- Page 1 User Guide HydroTap G5 ® UltraCare BCU 40 Visit our website to download the manuals 807041NZ v1.00 03.21 HydroTap G5 UltraCare User guide...
- Page 2 807041NZ v1.00 03.21 HydroTap G5 UltraCare User guide...
-
Page 3: Table Of Contents
Contents SECTION 1: SAFETY ........5 1.1 Explanation of symbols .......... 5 1.2 Before you start ............. 5 SECTION 2: Tap operation ......6 2.1 Classic ..............7 2.2 Touch-Free Wave ..........8 2.3 HydroTap Mixer taps ..........10 SECTION 3: Command Centre Screen ..11 3.1 How to use the Command Centre screen ..... - Page 4 Register product • Navigate to the register product menu. • Scan the QR code and follow the on screen steps to register your product. MAIN MENU 12:12 PM General System Safety & Energy Settings Settings Security Saving Info & Product Register Service Logs...
-
Page 5: Section 1: Safety
SECTION 1: SAFETY 1.1 Explanation of symbols Read the instructions WARNING Danger of electric shock Hot surface 1.2 Before you start Read the WARNINGS and PRECAUTIONS. Download & read the complete Command Centre installation instruction manual and user guide. Read and use the instructions supplied with individual kit components for a safe use and installation of replacement consumables. -
Page 6: Section 2: Tap Operation
SECTION 2: Tap operation Classic page 7 Touch-Free Wave page 8 HydroTap Mixer Taps page 10 807041NZ v1.00 03.21 HydroTap G5 UltraCare User guide... -
Page 7: Classic
SECTION 2: Tap operation 2.1 Classic Controls Push for manual dispense Pull for bottle fill (timed dispense) Lights Filter Boiling ready Chilled / sparkling Safety ready lock SAFETY ON active OFF inactive FILTER Ready to dispense. Filter within lifespan. SAFETY SAFETY FLASHING SLOWLY FLASHING SLOWLY... -
Page 8: Touch-Free Wave
SECTION 2: Tap operation 2.2 Touch-Free Wave Controls Touch-free Safety sensors on the tap top, sensor back and sides. (at back) Dispense sensors Clearance requirements 100mm 100mm Lights RED Boiling & safety sensors activated, water dispensed. Light BLUE Chilled sensor activated, water dispensed. - Page 9 SECTION 2: Tap operation 2.2 Touch-Free Wave continued Dispense options Sensor range 1 - 4cm. To dispense, hold hand within range of the sensors. Tap will not operate and light will flash if the sensors are touched or if your hand is too close. Boiling Boiling Water Chilled...
-
Page 10: Hydrotap Mixer Taps
SECTION 2: Tap operation 2.3 HydroTap Mixer taps Controls mixed water Cold Lift and rotate the lever to dispense mixed warm water. 807041NZ v1. 0 0 03.21 HydroTap G5 Ul t raCare User gui d e... -
Page 11: Section 3: Command Centre Screen
SECTION 3: Command Centre Screen 3.1 How to use the Command Centre screen The Command Centre has a colour touch screen liquid crystal display. The screen turns OFF after 5 minutes of non-use. Touch the screen to reactivate. Navigate to the required screen. Here's an example : Set the language - from the home screen Touch the ‘top left’... - Page 12 SECTION 3: Command Centre Screen OFF screen Touch the power button to turn the Command Centre ON or OFF. The LCD screen visually shows OFF when it is non- operational. You will hear the sound of an internal “click” as the HydroTap Command Centre turns ON or OFF.
-
Page 13: Home Screen
SECTION 3: Command Centre Screen 3.2 Home screen Status screens shown here are representative and may vary. Use the home screen to monitor the HydroTap status. Touch each icon to view the system status. Boiling temperature set Chilled temperature set point point (Chilled models) CO2 gas remaining (Sparkling models) -
Page 14: Main Menu
SECTION 3: Command Centre Screen 3.3 Main menu Use the Main menu to configure your HydroTap and access features and settings. Touch each icon to access further options. MAIN MENU 12:12 PM General System Safety & Energy Settings Settings Security Saving Info &... - Page 15 SECTION 3: Command Centre Screen Date and time Touch the text boxes on the screen and then press + and - to set the current date and time. Press the tick to confirm and save. Network Connect to Wi Fi (available as an option with selected products).
