Operating Instructions for Food Slicer
Hermann Scharfen
GmbH & Co. Maschinenfabrik KG
Model G330D
Model G350D
Model G330DW
Model G350DW
Ruhrstr. 76 a
Phone +49-02302-28277-0 Telefax 02302 – 22941
www.scharfen.de
0217
D - 58452 Witten
mail@scharfen.de
Advertisement
Table of Contents
Related Manuals for Scharfen G330D
Summary of Contents for Scharfen G330D
- Page 1 0217 regarding accessories reserved Operating Instructions for Food Slicer Model G330D Model G350D Model G330DW Model G350DW Hermann Scharfen Ruhrstr. 76 a D - 58452 Witten GmbH & Co. Maschinenfabrik KG Phone +49-02302-28277-0 Telefax 02302 – 22941 www.scharfen.de...
-
Page 2: Table Of Contents
UTOMATIC OR MANUAL MOVEMENT OF THE CARRIAGE 3.5. E LECTRONIC ONTROL 3.5.1. ADJUSTING THE SLICING FUNCTIONS 3.5.1.1. Adjusting the number of slices Modell G330D / G350D 3.5.2. G330DW /G350DW ADJUSTING THE SCALE FUNCTIONS FOR ODEL 3.5.2.1. Switching between slice counter and scale 3.6. -
Page 3: General Information
Scharfen spare parts any responsibility from our side is refused. In above cases the operator acts on his own risk and is responsible himself for damages which might occur. - Page 4 Otherwise there is a high risk of injury. Seite 4...
-
Page 5: Description Of The Machine
Always work with concentration, do not let distract yourself from your work. Only cut food products as indicated in these operating instructions. Never carry out experiments. Never try to cut foreign material. Never cut deep frozen products. Never check the sharpness of the blade with your fingers. Never detach the blade without suitable devices. -
Page 6: Usage
fixed ring around the blade, non-removable central blade protection, fixed, removable locked thickness plate when the carriage is tilted aside 1.5. Usage The following food products can be sliced by taking into account the maximum cutting capacity: The machine is only approved for cutting sliceable food Do not cut deep frozen food products For slicing cheese we recommend the teflonized execution. -
Page 7: General Plan Of The Machine
0-25 mm (infinitely variable) year of production see rating plate Manufacturer: Hermann Scharfen GmbH & Co. Maschinenfabrik KG Ruhrstr. 76-76a, D - 58452 Witten, Tel. +49 – 2302 – 282770 www.scharfen.de, mail@scharfen.de Seite 7... -
Page 8: Installation And Initial Operation
2.2. Installation The food slicer model G330D or G350D has to be installed on a plain, horizontal, non-slip and stable surface. If necessary the machine has to be screwed tight in addition. Recommended height of the working surface about 800 mm. Pay attention to the required counter space. -
Page 9: Switch Functions (Main Switch With Signal Lamp)
3.2. Switch functions (main switch with signal lamp) green push button main switch on red push button main switch off 3.3. Thickness of slices The thickness of slices is infinitely variable from 0 to 25 mm. In order to adjust the thickness of the slices you have to turn the thickness knob. -
Page 10: Adjusting The Slicing Functions
3.5.1. adjusting the slicing functions Model G330D / G350D is equipped with a counter. You can adjust the number of slices you want to slice. The slicing process will be stopped after reaching the adjusted number of slices. -
Page 11: Operation
Press the pushbutton 3 & 4 to set the desired weight. The pushbutton 4 is used to count upwards starting with 1 and pushbutton 3 is used to count downwards starting with 2000. Pressing and holding the respective button causes a correspondingly fast change in the numbers. For example with a set number of 200 gram the display shows gr 0200 = 000 If no pre-selection is desired, do not change the setting or set the value to zero. -
Page 12: Variable Slicing Length
Push blue pushbutton 2 in order to start the automatic operation. The food product is pushed against the blade by its own weight (gravity). The carriage is moved automatically In order to stop the slicing procedure push the yellow pushbutton 1 After having finished the slicing procedure turn thickness knob to zero. -
Page 13: Cleaning
Choose electronic functions as described in chapter 3.5 Push blue pushbutton 2 in order to start the automatic operation. The food product is pushed against the blade by its own weight (gravity). The carriage is moved automatically In order to stop the slicing procedure push yellow pushbutton 1 After having finished the slicing procedure turn thickness knob to zero. -
Page 14: Cleaning The Single Parts
The machine is only drip-proof. Therefore do not use high pressure cleaning devices, water hoses or similar devices. Furthermore you must not pour water over the machine. Danger of short circuit or machine defect. In such cases any claims regarding warranty will be refused. -
Page 15: Sharpening The Blade
Check again the complete machine. Only after having checked the machine plug it in for operation. 5. Sharpening the blade In case the cutting result should no longer be satisfactory or the food products are getting "beards", the blade has to be sharpened. There cannot be indicated a certain period for sharpening as this depends on the time of operation and the kind of food products. -
Page 16: Sharpening The Blade
5.3. Sharpening the blade < 2 sec. Switch on the machine Turn the hand wheel of the sharpening device in direction 1. By means of this the sharpening stone sharpening the blade is pushed towards the blade. Approximately 15 seconds are enough. Switch off the machine check if there has been built a visible burr at the edge of the blade If not: Sharpen again... -
Page 17: Trouble Shooting
Take off the blade guard and lubricate the threaded bushing, the adapter, and the fixing screw of the blade guard. Lubricate the thread of the star knob at the bottom of the carriage arm. 7. Trouble Shooting Trouble Solution grinding noise blade guard has not been mounted correctly loosen blade guard, mount it again and fix it blade guard is dirty...
