Installation Instructions for
Wend and Krysen Step Light
G
ENERAL RODUCT NFORMATION
P
This product is suitable for wet locations.
These fixtures are intended to be installed
utilizing NEC compliant junction boxes.
This product can be dimmed with
120v version is not dimmable.
This instruction shows a typical installation.
OUTDOOR
I
:
most MLV dimmers (12v only).
SAVE THESE INSTRUCTIONS!
700OSWEND92730_, 700OSKYSN92730_
CAUTION RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
7400 Linder Ave, Skokie,
www.techlighting.com
© 2019 Tech Lighting, L.L.C. All rights reserved.
Visual Comfort Group
920OSWENDSKY
-
IL
60077
847.410.4400
1.0
