- Page 1 Installation and Maintenance Instructions ® FlushMaster Solo Water Saver Urinal Flushing System Keeps Urinals Clean & Reduces Water Wastage 42214 FlushMaster Solo AC Mains / Solenoid WS005 FlushMaster Solo Installation & Maintenance Instructions - 87278 - January 2011 Page 1 of 12...
-
Page 2: Table Of Contents
99026 Zenith FlushMaster Direct Injection Airbreak 1.50 inch BSP/ 38 mm 99025 Zenith FlushMaster Direct Injection Airbreak 1.25 inch BSP/ 32 mm 99024 Zenith FlushMaster Direct Injection Airbreak 1.00 inch BSP / 25 mm NOTE: You may need the following (not included with this kit) -
Page 3: Key Features
Supply pressure 350kPa - 700kPa ( see recommendations on P7 ) Check Your Package Zenith FlushMaster Solo package includes. Zenith FlushMaster Solo WS005 Product Code 42214: Ceiling recessed Solo sensor complete with latching valve, power pack and plumbing Installation Procedure... -
Page 4: Set Up Water Discharge
Set Up Water Discharge Typical Installation with Direct Injection: Model WS005 Sensor latching Valve Single stall Isolating Valve Direct injection air break Sensor latching Valve Single trough Maximum trough Width 600 mm Isolating Valve Direct injection air break Airbreak Installation. The air break must be fitted in a vertical position. -
Page 5: Install Sensor
Install Sensor Typical Installation with Ceiling Recessed Sensor (Model WS005) Maximum dimension Example of Example of maximum minimum dimension dimension Ceiling sensor Ceiling sensor Position the centre of the ceiling sensor within *109 mm from the front of the NOTE: * dimensions may change depending urinal (as shown above). -
Page 6: Connect Latching Valve Cable
Connect Latching Valve Cable Run the latching valve cable to the sensor in conduit or within the building wall and ceiling. Do not extend the cable as this will affect correct operation. Locate plug on cable from the latching valve and detach it from circuit board. The plug should be lifted directly upwards. -
Page 7: Set Flush Timing
Set Flush Timing NOTE: Test mode: Units supplied with The rotary switch on the board is marked 0 to 9 a YELLOW rotary Position 0 is test mode, where the system will operate automatically for a number of cycles. switch, will not have Operational mode: a test mode. -
Page 8: Maintenance Instructions
Re-assemble in the reverse of above. Note the position of all parts in the diaphragm for correct assembly. To order quote Zenith part number 90279 Diaphragm Kit. Completing Installation After setting the desired filling time (p.7), Fit the sensor to the ceiling and wipe... -
Page 9: Problem Solving
Problem Solving Symptoms Possible Causes Suggested Action System does not flush. Water supply turned off. Check water supply, turn on tap. Latching valve installed backwards. Reinstall latching valve correctly. Latching valve cable damaged or Check cable and replug into sensor latching cable unplugged. -
Page 10: End Of Life Disposal
End of life disposal The use of this crossed out wheeled bin logo indicates that this product needs to be disposed of separately to any other household waste. Within each of the European Union member countries, provisions have been made for the collection and recycling of unwanted electrical and electronic equipment. -
Page 11: Notes
NOTES WELS Ratings: This system, when tested with a Caroma Leda urinal achieves a 4 Star WELS rating. In order to maintain the WELS ratings for alternative urinals, the flushmMaster must be set to deliver the correct volume of water as specified by the urinal manufacturer . -
Page 12: Warranty Information
Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zenith is entitled to do so, the liability of Zenith under any statutory warranty will be limited at Zenith’s option to the replacement of the...
