O r d e r i n g I n f o r m a t i o n
Description
26 AWG STC,
Unshielded, Riser
Jacket color: Gray
Packaging: Reel
Equivalent to 800A Series
*To designate reel length,
replace XX as follows:
02 = 304 m (1000 ft)
04 = 609 m (2000 ft)
05 = 762 m (2500 ft)
06 = 914 m (3000 ft)
10 = 1524 m (5000 ft)
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC's global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
101303AE 9/06 Original © 2006 ADC Telecommunications, Inc. All Rights Reserved
Number Unit
of Pairs Makeup
4 None
6 None
8 None
10 None
16 None
20 None
25 25
32 25 & 7
32 2 @16
40 2 @20
48 4 @12
50 2 @ 20, 1 @ 10
60 3 @ 20
64 4 @16
70 3 @ 20, 1 @ 10
80 4 @20
84 7 @12
96 8 @12
100 5 @20
125 5 @25
128 8 @16
144 12 @12
Outer Weight
Diameter Kg/Km
mm (inches) (lbs/1000')
4.3 (.17) 16.4 (11.0)
4.6 (.18) 26.8 (18.0)
5.1 (.20) 40.2 (27.0)
5.6 (.22) 46.1 (31.0)
6.4 (.25) 62.5 (42.0)
7.9 (.31) 77.4 (52.0)
7.6 (.30) 92.3 (62.0)
8.1 (.32) 114.6 (77.0)
8.1 (.32) 114.6 (77.0)
9.7 (.38) 153.3 (103.0)
10.7 (.42) 189 (127.0)
10.9 (.43) 195 (131.0)
11.9 (.47) 226.5 (152.0)
11.9 (.47) 241 (162.0)
12.7 (.50) 246 (165.0)
13.2 (.52) 293 (197.0)
13.7 (.54) 307 (206.0)
14.2 (.56) 344 (231.0
14.5 (.57) 379 (255.0)
16.3 (.64) 426 (320.0)
16.3 (.64) 484 (325.0)
17.0 (.67) 521 (350.0)
Catalog Number
CS0426H0-GYXX
CS0626H0-GYXX
CS0826H0-GYXX
CS1026H0-GYXX
CS1626H0-GYXX
CS2026H0-GYXX
CS2526H0-GYXX
CS3226H0-GYXX
CS3226H0SGYXX
CS4026H0-GYXX
CS4826H0-GYXX
CS5026H0-GYXX
CS6026H0-GYXX
CS6426H0-GYXX
CS7026H0-GYXX
CS8026H0-GYXX
CS8426H0-GYXX
CS9626H0-GYXX
CS0026H0-GYXX
CSC2526H0-GYXX
CSC2826H0-GYXX
CSC4426H0-GYXX
