- Page 1 Technical alterations and alterations Regarding accessories reserved Operating Intructions for Food Slicer Model V 330, V 330 F, V 330 T, V 330 FT Ruhrstr. 76 - 76 a D - 58452 Witten Hermann Scharfen Telefon 02302–28277-0 Telefax 02302-22941 GmbH & Co. Maschinenfabrik KG...
-
Page 2: Table Of Contents
Contents 1. General Information 1.1. Notes regarding the operating instructions 1.2. Notes regarding warranty 1.3. Notes regarding security 1.4. Dimensions of the machine and technical data 1.5. Description of the machine 1.6. General plan of the machine 1.7. Usage 2. Installation and initial operation 2.1. -
Page 3: General Information
Scharfen spare parts any responsibility from our side is refused. In above cases the operator acts on his own risk and is responsible himself for damages which might occur. -
Page 4: Dimensions Of The Machine And Technical Data
Manufacturer: Hermann Scharfen GmbH & Co. Maschinenfabrik KG Ruhrstr. 76-76a, D - 58452 Witten, Tel. 02302/28277-0 1.5. Description of the machine The blade is driven electrically with a 1-phase or 3-phase motor for continuous operation with high power transmission to the blade because of Power Grip belt drive. -
Page 5: General Plan Of The Machine
The hand protection of the carriage, the protecting plate of the end piece holder and the rifled plate of the end piece holder are made of a break-proof plastic allowed for food processing. For switching the machine on and off there is used a double red /green push button which is illuminated when the machine is switched on. -
Page 6: Installation And Initial Operation
- these operating instructions 2.2. Installation The food slicer model V 330 has to be installed on a plain, horizontal, non-slip and stable surface. Recommended height of the working surface about 800 mm. Pay attention to the required counter space. -
Page 7: Checking The Direction Of Blade Rotation
2.4. Checking the direction of blade rotation Switch on the machine. Push the green push button. Signal lamp is illuminated. For machines with 3-phase motor: The blade has to rotate in direction of arrow (counter clockwise). In case the blade rotates in wrong direction, the positions of the poles in the plug have to be changed by an electrician or service technician. -
Page 8: Slicing End Pieces
Take off end piece holder plate Turn back end piece holder Take out of the carriage the metal sheet with spikes (only model V 330 F) Tilt carriage aside Loosen the star knob of the carriage. -
Page 9: Cleaning The Single Parts
The carriage cannot be tilted aside in case the thickness plate is still opened Always tilt the carriage with care, do not use force! Remove blade guard Loosen the star knob and hold the blade guard with the other hand. ... -
Page 10: Sharpening The Blade
Do not let distract yourself from your work Place the splice bar of the blade guard onto the plastic bolt. Turn the blade guard to the blade and see to it that the flange of the blade guard is positioned in the centre of the blade. ... -
Page 11: Sharpening The Blade
5.3. Sharpening the blade < 2 sec. Switch on the machine Turn the yellow handwheel of the sharpening device in direction 1. By means of this the sharpening stone sharpening the blade is pushed towards the blade. Approximately 15 seconds are enough. ... -
Page 12: Trouble Shooting
Take off the blade guard and lubricate the threaded bushing, the adapter, and the fixing screw of the blade guard (we recommend Autol Top 2000, which is used in our factory) Lubricate the thread of the star knob at the bottom of the carriage arm (we recommend Autol Top 2000, which is used in our factory) 7.
