US Robotics ADSL 4-Port Router Quick Installation Manual page 12

Router Back
ADSL Digital subscriber line RJ-11 service jack
USB Port that accepts a USB cable to a printer.
1 - 4 Ethernet ports 1 - 4
Reset A recessed button that resets the router (see note below)
9VDC Input jack that accepts a cable from supplied power adapter
Power Rocker switch that turns the router on and off
NOTE: To reset the router, insert a pin or paper clip to briefly push the Reset
button. If you want to reset the router, do not press this button for more than 5
seconds, as this resets the router's configuration to the factory defaults.
10
