VIA Technologies Mobile360 D700 User Manual

Hide thumbs Also See for Mobile360 D700:

Advertisement

Quick Links

Download this manual
VIA Mobile360 D700
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mobile360 D700 and is the answer not in the manual?

Questions and answers

Related Manuals for VIA Technologies Mobile360 D700

Summary of Contents for VIA Technologies Mobile360 D700

  • Page 1 VIA Mobile360 D700 User Manual...
  • Page 2 1. Overview Front Lens Ambient Light Sensor Red LED Yellow LED Green LED Short Record/ Voice Key Button 4 x IR LED Rear Lens *Note: The lens can be rotated within a certain range, but it should not be rotated violently, otherwise it will cause the rotating mechanism to fail.
  • Page 3 Speaker Power Connector Micro SD Card Slot Micro SIM Card Slot Micro USB connector...
  • Page 4 Pedestal...
  • Page 5 1.1 Specifications Item Description Processor 800MHz ARM Cortex-A53 Dual-core System Memory 512MB DDR3L DRAM Internal Storage 128MB SPI Flash AMPAK AP6255 Wireless (802.11 a/b/g/n/ac +BT4.2) Ublox GPS receiver Quectel EC25-AF FDD: B2/B4//B5/B12/B13/B14/B66 4G/3G WCDMA: B2/B4/B5 Field of View FOV: D=116°, H=100°, V=56° Sensor Sony IMX307 Image Resolution...
  • Page 6 2. Getting Started with your Recorder VIA Mobile360 D700 supports Android phones and iPhone connections. The driving recorder supports automatic video recording to SD card after startup, and can be played back in mobile App. To use this feature, you need to insert a SD card into the driving recorder.
  • Page 7 2.1 Power On, Off and LED States Manual startup and shutdown: When using DC power adapter and 12-pin power connector (with Power On/Off switch) to connect the recorder; please press the switch manually to switch on and off the recorder. Automatic startup and shutdown: When using the 12-pin power connector to 12V/5A Car plug power...
  • Page 8 2.2 Connect with CAN bus The recorder supports connecting the CAN bus of the car, and can read the driving speed and fuel consumption from the CAN bus. When using the app connects the recorder, you can view information such as driving speed and fuel consumption of the journey.
  • Page 9 2.3 Using Your Recorder with a phone The driving recorder supports connecting with Android phone and iPhone. In order to use your recorder, installation of the official VIA Mobile360 App is required. You can scan the QR code below to download and install the VIA Mobile360 App. App for Android is also supplied on Google Play Store.
  • Page 10 Connect Driving Recorder: Once the VIA Mobile360 has been installed on your phone, open the app and follow the prompts to connect the recorder's Wi-Fi named by “VIA Mobile360_XXX” in the phone's WLAN setting. The default password is 12345678.
  • Page 11 After connecting to the recorder’s Wi-Fi, return to the VIA Mobile360 App. The app has established a connection with the recorder shown as below.
  • Page 12 3. VIA Mobile360 App Menu VIA Mobile360 App has the following menu: Live: View the live stream and GPS tracks of the recorder; Trips: View or download the trips on App; Stats: Statistics about the driving status of the vehicle during the trip; Album: View the videos in the SD card of the device and download the videos locally to the mobile phone.
  • Page 13 3.1 Live The “Live” interface showed as below: ①:Full screen; ②:Mute button; ③:Lens switch button; ④:Speed display; ⑤:GPS signal; ⑥:4G network signal: If there is no signal or the SIM card cannot access the Internet, the map will not be displayed. ⑦:Device Settings: Configuring the recorder parameters;...
  • Page 14 3.1.1 Device Settings Click the “Device Settings” button on the live interface to enter the device settings interface and configure the recorder parameters. Trip: alarm recording duration seconds/20 seconds/30 seconds), units display (Metric/Imperial) and alert sensitivity; Network: Switch recorder's Wi-Fi mode (need to reconnect after switching 2.4G/5G) and...
  • Page 15 Alert Sensitivity and Alarm Recording Duration: Set the alert sensitivity during vehicle driving. When the recorder detects that the G-Sensor value exceeds the threshold, it will record an alarm video. The length of the alarm video will depend on the value of the alarm recording duration.
  • Page 16 Click “Download” to download the trip to your phone locally. Click on the trip to enter the trip details screen. The trip details show the GPS map trajectory, the trip video, the collision alert video and other information of the trip. *Note: When the CAN bus is not connected, the App will not be able to display the fuel...
  • Page 17 Click on the trip video to play back. *Note: You will not be able to switch to live streaming when you download a trip.
  • Page 18 3.3 Stats The “Stats” interface can query the trip information within a certain period of time by date or date range. The “Stats” interface is shown as below.
  • Page 19 3.4 Album The album interface can play back or download the videos in the SD card of the device, including "Normal", "Collision", "Short Cut". Click on the video file to play back the video. Click the “Select” button on the upper right corner to select the video, then click the download icon “...
  • Page 20 Normal Video: When the recorder is turned on, it will automatically record to the SD card and record a file every 3 minutes. When the SD card runs out of space, the device will automatically delete the earliest video file and record in a cyclic manner.
  • Page 21 3.4 Me In the “Me” interface you can switch maps, share the App to friends and view the current App version. The “Me” interface is shown as below.
  • Page 22 4. Firmware Update When you connect your recorder your phone through the VIA Mobile360 App, it will automatically detect the latest firmware and prompt you when a new firmware upgrade is available. You can also check the firmware update manually in Device settings page of VIA Mobile360 App.
  • Page 23 FCC Regulations This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device cause harmful interference, and (2) this device must accept interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part...
  • Page 24 Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes modifications expressly approved manufacturer could void the user’s authority to operate the equipment.