-
Page 16: System Settings
SECTION 3: Command Centre Screen 3.5 System settings Configure your HydroTap to suit your needs. Navigate to system settings screen for all system settings. MAIN MENU 12:12 PM General System Safety & Energy Settings Settings Security Saving Info & Product Register Service Logs... -
Page 17: Filter Settings
SECTION 3: Command Centre Screen 3.5.1 Filter settings FILTER SETTINGS 12:12 PM Filter Tank Filter Filter Flush Flush Reset Life Filter flush Use Filter flush during commissioning of a new installation, and after every filter change. See page 31 for filter change instructions. Flush line tap Open filter door, uncoil flush line. - Page 18 SECTION 3: Command Centre Screen Start flush. Approximately 10L of water will flow, for 2 minutes. FILTER FLUSH 12:12 PM RUNNING..Water is now being flushed through the filter. This process is automatic and will take 2 minutes. Press pause to pause filter flush. The screen will show the filter has been flushed.
- Page 19 SECTION 3: Command Centre Screen Filter reset Reset the filter counters after filter replacement and flush. FILTER RESET 12:12 PM This will reset the usage counters for the chosen item. Select an item and press reset to confirm. Internal External filter filter disinfector...
-
Page 20: Temperature Settings
SECTION 3: Command Centre Screen 3.5.2 Temperature settings Boiling / Chilled set point Adjust as required. COLD/HOT SETPOINT 12:12 PM Chill Set Point Boiling Set Point °C °C Chilled models Default chill set point: 5-9ºC (Commercial). Scroll to select alternatives. Boiling models Default set point: 98ºC Set point range: 68-100ºC. - Page 21 SECTION 3: Command Centre Screen Boiling calibration Take care during boiling calibration as hot steam may vent from the tap spout. On start-up, the HydroTap self-calibrates, or go to this menu to recalibrate. Calibration will take around 10 minutes. External Booster For selected commercial Boiling models, an external booster is supplied or may be purchased as an upgrade to increase Boiling capacity.
-
Page 22: Dispense Times
SECTION 3: Command Centre Screen 3.5.3 Dispense times Set the “bottle fill” dispense time for each water type. Minimum dispense time: 5 seconds. Maximum dispense time: 15 seconds (default). DISPENSE TIMES 12:12 PM Boiling Chilled 3.5.4 Light sensor Follow the on screen instructions. Ensure the ambient light in the room is typical for operating conditions. -
Page 23: Quiet Mode
SECTION 3: Command Centre Screen 3.5.5 Quiet mode Lowering the fan speed can reduce noise. Increasing it may improve chilling performance. Residential models: 75% / 100% / Auto (default). Commercial models: 100% (default) / Auto. 3.5.6 Advanced settings 1 ADVANCED SETTINGS 1 12:12 PM Periodic Pulse Reduced Cavitation Mode Hot setpoint must be <... -
Page 24: Advanced Settings 2 (Wave Tap Only)
SECTION 3: Command Centre Screen 3.5.7 Advanced settings 2 (Wave Tap only) ADVANCED SETTINGS 2 12:12 PM Wave Tap Sensor Demister Mode Allows Control of Heating of Wave Tap Wave Tap Lock Mode Dual Sensors Required for Chilled/Sparkling Wave Tap Sensor Demister Mode •... -
Page 25: Safety & Security
SECTION 3: Command Centre Screen 3.6 Safety & security 3.6.1 Boiling safety (Not applicable to Touch-Free Wave Tap) BOILING SAFETY 12:12 PM Boiling safety lock Use the safety button to dispense hot water Hot isolation (additional boiling safety) 3 slow safety button presses required prior to dispensing Boiling safety lock •... -
Page 26: Passcode Protect
SECTION 3: Command Centre Screen 3.6.2 Passcode protect Activate passcode protection to limit access to certain settings. Users will be prompted for this passcode when attempting to access settings. Create a 4-digit passcode and re-enter, as prompted. The passcode will be deactivated if the HydroTap is reset (powered off and on again). -
Page 27: Energy Saving
SECTION 3: Command Centre Screen 3.7 Energy saving 3.7.1 Sleep mode • Disabled (default). • Enabled: Any attempt to dispense water will bring the HydroTap out of sleep mode. Allow sufficient time for the water to reach the set temperature. Sleep when... -
Page 28: On/Off Timer
SECTION 3: Command Centre Screen When sleeping Choose between the following modes: • Keep hot water at 68°C (default). Chilled water will be kept at setpoint, for chilled models. • Turn system OFF: boiling and chilled water will be OFF. 3.7.2 On/Off Timer The option that is in effect is highlighted. -
Page 29: Energy Use
SECTION 3: Command Centre Screen 3.7.2 On/Off Timer continued Select the day or range of days, then set the desired Off/ On times. Touch the tick to confirm and save. SET TIMER 12:12 PM Off at On at 3.7.3 Energy Use Track energy usage of your HydroTap by viewing the total energy consumed and the energy consumed since the last energy use reset. -
Page 30: Info & Logs
SECTION 3: Command Centre Screen 3.8 Info & logs INFO & LOGS 12:12 PM Filter System Recent About Logs Faults Faults System Filter Logs, System Faults, Recent Faults View the filter reset history, current and recent fault history. About System View the system information. -
Page 31: Section 4: User Maintenance
SECTION 4: User maintenance 4.1 Changing the internal filter The tap and screen will indicate that a filter needs to be changed. Depending on local water quality conditions and usage, the filter may require changing before the filter change indication is shown. You may also need to replace the filter if you notice an increase in chlorine, taste or odour. - Page 32 SECTION 4: User maintenance Moisten connector o-rings. Insert Rotate Push up Fit new filter. Initiate the filter flush program, using the screen (see page 17). Clean up and dispose of old cartridge and packaging. If the HydroTap is switched off for a long period of time (e.g.
