D1255RB/D1256RB/D1257RB
Installation Guide
Fire Keypads and
Fire Alarm
EN
Annunciator

Advertisement

loading

  Summary of Contents for Bosch D1255RB

  • Page 1 D1255RB/D1256RB/D1257RB Installation Guide Fire Keypads and Fire Alarm Annunciator...
  • Page 2 D1255RB/D1256RB/D1257RB | Installation Guide | Listings and Approvals Listings and Approvals UL 365 Police Station Burglar Alarm Units and Systems Local Burglar Alarm UL 609 Units and Systems UL 864 Control Units for Fire- protective Signaling Systems Household Burglar UL 1023...
  • Page 3: Table Of Contents

    Specifications ........17 Table 2: Keypad or Annunciator Connections 8 Table 3: Function List Description ....13 Table 4: Specifications for the D1255RB and D1256RB Keypads and the D1257RB Annunciator ........17 Bosch Security Systems B.V. | 2020.03 | F01U011791-03...
  • Page 4: Introduction

    D1255RB/D1256RB/D1257RB | Installation Guide | 1.0 Introduction 30 2 K pvtqf w evk qp 2.1.1 D1255RB The D1255RB has number keys (0 to 9) and Before installing the D1255RB, D1256RB, or function or menu keys, including [COMMAND] D1257RB, you should be familiar with the and [ENTER].
  • Page 5: Audible Tones

    You cannot connect external trouble event occurs, such as a service alert. annunciation devices to the To stop the signal on a D1255RB Keypad, D1255RB, D1256RB, and D1257RB. press [COMMAND][4]. To stop the tone on a D1256RB, press the [TROUBLE SILENCE] Fire Signal –...
  • Page 6: Installation

    Figure 2: Releasing the Enclosure Base Mounting Information (D1255RB, D1256RB, and D1257RB) The D1255RB, D1256RB, and D1257RB are low- profile, surface-mounted units molded in durable red plastic. Use the D56 Keypad Conduit Box (protected surface or flush mount) for mounting the units.
  • Page 7: Removing The Enclosure Base

    D1255RB/D1256RB/D1257RB | Installation Guide | 3.0 Installation Figure 4: Removing the Enclosure Base Figure 6: Removing the Red Cover 1 - Enclosure base 1 - Red cover Top hinges 6. Remove the faceplate. 5. Lift and remove the red cover.
  • Page 8: Setting The Address Switches

    1 - Mounting hole 2 - Flying leads 3 - Wiring harness 4 - Opening 5 - Connector Bosch Security Systems B.V. | 2020.03 | F01U011791-02...
  • Page 9: Keypad (Command Center) Assignments

    Important programming recommendations and requirements are described in this section for the D1256RB. Keypad (COMMAND CENTER) Assignments • Keypad Text: The D1256RB can be assigned to any one of the eight addresses in the control panel. Bosch Security Systems B.V. | 2020.03 | F01U011791-03...
  • Page 10: D1256Rb Programming Requirements

    PRESS ALARM SIL shows on the display. Pressing the [ALARM SILENCE] key silences any alarms(s) and disarms the area. The idle text, * FIRE SYSTEM *, appears on the display when the area is disarmed. Bosch Security Systems B.V. | 2020.03 | F01U011791-02...
  • Page 11: B9512G/B8512G And D9412Gv4/D7412Gv4/D7212Gv4 V2.Xx

    D1255RB/D1256RB/D1257RB | Installation Guide | 4.0 D1256RB Programming Requirements 4.2.2 B9512G/B8512G and D9412GV4/D7412GV4/D7212GV4 v2.xx RPS Menu Location Bx512G Program Record Sheet > Area Wide Parameters > Area/Bell Parameters, Open Close Options > Area Arming Text Figure 15: Example – Area Arming Text for Fire Applications...
  • Page 12: Function List

    Yes / No Yes / No Yes / No Yes / No Yes / No Yes / No Yes / No Refer to Function List in the program record sheet for the control panel. Bosch Security Systems B.V. | 2020.03 | F01U011791-02...
  • Page 13: Menu Item And Function

    D1255RB/D1256RB/D1257RB | Installation Guide | 4.0 D1256RB Programming Requirements 4.4.1 Menu Item and Function 4.4.2 CC Address # Program the first ten menu items as indicated in Table 3. This programming is necessary for the CC = command center = keypad D1256RB to operate properly.
  • Page 14: Passcode Worksheet

    D1256RB is assigned. Use Authority Level 14 together with the passcode you select. Ensure that Passcode Arm is disabled (blank) for the Authority Level. Refer to Authority Level Selections in the program record sheet for the control panel. Bosch Security Systems B.V. | 2020.03 | F01U011791-02...
  • Page 15: Keypad (Command Center) Functions

    D1255RB/D1256RB/D1257RB | Installation Guide | 4.0 D1256RB Programming Requirements 4.4.5 Keypad (Command Center) Functions Figure 19: Example – Keypad Functions The following keypad function must be enabled or passcode required to enable the [DETECTOR Keypad Functions RESET] key. Functions Command #27 Reset Sensors •...
  • Page 16: Figure 20: Custom Functions

    Custom Function 129 Custom Function 130 Custom Function 131 Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Custom Function Bosch Security Systems B.V. | 2020.03 | F01U011791-02...
  • Page 17: Specifications

    D1255RB/D1256RB/D1257RB | Installation Guide | 5.0 Specifications 70 2 Ur gek h k ecvk qpu Table 4: Specifications for the D1255RB and D1256RB Keypads and the D1257RB Annunciator Power Nominal 12 VDC supplied by the control panel Current Required Idle: 104 mA...
