Summary of Contents for Zenith Miniboil
- Page 1 Installation instructions & user manual Zenith Miniboil Models: Boiling/Ambient, Boiling Only AFFIX PRODUCT LABEL HERE 805757NZ 805757NZ v1.06 07.21 Miniboil Install Instructions...
- Page 2 8. Turn on the water and check for leaks. 9. Turn on the power. 10. Flush 7 - 10 litres of water through the filter. 11. Allow sufficient time for the unit to heat up, before using. 805757NZ v1.06 07.21 Miniboil Install Instructions...
-
Page 3: Table Of Contents
Step D - Connecting the water supply ......7 Step E - Connecting the tap ..........8 Step F - Testing and commissioning ......... 8 Operation ..............9 Font installation ............10 Cleaning ............... 11 End of Life Disposal ............11 805757NZ v1.06 07.21 Miniboil Install Instructions... -
Page 4: Warnings And Precautions
If this appliance is located where the ambient air temperature could fall below 5ºC, do not turn off the appliance electrically. This safeguard does not offer the same protection to the connecting pipework and fittings. 805757NZ v1.06 07.21 Miniboil Install Instructions... -
Page 5: Technical Specification
700 kPa connected via an isolation valve. • A 350kPa pressure limiting valve/DNR is supplied with the filter kit and must be installed. IMPORTANT! Do not proceed with the installation if these requirements are not met. 805757NZ v1.06 07.21 Miniboil Install Instructions... -
Page 6: Special Tools Required
Head position before securing it tightly against the bench / sink top. black plastic spacer benchtop Under no circumstances should the Tap be twisted after the installation is complete. s/s washer spider clamp fixing nut 805757NZ v1.06 07.21 Miniboil Install Instructions... -
Page 7: Step B - Installing The Filter
Installation Step B - Installing the filter Miniboil is supplied with an external filter (see diagram below). It is important the filter be securely fixed adjacent to the under sink unit in such a manner as to allow for easy access to the filter, for service and regular replacement. -
Page 8: Step E - Connecting The Tap
Wait 5 minutes after this point to allow adequate fill time. The unit is now ready for use. Test water delivery from the tap and check for appropriate temperatures. Use cable clips to tidy and secure Closed wiring. position 805757NZ v1.06 07.21 Miniboil Install Instructions... -
Page 9: Operation
• Reset filter counters: After filter is changed, hold down BOTH LEVERS for 10 seconds. The Filter Change light will turn ON, and after 10 seconds will turn OFF. This will reset the filter counters to zero. 805757NZ v1.06 07.21 Miniboil Install Instructions... -
Page 10: Font Installation
Sleep mode (Boiling Ambient model ONLY) Activate / deactivate sleep mode Miniboil can be set to Sleep mode to save energy. If Sleep mode is (BA model): enabled, the appliance will switch to Sleep if it has not been used for two hours. -
Page 11: Cleaning
Command Centre units must never be cleaned with water jets. End of Life Disposal In order to help preserve our environment we ask that you dispose of this product correctly. Please contact your local city council for collection centre details. 805757NZ v1.06 07.21 Miniboil Install Instructions... - Page 12 Ph: +(64 9) 838 8612 | Free Call 0800 558 055 zenithwater.co.nz WMKA00099 AS 3498 The terms “Zenith” and “HydroTap” are registered trade marks of Zenith Heaters Ltd. Zenith products described in this publication are manufactured under one or more patents and further patent applications are pending.
