuration
–
Firmware-update
–
Home (PC-site)
Factory (plant/maschine/PLC-site)
Name of this device (max. 15 character )
Number of this device (1-65535) for assignment of the connection
(no duplicate device numbers allowed, please note !)
operating mode LAN A
Auto LAN internet
Auto WLAN internet
Device number of the partner device for establishing a connection
Password of the partner device for establishing a connection, not necessary if
none is stored in the partner device
Operating mode LAN A
Auto LAN/WLAN internet
Auto WLAN/LAN internet
Auto LAN/LAN internet
Auto LAN (LTE) config
Auto WLAN (LTE) config
Bridge LAN internet/PLC
Bridge LAN (LTE) PLC
Password for connection security, max. 100 characters
(no mandatory entry)
LAN B WIFI
PC config
config PC
LAN B WIFI
PC PLC
PLC PC
PC config
PLC config
config PLC
config config
config config
USB LTE
config ---
config ---
USB LTE
config ---
config ---
PLC ---
--- internet
--- internet
config ---
--- internet