-
Page 33: Air Inlet Filter Maintenance
SECTION 4: User maintenance 4.2 Air inlet filter maintenance Remove and clean quarterly. Rinse off with tap water. Gently dry with a cloth or towel. Maintain at least a 50mm air gap in front of the air inlet screen at all times. Take care to keep the air inlet clear of blockage. -
Page 34: Cleaning
SECTION 4: User maintenance 4.3 Cleaning Wipe external surfaces with a damp cloth or antibacterial alcohol wipe, then immediately wipe dry with a clean, dry cloth or paper towel. Food-grade disinfection wipes may be used to clean around and within the tap spout. Do not use strong, corrosive, spray or abrasive cleaning materials. -
Page 35: Uv-C Module
SECTION 4: User maintenance 4.4 UV-C module It is recommended to replace the UV-C module, safety solenoid and chilled water hose every 2 years as part of regular maintenance. Replacement parts are included in “Service 2” and “Service 3” kits. To replace the UV-C module and chilled water hose: Turn power OFF Unplug the USB... -
Page 36: Safety Solenoid
SECTION 4: User maintenance 4.5 Safety solenoid This should only be performed by a qualified tradesperson. To replace the safety solenoid: MANIFOLD Turn power and water OFF ASSEMBLY It may be necessary to disconnect the hoses and move the Command Centre to enable access to the rear. -
Page 37: Chilled Hose And Tap Tube
SECTION 4: User maintenance 4.6 Chilled hose and tap tube The chilled tap tube and the blue silicone hose should be replaced every 12 months. A replacement tap tube and hose is included with Service Packs 1, 2 & 3. 1. -
Page 38: In-Field Sanitisation
SECTION 4: User maintenance 4.7 In-field sanitisation Sanitisation of the system is recommended at least every 12 months as part of regular maintenance, following replacement of the chilled water hose. Equipment required: 95235NZ In-Field HydroTap Sanitisation kit (can be re-used for all Services), containing: •... -
Page 39: Sanitisation Procedure
SECTION 5: In-field sanitisation Sanitisation procedure Prepare for sanitisation 1. Ensure all water tanks are full. 2. Turn off mains water supply. 3. DO NOT EMPTY BOILING TANK - it needs to remain full. Empty only the chilled tank. Use the service menu on the LCD screen to view tank levels. - Page 40 SECTION 5: In-field sanitisation 13. Turn ON the mains water supply. Check for and repair any leaks. Sanitise system 14. Allow the water to fill the cold tank. When the filling cycle is complete, you should here the solenoid valves close. 15.
-
Page 41: Maintenance Log
Type Kit no. ments: Filter 93706NZ Filter • Change water filter change • Zenith 1.5Z-CF filter 95236NZ Service Kit 1 • Change water filter • Zenith 1.5Z-CF filter • Clean air inlet filter Service • Silicone hose and • Replace silicone hose... - Page 42 Maintenance log Install date: ..................Time from Type Date Name Sign installation 6 months or Filter 6000 litres change 12 months (1 Service year) or 12000 litres 18 months (1.5y) Filter or 18000 litres change 24 months (2y) Service or 24000 litres 30 months (2.5y) Filter or 30000 litres...
- Page 43 Maintenance log Time from Type Date Name Sign installation 108 months (9y) Service or 108 000 litres 114 months (9.5y) Filter or 114 000 litres change 120 months (10y) Service or 120 000 litres 126 months (10.5y) Filter or 126 000 litres change Other services Time from...
- Page 44 Zenith Heaters Limited IRD/GST No. 95 640 729 18 Kawakawa Place, Westgate, Auckland 0814 New Zealand Ph: +(64 9) 838 8612 | Free Call 0800 558 055 zenithwater.co.nz WMKA00099 AU02691 AS 3498 807041NZ v1.00 03.21 HydroTap G5 UltraCare User guide...
