Installation Instructions for
Ikon Step Light
G
ENERAL RODUCT NFORMATION
P
This product is suitable for wet locations.
These fixtures are intended to be installed
utilizing NEC compliant junction boxes.
This product can be dimmed with
120v version is not dimmable.
This instruction shows a typical installation.
OUTDOOR
I
:
most MLV dimmers (12v only).
SAVE THESE INSTRUCTIONS!
700OSIKN92730_
CAUTION RISK OF FIRE
-
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
7400 Linder Ave, Skokie,
847.410.4400
www.techlighting.com
© 2019 Tech Lighting, L.L.C. All rights reserved.
Visual Comfort Group
920OSIKN
1.0
IL
60077
Advertisement
Table of Contents
Related Manuals for Tech Lighting Ikon 700OSIKN92730
Summary of Contents for Tech Lighting Ikon 700OSIKN92730
- Page 1 7400 Linder Ave, Skokie, 60077 847.410.4400 This product can be dimmed with most MLV dimmers (12v only). www.techlighting.com 120v version is not dimmable. © 2019 Tech Lighting, L.L.C. All rights reserved. This instruction shows a typical installation. Visual Comfort Group SAVE THESE INSTRUCTIONS!
- Page 2 Install the Fixture WIRING DIAGRAM MOUNTING PLATE FOR 120V FIXTURE BASE JUNCTION BOX DRIVER WIRING DIAGRAM TO FIXTURE FOR 12V ALLEN WRENCH & SET SCREW FIXTURE BASE JUNCTION BOX CCT TOGGLE ALLEN SCREW With the provided Allen wrench, loosen the set screw from the bottom of the fixture base. Remove the mounting plate from the fixture base.
