NTORQ 125
In street mode, the following features will be displayed on the connected instrument cluster :
1a. Odometer
1b. Clock
1c. Fuel gauge
1d. Speedometer
1e. Engine temperature gauge
1f. Helmet icon
1g. Low battery indicator
1h. Service reminder
1i. Trip A, B and F
1a. Odometer
Odometer registers the total distance covered by the vehicle in kilometer.
1b. Digital clock
Indicates the time in 12 hour format (AM or PM
1c. Fuel gauge
It indicates the approximate quantity of fuel available in the fuel tank
fuel available in the tank
If all six bar shows means fuel in the tank reaches above 5 litre approximately (Full tank)
When the fuel reaches half tank (3.3 liters approx.) the fuel gauge displays only three bars as shown.
When the fuel reaches minimum safe level (1.5 liters approx.), the last bar of the fuel gauge starts blinking and
low fuel indicator starts glowing. When the fuel reaches minimum safe level (1.5 liters approx.), the last bar of the
fuel gauge starts blinking and low fuel indicator starts glowing
displayed at alpha numeric display
If the fuel level goes below minimum safe level (1.1 liters approx.) 'FUEL EMPTY' message will be displayed at
alpha numeric display as shown.
).
There are six bars to indicate the quantity of
.
The message 'FUEL ON RESERVE' will be
.
-07-
